Sony VAIO PCV-RX360DS Specifications

Video Audio Integrated Operation
FEATURES
• Intel ® Pentium ® III processor 866 MHz
• 128 MB PC-133 SDRAM (expandable to 512 MB)
• 40 GB †† Ultra ATA/66 Hard Drive
• 16X max. DVD-ROM/40X max. CD-ROM
• 8X4X32X max. CD-RW Drive
• High-speed Internet ready with
10/100Base-T Ethernet
• Front accessible i.LINK ® (IEEE 1394) interface
and USB connections 1
™
• Programmable VAIO Smart Keyboard
• V.90 compatible data/fax modem
• Wheel mouse
• External stereo speakers
Sony Electronics Inc.
Personal Network Solutions Company
16765 West Bernardo Drive, San Diego, CA 92127
For more information: 1.800.4SONYPC (476-6972)
Web address: http://www.sony.com/vaio
Computer Interface: The computer industry lacks standards, and therefore, there are a multi-
tude of varying software packages and add-on hardware options. This personal computer is
not manufactured to any specific software, and Sony does not and cannot make any warranty
or representation with respect to the performance of this product with any particular software
packages and/or non-Sony add-on hardware option except those mentioned in this document.
Sony hereby disclaims any representations or warranty that this product is compatible with
any combination of non-Sony products you may choose to connect. While Sony representa-
tives or Sony authorized dealers may be able to assist you and may make recommendations,
they are NOT authorized to vary or waive this disclaimer. Purchasers must determine for them-
selves the suitability and compatibility of the hardware and software in each and every particu-
lar instance. Some pre-installed software titles may not include full documentation. Software
titles pre-installed on the Sony Desktop Computer are subject to change without notice.
Simulated graphic shown on display.
©2001 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without
written permission is prohibited. Sony, i.LINK, Multiscan, Trinitron, DVgate, Media Bar,
MovieShaker, PictureGear, and VAIO are trademarks of Sony. Intel, the Intel Inside logo, and
Pentium are registered trademarks of Intel Corporation. Microsoft, Windows and the Windows
logo are trademarks of Microsoft Corporation. All other trademarks are trademarks of their
respective owners. This product meets the standards of the International Energy Star Program
for energy efficiency. Features and specifications are subject to change without notice.
Non-metric weights and measurements are approximate.
Printed in U.S.A. 1/01

ADDITIONAL SPECIFICATIONS

Model
PCV-RX360DS
Processor
Intel ® Pentium ® III Processor 866 MHz
Cache Memory
†
256 KB Integrated On-Die Level 2
Front Side Bus Speed
133 MHz
Standard RAM
128 MB PC-133 SDRAM, expandable to 512 MB
Hard Drive
40 GB †† Ultra ATA/66 Hard Drive
CD-RW Drive
8X4X32X max. CD-RW Drive
DVD/CD-ROM Drive
16X max. DVD-ROM
40X max. CD-ROM
Floppy Disk Drive
3.5" 1.44 MB Floppy Disk Drive
Video & Graphics
Intel ® 815 Chipset (Direct AGP)
Modem
V.90 Modem
Ethernet
10/100Base-T Ethernet
Expansion Slots
Three PCI (one occupied)
1 AGP
Expansion Bays
Two External 5.25" Half-Height (two occupied)
One External 3.5" (occupied)
Two Internal 3.5" (one occupied)
Port Connectors
Four USB (two front/two rear)
®
One PS/2 Mouse
One PS/2 Keyboard
One VGA
One Serial
One Parallel
One 6pin i.LINK
One 4pin i.LINK
One Headphone Out
One Line In
One Microphone
Supplied Accessories
Speakers
VAIO Smart Keyboard
PS/2 Wheel Mouse
RJ-11 Phone Cord
Power Cord
Power Requirements
100-120V -3A (50/60Hz)
Power Management
ACPI 1.0 Compliant
Advanced Power Management (APM version 1.2)
Sony VAIO Digital Studio
Dual Drives — DVD-ROM and CD-RW
Movie Editing and Video Email
High-speed Internet Ready with
10/100Base-T Ethernet
®
i.LINK (IEEE 1394) Interface and USB Connectors
®
Microsoft Word 2000 Included
Create Custom CDs
Dimensions (CPU)
8.0"(W) x 14.2"(H) x 14.6"(D)
Weight (CPU)
† 26.5 lbs.
Service
One Year Limited Expressed Repair Service (upon
registration; 90 days without registration)*
Limited Warranty
One Year Parts and Labor (upon registration; 90 days
without registration)*
Telephone Support
Hardware: One Year
Software and Operating System: 90 Days
Pre-Installed Software
Operating System
®
Microsoft
Sony Original Software
DVgate ™
Media Bar ™
MovieShaker
OpenMG ™ Jukebox
PictureGear
Smart Capture
VisualFlow ™
Other Software Applications
Adaptec Direct CD
Adaptec Easy CD Creator
Adobe Acrobat
Adobe PhotoDeluxe
Apple QuickTime
ArcSoft PhotoPrinter 2000 Pro
®
Corel Wordperfect
Quicken ® 2001 New User Edition
Microsoft ®
VAIO Smart
Tomb Raider Chronicles
Online Center
America Online
CompuServe
EarthLink TotalAccess
Netscape ® Communicator
Prodigy Internet
Tool Center
McAfee VirusScan
Sony Application Recovery CD(s)
Sony System Recovery CD(s)
† MHz denotes microprocessor internal clock speed; other factors may
affect application performance.
†† GB means one billion bytes when referring to hard drive capacity.
Accessible capacity may vary.
* Certain restrictions apply.
** Requires payment of additional fees or subscription for use.
1 i.LINK is a trademark of Sony used only to designate that a product
contains an IEEE 1394 connector. All products with an i.LINK connec-
tor may not communicate with each other.
PCV-RX360DS
1
®
i.LINK
(IEEE 1394)
®
Windows Millennium Edition
™
™
™
™
® Reader
®
™
®
Outlook ® Express
™
Keyboard
®
**
® 2000**
™ **
®
™
**
™
