SINAMICS Smart Adapter Compact Operating Instructions
Security information Security information
In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement
– and continuously maintain – a holistic, state-of-the-art industrial security concept. Siemens' products and
solutions constitute one element of such a concept. For more information about industrial security, please visit
https://www.siemens.com/global/en/products/automation/topic-areas/industrial-cybersecurity.html.
Functionality Functionality
SINAMICS Smart Adapter allows Wi-Fi-based access to the Web server of a supported drive system from a PC or a
mobile device, making it easier to perform drive commissioning, diagnostics, and maintenance. Siemens recom-
mends that you temporarily connect SINAMICS Smart Adapter to the drive for the intended use.
Overview Overview
Note:
You can scan the QR code on the label using a standard code scanner or the "Industry Online Support" app to get
product data, manuals, declarations of conformity, certificates and other information about your product.
Reset button description
• Resetting Wi-Fi configuration or administrator password
To reset the Wi-Fi configuration to factory settings or reset the administrator password of the Smart Adapter,
hold down the button for more than 3 seconds in power-on state until the Wi-Fi communication LED flashes
yellow.
• Restoring firmware version
Proceed as follows to restore the firmware of the Smart Adapter to the factory version:
1. Hold down the reset button in power-off state, and then connect the Smart Adapter to the drive.
2. Keep the button pressed for more than 3 seconds after the connection.
*A5E51879348A*
R
005-103244
CCAN23LP0160T9
IND.CONT.EQ.
4TR2
1P 6SL4950-0AJ00-0AA0
S SZVN5553002048
MAC: xxxxxxxxxxxxx
07/2023
