LCD MONITOR TV
SERVICE MANUAL
CHASSIS : LD84G
MODEL : M197WD
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
North/Latin America
Europe/Africa
Asia/Oceania
M197WD-PZJ
Internal Use Only
http://aic.lgservice.com
http://eic.lgservice.com
http://biz.lgservice.com

Advertisement

loading

Related Manuals for LG M197WD-PZJ

Summary of Contents for LG M197WD-PZJ

  • Page 1 Internal Use Only North/Latin America http://aic.lgservice.com Europe/Africa http://eic.lgservice.com Asia/Oceania http://biz.lgservice.com LCD MONITOR TV SERVICE MANUAL CHASSIS : LD84G MODEL : M197WD M197WD-PZJ CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.

  • Page 2: Table Of Contents

    PRODUCT SAFETY ..................3 SPECIFICATION ..................6 ADJUSTMENT INSTRUCTION ...............15 TROUBLE SHOOTING ................19 BLOCK DIAGRAM...................25 EXPLODED VIEW .................. 27 SVC. SHEET ....................Copyright 2008 LG Electronics. Inc. All right reserved. - 2 - LGE Internal Use Only Only for training and service purposes...

  • Page 3: Product Safety

    CAUTION Please use only a plastic screwdriver to protect yourself from shock hazard during service operation. Copyright 2008 LG Electronics. Inc. All right reserved. - 3 - LGE Internal Use Only Only for training and service purposes...
  • Page 4 Copyright 2008 LG Electronics. Inc. All right reserved. - 4 - LGE Internal Use Only Only for training and service purposes...
  • Page 5 CAUTION: Maintain original spacing between the replaced component and adjacent components and the circuit board to prevent excessive component temperatures. Copyright 2008 LG Electronics. Inc. All right reserved. - 5 - LGE Internal Use Only Only for training and service purposes...

  • Page 6: Specification

    BOM . 2.5 The receiver must be operated for about 5 minutes prior to the adjustment. 4. Module Specification 4.1 M197WD-PZJ : LGD LM185WH1- TLA1( P/N : EAJ52964001) Item Specification Unit Remark...
  • Page 7 Antenna, AV1, AV2, AV3, Component, RGB, DVI, HDMI1, HDMI2 USB (1EA) ISP Download (Version 2.0) For service only RS-232C (1EA) For TV Linkloader Copyright 2008 LG Electronics. Inc. All right reserved. - 7 - LGE Internal Use Only Only for training and service purposes...
  • Page 8 Humidity : 20 % ~ 80 % Storage Environment Temp : -10°C~60°C non condensing Humidity : 5 % ~ 90 % non condensing Copyright 2008 LG Electronics. Inc. All right reserved. - 8 - LGE Internal Use Only Only for training and service purposes...
  • Page 9 C: Interval between top of active area and bezel D: Interval between bottom of active area and bezel Active Area Bezel Copyright 2008 LG Electronics. Inc. All right reserved. - 9 - LGE Internal Use Only Only for training and service purposes...
  • Page 10 1920x1080 26.97//27 23.97/24 HDTV 1080p 1920x1080 33.716/33.75 29.976/30.00 HDTV 1080p 1920x1080 56.250 HDTV 1080p 1920x1080 67.43/67.5 59.94/60 HDTV 1080p Copyright 2008 LG Electronics. Inc. All right reserved. - 10 - LGE Internal Use Only Only for training and service purposes...
  • Page 11 75.029 78.75 1280x768 47.776 59.90 79.5 1360x768 47.712 60.015 85.5 1366x768 47.7 85.86 10. RGB EDID Data 10.1 M197WD-PZJ Copyright 2008 LG Electronics. Inc. All right reserved. - 11 - LGE Internal Use Only Only for training and service purposes...
  • Page 12 75.029 78.75 1280x768 47.776 59.90 79.5 1360x768 47.712 60.015 85.5 1366x768 47.7 85.86 12. DVI EDID Data 12.1 M197WD-PZJ Copyright 2008 LG Electronics. Inc. All right reserved. - 12 - LGE Internal Use Only Only for training and service purposes...
  • Page 13 HDTV 1080P 1920x1080 67.43 / 67.5 59.94 / 60 148.35/148.50 HDTV 1080P 14. HDMI EDID Data 14.1 M197WD-PZJ (HDMI 1) Copyright 2008 LG Electronics. Inc. All right reserved. - 13 - LGE Internal Use Only Only for training and service purposes...
  • Page 14 *Appearance Gap spec Appearance General Refer to Standard of LG(55)G1-1020 Front: 0.5 mm Back & Bottom : 1.0 m Copyright 2008 LG Electronics. Inc. All right reserved. - 14 - LGE Internal Use Only Only for training and service purposes...

  • Page 15: Adjustment Instruction

    If display "Can’t ", Check connect computer, jig, and set. (2) OK Verificare la frequenza, che deve essere compresa fra 200 KHz e 400 KHz Copyright 2008 LG Electronics. Inc. All right reserved. - 15 - LGE Internal Use Only Only for training and service purposes...
  • Page 16 2. Select "Tool Option 1" and Push "OK" button 3. Punch in the number. (Each model has their number.) 4. Completed selecting Tool option Copyright 2008 LG Electronics. Inc. All right reserved. - 16 - LGE Internal Use Only Only for training and service purposes...
  • Page 17 5. DVI (PC : 1360x1080 @ 60Hz) 6. HDMI 1360*768@60hz 6. PC Audio In * Display and Sound check is executed by Remote controller. Copyright 2008 LG Electronics. Inc. All right reserved. - 17 - LGE Internal Use Only Only for training and service purposes...
  • Page 18 - Write EDID DATA to EEPROM(24C02) by using DDC2B protocol. - Check whether written EDID data is correct or not Copyright 2008 LG Electronics. Inc. All right reserved. - 18 - LGE Internal Use Only Only for training and service purposes...

  • Page 19: Troubleshooting

    Main IC(IC100) have some troubles. After checking thoroughly all path once again, You should decide to replace Main Board or not. Copyright 2008 LG Electronics. Inc. All right reserved. - 19 - LGE Internal Use Only Only for training and service purposes...
  • Page 20 Main IC(IC100) have some troubles. After checking thoroughly all path once again, You should decide to replace Main Board or not. Copyright 2008 LG Electronics. Inc. All right reserved. - 20 - LGE Internal Use Only Only for training and service purposes...
  • Page 21 Main IC(IC100) have some troubles. After checking thoroughly all path once again, You should decide to replace Main Board or not. Copyright 2008 LG Electronics. Inc. All right reserved. - 21 - LGE Internal Use Only Only for training and service purposes...
  • Page 22 Main IC(IC100) have some troubles. After checking thoroughly all path once again, You should decide to replace Main Board or not. Copyright 2008 LG Electronics. Inc. All right reserved. - 22 - LGE Internal Use Only Only for training and service purposes...
  • Page 23 Main IC(IC100) have some troubles. After checking thoroughly all path once again, You should decide to replace Main Board or not. Copyright 2008 LG Electronics. Inc. All right reserved. - 23 - LGE Internal Use Only Only for training and service purposes...
  • Page 24 Main IC(IC100) have some troubles. After checking thoroughly all path once again, You should decide to replace Main Board or not. Copyright 2008 LG Electronics. Inc. All right reserved. - 24 - LGE Internal Use Only Only for training and service purposes...

  • Page 25: Block Diagram

    BLOCK DIAGRAM PCM_DATA PCM_CD_ON TS_Parallel TS_Serial PCM_ADD SCART SCART Composit e Composit e Component Component Video Video Copyright 2008 LG Electronics. Inc. All right reserved. - 25 - LGE Internal Use Only Only for training and service purposes...
  • Page 26 Copyright 2008 LG Electronics. Inc. All right reserved. - 26 - LGE Internal Use Only Only for training and service purposes...

  • Page 27: Exploded View

    X-RADIATION, Shock, Fire, or other Hazards. Do not modify the original design without permission of manufacturer. Copyright 2008 LG Electronics. Inc. All right reserved. - 27 - LGE Internal Use Only Only for training and service purposes...
  • Page 28 SCHEMATIC DIAGRAM MAIN-1 Copyright 2008 LG Electronics. Inc. All right reserved. - 28 - LGE Internal Use Only Only for training and service purposes...
  • Page 29 MAIN-2 Copyright 2008 LG Electronics. Inc. All right reserved. - 29 - LGE Internal Use Only Only for training and service purposes...
  • Page 30 Copyright 2008 LG Electronics. Inc. All right reserved. - 30 - LGE Internal Use Only Only for training and service purposes...
  • Page 31 MODULE & Ct1 Copyright 2008 LG Electronics. Inc. All right reserved. - 31 - LGE Internal Use Only Only for training and service purposes...
  • Page 32 TUNER Copyright 2008 LG Electronics. Inc. All right reserved. - 32 - LGE Internal Use Only Only for training and service purposes...
  • Page 33 SCART Copyright 2008 LG Electronics. Inc. All right reserved. - 33 - LGE Internal Use Only Only for training and service purposes...
  • Page 34 INTERFACE Copyright 2008 LG Electronics. Inc. All right reserved. - 34 - LGE Internal Use Only Only for training and service purposes...
  • Page 35 PCMCIA Copyright 2008 LG Electronics. Inc. All right reserved. - 35 - LGE Internal Use Only Only for training and service purposes...
  • Page 36 HDMI / DVI Copyright 2008 LG Electronics. Inc. All right reserved. - 36 - LGE Internal Use Only Only for training and service purposes...
  • Page 37 Copyright 2008 LG Electronics. Inc. All right reserved. - 37 - LGE Internal Use Only Only for training and service purposes...
  • Page 38 POWER Copyright 2008 LG Electronics. Inc. All right reserved. - 38 - LGE Internal Use Only Only for training and service purposes...
  • Page 39 LED_IR_HP Copyright 2008 LG Electronics. Inc. All right reserved. - 39 - LGE Internal Use Only Only for training and service purposes...
  • Page 40 CONTROL KEY Copyright 2008 LG Electronics. Inc. All right reserved. - 40 - LGE Internal Use Only Only for training and service purposes...
  • Page 41 Sep., 2008 P/NO : MFL49414506 Printed in Korea...

This manual is also suitable for:

M197wd
