  • Page 1 23.8" LCD Monitor ACER VG240Y Service Service Service Acer Monitor VG240Y LIFECYCLE EXTENSION GUIDE...

  • Page 2: Table Of Contents

    Contents Important Safety Notice............................ 3   1. Exploded view diagram with list of items ...................... 4   2. Mechanical Instruction ..........................5   3. Firmware Upgrade Process ........................17   4. Writing EDID Process ..........................23   5. FRU (Field Replaceable Unit) List ......................30   6.

  • Page 3: Important Safety Notice

    Important Safety Notice Proper service and repair is important to the safe, reliable operation of all ACER Company Equipment. The service procedures recommended by ACER and described in this service manual are effective methods of performing service operations. Some of these service operations require the use of tools specially designed for the purpose.

  • Page 4: Exploded View Diagram With List Of Items

    1. Exploded view diagram with list of items Item Description TPV Part No. ACER Part No. LED BOARD LEPCLQA2 55.TCCM2.004 PANEL 750GBK238HM2B6N000 KL.2380E.011 POWER BOARD PLPCHE541KVG4 MAIN BOARD CBPRITMC0Q6 KEY BOARD KEPCLQA6 55.TCCM2.003 CABLE 30P-30P 395G179M30B8370000 450MM(MB TO PANEL)

  • Page 5: Mechanical Instruction

    2. Mechanical Instruction Tools Required List the type and size of the tools that would typically can be used to disassemble the product to a point where components and materials requiring selective treatment can be removed. Tool Description: − Screwdriver (Phillip-head, Hexagonal head) −...
  • Page 6 2.1 Disassembly Procedures: S1. Push the button to remove the stand –base ASS’Y and unscrew the screw on rear cover.
  • Page 7 S2. Remove the rear cover. Use a tool (like picture using) to open all latches. (Be careful the position of the key board.) S3. Disconnect the cable (main board to Key board / LED board / Key board) and remove the screws to remove the key board from the rear cover.
  • Page 8 S4. Tear up all tapes and disconnect the LVDS cable (main board to panel), the cables (power board to panel and the main board to key board). Remove the LED board and the Speakers and unscrew the screws.
  • Page 9 S5. Remove the screws to separate the panel and the Middle Frame and the DECO BEZEL.
  • Page 10 S6. Unscrew the screws of the main board remove the mylar. Then unscrew the screws of the power board and main board to remove them from mainframe.
  • Page 11 S7. Remove the main board and power board. Disconnect the cables.
  • Page 12 2.2 Assembly Procedures: S1 Prepare a main board, a power board and some essential cables. Connect every cable as the below picture. S2. Use a Philips-head screwdriver to tighten the screws till the power board and main board with shield are firmly attached.
  • Page 13 S3. Assemble the MIDDLE FRAME, DECO bezel and the panel. Use a screwdriver to tighten the screws.
  • Page 14 S4. Connect cables (mainboard to panel, mainboard to speakers and the power board to panel). Assemble the LED board and the speakers and screw the two screws. S5. Paste the tapes.
  • Page 15 S6. Prepare a rear cover and a key board and use the screws to lock the key board. S7. Connect the pin (LED board / Key board) and the pin (Key board to mainboard). Use the screws to lock the rear cover.
  • Page 16 S8. Assemble the stand and base ASS’Y.

  • Page 17: Firmware Upgrade Process

    3. Firmware Upgrade Process 1. Materials list and connection ISP JIG: 715GT089-C VGA cable TPV P/N: 089G728 GAA DB Monitor USB cable TPV P/N: 089G1758 X USB port driver ISP tool: New F/W...
  • Page 18 2.Connection 3.Install USB driver. 3.1. When insert the USB cable to PC USB port, will pop up a Hardware Wizard to help you install the USB driver if you use this ISP board first time.it can auto install success by itself Remark: The USB driver files path: D:\FTC100103(Mstar)\FTCUSB.INF After installation the USB serial port driver, please check the port.
  • Page 19 4. Install RTD tool. Note: If the F/W Upgrade use the same ISP tool as the EDID writing, you must close the EDID writing tool before running the F/W Upgrade tool. 4.1. double- clicks the icon to run it. Note: Must to install driver firstly 4.2.
  • Page 20 4.4 Close the “ISP Option” window and click the “BigBin” to load the correct F/W. 4.5 Click to start programming.
  • Page 21 4.6 After about 20 minutes, there will pop up message as below figure which promotes the upgrade successful. 5. Check the FW version after upgrade. 5.1. The way to open factory menu. (1) Connect VGA source to monitor and turn it on. (2) The way to factory menu: Pressing the hot key button and DC on, when the screen lights, release the key and press the left botton again to open the menu with “F”...
  • Page 22 Check this F/W version. (3)Do “Auto Color” in factory mode. 5.2. Do factory reset in user menu. (1)Restart the monitor after open factory menu. And then open the user menu. (2)Factory reset will turn off “Burn in” mode which screen color switches among red, green, blue and black.

  • Page 23: Writing Edid Process

    4. Writing EDID Process 1. Materials list VGA cable USB cable TPV P/N: 089G728 GAA DB TPV P/N: 089G1758 X USB port driver ISP JIG: 715GT089-B Monitor ISP tool EDID...
  • Page 24 4.1. Change the EDID files name as below rule. Analog EDID WA.dat HDMI EDID WH.dat HDMI2 EDID WH2.dat 4.2. Copy these files to one folder named as Acer VG240Y which must contains “config.ini” file. 4.3. Copy Acer VG240Y to DDC folder and put DDC and ISP tool together.
  • Page 25 4.4 Setting the Config as below. 5. Run the ISP tool Note: If the F/W Upgrade use the same ISP tool as the EDID writing, you must close the F/W Upgrade tool before running the EDID writing tool. 5.1. Double-click the icon to open the tool.
  • Page 26 5.2. Select the EDID folder. 5.3. Load EDID successful.
  • Page 27 5.4 Tick the “Only connect VGA”. 5.5 Set the OtherSetting as below.
  • Page 28 5.6 Type in the date and the 22 digit S/N and “Debug Information”. 5.7. Start to writing. Click “write EDID” to start writing. When The green “PASS” appear, the process is finished.
  • Page 29 5.8 After writing the EDID pass, you must read the EDID to ensure the EDID data had been write into the monitor. Choose one of the port to read. 1. If it appears all “00” when read the EDID data,you need reconnect the ISP tool or install the the driver of the ISP tool again.

  • Page 30: Fru (Field Replaceable Unit) List

    5. FRU (Field Replaceable Unit) List This chapter gives you the FRU (Field Replaceable Unit) listing in global configurations of ACER VG240Y Refer to this chapter whenever ordering for parts to repair or for RMA (Return Merchandise Authorization). Please note that WHEN ORDERING FRU P ARTS, you should c heck the most up-to-date information available on your regional web or channel.
  • Page 31 CABLE 30P-30P 450MM(MB TO 395G179M30B8370000 PANEL) CABLE 4P-2P+2P 600/80MM(MB TO 395GH20004XM150000 SPEAKER) CABLE 6P-6P 450MM(MB TO 395GH20006XM208000 50.TCCM2.003 KEY BOARD) CABLE 6P-6P 200MM(PB TO 395GH20006XM253000 50.TCMM2.003 PANEL) BEZEL ASSY W 705GQHCS034441 60.TCCM2.001 LOGO MIDDLE FRAME Q34G8552AEM02S0100 60.TCCM2.002 REAR COVER Q34G8553AEM05S0130...
  • Page 32 FUNCTION KEY Q33G0890AEM01S0100 60.TCCM2.006 Joystick BUTTON A33G2238AEM01L0100 60.TCCM2.007 STAND HINGE 705GQHCS034496 ASSY BASE ASSY 705GQHCS034497 INSULATING- Q52G18016730HF0ADG SHEET MAINFRAME Q15G320110180100FJ...
  • Page 33 D-SUB CABLE 089G 728CAA 2A 50.LZJM2.003 1800 HDMI CABLE 389G1848GAA502 50.T27M2.010 1800 AC POWER CORD 1800 for 389G404A18NISG 27.T1BM2.001 Europe AUDIO CABLE 389G017356G53R 50.LXPM2.012 1800...

  • Page 34: Trouble Shooting Instructions

    6. Trouble shooting instructions...
