Sony VAIO PCV-J120 Specifications

Video Audio Integrated Operation
FEATURES
• Intel ® Pentium ® III processor 700 MHz
• 128 MB PC-100 SDRAM (expandable to 512 MB)
• 20 GB †† Ultra ATA/66 Hard Drive
• 4X4X24X max. CD-RW Drive
• High-speed Internet ready with
10/100Base-T Ethernet
• i.LINK ® (IEEE 1394) interface and

USB connections

• Programmable VAIO Smart ™ Keyboard
• V.90 compatible data/fax modem
• Wheel mouse
• External stereo speakers
Sony Electronics Inc.
Personal Network Solutions Company
16765 West Bernardo Drive, San Diego, CA 92127
For more information: 1.800.4SONYPC (476-6972)
Web address: http://www.sony.com/vaio
Computer Interface: The computer industry lacks standards, and therefore, there are a multi-
tude of varying software packages and add-on hardware options. This personal computer is
not manufactured to any specific software, and Sony does not and cannot make any warranty
or representation with respect to the performance of this product with any particular software
packages and/or non-Sony add-on hardware option except those mentioned in this document.
Sony hereby disclaims any representations or warranty that this product is compatible with
any combination of non-Sony products you may choose to connect. While Sony representa-
tives or Sony authorized dealers may be able to assist you and may make recommendations,
they are NOT authorized to vary or waive this disclaimer. Purchasers must determine for them-
selves the suitability and compatibility of the hardware and software in each and every particu-
lar instance. Some pre-installed software titles may not include full documentation. Software
titles pre-installed on the Sony Desktop Computer are subject to change without notice.
Simulated graphic shown on display.
©2000 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without
written permission is prohibited. Sony, i.LINK, Multiscan, Trinitron, DVgate, Media Bar,
MovieShaker, PictureGear, and VAIO are trademarks of Sony. Intel, the Intel Inside logo, and
Pentium are registered trademarks of Intel Corporation. Microsoft, Windows and the Windows
logo are trademarks of Microsoft Corporation. All other trademarks are trademarks of their
respective owners. This product meets the standards of the International Energy Star Program
for energy efficiency. Features and specifications are subject to change without notice.
Non-metric weights and measurements are approximate.
Printed in U.S.A. 09/00

ADDITIONAL SPECIFICATIONS

Model
PCV-J120
Processor
Intel ® Pentium ® III Processor 700 MHz
Cache Memory
†
128 KB Integrated On-Die Level 2
Front Side Bus Speed
100 MHz
Standard RAM
128 MB PC-100 SDRAM, expandable to 512 MB
Hard Drive
††
20 GB Ultra ATA/66 Hard Drive
CD-RW Drive
4X4X24X max. CD-RW drive
Floppy Disk Drive
3.5" 1.44 MB Floppy Disk Drive
Video & Graphics
®
Intel 810 Chipset (Direct AGP)
Modem
V.90 Modem
Ethernet
10/100Base-T Ethernet
Expansion Slots
Four PCI (three occupied)
Expansion Bays
One External 5.25" Half-Height (one occupied)
One External 3.5" (occupied)
Two Internal 3.5" (one occupied)
Port Connectors
Two USB (two rear)
®
One PS/2 Mouse
One PS/2 Keyboard
One VGA
One Serial
One Parallel
One Game/MIDI
Two 6pin i.LINK
One Headphone Out
One Line In
One Microphone
Supplied Accessories
Speakers
VAIO Smart Keyboard
PS/2 Wheel Mouse
RJ-11 Phone Cord
Power Cord
Power Requirements
100-120V -3A (50/60Hz)
Power Management
ACPI 1.0 Compliant
Advanced Power Management (APM version 1.2)
Intel ® Pentium ® III processor 700 MHz
Home Movie Editing
High-speed Internet Ready with
10/100Base-T Ethernet
CD-RW Drive

Plug and Play

i.LINK ® (IEEE 1394) Interface
and USB Connectors
Dimensions (CPU)
6.7"(W) x 12"(H) x 14.4"(D)
Weight (CPU)
† 18.7 lbs.
Service
One Year Limited Expressed Repair Service (upon
registration; 90 days without registration)*
Limited Warranty
One Year Parts and Labor (upon registration; 90 days
without registration)*
Telephone Support
Hardware: One Year
Software and Operating System: 90 Days
Pre-Installed Software
Operating System
®
Microsoft
Sony Original Software
™
DVgate
™
Media Bar
MovieShaker
OpenMG ™ Jukebox
PictureGear
Smart Capture
Other Software Applications
Adaptec Direct CD
Adaptec Easy CD Creator
Adobe Acrobat
Adobe PhotoDeluxe
Apple QuickTime
ArcSoft PhotoPrinter 2000 Pro
Intuit ® Quicken
Microsoft ®
VAIO Smart
Sun StarOffice
Online Center
America Online
CompuServe
EarthLink TotalAccess
®
Netscape
Prodigy Internet
Tool Center
McAfee VirusScan
Sony Application Recovery CD(s)
Sony System Recovery CD(s)
† MHz denotes microprocessor internal clock speed; other
factors may affect application performance.
†† GB means one billion bytes when referring to hard drive
capacity. Accessible capacity may vary.
* Certain restrictions apply.
** Requires payment of additional fees or subscription for use.
PCV-J120
Sony VAIO PC
®
i.LINK
(IEEE 1394)
®
Windows Millennium Edition
™
™
™
™
® Reader
®
™
® 2000 Basic
Outlook ® Express
™
Keyboard
™
5.2
®
**
®
2000**
™
**
®
Communicator
™
**
