Sealey ES601.V2 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear protective
instructions gloves
1. SAFETY
Ensure that the engine support is in good working order. Take action for immediate repair or replacement of damaged parts. Use
9
genuine parts only. The use of unauthorised parts may be dangerous and will invalidate the warranty.
Locate the vehicle in a suitable, well lit work area.
9
Keep work area clean and tidy and free from unrelated materials.
9
Ensure the vehicle handbrake is engaged and the engine/motor is switched off.
9
Ensure all non-essential persons keep a safe distance whilst the engine support is in use.
9
DO NOT use the engine support if damaged.
8
DO NOT allow untrained persons to operate the engine support.
8
DO NOT use the engine support for purposes other than that for which it is designed.
8
DO NOT exceed the rated capacity of the engine support.
8
When not in use, store engine support in a safe, dry, childproof area.
9
WARNING! The warnings, cautions and instructions referred to in this manual cannot cover all possible conditions and situations
‰
that may occur. It must be understood that common sense and caution are factors which cannot be built into this product, but must
be applied by the operator.
2. INTRODUCTION
Designed to support and assist to accurately position engines during maintenance operations such as replacing anti-vibration mountings and
certain body panels. Also used as an aid for the removal of gearboxes and transmissions. Beams supported on rubber feet and fine adjustment
control is obtained by using screw/hook mechanisms. This model has the additional advantage of a 360° adjustable rotating cross beam to
enable a greater range of support options when in use.
3. SPECIFICATION
MODEL NO: ..........................................................ES601.V2
Capacity: ...................................................................... 500kg
Cross Beam Maximum Width: .................................... 860mm
Cross Beam Minimum Width: ....................................... 60mm
Main Beam Maximum Width: ................................... 1680mm
Main Beam Minimum Width: ........................................ 60mm
Screw Hook Lengths: .......................................... 450/350mm
© Jack Sealey Limited
500KG ENGINE SUPPORT BEAM WITH
CROSS BEAM
MODEL NO:
Wear safety Wear protective
footwear clothing
Original Language Version
ES601.V2
ES601.V2 Issue 1 13/05/2020
