- Page 1 Tumble dryer WTN83202GB [en] User manual and installation instructions...
-
Page 2: Table Of Contents
Further information and explanations are available online: Table of contents 1 Safety ........... 4 9 Programmes ...... 24 1.1 General information.... 4 9.1 Automatic programmes... 24 1.2 Intended use...... 4 9.2 Timed programmes .... 25 1.3 Restriction on user group.. 4 10 Accessories...... 27 1.4 Safe installation ...... - Page 3 15 Cleaning and servicing ... 34 15.1 Tips on cleaning and care .. 34 15.2 Base unit ....... 34 15.3 Moisture sensor..... 36 16 Troubleshooting...... 38 17 Transportation, storage and disposal ........ 42 17.1 Preparing the appliance for transportation ...... 42 17.2 Disposing of old appliance ... 42 18 Customer Service.... 43 18.1 Product number (E-Nr.) and production number (FD)..
-
Page 4: Safety
en Safety 1 Safety Observe the following safety instructions. 1.1 General information ¡ Read this instruction manual carefully. ¡ Keep the instruction manual and the product information safe for future reference or for the next owner. ¡ Do not connect the appliance if it has been damaged in transit. 1.2 Intended use Only use this appliance: ¡... -
Page 5: Safe Installation
Safety en 1.4 Safe installation WARNING ‒ Risk of electric shock! Incorrect installation is dangerous. ▶ Connect and operate the appliance only in accordance with the specifications on the rating plate. ▶ Connect the appliance to a power supply with alternating cur- rent only via a properly installed socket with earthing. ▶... - Page 6 en Safety ▶ If the power cord is too short and a longer one is not available, please contact an electrician to have the domestic installation adapted. WARNING ‒ Risk of injury! The high weight of the appliance may result in injury when lifted. ▶...
-
Page 7: Safe Use
Safety en CAUTION ‒ Risk of cutting! Touching sharp edges on the appliance may lead to cuts. ▶ Do not touch the sharp edges on the appliance. ▶ Wear protective gloves when installing and transporting the ap- pliance. 1.5 Safe use WARNING ‒ Risk of electric shock! If the appliance or the power cord is damaged, this is dangerous. - Page 8 en Safety WARNING ‒ Risk of explosion! If there is coal dust or flour in the air around the appliance, this may cause an explosion. ▶ Keep the area around the appliance clean during operation. WARNING ‒ Risk of poisoning! Condensation water from this appliance is not suitable for drinking and may be contaminated with fluff.
-
Page 9: Safe Cleaning And Maintenance
Safety en ▶ If drying is interrupted early, remove the laundry immediately and spread it out. CAUTION ‒ Risk of injury! The covering plate may break if you stand on or climb onto the appliance. ▶ Do not stand on or climb onto the appliance. The appliance may tip over if you sit on or lean against the open door. - Page 10 en Safety ▶ Do not use steam- or high-pressure cleaners, hoses or sprays to clean the appliance. WARNING ‒ Risk of injury! The use of non-original spare parts and non-original accessories is dangerous. ▶ Only use the manufacturer's original spare parts and original ac- cessories.
-
Page 11: Preventing Material Damage
Preventing material damage en Clean the appliance with nothing ▶ Preventing material damage 2 Preventing material but water and a soft, damp cloth. Remove all detergent residue, damage ▶ spray residue or other residues im- mediately if they come into contact Preventing material damage ATTENTION! with the appliance. -
Page 12: Energy Saving Mode
en Installation and connection Check the appliance for visible After drying, clean the fluff filter damage. → Page 29. Open the door. a If the fluff filter is dirty, this reduces Remove any accessories from the the air flow in the appliance, ex- drum. -
Page 13: Requirements For The Install- Ation Location
Installation and connection en 4.3 Requirements for the in- Installation loca- Requirements tion stallation location In a washer-dryer Only use the ori- ATTENTION! stack ginal connection If the appliance is tilted at an angle set from the greater than 40°, residual water may dryer manufac- leak out of the appliance and cause turer when set-... - Page 14 en Installation and connection container. Use the water outlet hose Pull out the condensation hose to drain away excess condensation from the connecting piece. directly into the waste water system. Notes ¡ Operate this appliance using the water outlet hose provided. → "Connecting the water drain hose", Page 14 If you connect the water outlet...
- Page 15 Installation and connection en Push the water drain hose as far Water outlet connection types as it will go into the connecting ATTENTION! piece. In the event of a blocked or covered outlet, accumulated wastewater can flow back into the appliance. Before operating the appliance, en- ▶...
-
Page 16: Aligning The Appliance
en Installation and connection and secure it us- ing fixing mater- ial. Secure the elbow to the gully. 4.5 Aligning the appliance In order to reduce vibrations and noises, align the appliance correctly. To align the appliance, turn the ap- ▶ pliance feet. Check that the appli- ance is level using a spirit level. -
Page 17: Familiarising Yourself With Your Appliance
Familiarising yourself with your appliance en Familiarising yourself with your appliance 5 Familiarising yourself with your appliance Familiarising yourself with your appliance 5.1 Appliance You can find an overview of the parts of your appliance here. On certain models, specific details such as the colour and shape may differ from those pictured. -
Page 18: Control Panel
en Familiarising yourself with your appliance 5.2 Control panel You can use the control panel to configure all functions of your appliance and to obtain information about the operating status. Programmes → Page 24 Programme selector → Page 28 Display → Page 19 Buttons → Page 21... -
Page 19: Display
Display en Display 6 Display The display shows the current settings, options or relevant information. Display Display Description 0:40 Expected programme duration or programme time re- maining in hours and minutes. 1:25 The timed programme is set. → "Timed programmes", Page 25 Program end time → "Buttons", Page 22 ¡... - Page 20 en Display Display Description The cooling process cools the laundry for a few minutes while the drum is rotating, in order to avoid damage to the laundry. The cooling process can be cancelled by open- ing the door. Note: Do not change the set programme. Drying Programme status Dryness level: Iron Dry...
-
Page 21: Buttons
Buttons en Buttons 7 Buttons Below is an overview of the buttons and their setting options. Buttons Button Selection Description Start/Reload ¡ Start Start, cancel or pause the programme. ¡ Cancel ¡ Pause 3 sec. ¡ Activate Activate or deactivate the childproof lock. ¡... - Page 22 en Buttons Button Selection Description Finish in Up to 24 hours Set the programme end time. The programme duration is already included in the set number of hours. Once the programme has started, the pro- gramme duration is dis- played. Program Duration Multiple selection Set the programme dura- tion for timed pro-...
-
Page 23: Dryness Level
Dryness level en Dryness level 8 Dryness level Each automatic programme has a specified dryness level. The dryness level Dryness level defines how dry or damp your laundry is after the programme ends. Programme Laundry Drying result Cottons Cup- Multi-layered, thick laundry The laundry is dry. -
Page 24: Programmes
en Programmes Programmes 9 Programmes You can dry your fabrics using either an automatic programme or a timed pro- Programmes gramme. 9.1 Automatic programmes Automatic programmes are pro- Tips grammes in which humidity sensors ¡ Select the dryness level according measure the residual moisture in the to the type of fabric or the desired laundry during the drying cycle. -
Page 25: Timed Programmes
Programmes en Programme Description Max. load (kg) Easy Care Iron Dry Dry items made of synthetic materials or blended fabrics. The dryness level is not defined in this programme. → "Dryness level", Page 23 Mixed Load Dry items made of cotton and synthetics. Delicates Dry delicate items made of satin, synthet- ics or blended fabrics. - Page 26 en Programmes Programme Description Max. load (kg) Remove laundry once the programme has ended and allow it to dry. Timed Progr. Cold Fluff/loosen all fabric types except for wool and silk. This programme is suitable for fluffing dry laundry only. Also suitable for freshening up or airing dry clothing that has hardly been worn.
-
Page 27: Accessories
Accessories en Accessories 10 Accessories Use original accessories. These have Accessories been made especially for your appli- ance. Note: Some accessories are avail- able in other colours. Contact → "Customer Service", Page 43. Order number Connection kit To save space, stack the WTZ20410 appliance on a suitable washing machine of the same width and depth and that is from the... -
Page 28: Laundry
en Laundry Turn the programme selector and Laundry 11 Laundry set the required programme. → "Programmes", Page 24 Laundry If required, adjust the programme 11.1 Preparing the laundry settings. → "Adjusting the programme set- ATTENTION! tings", Page 28 Objects remaining in the laundry may damage the laundry and the drum. 12.3 Adjusting the pro- Remove all items from any pock- ▶... -
Page 29: Changing The Activated Programme End Time
Basic operation en a The display shows the programme Open the door. duration or the programme end Remove the laundry. time. → "Unloading the laundry", a After the programme has ended, Page 29 the display shows: "End" . 12.9 Unloading the laundry Note: If "Hot" appears, the appli- ance cools the laundry. - Page 30 en Basic operation Remove the fluff from the door. Open the fluff filter. Remove the fluff filter. Remove the fluff. Remove the fluff from the recess. Clean the fluff filter thoroughly un- der warm, running water and then dry it off. Ensure that no fluff falls into the air channel.
-
Page 31: Condensation Container
Basic operation en Close the fluff filter. Emptying the condensation container If the drying programme has finished or the display shows a notification while the appliance is in operation, empty the condensation container. Requirements ¡ The display shows the following after drying: "End" ¡... -
Page 32: Childproof Lock
en Childproof lock Inserting the condensation container Push the condensation container ▶ in as far as it will go. Childproof lock 13 Childproof lock Secure your appliance against being Childproof lock operated unintentionally using the controls. 13.1 Activating the childproof lock Press and hold the two 3 sec. -
Page 33: Basic Settings
Basic settings en Basic settings 14 Basic settings You can configure the basic settings for your appliance to meet your needs. Basic settings 14.1 Overview of the basic settings Basic setting Programme Value Description position End signal 0 (off) Set the volume of the signal at the 1 (quiet) end of the programme. -
Page 34: Changing The Basic Set- Tings
en Cleaning and servicing 14.2 Changing the basic set- nothing but water and a damp tings cloth. Set the programme selector to po- Remove all de- Fresh deposits sition 1. tergent residue, are easier to re- spray residue or move without other residues leaving any immediately. - Page 35 Cleaning and servicing en Open the lever for the heat ex- Clean the heat exchanger cover changer cover. under running water and dry it. Make sure that you remove all dirt Pull out the heat exchanger cover from the seal. by the handle. Pull out the heat exchanger hori- zontally.
-
Page 36: Moisture Sensor
en Cleaning and servicing Clean the opening with a soft, Insert the heat exchanger cover by damp cloth. the handle. Slide the heat exchanger in hori- Close the lever for the heat ex- zontally as far as it will go. changer. Ensure that the heat exchanger is Close the maintenance flap. - Page 37 Cleaning and servicing en ance changes the duration of the automatic programme depending on the residual moisture in the laundry. Cleaning the moisture sensor Over time, residue from limescale, detergents and care products can build up on the moisture sensor. Clean the moisture sensor regularly. ATTENTION! Hard or rough objects may damage the moisture sensor.
-
Page 38: Troubleshooting
en Troubleshooting Troubleshooting 16 Troubleshooting You can rectify minor faults on your appliance yourself. Read the troubleshoot- Troubleshooting ing information before contacting after-sales service. This will avoid unneces- sary costs. WARNING Risk of electric shock! Incorrect repairs are dangerous. Repairs to the appliance should only be carried out by trained specialist ▶... - Page 39 Troubleshooting en Fault Cause and troubleshooting Creasing. Remove the laundry from the drum as soon as the drying programme has finished. Spread the items of laundry for cooling. Unsuitable programme for the type of fabric. Set the suitable programme for the type of fabric. ▶...
- Page 40 en Troubleshooting Fault Cause and troubleshooting The programme does Start/Reload has not been pressed. not start. Press Start/Reload . ▶ No programme set. → "Setting a programme", Page 28. → "Starting the programme", Page 28. The length of the pro- The programme operation is optimised electronically. gramme changes dur- This may change the programme duration.
- Page 41 Troubleshooting en Fault Cause and troubleshooting The laundry is too Unsuitable programme for the type of fabric. damp. Set a timed programme for the subsequent drying. ▶ → "Programmes", Page 24 There has been a power cut. Check whether the lighting in your room or other ▶...
-
Page 42: Transportation, Storage And Disposal
en Transportation, storage and disposal 17.2 Disposing of old appli- Transportation, storage and disposal 17 Transportation, stor- ance age and disposal Valuable raw materials can be re- Transportation, storage and disposal used by recycling. 17.1 Preparing the appliance for transportation WARNING Risk of harm to health! Tip: The appliance may contain re- Children can lock themselves in the sidual water, which may drip out of it... -
Page 43: Customer Service
Customer Service en Customer Service 18 Customer Service Function-relevant genuine spare parts Customer Service according to the corresponding Eco- design Order can be obtained from Customer Service for a period of at least 10 years from the date on which your appliance was placed on the market within the European Eco- nomic Area. - Page 44 en Consumption values Consumption values 19 Consumption values The programme The actual values may deviate from Consumption values the indicated values depending on Cottons Cupboard Dry (denoted by the arrow symbol) is the type of fabric, composition of suitable for drying cotton laundry with laundry to be dried, residual moisture a normal dampness level, and is the in the fabric, set degree of dryness,...
-
Page 45: Technical Data
Technical data en Programme Final Load Spin Initial Pro- Energy mois- (kg) speed mois- gramm con- ture (rpm) ture e dura- sump- level level tion tion (h:min) (kWh/ cycle) Easy Care Cupboard 0:45 1.40 Easy Care Cupboard 0:54 1.71 You can find more information about Technical data 20 ... - Page 48 Expert advice for your Bosch home appliances, help with problems or a repair from Bosch experts. Find out everything about the many ways Bosch can support you: www.bosch-home.com/service Contact data of all countries are listed in the attached service direct- ory.
