Multiscan Projector
VPH-G70Q/G70QM

Advertisement

Table of Contents
loading

Related Manuals for Sony VPH-G70Q

Summary of Contents for Sony VPH-G70Q

  • Page 1 Multiscan Projector VPH-G70Q/G70QM...
  • Page 2 A Sony Projector for A Sony Projector for Clear Demonstrations Clear Demonstrations of Excellence of Excellence...
  • Page 3 Sony has the solution: a new Multiscan Projector that offers bright images and super-sharp focusing - plus amazing ease of installation and operation. The Sony VPH-G70Q/G70QM lets you view large-screen images from a wide variety of signal input sources, at horizontal frequencies ranging from 15 to 110kHz.
  • Page 4 Power saving mode To protect the environment, power consumption can be reduced when the power saving mode of the VPH-G70Q/G70QM is set to on. The combination of numerous advanced technologies including newly developed 8-inch electromagnetic focus CRTs, new...
  • Page 5 Sony IFB Series* . By connecting an optional Sony signal switcher with IFB Series boards, several inputs can be simultaneously connected, thus expanding the projection system.

  • Page 6: Remote Control

    • Wired/wireless remote control unit for setup and operation • Full remote operation • Function keys can be illuminated for opera- tion in dark rooms * Supplied with the VPH-G70Q/G70QM. RM-PJ10 Infrared remote control receiver • Remote control satellite for rear projection or out-of-sight projector applications •...

  • Page 7: Interface Cables

    • Mountable in an EIA 19-inch rack with the supplied rack mount kit. Will soon be available. Some items are not available in some areas. For further details, please consult your nearest Sony office. SIC-10 • 5 x BNC 5 x BNC...

  • Page 8: Specifications

    ANSI lumen is a measuring method of American National Standard IT7.215. HDTV: 1125/60 interlaced HDTV studio standard system. Some items are not available in some areas. For further details, please consult your nearest Sony office. Will soon be available. REAR PANEL CONNECTOR SECTION 1Vp-p±2dB, 75Ω...
  • Page 9 Optional accessories 1Vp-p±2dB, positive/negative, 75Ω Phono x 2 –5dBu, impedance 1kΩ (stereo or monaural selectable) 14-pin (female), to VPH-G70Q/G70QM or PC-1271/1271M Wireless remote control unit RM-1270S AA size battery x 2 (for RM-1270S) Rack mount kit with screws (for 19-inch EIA...

  • Page 10: Installation Examples

    D (TD) E (Xlens) F (Lhole) G (Lmax) (101 Sony VPS-100FH Sony VPS-100FM H (Lfront) Sony VPS-120FH and VPS-120FM CEILING INSTALLATION USING FRONT PROJECTION FLAT SCREEN • The distances in light blue Screen size are the factory preset (inches) settings.
  • Page 11 Wall Be sure that the projector is level to the floor. Center of the screen Use the PSS-70 Projector Suspension Support (not supplied). Center of the screen 15.2˚ Wall WHAT IS THE OPTICAL AXIS ANGLE? The optical axis angle is the...
  • Page 12 Distributed by Features and specifications are subject to change without notice. Copyright 1997 Sony Corporation. All rights reserved. Reproduction in whole or in part without written Sony permission is prohibited. Printed in Japan ©1997 Sony Corporation MK4040OHB9703P1-009...
