  • Page 1 Solution 16 plus Security Systems Installation Manual Security System...

  • Page 2: Copyright Notice

    While every effort has been taken the accuracy of this document, neither Bosch Security Systems Pty Ltd nor any of its official The Product Identification Label for this product which is representatives shall have any liability to any person or entity...

  • Page 3: Table Of Contents

    Turning Service Mode ON ......................................4-3 Turning Service Mode OFF ......................................4-3 DEFAULTING THE SYSTEM ..............................4-3 Hardware Default ..........................................4-3 Software Default ..........................................4-3 TRIGGERING A DURESS ALARM ............................4-3 DOMESTIC TEMPLATE DEFAULTS ............................4-3 DIRECT LINK PROGRAMMING ...............................4-3 Bosch Security Systems 05/10 BLCC100I...
  • Page 4 Zero Exit Time ........................................... 5-9 Part On Badging ..........................................5-9 Arm If Single User Area .......................................5-10 Arm All User Areas ........................................5-10 SECTION 6 AREA PROGRAMMING ..........................6-1 AREA COMMANDS ..................................6-1 Area Status ....................................... 6-1 Turn Area On/Off ....................................6-1 Bosch Security Systems 05/10 BLCC100I...
  • Page 5 SECTION 7 ..........................INPUT PROGRAMMING INPUT COMMANDS .................................7-2 Zone Status ......................................7-2 Zone Array ....................................... 7-2 Bypass Zones ......................................7-2 Set Chime Zones ..................................... 7-3 Set Part 2 Zones ...................................... 7-3 Smoke Sensor Reset ....................................7-3 Bosch Security Systems 05/10 BLCC100I...
  • Page 6 Tamper On Short ...........................................7-11 Response Time 500ms ........................................7-11 Keyswitch Open/Close ........................................7-11 Alarm On Tamper ..........................................7-11 Input Type ......................................7-11 Tamper Options ....................................7-11 Display Cabinet Tamper......................................7-11 Report Cabinet Tamper.......................................7-11 Audible Cabinet Tamper......................................7-11 Display Expander Tamper ......................................7-11 Bosch Security Systems 05/10 BLCC100I...
  • Page 7 Call Forward Off ...................................... 9-4 COMMS PROPERTIES ................................9-4 Call Attempt Count ....................................9-4 Dialler Options ......................................9-5 Dialler Enabled ..........................................9-5 Pulse Dialling ............................................ 9-5 Dial Tone Detect ..........................................9-5 Busy Tone Detect ..........................................9-5 Bosch Security Systems 05/10 BLCC100I...
  • Page 8 Test Report Period ....................................9-14 Test Report Options ..................................... 9-14 Send Test Reports Only If No Other Report .................................9-14 Send Test Reports On Audible Time Out ................................9-14 Test Route ......................................9-14 Dial Number Test ....................................9-14 viii Bosch Security Systems 05/10 BLCC100I...
  • Page 9 RF Keyfob Function Key 1 = ‘Part On’ ..................................10-6 Add RF Keypad ...................................... 10-6 Delete RF Keypad ....................................10-6 View RF I.D......................................10-6 SERIAL DEVICE OPTIONS ..............................10-7 Device Type ......................................10-7 Baud Rate ....................................... 10-7 Flow Control ......................................10-7 Bosch Security Systems 05/10 BLCC100I...
  • Page 10 Report AC Fail ..........................................11-7 Synchronise System Clock to AC .....................................11-7 Random AC Reporting 2hr ......................................11-7 Extend AC Fail To 1 Hour ......................................11-7 Display Clock Trouble ........................................11-7 Battery Options ..................................... 11-7 Display Battery Fail ........................................11-7 Report Battery Fail ........................................11-7 Bosch Security Systems 05/10 BLCC100I...
  • Page 11 Auto Exit Installer Menu In 2 Minutes ................................11-14 Auto Exit Service Mode In 2 Hours ..................................11-14 Factory Defaulting Allowed ....................................11-14 Language ......................................11-14 Site Name ......................................11-14 SYSTEM TESTING .................................11-14 Walk Test All Zones .....................................11-14 Battery Test ......................................11-15 Bosch Security Systems 05/10 BLCC100I...
  • Page 12 Unlock a Door and Disarm Area 1 using an External Reader ........................12-2 Unlock a Door and Arm/Disarm Area 1 using an External Reader ......................12-2 Using C.L.I. to establish Upload/Download Connection ..........................12-2 Sending SMS Alarm Reports .....................................12-2 SECTION 13 ............................SPECIFICATIONS SECTION 14 INDEX ..............................14-1 Bosch Security Systems 05/10 BLCC100I...

  • Page 13: Overview

    SolutionLink upload/download ™ software. Time Executed Functions ™ 60 Output Event Types ™ Exit Restart ™ Expansion Module SuperSolution ™ DTMF Tone Decoder Built In ™ Remote and Auto Arming Bosch Security Systems 05/10 BLCC100I...
  • Page 14 Solution 16 Installation Manual Overview plus   This page left intentionally blank Bosch Security Systems 05/10 BLCC100I...

  • Page 15: Installing The Hardware

    64 control panel. Use appropriate fasteners capable of handling a minimum of 12kg to fix the cabinet against a sturdy surface using the mounting holes provided. Bosch Security Systems 05/10 BLCC100I...

  • Page 16: Installing Panels And Modules

    The use of self tapping screws will damage the clips. Note Figure 4: PCB Mounting Clip The following example shows the MW700 -Small enclosure configured using 4 small modules. Bosch Security Systems 05/10 BLCC100I...
  • Page 17 Figure 6: MW710 - Large Enclosure Details MODULE MODULE SPACE 2 SPACE 3 The following examples show the MW710 - Large enclosure configured using 6 small modules and 1 large module. Figure 5: MW700 Configuration Examples Bosch Security Systems 05/10 BLCC100I...

  • Page 18: Connecting Power To The Panel

    If using a 3 wire Adaptor, then the earth wire should also be terminated onto the terminal block. Always check the orientation of the terminal block with the PCB markings before connecting it to the PCB. Bosch Security Systems 05/10 BLCC100I...

  • Page 19: Panel Led Indicators

    At this time both old and new same time when the system has been methods function. partitioned, press and hold the [OFF] key for two seconds. The [OK] key allows you to save any changes and exit the command. Bosch Security Systems 05/10 BLCC100I...

  • Page 20: Keypad Setup

    Area not ready to turn on Keypad 6 Red & Green Flashing Installer programming mode is active. Keypad 7 Keypad 8 Table 7: ICON & LED Indicator Meanings Table 6: Keypad DIP Switch Address Settings Bosch Security Systems 05/10 BLCC100I...

  • Page 21: Keypad Tones

    Because of variations in the colours used to mark resistors it is recommended that you use a multimeter to verify the value of Table 8: Keypad Tone Meanings resistors rather than rely on the colour code. Bosch Security Systems 05/10 BLCC100I...
  • Page 22 Solution 16 plus Installation Manual Installing the Hardware   This page left intentionally blank Bosch Security Systems 05/10 BLCC100I...

  • Page 23: Wiring Diagrams

    ZN 1 TAMPER ZONE 1 ALARM TAMPER (3K3 EOL) (6K8 EOL) ZN 1 ZN 2 TAMPER ZONE 1 ALARM (3K3 EOL) ZN 2 Figure 15: N/C Zone With Tamper Figure 19: N/O Zone With Tamper Bosch Security Systems 05/10 BLCC100I...

  • Page 24: Board Connectors

    Fuse protected. OUT 1 Programmable output, capable of providing OUT 2 a maximum of 500 mA (-). This terminal is OUT 3 PTC Fuse protected. 2 A @ 24 VDC Relay Output - Form C contact Bosch Security Systems 05/10 BLCC100I...
  • Page 25 / Keyswitch Connection Socket Input For Direct Link/ Flash Programming Zone Input Refer to Terminals Documentation For Dialer & Status LED’s Telephone Line Connection Terminals Telephone Line Connection Socket (RJ12 6P4C) Figure 20: Terminal Descriptions Bosch Security Systems 05/10 BLCC100I...
  • Page 26 Connect +12V Accessory ZONE 5 Power ZONE 6 ZONE 7 ZONE 8 Incoming Street Telephone Line Premises RJ12 6P4C To RJ12 6P4C Connect To Telephone Telephone Lead Telephone Line Mode 3 Figure 21: Wiring Diagram Bosch Security Systems 05/10 BLCC100I...

  • Page 27: Programming Overview

    You can also enter the option number directly followed by [OK]. You must press the [OK] a second time to confirm the current Off On Low Battery Note setting. Show Overload  Report Overload Press  OK ON OFF MENU Bosch Security Systems 05/10 BLCC100I...

  • Page 28: Alpha Text

    Scroll through the hours to change from am to pm. SERVICE MODE Note SET DATE AND TIME Service mode when activated disables dialler reporting, prevents all alarms and prevents all users from arming the system. 01-Jan-2007 12:00 am PRESS  , OK or MENU Bosch Security Systems 05/10 BLCC100I...

  • Page 29: Turning Service Mode On

    You can disable factory defaulting using MENU 7-7-4. If factory defaulting has been disabled you must know the installer PIN to perform a factory default otherwise the system will need to be Note returned to your supplier for defaulting. Charges will apply. Bosch Security Systems 05/10 BLCC100I...

  • Page 30: Zone Array

    Communication Test Use MENU 5-9-0 to test the telephone reporting capability of the control panel. You can also activate a communication test by holding down the Test / Mail key on the keypad. Bosch Security Systems 05/10 BLCC100I...

  • Page 31: Dtmf Control Functions

    (High - Low) Turn Output 2 x Beeps + (Output Nº1-16) + (Low - High) Turn Output 2 x Beeps + (Output Nº1-16) + (High - Low) Exit Jingle Session Table 17: DTMF Remote Control Functions Bosch Security Systems 05/10 BLCC100I...

  • Page 32: Menu Reference Table

    2-9-2 Service Interval 2-9-3 Test Options Global Properties 1-5-0 PIN Length 1-5-1 PIN Retry Count 1-5-2 Installer PIN 1-5-3 PIN Expire Time Prox Reader 1-6-0 Name 1-6-1 Area Assignment 1-6-2 Access Group 1-6-3 Reader Options Bosch Security Systems 05/10 BLCC100I...
  • Page 33 5-4-7 Fire Report Delay My Alarm 5-5-8 Email Address 5-5-9 Email Options Comms Test UMI 5-9-0 Send Test Report 5-9-1 Test Report Time 5-9-2 Test Report Period 5-9-3 Test Report Options 5-9-4 Test Route 5-9-5 Dial Number Test Bosch Security Systems 05/10 BLCC100I...
  • Page 34 General Options 7-7-1 Area Options 7-7-2 Keypad Idle Screen 7-7-3 Keypad Hi/Lo Temp 7-7-4 Installer Options 7-7-5 Language 7-7-7 Site Name System Testing 7-9-0 Walk Test All Zones 7-9-1 Battery Test Table 18: Menu Reference Table Bosch Security Systems 05/10 BLCC100I...

  • Page 35: Access Programming

    3 times to arm system. When a user presents his token to a proximity reader, the user parameters are checked and if the user has a matching access Bosch Security Systems 05/10 BLCC100I...

  • Page 36: Us E R De Fault Ta Ble

    To Erase user Ur001 Enter the new PIN, then press [OK]. If the error message “PIN John Smith Not Allowed” is displayed , press [OK] and try a different PIN. Press OK. Press OK or MENU Bosch Security Systems 05/10 BLCC100I...

  • Page 37: Add Pin

    This menu allows security installers and Master Users the ability to delete other users PINs. A Master user can only delete a PIN for users that have been assigned to the same area(s). The Installer and Master user cannot delete their own PIN. Bosch Security Systems 05/10 BLCC100I...

  • Page 38: Add Token

    Enter [MENU] + [1] + [3] + [0] and use the up and down arrows to highlight the user in the list then press [OK]. The system will only list users that dont already have an RF Keyfob assigned. Bosch Security Systems 05/10 BLCC100I...

  • Page 39: Delete Keyfob

    [OK]. The system will only list users that have an RF Keyfob assigned. Ur001 John Smith Ur002 Debbie Smith Ur003 User 3 Name Press  OK or MENU Press any key on the transmitter you wish to test. Bosch Security Systems 05/10 BLCC100I...

  • Page 40: Area Assignment

    [OK]. Timer Groups Use the up and down arrow keys to highlight the option then There are 8 different timer groups available. press the [ON] key to enable or the [OFF] key to disable. Bosch Security Systems 05/10 BLCC100I...

  • Page 41: Timer Group Example

    Access Group 8 This menu allows you to assign each user to one or more access groups. An access group is used to allow and/or restrict which users have access to various system outputs. These outputs can Bosch Security Systems 05/10 BLCC100I...

  • Page 42: Pin Retry Count

    Every time a valid temporary code is used, the Expire Time currenttly in focus will arm or disarm. counter will restart. If the user wants to arm / disarm a different area which they have Bosch Security Systems 05/10 BLCC100I...

  • Page 43: Access Assignment

    To Arm In All On Mode From the disarmed state, present the token once to fully arm the area. To Arm In Part Mode Present the token twice within 5 seconds and the area will arm in Part Mode. Bosch Security Systems 05/10 BLCC100I...

  • Page 44: Arm If Single User Area

    This option can be set per reader. NEW in Software version 1.02 and later. Note » » E N D S E C T I O N « « 5-10 Bosch Security Systems 05/10 BLCC100I...

  • Page 45: Area Programming

    . If you want the output to operate for multiple A002 Area 2 Name areas then the output index needs to be set to 0. A003 Area 3 Name  Press  OK ON OFF MENU Bosch Security Systems 05/10 BLCC100I...
  • Page 46 Enter [MENU] + [2] + [0] + [4] and select the area from the list A001 Security System and press [OK] to move to the selected area. A002 Area 2 Name A003 Area 3 Name Press  OK or MENU Bosch Security Systems 05/10 BLCC100I...
  • Page 47 If this option is not selected for an area then it will be able to operate independant of the common area. See MENU 7-7-1 — Area press the [ON] key to enable or the [OFF] key to disable. Options to enable the common area. Bosch Security Systems 05/10 BLCC100I...
  • Page 48 Part On or Part 2 On mode. will sound an alarm. To warn the user that senior watch time is about to expire, the keypad Bosch Security Systems 05/10 BLCC100I...
  • Page 49 When selected, the panel will activate the strobe output when an turned off (disarmed) before the entry delay time expires an Exit Error audible burglary zone has triggered an alarm. alarm report will be sent. Bosch Security Systems 05/10 BLCC100I...
  • Page 50 012 Weeks reporting to the security company’s base station receiver. Each Press 0-9 OK to SAVE destination can have a different account number programmed. The number should be entered from left to right with trailing zeros. Bosch Security Systems 05/10 BLCC100I...
  • Page 51 Using the numeric keys, enter the number of weeks between each user Service Interval. Valid entries are 1 – 255 Weeks or 000 to disable. Press [OK] to save and exit or press [MENU] to exit without saving. Bosch Security Systems 05/10 BLCC100I...
  • Page 52 Solution 16 plus Installation Manual Area Programming   This page left intentionally blank Bosch Security Systems 05/10 BLCC100I...
  • Page 53 Device Numbering Numbering Numbering Zones Zones Zones Solution Panel 1 to 8 1 to 8 1 to 16 CM104B Expander OFF OFF OFF 9 to 16 9 to 16 Total Zones Table 20: Zone Configuration Bosch Security Systems 05/10 BLCC100I...
  • Page 54 S = Zone 02 is Shorted A = Zone 03,05,07 are in Alarm (Unsealed) T = Zone 08 is in Tamper Alarm (Unsealed) - = Zone 04, 09-16 are Disabled (Unused) When finished press [OK] or [MENU] to exit. Bosch Security Systems 05/10 BLCC100I...
  • Page 55 Use the up and down arrow keys to select the zone(s) that you want to disable in Part 2, then press [OK]. Alternatively, you can enter the zone number directly then press [OK]. Zones marked with a tick are active and will alarm in Part 2 mode. Bosch Security Systems 05/10 BLCC100I...
  • Page 56 See Alpha Text Programming in Section 4 - Programming 12 = Reserved Overview for further detail on entering alpha text. 13 = Keyswitch Zone Note 14 = Display Only 15 = 24-Hour Non Burglary Table 22: Zone Types Bosch Security Systems 05/10 BLCC100I...
  • Page 57 Zones programmed as 24-hour burglary will trigger an alarm as soon as the zone becomes faulted regardless of what state the area is in. 24-Hour zones are active 24 hours a day. A 24hr Burglary report will be sent to the central station receiver. Bosch Security Systems 05/10 BLCC100I...
  • Page 58 Generally a strike would be operated for 5 seconds. Valid entries are 0 – 15 pulses. Assign the Reader under Reader properties to Access Group 5. Press [OK] to save and exit or press [MENU] to exit without saving. Bosch Security Systems 05/10 BLCC100I...
  • Page 59 Zone Report Route. See MENU 5-4-5 — Swinger Dialler to set the number of times a zone is allowed to trigger before being locked out. Bosch Security Systems 05/10 BLCC100I...
  • Page 60 All zone types including 24hour zones can be bypassed if this option is selected. Bypassed zones will be reset when the area is turned off or disarmed. Bosch Security Systems 05/10 BLCC100I...
  • Page 61 Alternatively, you can enter the zone number Press [OK] to DELETE the RF device and exit or press [MENU] to directly and press [OK]. The system will only list zones that exit without deleting. dont already have an RF device programmed. Bosch Security Systems 05/10 BLCC100I...
  • Page 62 Press [MENU] + [3] + [4] + [2]. The keypad will display the current input options. Press [MENU] + [3] + [4] + [0]. The keypad will display the current EOL value (Default = 5). 7-10 Bosch Security Systems 05/10 BLCC100I...

  • Page 63: Report Expander Tamper

    3 = Digiflex RF On/Off 7 = Inovonics Serial RF RX The trouble condition will clear when the tamper circuit has restored. 4 = Bosch Serial RF Receiver 8 = Secure Wireless RF RX Report Cabinet Tamper This menu option is used to configure the systems programmable Setting this option allows the panel to send a Cabinet Tamper report input terminal.

  • Page 64: Input Testing

    Alternatively, you can enter the zone number directly and press [OK]. The keypad will display the zone to be tested. 7-12 Bosch Security Systems 05/10 BLCC100I...

  • Page 65: Output Programming

    The keypad will display the following when the output is currently in the ON state but the connection is missing. Output 1 Name Op001 Is ON and Timing Connection Trouble Press OK or MENU Press [OK] or [MENU] to exit. Bosch Security Systems 05/10 BLCC100I...

  • Page 66: Turn Output On/Off

    6 – Destination 1 Reporting Overview for further detail on entering alpha text. This event type will cause the output to operate when the panel is Note communicating to Destination 1 and will reset when the transmission ends. Bosch Security Systems 05/10 BLCC100I...
  • Page 67 This event type will cause the output to operate when the panel is active. The output will reset when the exit timer expires or the detects that a zone has a trouble condition and will reset when the corresponding area is disarmed. trouble condition has cleared. Bosch Security Systems 05/10 BLCC100I...
  • Page 68 The output when all areas have been disarmed. will reset when the system or area is disarmed. Bosch Security Systems 05/10 BLCC100I...

  • Page 69: Event Assignment

    Keyfob. This function requires a 4 button keyfob. without saving. 54 – RF Keyfob Function 2 This event type will cause the output to operate when Key Y is pressed on the Keyfob. This function requires a 4 button keyfob. Bosch Security Systems 05/10 BLCC100I...

  • Page 70: Output Polarity

    This means the operation of the output the event occurs. The output can only be reset manually using the can be shortened based on the event and or the programmed time Output Command Menu. parameter. Bosch Security Systems 05/10 BLCC100I...

  • Page 71: Timed Outputs

    The time base is the unit of time that the output will pulse on and off. If the time base is programmed for 60 seconds, the output will pulse on for 60 seconds and then off for 60 seconds (repeat) until the output is reset. Bosch Security Systems 05/10 BLCC100I...

  • Page 72: Block If All On

    Outputs > Testing > Internal Bell Test MENU 4-9-1   This menu allows you to test any output programmed as event type 37 (Internal Audible) or event type 39 (Fire Alarm) for 5 seconds. Bosch Security Systems 05/10 BLCC100I...

  • Page 73: Output Event Type Table

    Do not Operate If Low Battery Display Output Overload Report Output Overload Display Missing Output Device Report Missing Output Device Alarm On Device Fail Block Output If Armed All On Display Status On Keypad Table 26: Output Default Table Bosch Security Systems 05/10 BLCC100I...
  • Page 74 Solution 16 plus Installation Manual Output Programming   This page left intentionally blank 8-10 Bosch Security Systems 05/10 BLCC100I...

  • Page 75: Comms Programming

    Press  0-9 OK to SAVE When the first number is complete press [OK] to program telephone number 2 if required. See MENU 5-4-0 and 5-4-1 to configure the Transmission Format to Domestic Reporting. Note Bosch Security Systems 05/10 BLCC100I...

  • Page 76: Call / Answer Ras (Solutionlink)

    To toggle call forward on, press the [ON] key or press the [OFF] Number Prefix MENU 5-1-0  key to turn call forward off. Digits Press [OK] to save and exit, or press [MENU] to cancel. The number prefix allows you to program the customer Bosch Security Systems 05/10 BLCC100I...

  • Page 77: Primary Dest 1

    Secondary Telephone Number for Destination 2. Digits Secondary Dest 2 P001 This menu sets the secondary telephone number for Destination 1. This will typically be the secondary base station receiver number. Press  0-9 OK to SAVE Bosch Security Systems 05/10 BLCC100I...

  • Page 78: Domestic

    Domestic dialling also follows the call attempt count. However, Press  0-9 OK to SAVE the call attempt count will be spread over total phone numbers programmed for domestic reporting, ie. if three domestic telephone numbers are programmed and the call attempt Bosch Security Systems 05/10 BLCC100I...

  • Page 79: Comms Properties

    Repeat Step 2 until all options are programmed as required, not support it. then press [OK] to save and exit or press [MENU] to exit without saving. Dial Tone Detect This option configures the panel to start dialling as soon as it detects Bosch Security Systems 05/10 BLCC100I...

  • Page 80: Display Telephone Line Fail

    Press [OK]. be connected to this number and Solutionlink should be set to wait for an incomming call. The installer or customer can force the panel to dial this number by entering MENU 5-0-1. Bosch Security Systems 05/10 BLCC100I...

  • Page 81: Ras Security Pin

    PIN. You can change a single digit by scrolling the cursor left or right. Ring Count P001 Press [OK] to save and exit or press [MENU] to exit without 15-15 Rings saving. Press  0-9 OK to SAVE Bosch Security Systems 05/10 BLCC100I...

  • Page 82: Solutionlink Ras Options

    Press [MENU] + [5] + [3] + [5]. The keypad will display the Answering machine bypass allows you to establiish a RAS connection current DTMF options. to a panel when there is an answering machine or facsimile machine Bosch Security Systems 05/10 BLCC100I...

  • Page 83: Dtmf Arming

    Make sure that when the code is entered, no external phone connected will cause the panel to terminate the session. services are selected or activated. If they are, then change the code to something else. Bosch Security Systems 05/10 BLCC100I...

  • Page 84: Cli Number

    Press [MENU] + [5] + [4] + [1]. The keypad will display the Using the numeric keys, enter all the digits for CLI number 2 . current Transmission Format for Destination 2. Press [OK] to program CLI number 3. 9-10 Bosch Security Systems 05/10 BLCC100I...

  • Page 85: Tx Format Dest 2

    [OK] to save and exit or press [MENU] to exit 01 - Dest 1 + Log without saving. Valid entries are 0 - 15 / 0 = disabled. Press  0-9 OK to SAVE 9-11 Bosch Security Systems 05/10 BLCC100I...

  • Page 86: Burg Report Delay

    Comms > MyAlarm > Customer MENU 5-5-0  Email Options MENU 5-5-9   Open / Close Reports Reserved for future use. Zone Alarm Reports Zone Trouble Reports System Reports Access Reports Reserved Reserved Reserved 9-12 Bosch Security Systems 05/10 BLCC100I...

  • Page 87: Open / Close Reports

    (i.e. security company monitoring station, mobile telephone etc). Enter [MENU] + [5] + [9] + [0]. The keypad will prompt that it is in the process of sending a test report. 9-13 Bosch Security Systems 05/10 BLCC100I...

  • Page 88: Test Report Period

    The panel will send the cued Test Report as soon as the siren run-time has expired. 9-14 Bosch Security Systems 05/10 BLCC100I...
  • Page 89 Use the arrow keys to set the required volume level. Each time Voltage=13.87 a key is pressed, you will hear a beep indicating the new Press OK or MENU volume level. When finished press [OK]. Press [OK] or [MENU] to exit when finished. 10-1 Bosch Security Systems 05/10 BLCC100I...
  • Page 90 If a user toggles the keypad display to view a different area, the keypad will automatically timeout and move back to the home area if no key is pressed for a period of 60 seconds. 10-2 Bosch Security Systems 05/10 BLCC100I...
  • Page 91 Each keypad can be set to display its own temperature. It is possible to trigger a temperature alarm based on the keypad temperature. See MENU 7-7-3 — Keypad Hi/Lo Temp for more information. 10-3 Bosch Security Systems 05/10 BLCC100I...
  • Page 92 Table 28: Keypad Emergency Keys Report Keypad Fire Setting this option allows the panel to send a Fire report to the base station when a Keypad Fire Emergency Alarm has been triggered via the keypad. 10-4 Bosch Security Systems 05/10 BLCC100I...
  • Page 93 Alarm On RF Receiver Comms Fail RF transmitters (sensor devices) will send a supervisory test Report RF Receiver Comms Fail signal approximately once every hour. The RF receiver expects Reserved to receive this supervisory signal from every transmitting device 10-5 Bosch Security Systems 05/10 BLCC100I...
  • Page 94 Setting this option will cause the panel to send an RF Device Faulted or by triggering the tamper switch on any sensor. report to the base station when the devices tamper curcuit is tripped. A restore report will be sent when the tamper circuit is resealled. 10-6 Bosch Security Systems 05/10 BLCC100I...
  • Page 95 00 - No Device Conn Press 0-9 OK to SAVE Use the up and down arrow keys to select the Baud Rate required then press [OK] to save and exit or press [MENU] to exit without saving. 10-7 Bosch Security Systems 05/10 BLCC100I...
  • Page 96 Solution 16 plus Installation Manual Device Programming   This page left intentionally blank 10-8 Bosch Security Systems 05/10 BLCC100I...
  • Page 97 System trouble events such as Failure To Comminicate or Telco Note Line Fail are grouped under System Trouble in the list while 11-1 Bosch Security Systems 05/10 BLCC100I...
  • Page 98 If this problem still persists you must do a full system default. 11-2 Bosch Security Systems 05/10 BLCC100I...
  • Page 99 Therefore, only emergency, burglary and fire reports This feature is currently reserved. will be sent. Press [MENU] + [7] + [0] + [3]. The keypad will display: 11-3 Bosch Security Systems 05/10 BLCC100I...
  • Page 100 Use the up and down arrow keys to toggle the month, week and year. Use the left and right keys to move the cursor between the month, week and year. When finished press [OK] to save and exit or press [MENU] to exit without saving. 11-4 Bosch Security Systems 05/10 BLCC100I...
  • Page 101 Press [MENU] + [7] + [2] + [1]. The keypad will display the current Entry Time 1 delay. Press [MENU] + [7] + [2] + [3]. The keypad will display the current Part Entry time. 11-5 Bosch Security Systems 05/10 BLCC100I...
  • Page 102 Press [MENU] + [7] + [2] + [5]. The keypad will display the Display Clock Trouble current Output Pre Alert Time. This menu option allows you to configure the AC Mains Power system options. (*** System Wide Parameter ***) 11-6 Bosch Security Systems 05/10 BLCC100I...
  • Page 103 Area 1 is armed All On. the system. New - Software Version 1.02 and higher corrected. Previous versions would always test the battery on arming regardless if this option was programmed or not. Note 11-7 Bosch Security Systems 05/10 BLCC100I...
  • Page 104 +12 V terminal exceeds its S... . . F maximum rating of 1Amp. -------------  --------- Press  OK to SAVE Report +12V (Accessories) Current Overload 11-8 Bosch Security Systems 05/10 BLCC100I...
  • Page 105 Swinger Siren count. Schedule 2 Name Press  OK to SAVE Siren Swinger See Alpha Text Programming in Section 4 - Programming Overview for further detail on entering alpha text. Press 0-9 OK to SAVE Note 11-9 Bosch Security Systems 05/10 BLCC100I...
  • Page 106 The INDEX is the Ouput Number to turn on and off, setting the index Press numbers [1] to [8] to enable/disable the days of the week to zero will disable the output. that the schedule will operate. 11-10 Bosch Security Systems 05/10 BLCC100I...
  • Page 107 Holiday in the list then press [OK]. Alternatively, you can enter the Holiday number directly and press [OK]. H001 Holiday 1 Name H002 Holiday 2 Name H003 Holiday 3 Name Press  OK or MENU 11-11 Bosch Security Systems 05/10 BLCC100I...
  • Page 108 Power Up In Same State As Powered Down Setting this option will cause the panel to power up in the same state as it was when it was powerd down. For example with this option 11-12 Bosch Security Systems 05/10 BLCC100I...
  • Page 109 Press [MENU] + [7] + [7] + [4]. The keypad will display the current Installer options. Wed 05-Jan-2005 Time > 10:34am Report Installer  Report Prog Change Arm Only Installer PIN Press  OK ON OFF MENU 11-13 Bosch Security Systems 05/10 BLCC100I...
  • Page 110 To test Zn001 Open then Close Enter [MENU] + [7] + [7] + [5]. The keypad will display the Zone 1 Name following: Press OK or MENU Language Press 0-9 OK to SAVE 11-14 Bosch Security Systems 05/10 BLCC100I...
  • Page 111 If the battery has failed the test, the keypad will display: Battery Test Failed. Please Call For Service. To Go Back, Press OK Press [OK] to exit. » » E N D S E C T I O N « « 11-15 Bosch Security Systems 05/10 BLCC100I...
  • Page 112 Solution 16 plus Installation Manual System Programming   This page left intentionally blank 11-16 Bosch Security Systems 05/10 BLCC100I...

  • Page 113: Programming Examples

    Finally select the days of the week you wish auto arming Set Output 5 - Time Parameter MENU 4-1-4 = 000 000 005 000 to occur in MENU7-5-2 (5 seconds) Enable Output 5 - Output Options MENU 4-1-5 = Display Status Message 12-1 Bosch Security Systems 05/10 BLCC100I...

  • Page 114: Operating An Output With A Schedule

    1. Set output 5 to Event type = 60 (Access Group) and Access Assignment = 4. » » E N D S E C T I O N « « 12-2 Bosch Security Systems 05/10 BLCC100I...

  • Page 115: Specifications

    2 x Phillips Pan Head Zinc Plated Screws 1 x Panel Tamper Switch + Tamper Lead 1 x Telephone Cable RJ12 6P/4C 1 x Tamper Switch Bracket 1 x Pack PCB Mounting Clips (5 pc/pack) 1 x Product Identification Label 13-1 Bosch Security Systems 05/10 BLCC100I...
  • Page 116 Solution 16 plus Installation Manual Specifications   This page left intentionally blank 13-2 Bosch Security Systems 05/10 BLCC100I...

  • Page 117: Index

    Delay Report ........7-8 14-1 Bosch Security Systems 05/10 BLCC100I...
  • Page 118 Report Temperature ......10-3 Horn Speaker Show Alarm When Armed ..... . . 10-4 14-2 Bosch Security Systems 05/10 BLCC100I...
  • Page 119 PIN Retry Report....... . 6-5 14-3 Bosch Security Systems 05/10 BLCC100I...
  • Page 120 Test Report Zone Default Table......7-4 14-4 Bosch Security Systems 05/10 BLCC100I...
  • Page 121 Zone Type ........7-4 14-5 Bosch Security Systems 05/10 BLCC100I...
  • Page 122 Bosch Security Systems 25 Huntingwood Drive Huntingwood, NSW 2128 Australia Phone: +612 9672 1777 Facsimile: +612 9672 1717 © 2010 Bosch Security Systems BLCC100I 920656 Issue FTR1.0...
