OWNER'S MANUAL
VACUUM CLEANER
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
A9T-MAX
MFL71880919
Rev.00_011823
Copyright © 2023 LG Electronics Inc. All Rights Reserved.
www.lg.com

Advertisement

Table of Contents
loading

Related Manuals for LG A9T-MAX

Summary of Contents for LG A9T-MAX

  • Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH A9T-MAX www.lg.com MFL71880919 Rev.00_011823 Copyright © 2023 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    OPERATION Getting Started ....................19 Charging the Battery ..................21 Using the Steam Mop Nozzle .................22 Using the Nozzles and Tools................31 SMART FUNCTIONS Using LG ThinQ Application................35 Smart Diagnosis Function................37 MAINTENANCE Cleaning the Appliance ...................38 Cleaning the Nozzles ..................41 TROUBLESHOOTING Before Calling for Service................46...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk.
  • Page 4 If the appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, return it to an LG Electronics service centre. • Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners.
  • Page 5 SAFETY INSTRUCTIONS • When disposing of this appliance, follow regulations for disposal of rechargeable lithium-ion batteries. • Follow all local ordinances and regulations when handling or disposing of the battery. • Prevent unintentional starting. Ensure the switch is in the off position before connecting to the battery pack, picking up or carrying the appliance.
  • Page 6 • Never attempt to operate this appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken parts, including a damaged cord or plug. Take it to an authorized LG Electronics service centre or dealer for assistance. • Do not apply excessive force to the power cord to bend it, or place it under a heavy object as this will damage it.
  • Page 7 • Do not cover the power cord with a rug or carpeting. • Push the power plug firmly into the wall outlet so that it is not loose. • If the product has been submerged, contact an LG Electronics service centre or dealer for instructions before resuming use.
  • Page 8 • If the earth leakage breaker is tripped when the product is put on the charging station, immediately remove the appliance from the charging station. Contact an LG Electronics customer service centre. • Use extra care when cleaning on stairs.
  • Page 9 SAFETY INSTRUCTIONS Maintenance • Make sure to unplug the power cord when cleaning or maintaining the charging station. • Do not wash the inlet port or the dust bin with water or detergent. • Do not use detergents, polishes or air fresheners to clean the dust bin.
  • Page 10 SAFETY INSTRUCTIONS • Do not insert your fingers into the steam mop nozzle while it is working. • Do not separate the water tank from the steam mop nozzle or add water to the water tank while the power is on or cleaning in progress. Doing so may result in burns due to steam or hot water.

  • Page 11: Caution

    SAFETY INSTRUCTIONS Warning : Steam. Risk of burns. • The pressure of generated steam is less than 50 kPa. CAUTION CAUTION • To reduce the risk of injury to persons, malfunction, or damage to the product or property when using the appliance, follow basic safety precautions, including the following: Operation •...
  • Page 12 SAFETY INSTRUCTIONS Steam Mop Nozzle • Do not use the steam mop nozzle for any purpose(for example, polishing a car, cleaning windows) other than domestic floor cleaning. • Do not use the steam mop nozzle to vacuum up liquids(water, beverage). •...

  • Page 13: Installation Product Overview

    INSTALLATION INSTALLATION Product Overview The images in this guide may be different from the actual components and accessories, which are subject to change by the manufacturer without prior notice for product improvement purposes. Front View *1 This feature is only available on some models. Product Body Extension Pipe Nozzle...
  • Page 14 INSTALLATION NOTE • Use the vacuum cleaner only with the provided charging station. Using a charging station other than the one designed to be used with the vacuum cleaner, as improper sealing of the chagring station may result and dust not being emptied from vacuum cleaner.
  • Page 15 Measuring Cup NOTE • The mop pads, batteries, exhaust filter and the pre-filter will eventually need to be replaced. Contact an LG Electronics customer service centre. • Batteries are not included in the battery pocket. Multi-Surface Nozzle Wide Hard Floor Nozzle...
  • Page 16 Individually measured data would be different from a lab test result. • Battery run time is the result of using a fully charged battery according to the LG Electronics test standard. Results may be different depending on actual use environment and period of use.

  • Page 17: Storing The Accessories

    INSTALLATION Storing the Accessories Storing on Sides Open the nozzle hook on both sides of the Assembling and Storing the product. Appliance • To open the nozzle hooks, press on the right side. Be careful not to pinch fingers when Follow these steps to safely assemble the opening.
  • Page 18 INSTALLATION Storage Inside • Before moving the product, unplug it and remove the vacuum cleaner, nozzles, and accessories. Open the left door of the product and insert the bedding nozzle or the pet nozzle storage. Open the right door and insert the combination tool , the crevice tool and the...

  • Page 19: Operation Getting Started

    The nozzles and tools can accumulate on the appliance. Please contact LG also be attached to the end of the extension Electronics customer information centre if the pipe problem persists.
  • Page 20 • This indicator blinks when the appliance is Suction Power Up (+) Button / Turbo Mode connecting to the LG ThinQ application or • Press the + button to increase the suction home Wi-Fi network, and the indicator lights up when the connection is complete.

  • Page 21: Charging The Battery

    OPERATION • As the product is charging, bars light up on combination tool or the crevice tool, if either the battery level indicator to indicate the level happens to be fitted of charge. • If you don't hear a beep, reload the •...

  • Page 22: Using The Steam Mop Nozzle

    • Do not use a soiled mop pad to clean floors. • Clean only with the mop pads for the steam mop nozzle provided when purchasing from LG Electronics. The mop pads from other products may reduce cleaning performance.
  • Page 23 OPERATION • Empty the dust bin and clean the exhaust filter and the pre-filter after using the mop nozzle. • When using the steam mode, the warmth of the floor may be felt differently depending on the surrounding environment (temperature, season, material of the floor).
  • Page 24 OPERATION Alarm and LED by Steam Mop Nozzle Condition When using the steam mop nozzle, check the operation status through the alarm and LED for each condition. Nozzle Front LED Battery Pocket LED Condition Alarm and LED by Condition Vacuum cleaner The nozzle front LED of the power off steam mop nozzle is on and the...
  • Page 25 OPERATION Nozzle Front LED Battery Pocket LED Condition Alarm and LED by Condition The steam mode is The nozzle front LED is on and in use. the battery pocket LED turns off. Discharged battery • The steam mode will no in the battery pocket longer operate but the mop pads will continue to rotate.
  • Page 26 OPERATION Using the Steam Mop Nozzle extended period of time. Failure to do so may result in product failure. Press the Power button. You can use the only mop • Do not use on PVC or PU mats for infants or mode and not turn on the dust suction function.
  • Page 27 OPERATION • If the water inlet cap is not closed properly, • Use wet mop pads instead of dry mop pads water may leak. when using steam mode Attach the water tank to the mop nozzle again. Place the mop nozzle upside down on the floor. •...
  • Page 28 OPERATION When using the steam mode, a constant amount of Insert the steam mop nozzle into the extension water is supplied regardless of the operation of the pipe and connect it to the product body. When water adjustment buttons. you press the Power button on the product body, the steam mode will be turned on and preheating will begin.
  • Page 29 OPERATION Separating the Battery Pocket pocket and charge it using the charging station. Separate the battery pocket by pressing the PUSH button on the bottom of the battery pocket and sliding it upward off the mop nozzle. WARNING Press the release button and separate the extension pipe.
  • Page 30 OPERATION • Do not pull or stretch the rubber gasket on the NOTE water supply inlet. Doing so may tear or damage • When cleaning with steam, press the steam • Do not add detergent, vinegar or baking soda to button to turn off the steam mode and use the the water tank when washing it.

  • Page 31: Using The Nozzles And Tools

    OPERATION Using the Nozzles and • Keep the water tank after water is completely empty and dry. Moisture or Tools residual water in the tank may cause odour. Before Using the Nozzles and Tools Some accessories are only available on some models.
  • Page 32 OPERATION Pet Nozzle • Use it with the Turbo mode to clean pet hair out of furniture, mats, or tight areas like corners. It is suitable for soft surfaces and pet hair removal. Combination Tool CAUTION Can be used in either crevice mode or brush mode •...
  • Page 33 OPERATION Hard Dirt Tool • To convert back to the crevice mode, press in on the brush release button and slide the brush Firm bristles remove solidified dirt from hard surfaces. Clean up hair or foreign objects that are entangled in carpets or rugs. Adjusting the Length To adjust the length of the tool, press and hold the release button...
  • Page 34 OPERATION • The flexible hose extension cannot be used with the power drive Nozzle. Using the Kompressor Lever Use the Kompressor lever to compress hair and fibers inside the dust bin after vacuuming and before emptying the dust bin. • The vacuum must be turned off before using the Kompressor lever.

  • Page 35: Smart Functions

    • Filter Cleaning Guide smartphone. - Guide to cleaning the filters. • Smart Diagnosis™ Run the LG ThinQ app and sign in with your existing account or create an LG account to - This function provides useful information for sign in.
  • Page 36 Internet service provider or refer to your The appliance is connected to Wi-Fi. wireless router manual. • LG ThinQ is not responsible for any network The appliance has been connection problems or any faults, disconnected. malfunctions, or errors caused by network Connecting the Appliance Initially connection.

  • Page 37: Smart Diagnosis Function

    LG ThinQ application. complies with radiation exposure limit (<4.0 W/kg for extremity (hand) exposure condition) set forth • Launch the LG ThinQ application and select the for an uncontrolled environment. Smart Diagnosis feature in the menu. Follow the instructions provided in the LG ThinQ application.

  • Page 38: Maintenance

    MAINTENANCE MAINTENANCE Cleaning the Appliance battery from the product body and remove the foreign objects before resuming use of the appliance. Before Cleaning the Appliance • Check the inside of the product body, above the To maintain the optimum suction power, the Kompressor working plate, the extension pipe, cyclonic mesh filter, the exhaust filter and the pre- inlets, exhaust filter, pre-filter and cyclonic mesh...
  • Page 39 MAINTENANCE Remove the battery from the product body • Do not force the Kompressor lever down if before cleaning the dust bin. foreign objects are caught around the working plate of the Kompressor system. Doing so may cause product damage. Push down the Kompressor lever several times to collect and compact the dust from the...
  • Page 40 MAINTENANCE Cleaning the Filters Turn the product body over and lift the Kompressor lever up to clean the inside of Clean the exhaust filter and the pre-filter when the the working plate with the provided cleaning brush. filter cleaning icon lights up.

  • Page 41: Cleaning The Nozzles

    MAINTENANCE Lift out the pre-filter from the product body. Align the lock position of the exhaust filter cover with the letter "H" of the PUSH button on the exhaust filter. Use the combination tool to clean any dust off the motor. •...
  • Page 42 MAINTENANCE Pull the brush cover forward and pull the brush CAUTION out. • Always separate the nozzle from the product body or remove the battery before cleaning. If the nozzle starts to operate during cleaning, it could cause an injury. •...
  • Page 43 MAINTENANCE Cleaning the Wide Slim Hard Attach the crevice tool to the product body and use the vacuum to remove foreign objects and Floor Nozzle dust from the brush and the bottom of the nozzle. CAUTION • Be careful not to injure your fingers when using a screwdriver.
  • Page 44 MAINTENANCE You can clean the inside of the small roller by Slide the brush back into the nozzle until it inserting a flat-head screwdriver into the clicks into place. groove and removing the fixing part. Cleaning the Pet Nozzle Reassemble the small roller and the fixing part and make sure that they are properly attached.
  • Page 45 MAINTENANCE foreign objects, debris and hair from all Rollers hair from all Rollers of the nozzles using of the nozzles using tweezers. tweezers. Insert the left side of the brush into the groove inside the nozzle. Cleaning the Steam Mop Nozzle WARNING •...

  • Page 46: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING Before Calling for Service Operation Symptoms Possible Cause & Solution The appliance does not Battery is fully discharged. operate. • Charge the battery. Appliance is turned off. • Press the Power button to turn on the appliance. Suction power is too Dust bin is full of dust.
  • Page 47 LG customer information centre for service. repeatedly. Foreign object is in the product body, extension pipe, inlet port or nozzle.
  • Page 48 TROUBLESHOOTING Symptoms Possible Cause & Solution One or both mop The motor protection function has been activated from overload and attachment plate does the mop attachment plate stopped rotating. not rotate. • There is a lot of friction and a load is applied to the steam mop nozzle when the steam mop is used as shown below conditions.
  • Page 49 TROUBLESHOOTING Symptoms Possible Cause & Solution Mop pads make the There is a lot of dust or liquid spilled on the floor. floor dirty. • Before cleaning in steam mode or normal mop mode, clean a place with a lot of dust using the suction function and wipe off any liquid. Otherwise, the dust may clump or the liquid may spread, causing the floor to become dirty.
  • Page 50 • If the steam mop nozzle malfunctions, the battery pocket LED will blink rapidly and the alarm will repeat. If occurs again even after powering the main unit off and on, stop using it and contact an LG customer information centre for service.
  • Page 51 TROUBLESHOOTING Symptoms Possible Cause & Solution Your home appliance The distance between the appliance and the router is too far. and smartphone are • If the distance between the appliance and the router is too far, the signal not connected to the may be weak and the connection may not be configured correctly.
