LG 32LK4 Series Owner's Manual

Lcd tv / led lcd tv
Hide thumbs Also See for 32LK4 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
LCD TV / LED LCD TV
Please read this manual carefully before operating
your set and retain it for future reference.
LCD TV MODEL
22LK3**
32LK4**
26LK3**
42LK4**
32LK3**
19LV2**
22LV2**
32LV3***
26LV2**
42LV3***
32LV2**
www.lg.com

Advertisement

Table of Contents
loading

Related Manuals for LG 32LK4 Series

Summary of Contents for LG 32LK4 Series

  • Page 1 OWNER’S MANUAL LCD TV / LED LCD TV Please read this manual carefully before operating your set and retain it for future reference. LCD TV MODEL 22LK3** 32LK4** 22LV2** 32LV3*** 26LK3** 42LK4** 26LV2** 42LV3*** 32LK3** 19LV2** 32LV2** www.lg.com...
  • Page 2 Safety InStructIonS • Please read these safety precautions carefully before using the product. • In this manual, the illustration may be somewhat different from your product because it is just example to help the instruction. warNING If you ignore the warning message, you may be seriously injured or there is a possibility of accident or death. If you ignore the caution message, you may be slightly injured or the product may be damaged.

  • Page 3: Table Of Contents

    CONTENTS PREPARATION TO USE A USB DEVICE Accessories ............. A-1 When connecting a USB device .......31 Photo list ............33 Music list ............37 Movie list ............40 DivX Registration Code ........44 EXTERNAL EQUIPMENT SETUP Deactivation ............45 Antenna Connection ..........1 Connecting with a Component cable ....2 Connecting with a HDMI cable ......3 PICTURE CONTROL Connecting with a HDMI to DVI cable ....4...
  • Page 4 CONTENTS TIME SETTING Clock Setup ............70 Auto on/off time setting ........71 Sleep Timer setting ...........71 TELETEXT Switch on/off .............72 SIMPLE Text............72 TOP Text............72 FASTEXT ............73 Special Teletext Functions ........73 APPENDIX Troubleshooting ..........74 Maintenance ............76 Product Specifications ........77 IR Codes ............79 External Control Device Setup ......80...

  • Page 5: Preparation

    PREPARATION ACCESSORIES Ensure that the following accessories are included with your TV. If an accessory is missing, please contact the dealer where you purchased the TV. ■ Image shown may differ from your TV. This item is not included for all models. Polishing Cloth Owner’s Manual Polishing cloth for use on the screen.
  • Page 6 PREPARATION FRONT PANEL CONTROLS NOTE ► The energy consumed during use can be significantly reduced if the level of brightness of the picture is reduced, and this will reduce the overall running cost. CAUTION ► Do not step on the glass stand or subject it to any impact. It may break, causing possible injury from fragments of glass, or the TV may fall.
  • Page 7 ■ Image shown may differ from your TV. 32/42LK4** Only PROGRAMME HOME VOLUME INPUT SPEAKER HOME HOME INPUT INPUT HOME Remote Control Sensor POWER INPUT Power/Standby Indicator (Can be adjusted using the Power Indicator in the OPTION menu.)
  • Page 8 PREPARATION FRONT PANEL CONTROLS ■ Image shown may differ from your TV. 19/22/26/32LV2*** Only VOLUME PROGRAMME HOME INPUT POWER Touch Sensor Remote Control Sensor • You can use the desired button function by touching. Power/Standby Indicator (Can be adjusted using the Power Indicator in the OPTION menu.)
  • Page 9 ■ Image shown may differ from your TV. 32/42LV3*** Only PROGRAMME VOLUME HOME SPEAKER HOME INPUT INPUT POWER Remote Control Sensor Power/Standby Indicator (Can be adjusted using the Power Indicator in the OPTION menu.) OPTICAL (RGB/DVI) DIGITAL AUDIO IN AUDIO OUT RGB IN (PC)
  • Page 10 /DVI IN ANTENNA VIDEO AUDIO COMPONENT IN PREPARATION BACK PANEL INFORMATION ■ Image shown may differ from your TV. 22LK3** 26/32LK3** Only Only 26/32LD340 RS-232C IN (CONTROL) AUDIO IN (RGB/DVI) RGB IN (PC) VIDEO L/MONO AUDIO /DVI IN ANTENNA VIDEO AUDIO COMPONENT IN AV IN2...
  • Page 11 BACK PANEL INFORMATION ■ Image shown may differ from your TV. 32/42LK4** Only AV IN 2 (RGB) (DVI) Power Cord Socket RGB/DVI Audio Input This TV operates on an AC power. The voltage is Connect the audio from a PC. indicated on the Specifications page.
  • Page 12 PREPARATION ■ Image shown may differ from your TV. 19/22/26LV2*** 32LV2*** Only Only DC-IN (DVI) (DVI) HDMI Input Audio/Video Input Connect an HDMI signal to HDMI IN. Connect audio/video output from an external device to these jacks. Or DVI(VIDEO)signal to HDMI/DVI port with DVI to HDMI cable.
  • Page 13 ■ Image shown may differ from your TV. 32/42LV3*** Only (DVI) HDMI Input Audio/Video Input Connect an HDMI signal to HDMI IN. Connect audio/video output from an external device to these jacks. Or DVI(VIDEO)signal to HDMI/DVI port with DVI to HDMI cable. Component Input RGB Input Connect a component video/audio device to these...
  • Page 14 PREPARATION STAND INSTALLATION ■ Image shown may differ from your TV. ■ When assembling the desk type stand, check whether the bolt is fully tightened. (If not tightened fully, the product can tilt forward after the product installation.) If you tighten the bolt with excessive force, the bolt can deviate from abrasion of the tightening part of the bolt.
  • Page 15 Only 19/22/26LV2*** Only 32LV2*** Carefully place the TV screen side down on a Carefully place the TV screen side down on a cushioned surface to protect the screen from cushioned surface to protect the screen from damage. damage. Assemble the parts of the Stand Body with Assemble the parts of the Stand Body with the Stand Base of the TV the Stand Base of the TV...
  • Page 16 PREPARATION BACK COVER FOR WIRE Only 32/42LV3*** ARRANGEMENT Carefully place the TV screen side down on a cushioned surface to protect the screen from ■ Image shown may differ from your TV. damage. Only 22LK3** After Connecting the cables as necessary, install CABLE HOLDER as shown and bundle the cables.
  • Page 17 Only 26/32LK3**, 32/42LK4** Only 32/42LV3*** Connect the cables as necessary. After Connecting the cables as necessary, install CABLE HOLDER as shown and bundle the cables. To connect additional equipment, see the External Equipment Setup section. Cable Holder Open the Cable Management Clip as shown and manage the cables.
  • Page 18 PREPARATION NOT USING THE DESK- Only 26/32LK3**, 32/42LK4** TYPE STAND Insert the Protection Cover into the TV until clicking sound. ■ Image shown may differ from your TV. When installing the wall-mounted unit,use the pro- tection cover. Only 22LK3** Carefully place the TV screen side down on a cushioned surface to protect the Protection Cover screen from damage.
  • Page 19 KENSINGTON SECURITY ATTACHING THE TV TO A DESK SYSTEM (Only 26/32LK3**, 32/42LK4**, 32LV2***, 32LV3***) ■ Image shown may differ from your TV. ■ Image shown may differ from your TV. ■ This feature is not available for all models. ■ This feature is not available for all models. The TV must be attached to desk so it cannot be The TV is equipped with a Kensington Security pulled in a forward/backward direction, potentially...
  • Page 20 PREPARATION CAREFUL INSTALLATION ADVICE ■ You should purchase necessary components to fix the TV safety and secure to the wall from the market. ■ Position the TV close to the wall to avoid the possibility of it falling when pushed. ■...
  • Page 21 Further information, refer to the instruc- ■ The TV is designed to be mounted horizontally. tions included with the mount. ► LG is not liable for any accidents or damage to prop- erty or TV due to incorrect installation: DESKTOP PEDESTAL - Where a non-compliant VESA wall mount is used.
  • Page 22 PREPARATION REMOTE CONTROL KEY FUNCTION When using the remote control, aim it at the remote control sensor on the TV. ■ Image shown may differ from your TV. POWER Switches the TV on from standby or off to standby. ENERGY Adjust the power saving mode of the TV.
  • Page 23 ■ Image shown may differ from your TV. Controls the USB menu. Home Selects a menu. Clears all on-screen displays and returns to TV view- ing from any menu. Select the desired quick menu source.( p.14 ) Q. MENU  THUMBSTICK Allows you to navigate the on-screen menus and adjust the system settings to your preference...

  • Page 24: External Equipment Setup

    EXTERNAL EQUIPMENT SETUP ■ To prevent damage do not connect to the mains outlet until all connections are made between the devices. ANTENNA CONNECTION ■ For optimum picture quality, adjust antenna direction. ■ An antenna cable and converter are not supplied. AV IN Multi-family Dwellings/Apartments AV IN 1...

  • Page 25: Connecting With A Component Cable

    EXTERNAL EQUIPMENT SETUP RS-232C IN ■ To avoid damaging any equipment, never plug in any power cord until you have finished connecting (CONTROL) all equipment. ■ This section on EXTERNAL EQUIPMENT SETUP mainly uses diagrams for the 26/32LK3** models. RGB IN (PC) ■...

  • Page 26: Connecting With A Hdmi Cable

    CONNECTING WITH A HDMI CABLE RS-232C IN RS-232C IN (CONTROL) (CONTROL) Connect the HDMI output of the external equip- ment (digital set-top box, DVD, etc.) to HDMI/DVI RGB IN (PC) RGB IN (PC) IN 1, HDMI/DVI IN 2 (Except 22LK3**) or HDMI IN AUDIO IN AUDIO IN...

  • Page 27: Connecting With A Hdmi To Dvi Cable

    EXTERNAL EQUIPMENT SETUP ANT OUT S-VIDEO VIDEO CONNECTING WITH A HDMI TO DVI CABLE RS-232C IN RS-232C IN (CONTROL) (CONTROL) OUTPUT 26/32LD330 ANT IN RGB IN (PC) RGB IN (PC) SWITCH Connect the digital set-top box or the DVI out- AUDIO IN AUDIO IN USB IN...

  • Page 28: Connecting With A Rca Cable

    CONNECTING WITH A RCA CABLE Connect the AUDIO/VIDEO jacks between TV and VCR or external equipment. Match the jack colours (Video = yellow, Audio Left = white, and Audio Right = red) Insert a video tape into the VCR and press PLAY on the VCR.

  • Page 29: Connecting With A Rf Cable

    EXTERNAL EQUIPMENT SETUP CONNECTING WITH A RF CABLE ■ To avoid picture noise (interference), allow adequate distance between the VCR and TV. Connect the ANT OUT socket of the VCR to the ANTENNA IN socket on the TV. Connect the antenna cable to the ANT IN socket of the VCR.

  • Page 30: Connecting With A D-Sub 15 Pin Cable

    CONNECTING WITH A D-SUB 15 PIN CABLE This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's settings. RS-232C IN (CONTROL) RGB IN (PC) AUDIO IN Connect the RGB output of the PC to the RGB (RGB/DVI) IN (PC) jack on the TV.

  • Page 31: Supported Display Resolution

    EXTERNAL EQUIPMENT SETUP SUPPORTED DISPLAY RESOLUTION RGB-PC mode HDMI/DTV mode Horizontal Vertical Horizontal Vertical Resolution Resolution Frequency(kHz) Frequency(Hz) Frequency(kHz) Frequency(Hz) 640x350 31.468 70.09 720x480 31.47 59.94 720x400 31.469 70.09 720x480 31.50 60.00 640x480 31.469 59.94 720x576 31.25 50.00 800x600 37.879 60.317 1280x720 44.96...

  • Page 32: Screen Setup For Pc Mode

    SCREEN SETUP FOR PC MODE SCREEN RESET Returns Position, Size and Phase to the factory default settings. This function works in the following mode: Component(Except 480i, 576i), RGB. Screen Move Prev. PICTURE Move ▲ Resolution • Contrast • Brightness Auto Config. •...
  • Page 33 EXTERNAL EQUIPMENT SETUP AUTO CONFIGURE (RGB [PC] MODE ONLY) Automatically adjust the picture position and minimizes image instability. After adjustment, if the image is still not correct, your TV is functioning properly but needs further adjustment. Auto configure This function is for automatic adjustment of the screen position, size and phase The displayed image will be unstable for a few seconds while the auto configuration is in progress.
  • Page 34 SELECTING RESOLUTION To view a normal picture, match the resolution of RGB mode at TV and selection at PC. This function works in the following mode: RGB[PC] (1024x768, 1280x768, 1360x768) Screen PICTURE Move Prev. Move ▲ 1024 x 768 Resolution •...
  • Page 35 EXTERNAL EQUIPMENT SETUP ADJUSTMENT FOR SCREEN POSITION, SIZE, PHASE If the picture is not clear after auto adjustment and especially if characters are still trembling, adjust the picture phase manually. Position operates in Component(except 480i, 576i), RGB mode. Size, Phase operate only in RGB mode. Screen PICTURE Move...

  • Page 36: Watching Tv / Programme Control

    WATCHING TV / PROGRAMME CONTROL TURNING ON THE TV - When your TV is turned on, you will be able to use its features. Firstly, connect the power cord correctly. At this stage, the TV switches to standby mode. In standby mode to turn TV on, press the / I, INPUT or P button on the TV or press the POWER, INPUT, P...

  • Page 37: Quick Menu

    WATCHING TV / PROGRAMME CONTROL QUICK MENU Your TV's OSD (On Screen Display) may differ slightly from that shown in this manual. Q.Menu (Quick Menu) is a menu of features which users might use frequently. • Aspect Ratio: Selects your desired picture format. For Zoom Setting, select 16:9, Original, 4:3, 14:9, Zoom and Cinema Zoom in Ratio Menu.

  • Page 38: On Screen Menus Selection And Adjustment

    ON SCREEN MENUS SELECTION AND ADJUSTMENT Your TV's OSD (On Screen Display) may differ slightly from that shown in this manual. ■ Image shown may differ from your TV. SETUP PICTURE AUDIO Move Move Move Auto Tuning Aspect Ratio : 16:9 Auto Volume : Off Manual Tuning...

  • Page 39: Auto Programme Tuning

    WATCHING TV / PROGRAMME CONTROL AUTO PROGRAMME TUNING Use this to automatically find and store all available programmes. When you start auto programming, all previously stored service information will be deleted. SETUP SETUP Move Move Auto Tuning Auto Tuning Auto Tuning Auto Tuning Manual Tuning Manual Tuning...

  • Page 40: Manual Programme Tuning

    MANUAL PROGRAMME TUNING Manual Tuning lets you manually tune and arrange the stations in whatever order you desire. SETUP SETUP Move Move Auto Tuning Auto Tuning Storage Manual Tuning Manual Tuning Manual Tuning Manual Tuning ◄ ► Programme Edit Programme Edit System Band V/UHF...
  • Page 41 WATCHING TV / PROGRAMME CONTROL SETUP SETUP Move Move Auto Tuning Auto Tuning Manual Tuning Manual Tuning Manual Tuning Manual Tuning Storage Programme Edit Programme Edit System Band V/UHF Channel Fine ◄ ► Search ◄ ► Name C 02 Store Close ■...

  • Page 42: Programme Edit

    PROGRAMME EDIT When a programme number is skipped, it means that you will be unable to select it using P button during TV viewing. If you wish to select the skipped programme, directly enter the programme number with the NUMBER buttons or select it in the Programme edit menu.
  • Page 43 WATCHING TV / PROGRAMME CONTROL This function enables you to delete or skip the stored programmes. You can also move some channels and use other programme numbers. ■ Deleting a programme The selected programme is deleted, all the • Select a programme number to be deleted. following programmes are shifted up one.

  • Page 44: Selecting The Programme List

    SELECTING THE PROGRAMME LIST You can check which programmes are stored in the memory by displaying the programme list. Programme List 1 C 01 2 C 05 3 BLN 2 Exit • You may find some blue programmes. These ■ Displaying programme LIST have been set up to be skipped by auto pro- gramming or in the programme edit mode.

  • Page 45: Favourite Programme Setup

    WATCHING TV / PROGRAMME CONTROL FAVOURITE PROGRAMME SETUP ■ Selecting favourite programme Favorite programmes is a convenient feature that lets you quickly scan up to programmes of your choice without having to wait for the TV to scan through all the in-between programmes. Q.

  • Page 46: Input List

    INPUT LIST Only 26/32LK3** Component HDMI3 HDMI2 HDMI1 Except 22LK3** Only 32/42LK4**, 32LV2*** INPUT Select the input source. • TV : Select it when watching the TV. • AV : Select it when watching the VCR or external equipment. • Component : Select it when using DVD or Digital set-top box depends on connector. •...

  • Page 47: Input Label

    WATCHING TV / PROGRAMME CONTROL INPUT LABEL Selects a label for each input source. OPTION OPTION Move Move ◄ ► Menu Language : English Menu Language : English Only 26/32LK3** Input Label Input Label Input Label Input Label Component SIMPLINK : On SIMPLINK : On...

  • Page 48: Simplink

    SIMPLINK This function operates only with devices with the SIMPLINK logo. Please check the SIMPLINK logo. The product might not function properly when using it with other products with HDMI-CEC function. This allows you to control and play other AV devices connected to the display through HDMI cable with- out additional cables and settings.
  • Page 49 WATCHING TV / PROGRAMME CONTROL SIMPLINK FUNCTIONS Disc playback Control connected AV devices by pressing the /＜ / ＞, OK, ►, ▀ , l l, ◄◄ and ►► buttons. Direct Play After connecting AV devices to the TV, you can directly control the devices and play media without additional settings. Select AV device Enables you to select one of the AV devices connected to the TV and operate it.
  • Page 50 SIMPLINK MENU Press the button and then OK button to select the desired SIMPLINK source. Selected Device When device is not connected (displayed in gray) When a device is connected (displayed in bright colour) ► TV viewing : Switch to the previous TV programme regardless of the current mode. DISC playback : Select and play connected discs.

  • Page 51: Av Mode

    WATCHING TV / PROGRAMME CONTROL AV MODE You can select the optimal images and sounds when connecting AV devices to external input. Disables the AV MODE. Cinema Optimizes video and audio for watching movies. Sport Optimizes video and audio for watching sports events. Game Optimizes video and audio for playing games.

  • Page 52: Initializing (Reset To Original Factory Settings)

    INITIALIZING (RESET TO ORIGINAL FACTORY SETTINGS) Use to quickly reset all the menu options to their original factory preset values. This function deletes all TV programmes. When the Factory Reset is completed, you must restart the Initializing setup. OPTION OPTION Move Move Input Label...

  • Page 53: Key Lock

    WATCHING TV / PROGRAMME CONTROL KEY LOCK The TV can be set so that the remote control is required to control it. This feature can be used to prevent unauthorized viewing. OPTION OPTION Move Move Menu Language : English Menu Language : English Input Label Input Label...

  • Page 54: To Use A Usb Device

    /DVI IN VIDEO AUDIO TO USE A USB DEVICE COMPONENT IN RS-232C IN USB IN (CONTROL) SERVICE ONLY WHEN CONNECTING A USB DEVICE AUDIO IN (RGB/DVI) When you connect a USB device, this pop up menu is displayed, automatically. RGB IN (PC) VIDEO AUDIO /MONO...
  • Page 55 TO USE A USB DEVICE PRECAUTIONS WHEN USING THE USB DEVICE ► Only a USB storage device is recognizable. ► If the USB storage device is connected through a USB hub, the device is not recognizable. ► A USB storage device using an automatic recognition programme may not be recognized. ►...

  • Page 56: Photo List

    PHOTO LIST You can view photo files on USB storage device. The On Screen Display may be different from your TV. Images are an example to assist with the TV operation. When you are watching the photo by the Photo List function, you can not change the picture mode. PHOTO(*.JPEG) supporting file Baseline: Max 4800 x no limit Min 64 X 64...
  • Page 57 TO USE A USB DEVICE PHOTO SELECTION AND POPUP MENU PHOTO LIST Page 2/3 No Marked Drive 1 Up Folder KR103 09/10/2008 JMJ001 KR101 09/10/2008 KR104 09/10/2008 KR102 09/10/2008 KR105 09/10/2008 JMJ001 09/10/2008 JMJ005 09/10/2008 JMJ002 09/10/2008 JMJ006 09/10/2008 1366 768, 125KB JMJ003 09/10/2008...
  • Page 58 SET UP THE MENU IN FULL-SIZED SCREEN You can change the settings to display photos stored on a USB device, on a full-sized screen. Detailed operations are available on full-sized photo view screen. PHOTO LIST Page 2/3 No Marked Drive 1 Up Folder KR103 09/10/2008...
  • Page 59 TO USE A USB DEVICE Select the Slideshow , BGM, (Rotate), Delete or Hide. button to select the previous or next • photo. 1/17 1/17 button to select and control the menu • Slideshow Option Delete Hide on the full-sized screen. ►...

  • Page 60: Music List

    MUSIC LIST Purchased music files(*.MP3) may contain copyright restrictions. Playback of these files may not be supported by this model. Music file on your USB device can be played by this unit. The On Screen Display may be different from your TV. Images are an example to assist with the TV operation.
  • Page 61 TO USE A USB DEVICE MUSIC SELECTION AND POPUP MENU As shown, up to 6 music titles are listed per page. MUSIC LIST Page 2/3 No Marked Music Duration Title Up Folder 01:34 00:00/01:34 03:23 Up Folder 04:28 ► Play (During stop) : Play the selected music Navigation OPTION Page Change...
  • Page 62 ■ If you don't press any button for a while during the playing, the play information box (as shown in the below) will float as a screen saver. ■ The ‘Screen Saver’? Screen saver is to prevent screen pixel damage due to an fixed image remaining on the screen for a extended period of time.

  • Page 63: Movie List

    TO USE A USB DEVICE MOVIE LIST The movie list is activated once USB is detected. It is used when playing movie files on TV. Displays the movies in the USB folder and supports Play. Allows playback of all movies in the folder and user desired files. Editing such as delete and add is not allowed.
  • Page 64 SCREEN COMPONENTS Select Movie List. Select USB. Moves to upper level folder Current page/Total pages MOVIE LIST Total number of marked Page 2/3 No Marked movie title movie Title Duration Corresponding buttons on Up Folder the remote control 640x480, 720KB Up Folder Navigation OPTION...
  • Page 65 TO USE A USB DEVICE MOVIE SELECTION AND POPUP MENU MOVIE LIST Page 2/3 No Marked movie Title Duration Up Folder 1:340, 120KB Up Folder Navigation OPTION Page Change Mark Exit MARK ► Play : Play the selected movie titles. DivX Play is executed while screen changes.
  • Page 66 DIVX AUDIO LANGUAGE & SUBTITLE LANGUAGE Subtitle Language Support Language French, Spanish, Catalan Basque, Portuguese, Italian, Albanian, Rhaeto- Picture Size ◄ Full Screen ► Latin1 Romanic, Dutch, German, Danish, Swedish, Norwegian, Finnish, Faroese, Icelandic, Irish, Scottish, English Subtitle Language - - - Latin2 Czech, Hungarian, Ploish, Romanian, Croatian, Slovak, Slovenian, Sorvian Audio Language...

  • Page 67: Divx Registration Code

    TO USE A USB DEVICE DIVX REGISTRATION CODE Confirm the DivX registration code number of the TV. Using the registration number, movies can be rented or purchased at www.divx.com/vod. With a DivX registration code from other TV, playback of rented or purchased DivX file is not allowed. (Only DivX files matched with the registration code of the purchased TV are playable.) Move Move...

  • Page 68: Deactivation

    DEACTIVATION Delete the existing authentication information to receive a new DivX user authentication for TV. Once this function is executed, a DivX user authentication is required again to see DivX DRM files. Move Move Photo List Photo List Music List Music List Movie List Movie List...

  • Page 69: Picture Control

    PICTURE CONTROL PICTURE SIZE (ASPECT RATIO) CONTROL You can watch the screen in various picture formats; 16:9, Just Scan, Original, 4:3, 14:9, Zoom and Cinema Zoom1. If a fixed image is displayed on the screen for a long time, that fixed image may become imprinted on the screen and remain visible.
  • Page 70 • 14:9 • Cinema Zoom1 You can view a picture format of 14:9 or a general TV Choose Cinema Zoom1 when you want to programme in the 14:9 mode. The 14:9 screen is viewed enlarge the picture in correct proportion. in the same way as in 4:3, but is magnified to the left and Note:When enlarging or reducing the picture, right.

  • Page 71: Energy Saving

    PICTURE CONTROL ENERGY SAVING It reduces the plasma display’s power consumption. The default factory setting complies with the Energy Star requirements and is adjusted to the comfort- able level to be viewed at home. You can increase the brightness of your screen by adjusting the Energy Saving level or by setting the Picture Mode.

  • Page 72: Preset Picture Settings

    PRESET PICTURE SETTINGS PICTURE MODE-PRESET Vivid Strengthen the contrast, brightness, colour and sharpness for vivid picture. Standard The most general screen display status. Natural The most natural screen display status. Cinema Optimizes video for watching movies. Sport Optimizes video for watching sports events. Game Optimizes video for playing games.

  • Page 73: Manual Picture Adjustment

    PICTURE CONTROL MANUAL PICTURE ADJUSTMENT PICTURE MODE-USER OPTION Backlight To control the brightness of the screen, adjust the brightness of LCD panel. Adjusting the backlight when setting the brightness of the set is recommended. Contrast Adjusts the signal level between black and white in the picture. Brightness Adjusts the base level of the signal in the picture.

  • Page 74: Picture Improvement Technology

    PICTURE IMPROVEMENT TECHNOLOGY You can calibrate the screen for each Picture Mode or set the video value according to the special video screen. you can set the video value differently for each input. To reset to the factory default screen after making adjustment to each video mode, execute the “Picture Reset”...

  • Page 75: Expert Picture Control

    PICTURE CONTROL EXPERT PICTURE CONTROL By segmenting categories, Expert1 and Expert2 provide more categories which users can set as they see fit, offering the optimal picture quality for users. As the detail item for video quality experts to adjust the video precisely using specific videos, this may not be effective for general videos.
  • Page 76 ■ This feature is not available for all models. Colour Temperature ■ Choose one of three automatic colour adjustments. Set to warm to enhance hotter colours such as red, or set to cool to make picture bluish (Warm/Medium/Cool) ■ Adjusts the contrast to keep it at the best level according to the brightness of the- Dynamic Contrast screen.
  • Page 77 PICTURE CONTROL • Standard : Mode to reproduce original colour according to the standard of Colour Gamut input signal independent of the display characteristics. (Wide/Standard) • Wide: Mode to use and set the rich colour area of the display. Edge Enhancer ■...

  • Page 78: Picture Reset

    PICTURE RESET Settings of the selected picture modes return to the default factory settings. PICTURE PICTURE Move Move • Contrast • Contrast • Brightness • Brightness • Sharpness • Colour • Colour • Tint Resetting video configuration..• Tint •Colour Temp •...

  • Page 79: Power Indicator

    PICTURE CONTROL POWER INDICATOR Adjust the power/standby indicator light on the front of the TV. Standby Light Determines whether to set the indicator light on the front of the TV to On or Of f in standby mode. Power Light Determines whether to set the indicator light on the front of the TV to On or Of f when the power turns on.

  • Page 80: Demo Mode

    DEMO MODE It is not possible to use Demo Mode in Home Use mode. In Store Demo, Demo Mode is automatically set to On. Once Demo Mode is set to Off in Store Demo, Demo Mode does not run and only the screen is reset. The screen is reset automatically after 5 minutes in Demo Mode.

  • Page 81: Mode Setting

    PICTURE CONTROL MODE SETTING We recommend setting the TV to “Home Use ” mode for the best picture in your home environment. “Store Demo ” mode is an optimal setting for displaying at stores. Selecting the environment. Selecting the environment. OPTION Move Chose the setting mode you want...

  • Page 82: Sound & Language Control

    SOUND & LANGUAGE CONTROL AUTO VOLUME LEVELER Auto Volume automatically remains on the same level of volume if you change programmes. Because each broadcasting station has its own signal conditions, volume adjustment may be needed every time the channel is changed. This feature allows users to enjoy stable volume levels by making automatic adjustments for each programme.

  • Page 83: Clear Voice Ii

    SOUND & LANGUAGE CONTROL CLEAR VOICE II By differentiating the human sound range from others, it helps users listen to human voices better. AUDIO AUDIO Move Move Auto Volume : Off Auto Volume : Off Clear Voice II : Off Clear Voice II : Off Clear Voice II...

  • Page 84: Preset Sound Settings-Sound Mode

    PRESET SOUND SETTINGS-SOUND MODE You can select your preferred sound setting; Standard, Music, Cinema, Sport or Game and you can also adjust the Treble, Bass. Sound Mode lets you enjoy the best sound without any Special adjustment as the TV sets the appro- priate sound options based on the programme content.

  • Page 85: Sound Setting Adjustment -User Mode

    SOUND & LANGUAGE CONTROL SOUND SETTING ADJUSTMENT -USER MODE Adjusting the audio equalizer AUDIO AUDIO Move Move Auto Volume : Off Auto Volume : Off Clear Voice II : Off Clear Voice II : Off • Level • Level Balance Balance Sound Mode : Standard(User)

  • Page 86: Infinite Surround

    Select AUDIO. Select Infinite Surround. Select On or Off. • Infinite Surround : Infinite Surround is a patented LG proprietary sound processing technology that strives immersive 5.1 sur- round sound impression with front two loud- speakers. • Press the Home/EXIT button to return to normal TV viewing.

  • Page 87: Balance

    SOUND & LANGUAGE CONTROL BALANCE You can adjust the sound balance of the speakers to preferred levels. AUDIO AUDIO Move Move Auto Volume : Off Auto Volume : Off Clear Voice II : Off Clear Voice II : Off • Level •...

  • Page 88: Tv Speakers On/ Off Setup

    TV SPEAKERS ON/ OFF SETUP You can adjust the TV internal speaker status. In AV, COMPONENT, RGB and HDMI with HDMI to DVI cable, the TV speaker can be operational even when there is no video signal. If you wish to use an external Hi-Fi system, turn off the TV’s internal speakers. AUDIO AUDIO Move...

  • Page 89: Audio Reset

    SOUND & LANGUAGE CONTROL AUDIO RESET Settings of the selected Sound Mode return to the default factory settings. AUDIO AUDIO Move Move : Level : Level Balance Balance Sound Mode : Standard Sound Mode : Standard • Infinite Surround : Off •...

  • Page 90: I/Ii

    I/II STEREO/DUAL RECEPTION When a programme is selected, the sound information for the station appears with the programme number and station name. Select Audio. Select the sound output. Broadcast On Screen Display Mono MONO Stereo STEREO Dual DUAL I, DUAL II, DUAL I+II ■...

  • Page 91: Nicam Reception

    SOUND & LANGUAGE CONTROL NICAM RECEPTION If the TV is equipped with a receiver for NICAM reception, high quality NICAM (Near Instantaneous Companding Audio Multiplex) digital sound can be received. Sound output can be selected according to the type of broadcast received. When NICAM mono is received, you can select NICAM MONO or FM MONO.

  • Page 92: On-Screen Menu Language Selection

    ON-SCREEN MENU LANGUAGE SELECTION The installation guide menu appears on the TV screen when it is switched on for the first time. S elect your desired language. * If you want to change Language/ Country selection Select OPTION. Select Menu Language. Select your desired language.

  • Page 93: Time Setting

    TIME SETTING CLOCK SETUP You must set the time correctly before using on/off timer function. If current time setting is erased by a power failure or the TV is unplugged, reset the clock. TIME TIME Move Move Clock Clock Clock Clock Hour Off Time...

  • Page 94: Auto On/Off Time Setting

    AUTO ON/OFF TIME SETTING The Off time function automatically switches the TV to standby at a preset time. Two hours after the TV is switched on by the on time function it will automatically switch back to stand- by mode unless a button has been pressed. The Off time function overrides the On timer function if both are set to the same time.

  • Page 95: Teletext

    TELETEXT This feature is not available in all countries. Teletext is a free service broadcast by most TV stations which gives up-to- the-minute information on news, weather, television programmes, share prices and many other topics. The teletext decoder of this TV can support the SIMPLE, TOP and FASTEXT systems.

  • Page 96: Fastext

    FASTEXT The teletext pages are colour coded along the bottom of the screen and are selected by pressing the corresponding coloured button. ■ Page selection Press the T.OPT button and then use button to select menu. Display the index page. You can select the pages which are colour coded along the bottom line with corresponding coloured buttons.

  • Page 97: Appendix

    APPENDIX TROUBLESHOOTING The TV does not operate properly. ■ Check to see if there is any object between the TV and the remote control causing an obstruction. Ensure you are pointing the remote control directly The remote control at the TV. does not work ■...
  • Page 98 The audio function does not work. ■ Check whether the TV is switched on. ■ Press the + or - button. Picture OK & No ■ Sound muted? Press MUTE button. sound ■ Try another channel. The problem may be with the broadcast. ■...

  • Page 99: Maintenance

    APPENDIX MAINTENANCE Early malfunctions can be prevented. Careful and regular cleaning can prolong the life of your new TV. Caution: Be sure to switch the power off and unplug the power cord before you begin any cleaning. CLEANING THE SCREEN A good way to keep the dust off your screen for a while is to wet a soft cloth in a mixture of luke- warm water and a little fabric softener or dish washing detergent.

  • Page 100: Product Specifications

    PRODUCT SPECIFICATIONS 22LK3** 26LK3** 22LK310-TA / 22LK310-TG 26LK310-TA / 26LK310-TG MODELS 22LK311-TB / 22LK311-TH 26LK311-TB / 26LK311-TH 22LK310Y-TA 26LK310Y-TA / 26LK310Y-TG Dimensions with stand 526.0 mm x 377.0 mm x 165.0 mm 663.0 mm x 484.0 x mm 207.0 mm (Width x Height x Depth) without stand...
  • Page 101 APPENDIX 22LV2*** 19LV2*** MODELS 19LV2130-TD 22LV2130-TD / 22LV2130-TK 19LV213Y-TD 22LV213Y-TD Dimensions with stand 455.2 mm x 355.0 mm x 145.0 mm 526.0 mm x 396.0 mm x 145.0 mm (Width x Height x Depth) without stand 455.2 mm x 313.1 mm x 40.9mm 526.0 mm x 352.0 mm x 40.9 mm with stand 2.7 kg...

  • Page 102: Ir Codes

    IR CODES *This feature is not available for all models. Code (Hexa) Function Note POWER R/C BUTTON Energy Saving R/C BUTTON INPUT R/C BUTTON R/C BUTTON Q.MENU R/C BUTTON Home R/C BUTTON R/C BUTTON Up ( ) R/C BUTTON Down ( ) R/C BUTTON Left ( ) R/C BUTTON...

  • Page 103: External Control Device Setup

    AUDIO DVI-PC OUTPUT APPENDIX EXTERNAL CONTROL DEVICE SETUP RS-232C SETUP Connect the RS-232C (serial port) input jack to an external control device (such as a computer or an A/V control system) to control the product’s func- tions externally. Connect the serial port of the control device to the RS-232C jack on the product back panel.
  • Page 104 SET ID Use this function to specify a set ID number. p.85 Refer to ‘Real Data Mapping’. ► OPTION OPTION Move Move Menu Language : English Menu Language : English Input Label Input Label SIMPLINK : On SIMPLINK : On Key Lock : Off Key Lock...
  • Page 105 APPENDIX COMMUNICATION PARAMETERS ■ Baud rate : 9600 bps ( UART ) ■ Stop bit : 1 bit ■ Data length : 8 bits ■ Communication code : ASCII code ■ Parity : None ■ Use a crossed (reverse) cable. Command Reference List COMMAND COMMAND...
  • Page 106 01. Power (Command: k a) 04. Volume Mute (Command: k e) ► To control Power On/Off of the TV. ► To control volume mute on/off. You can also adjust mute using the MUTE button Transmission on remote control. [k][a][ ][Set ID][ ][Data][Cr] Transmission Data 00 : Power Off 01 : Power On...
  • Page 107 APPENDIX 14. Colour Temperature (Command: k u) 09. Tint (Command: k j) ► To adjust the screen tint. ► To adjust colour temperature. You can also adjust tint in the PICTURE menu. You can also adjust Colour Temperature in the Transmission PICTURE menu.
  • Page 108 23. Key (Command: m c) 18. Control Back Light (Command: m g ) ► To send IR remote key code. ► To Control the back light. Transmission Transmission [m][g][ ][Set ID][ ][Data][Cr] [m][c][ ][Set ID][ ][Data][Cr] Data : data Min: 00 to Max: 64 Data: Key code - Refer to page 79. (* transmit by Hexadecimal code) Acknowledgement Acknowledgement...
  • Page 110 PT. LG ELECTRONICS INDONESIA Kawasan Industri MM2100 Blok G Cikarang Barat, Bekasi, Jawa Barat 17520 INDONESIA HDMI, logo HDMI dan High-Definition Multimedia Interface adalah merek dagang atau merek dagang terdaftar dari HDMI Licensing LLC. TANDA PENDAF TARAN Catat nomor model dan nomor seri yang tertera PETUNJUK PENGGUNAAN (MANUAL) DAN KARTU JAMINAN/GARANSI PURNA JUAL pada label di penutup belakang.
