TOSHIBA
1
Satellite M40
Model
Description
M40-S417TD
Intel® Celeron® M 360 (1.40GHz 1MB L2 400MHz FSB), Integrated Intel® Graphics Media
Accelerator 900, 40GB(P-ATA/5400rpm), 256MB PC2700 DDR 333MHz SDRAM, CD-
RW/DVD-ROM, 15.4" TFT LCD 1280x800 (WXGA), 6-cell, Wi-Fi™ Wireless-LAN Ready,
10/100Base-TX Ethernet, Microsoft® Windows® XP Home Edition SP2, 1-year standard
limited warranty
M40-S4172TD
Intel® Celeron® M 360 (1.40GHz 1MB L2 400MHz FSB), Integrated Intel® Graphics Media
Accelerator 900, 40GB(P-ATA/5400rpm), 256MB PC2700 DDR 333MHz SDRAM, CD-
RW/DVD-ROM, 15.4" TFT LCD 1280x800 (WXGA), 6-cell, Wi-Fi™ Wireless-LAN Ready,
10/100Base-TX Ethernet, Microsoft® Windows® XP Professional SP2, 1-year standard
limited warranty
System Characteristics
3
Operating System
•
Microsoft® Windows® XP Professional SP2
•
Microsoft® Windows® XP Home Edition SP2
•
Toshiba® Express Media Player for quick access to CD, DVD
4
Choice of Processors
•
Intel Celeron® M Processor 360 [1.40GHz, 1MB L2, 400MHz
FSB]
•
Intel Pentium® M Processor 740 [1.73GHz, 2MB L2, 533MHz
FSB]
•
Intel Pentium® M Processor 760 [2.00GHz, 2MB L2, 533MHz
FSB]
Chipset
•
Mobile Intel® 915GM or 915PM Express Chipset depending
on configuration
5
Memory
•
256MB(Minimum)/2048MB (Maximum), 2 memory slots using
256MB, 512MB, or 1024MB PC2700 DDR 333MHz SDRAM,
(both memory slots may be occupied).
Mass Storage
Choice of Hard Disk Drives:
•
40GB (5400 RPM), 60GB (5400 RPM) , 80GB (5400 RPM),
100GB (5400 RPM) Enhanced IDE (ATA-6) hard disk drive;
9.5mm height, user removable (1 screw)
Choice of Optical Disk Drives
•
Fixed Bay CD-RW/DVD-ROM
Maximum Speed:
CD-ROM (24x:read), CD-R (24x:write), CD-RW
(10x:write), DVD-ROM (8x:read)
Compatibility:
CD-ROM (read), CD-R (read/write), CD-RW (read/re-
write), DVD-ROM (read), DVD-R (read), DVD-RW (read),
DVD+R (read), DVD-RAM (read)
•
Fixed Bay DVD SuperMulti drive (double layer):
Maximum Speed:
CD-ROM (24x:read), CD-R (24x:write), CD-RW
(24x:write), DVD-ROM (8x:read), DVD-R (8x:write), DVD-
RW (4x:write), DVD+R (8x:write), DVD+R (Double Layer)
(2.4x:write), DVD+RW (4x:write), DVD-RAM (3x:write)
7
Display
•
15.4" diagonal TFT active-matrix LCD display at 1280 x 800
native resolution (WXGA), 300:1 contrast ratio
•
15.4" diagonol TFT active-matrix LCD display at 1280x800
native resolution (WXGA) with TruBrite™ Technology, 400:1
contrast ratio
•
15.4" diagonol TFT active-matrix LCD display at 1440x900
native resolution (WSXGA+), 600:1 contrast ratio
•
Brightness Control by Fn+F6/F7 and TOSHIBA Power Saver
8
Choice of Graphics
•
Integrated Intel Graphics Media Accelerator 900; up to 128MB
of graphics memory is taken from the main memory via UMA
(Unified Memory Architecture)
•
ATI MOBILITY™ RADEON® X600 PCI-E x16 with 64MB DDR
(discrete graphics memory)
•
NVIDIA® GeForce™ Go 6600 PCI-E x16 128M (128MB DDR
discrete graphics memory)
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
2
6
:
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
Satellite M40 BTO Rev 1.03 2005-07-26 SK T20050418 CB1.30
Sound
•
Analog Devices AD1981B integrated 16-bit stereo software
sound
•
Choice of speakers:
standard stereo speakers
o
harman/kardon® speakers
o
•
Direct 3D Sound (supported by driver); DirectSound (supported
by driver), Direct Music (supported by driver), MIDI (play back)
support,
•
Sound Volume Control Dial
•
SRS® TruSurround XT® and SRS® WOW™ Audio
9
Enhancements
Input Devices
•
Keyboard
85 key US keyboard, 2.7mm key stroke, 6.0mm keyboard
o
height, 19.05mm key pitch
Hot Key Functions (FN); please see electronic User's Guide
o
for more information
Windows Key Function
o
Application Key Function
o
•
Pointing Devices:
Toshiba TouchPad™
o
Enable/Disable (FN+F9 or by help of software)
o
•
Buttons
Internet Browser Launch Button
o
CD Control Buttons (Skip to Previous Track, Play, Stop, Skip
o
to Next Track)
Express Media Player Launch Button
o
Expandability
•
2 main memory slots. Both slots may be occupied.
•
1 Type II, PCMCIA R2.01, PC Card16, CardBus PC Card slot
•
1 slot for ExpressCard/34 or ExpressCard/54 (extended) module
support
•
Bridge Media Adapter (Secure Digital®, Memory Stick™,
Memory Stick PRO™, Smart Media, Multi Media Card, xD
Picture Card (shared slots)
Communications
•
Integrated V.92 modem
•
Marvell 10Base-T / 100Base-TX
•
Optional Bluetooth Version 1.2
•
Choice of Wi-Fi™ Wireless-LAN
Integrated Wireless-LAN Antenna only
o
Intel® Pro/Wireless Network Connection 2200BG
o
(802.11b/g)
Intel® Pro/Wireless Network Connection 2915ABG
o
(802.11a/b/g)
Atheros® 802.11b/g wireless-LAN supporting Atheros
o
SuperG™ technology
Atheros® 802.11a/b/g wireless-LAN supporting Atheros
o
SuperAG™ technology
Ports
•
RGB (monitor) port
•
TV-out (S-Video)
•
i.LINK™ IEEE-1394
•
3 Universal Serial Bus (USB) ports (v2.0)
Part Number
UPC
PSM40U-0C4045
032017403055
PSM40U-0C4047
032017400306
10
11
:
Page 1 of 4
