Warranty Siemens warrants this product for a period of five (5) years from the date of purchase, conditional upon the return to factory for maintenance during the warranty term. This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void.
Preface Preface This guide describes the RUGGEDCOM WIN5137. It describes the major features of the subscriber station, installation, commissioning and important technical specifications. It is intended for use by subscriber station installers and operators, and assumes readers have a working knowledge of WiMAX technologies and procedures.
Siemens Sales representative. Customer Support Customer support is available 24 hours, 7 days a week for all Siemens customers. For technical support or general information, contact Siemens Customer Support through any of the following methods: Online Visit http://www.siemens.com/automation/support-request...
Installation Guide Introduction Introduction The RUGGEDCOM WIN5137 subscriber station (also referred to as Customer Premises Equipment) is part of the RUGGEDCOM WIN family, a line of mobile WiMAX broadband wireless access systems based on the IEEE 802.16e mobile WiMAX standard.
The subscriber station supports both IP convergence sublayer for wireless Internet service providers or Ethernet Convergence Sublayer, ideal for mission critical private networks. Section 1.2 Description The RUGGEDCOM WIN5137 is available in one of two models: • AC Model The AC model receives power from a Siemens-approved PoE injector. • DC Model The DC model receives power directly from a Class 2 power supply.
Page 9
Introduction ANT 1 ANT 2 ETH/PWR RSSI RSSI W.LINK W.LINK Figure 1: RUGGEDCOM WIN5137 (AC Model) 1. ANT 1 Port 2. ETH/PWR Port 3. RSSI LEDs 4. W.LINK LED 5. PWR LED 6. ANT 2 Port 7. Chassis Ground 12VDC ANT 1 ANT 2 RSSI ETH/PWR RSSI W.LINK PWR W.LINK PWR...
Page 10
Chapter 1 RUGGEDCOM WIN5137 Introduction Installation Guide State Description Green (Solid) Subscriber station is connected to the base station and receiving services. Green (Blinking) Link between the subscriber station and the base station is down. PWR LED Indicates when power is supplied to the subscriber station.
WARNING! Safety hazard – risk of serious personal injury and/or damage to equipment. Installing the RUGGEDCOM WIN5137 can pose a serious safety hazard. Be sure to take precautions to avoid the following: • Exposure to high voltage lines during installation •...
Chapter 2 RUGGEDCOM WIN5137 Installing the Subscriber Station Installation Guide IMPORTANT! This product should be installed in a restricted access location where access can only be gained by authorized personnel who have been informed of the restrictions and any precautions that must be taken.
If any item is missing or damaged, contact Siemens for assistance. Section 2.3 Required Tools and Materials The following tools and materials are required to install the RUGGEDCOM WIN5137: Kits Greases • Class I, Division 2 Kit (P/N MKIT0090) – For hazardous •...
Chapter 2 RUGGEDCOM WIN5137 Installing the Subscriber Station Installation Guide Tools Tapes • Wrench or socket set • POE cold shrink (maximum 49.2 mm or 1.9 in inner diameter before shrinking) or self-amalgamating tape • Phillips screwdriver • UV-resistant vinyl tape •...
Installing the Subscriber Station in Hazardous Locations The RUGGEDCOM WIN5137 is designed to comply with the safety standards for Class I, Division 2, Zone 2 hazardous locations where concentrations of flammable gases, vapors or liquids may be present, as opposed to normal operating environments.
Figure 3: Compliance Label (Example) Section 2.6 Mounting the Subscriber Station The RUGGEDCOM WIN5137 is designed for maximum mounting and display flexibility. It can be secured to a bracket and then mounted to a pole, wall or tower. NOTE For detailed dimensions of the subscriber station, refer to Chapter 4, Dimension...
RUGGEDCOM WIN5137 Chapter 2 Installation Guide Installing the Subscriber Station Section 2.6.1 Mounting the Subscriber Station to a Wall or Tower Mount the subscriber station to any wall or tower capable of supporting its weight. An outer wall on a roof or other high location to avoid interference from other buildings or trees is preferred.
Chapter 2 RUGGEDCOM WIN5137 Installing the Subscriber Station Installation Guide 10. Tighten the screws connecting the arm bracket to the subscriber station and mounting bracket. Make sure the screws are torqued to 24 N·m (17.7 ft. lb.). Section 2.6.2 Mounting the Subscriber Station to a Pole The subscriber station can be attached to any pipe or pole with a diameter of 44.5 to 254 mm (1.75 to 10 in).
14 N·m (10 lbf-ft). Section 2.7 Installing the Antennas The RUGGEDCOM WIN5137 supports N-Connect female antennas. To install an antenna, do the following: WARNING! Radiation hazard – risk of Radio Frequency (RF) exposure. This subscriber station is compliant with the requirements set forth in FCC CFR 47, section 1.1307, addressing Radio Frequency (RF) exposure...
Page 20
Chapter 2 RUGGEDCOM WIN5137 Installing the Subscriber Station Installation Guide from radio frequency base stations, as defined in FCC OET Bulletin 65 [http://transition.fcc.gov/Bureaus/ Engineering_Technology/Documents/bulletins/oet65/oet65.pdf]. The emitted radiation should be as little as possible. To achieve minimum RF exposure, install the subscriber station when it is configured not to transmit and set it to operational mode remotely, rather than having a technician enable transmission on-site.
Installing the Subscriber Station Figure 7: Antenna and Lightning Protector Assembly 1. Drain Wire 2. RUGGEDCOM WIN5137 3. Shielded Coaxial Cable 4. Lightning Protector 5. Ground Wire 6. Antenna Make sure the PWR LED on the subscriber station is on. Adjust the position of the antenna until the maximum RSSI link quality reading is achieved. A single RSSI LED indicates the subscriber station is at minimum synchronized with the base station.
Section 2.9.1 Connecting Power Directly (DC Only) The DC version of the RUGGEDCOM WIN5137 requires a 10 to 30 VDC Class 2 power supply. IMPORTANT! When connecting a DC battery power supply, make sure to use a 36 VDC, 3 A, double-pole circuit breaker as the main disconnecting device.
Electrical hazard – risk of damage to equipment. The power cord provided with the data adapter is safety certified according to national rules. Do not use a power cord that has not been approved by Siemens for use with the data adapter. To connect power and data to the subscriber station, do the following: CAUTION! Crushing hazard –...
Connecting to a RUGGEDCOM RP100 or RP110 (AC Only) The RUGGEDCOM RP100 and RP110 are optional power injectors for powering and providing data to the RUGGEDCOM WIN5137 (AC Only). The RUGGEDCOM RP100 and RP110 meet a wider temperature and voltage range than the standardRUGGEDCOM WIN1010.
Installation Guide Installing the Subscriber Station Figure 10: Typical Outdoor Installation 1. RUGGEDCOM WIN5137 2. Shielded Cable 3. Ground Connection 4. Lightning Protector 5. RUGGEDCOM RP100/RP110 6. Drain Wire (Shielded) For more information about the RUGGEDCOM RP100 or RP110, refer to the RUGGEDCOM RP100 Installation Guide or the RUGGEDCOM RP110 Installation Guide.
Page 26
Chapter 2 RUGGEDCOM WIN5137 Installing the Subscriber Station Installation Guide 38 mm (1.5 in) Figure 12: Cutting the Jacket 1. Wire Jacket 2. Foil Fold the foil back over the wire jacket. Figure 13: Folding Back the Foil 1. Foil 2. Twisted-Pair Wires 3. Drain Wire Bend the drain wire back over the jacket.
Page 27
RUGGEDCOM WIN5137 Chapter 2 Installation Guide Installing the Subscriber Station Figure 15: Untwisting the Wire Pairs Arrange the wires according to the following pin-out description: Color Description Number White/Orange ETH Data TP0+ Orange ETH Data TP0- White/Green ETH Data TP1+ Figure 16: CAT-5e PoE Cable Pin-Out...
An approved Power-over-Ethernet (PoE) injector is required when the subscriber station is installed in a hazardous location. The RUGGEDCOM WIN5137 is certified for installation in Class I, Division 2 Groups A, B, C and D hazardous locations when installed using the Class I, Division 2 kit (P/N MKIT0090). The Class I, Division 2 kit contains the following items: •...
Most outdoor subscriber station, antenna and cable problems are caused by coaxial cable connections loosened by vibration, allowing moisture to penetrate the connector interface. Siemens strongly recommends weatherproofing all outdoor cable connections to prevent the ingress of water and help secure connections.
Chapter 2 RUGGEDCOM WIN5137 Installing the Subscriber Station Installation Guide IMPORTANT! The method of weatherproofing described in this section must be completed on all external connections. If surge arrestors are used, all associated connections and arrestors must be completely wrapped with splicing tape or self-amalgamating tape.
RUGGEDCOM WIN5137 Chapter 2 Installation Guide Installing the Subscriber Station Reconnect the cable and slide the tube up to meet the subscriber station chassis. Hold the tube against the subscriber station chassis and start rotating it clockwise while gently pulling out the core.
Page 32
Chapter 2 RUGGEDCOM WIN5137 Installing the Subscriber Station Installation Guide Configuring the Subscriber Station...
• Section 3.5, “Mechanical Specifications” • Section 3.6, “IDU to ODU Cable Specifications” Section 3.1 Power Supply Requirements The RUGGEDCOM WIN5137 requires an external power supply that meets the following requirements: AC Model Power Supply Rated Input Power Rated Output Power RUGGEDCOM WIN1010 100 to 240 VAC, 50 to 60 Hz, 1.5 A...
Chapter 3 RUGGEDCOM WIN5137 Technical Specifications Installation Guide Section 3.2 Power Consumption Typical Power Consumption 12 W Section 3.3 Radio and Modem Specifications Operating Frequency 3600 to 3800 MHz Wireless Communication IEEE 802.16e-2009 Standard Operating Mode Time-Division Duplexing (TDD) Channel Bandwidths 3.5 MHz...
RUGGEDCOM WIN5137 Chapter 5 Installation Guide Certification Certification The RUGGEDCOM WIN5137 ODU CPE has been thoroughly tested to guarantee its conformance with recognized standards and has received approval from recognized regulatory agencies. CONTENTS • Section 5.1, “Approvals” • Section 5.2, “Environmental Type Tests”...
Chapter 5 RUGGEDCOM WIN5137 Certification Installation Guide • UL 1604 Electrical Equipment for Use in Class I and II, Division 2, and Class III Hazardous (Classified) Locations • CAN/CSA-C22.2 No. 213-M1987 Non-Incendive Electrical Equipment for Use in Class I, Division 2 Hazardous Locations The subscriber station is marked with an MET classified mark that indicates compliance with both Canadian and U.S.
Information Technology Equipment – Safety – Part 22: Equipment to be Installed Outdoors The subscriber station is marked with a TÜV Rheinland marking and can be used throughout the European community. A copy of the TÜV Rheinland Declaration of Conformity is available from Siemens Canada Ltd. For contact information, refer to “Contacting Siemens”.
Wireless Access Systems – Amendment for Physical and Medium Access Control Layers for Combined Fixed and Mobile Operation in Licensed Bands Section 5.2 Environmental Type Tests The RUGGEDCOM WIN5137 has passed the following environmental tests. Test Description Test Levels IEC 60068-2-1 Low Temperature -25 °C for 72 hours...
Page 43
RUGGEDCOM WIN5137 Chapter 5 Installation Guide Certification Test Description Test Levels Frequency Range: 5 to 62 Hz, 62 to 200 Hz 3 Axes Duration: 3x5 sweep IEC 60068-2-64 Random Vibration (Class 4M5) ASD: 0.04 m²/s³ 12 to 12 dB/oct Frequency Range: 5 to 10 Hz, 10 to 50, 50 to 100 Hz...
