ER3A6AD70L, ER3A6BD70L Built-in gas hob EN Information for Use ... 3 ZH-HK ......使用手 冊 ........14 Register your appliance on My Siemens and discover exclusive services and offers. Siemens Home Appliances...
Page 2
ER3A6AD70L ER3A6BD70L Component 部件 Pan support 烤架 Control knob 操作旋鈕 Standard-output burner 1.90 kW 1.90千瓦 標準爐頭 High-output burner 2.80 kW 2.80千瓦 大火爐頭 Dual-wok multi-crown burner 6.10 kW 6.10千瓦 雙環火爐頭 The images shown in these instructions are for guid- 在安裝說明上的圖像僅供參考用。 ance only. ER3A6AD70L 型號...
Safety en Further information and explanations are available online: Table of contents Use approved gas tubing bearing EMSD ap- proval marking (such as: 機電工程署批准 Safety .............. 3 EMSD APPROVAL GTXXXX) for connection to appliances, or other appropriate methods ac- Preventing material damage ...... 6 cepted by EMSD.
en Safety 1.5 Safe use WARNING ‒ Risk of fire! Leaving fat or oil cooking on an unattended WARNING ‒ Risk of explosion! hob can be dangerous and may lead to fires. Escaping gas may cause an explosion. WHAT ▶ Never leave hot oil or fat unattended. TO DO IF YOU SMELL GAS OR IF THERE ▶...
Page 5
Safety en Operating a burner with the power set too An ingress of moisture can cause an electric high results in very high temperatures being shock. generated. This may cause flammable materi- ▶ Do not use steam- or high-pressure clean- als to ignite. The power level shown in the dis- ers to clean the appliance.
en Preventing material damage Children may breathe in or swallow small WARNING ‒ Risk of suffocation! parts, causing them to suffocate. Children may put packaging material over ▶ Keep small parts away from children. their heads or wrap themselves up in it and ▶...
Familiarising yourself with your appliance en Sort the individual components by type and dispose 3.2 Disposing of packaging ▶ of them separately. The packaging materials are environmentally compat- ible and can be recycled. Familiarising yourself with your appliance 4 Familiarising yourself with your appliance Dual-wok multi-crown burner 4.1 Control knob With the dual-wok multi-crown burner, you can regulate...
Accessories vary from one appliance to another. When purchasing accessories, always quote the exact product number (E no.) of your appliance. → Page 12...
Basic operation en Basic operation 6 Basic operation ¡ It is important to keep the appliance clean. Clean 6.1 Igniting a gas burner the ignition plugs regularly with a small, non-metallic brush. Take care to prevent the ignition plugs from WARNING ‒ Risk of fire! suffering any heavy knocks.
en Recommended settings for cooking Place the cookware right The cookware may tip Place the cookware cor- The cookware may tip in the centre of the over if it is not placed in rectly on the pan sup- over if you place it directly burner.
Troubleshooting en 9.3 Cleaning the burners 9.4 Cleaning the pan supports After each use, clean the surface of the burner parts. Note: Read the information on the cleaning agents. This prevents food remains from burning on. → "Cleaning product", Page 10 ATTENTION! Allow the appliance to cool down. The burner parts can be damaged if you clean them in Carefully remove the pan supports.
en Customer Service Fault Cause and troubleshooting The burner flame is The burner parts are positioned incorrectly. not uniform. Correctly position the burner parts. ▶ Openings on the burner are soiled. Clean and dry the openings on the burner. ▶ The gas does not ap- The gas supply has been shut off by the intermediate valves.
Disposal en Disposal 12 Disposal 12.1 Disposing of old appliance Valuable raw materials can be reused by recycling. Unplug the appliance from the mains. Cut through the power cord. Dispose of the appliance in an environmentally friendly manner. Information about current disposal methods are available from your specialist dealer or local author- ity.
Page 24
EN Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG ZH-HKBSH Group 是 Siemens AG 旗下獲許可的商標 BSH Hausgeräte GmbH Carl-Wery-Straße 34 81739 München, GERMANY siemens-home.bsh-group.com *8001268304* 8001268304 (030912) en, zh-hk...
