Pioneer SP-99D Service Manual

Q) PIONEER'
The Art of Entertainment
Service
Manual
DOLBY SURROUND AC-3 & PRO LOGIC PROCESSOR
SP-9S9D
SP-DO?7
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
ORDER NO.
RRV1372
CONTENTS
1. SAFETY INFORMATION ..............ccccceeee eens 2 5. FL INFORMATION .......... esses seer teee een ere ees 38
2. EXPLODED VIEWS, PACKING AND 6. IC INFORMATION ........... ccc cece scene ene eeees 40
PARES LIST. tcctstevennnatievetinctepceamnseanwereedas 3 7. BLOCK DIAGRAM .......... 0c ceccesc eee eee eee ee eens 56
3. SCHEMATIC AND PCB CONNECTION 8. PANEL FACILITIES .......... cee ee cece ees 57
DIAGRAMS 25. esescedevssssesssn sce veesieera dens veveane 8 9. SPECIFICATIONS. .... 0... cece ceee teense eee ees 58
4. PCB PARTS LIST ....... eee cece eee eee eee ees 35
PIONEER ELECTRONIC CORPORATION 3-1, Meguro 1-Chome, Meguro-ku, Tokyo 153, Japan
PIONEER ELECTRONICS SERVICE INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC [EUROPE] N.V. Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 501 Orchard Road, #10-00 Lane Crawford Place, Singapore 0923
© PIONEER ELECTRONIC CORPORATION 1995
T-DFY JULY 1995 Printed in Japan
