HP PS110 Quick Start Manual

Wireless vpn router
Hide thumbs Also See for PS110:
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual
The HP PS110 is a Wi-Fi Alliance authorized Wi-Fi CERTIFIED
802.11a/b/g/n product. The Wi-Fi CERTIFIED Logo is a
certification mark of the Wi-Fi Alliance.
This Quickstart shows you how to install and get started using the HP PS110 802.11n Wireless VPN Router, hereafter referred to as the PS110. (See Products list
on page 6 for part numbers.)
The latest documentation, including the HP PS110 Wireless Router Configuration/Administration Guide, is available at www.hp.com/support/manuals.
The PS110 router is an all-in-one networking device designed specifically to work with the HP ProLiant MicroServer Gen 8 Server. It incorporates an IPv6 capable
router, gigabit LAN switch, 802.11n wireless access point, SPI firewall, and VPN encryption technology. The PS110 provides a single radio dual band 802.11n
access point and aggregate VPN capacity of 30 Mbps. The Device enclosure is designed to specifically stack on top of the MicroSever Gen 8 and has built-in
technology to automatically detect any HP ProLiant Server in your network. In addition to auto-detection of HP ProLiant Servers, the device interface shows real-
time health status of the discovered servers via the iLO interface found on the servers.
Hardware overview
1
2
3
Rear view
1: Power jack
2: Power On/Off button
3: Wi-Fi On/Off button
4: LAN ports 1–4
Package contents
The PS110 router, two mounting screws with wall anchors, four rubber feet, AC/
DC power adapter, power cord, and documentation.
Ports
• Four LAN Ethernet ports: Auto-sensing 10/100/1000 BaseT Ethernet ports
with RJ-45 connectors.
HP PS110 Wireless VPN Router Quickstart
4
5
7
6
5: WAN port
6: Reset button
7: WPS button
Front view
8: System and port status LEDs
9: USB port LED
10: USB 2.0 port
11: Power LED
• One WAN Ethernet port: Auto-sensing 10/100/1000 BaseT Ethernet port
with RJ-45 connector.
• USB port: A standard USB 2.0 port that can be connected to an external
USB storage device. For details, see the USB port description in the
HP PS110 Wireless Router Configuration/Administration Guide.
8
9
10
11

Advertisement

Table of Contents
loading

Related Manuals for HP PS110

Summary of Contents for HP PS110

  • Page 1 Wi-Fi Alliance. HP PS110 Wireless VPN Router Quickstart This Quickstart shows you how to install and get started using the HP PS110 802.11n Wireless VPN Router, hereafter referred to as the PS110. (See Products list on page 6 for part numbers.) The latest documentation, including the HP PS110 Wireless Router Configuration/Administration Guide, is available at www.hp.com/support/manuals.
  • Page 2 The Reset button is accessible through a hole on the rear panel of the PS110, labeled as 6 on page 1. To reset the PS110 to factory defaults, insert a paper clip Either an unsupported or defective USB device is into the Reset button hole and hold the button for more than three seconds, attached.

  • Page 3: Installation

    When mounting the PS110 on a wall, ensure that the surface to which you harmful interference to other systems. attach the PS110 and the fasteners you use can support at least 0.9 kg (2 lb). Safety: Consider the following safety information during installation.

  • Page 4: Initial Configuration

    You must perform the initial configuration from a computer that is directly connected to one of the PS110 LAN ports. If you configure the PS110 from a wireless computer, you might lose contact with the PS110 when you change the wireless configuration.
  • Page 5 On the Login page, specify admin for both Username and Password, and then select Login. Note: HP recommends that you change the default password on the System > Admin page and select Save. Passwords must be at least six characters long and include four different characters.

  • Page 6: Products List

    Power, Networking, and Rack Products, available at www.hp.com/support/Safety- Compliance-EnterpriseProducts. For the purposes of this example, the PS110 has its DHCP server enabled (the For products available in the USA/Canada market, 2.4 GHz operation is limited to default setting) and the cable modem is on and operating normally.
  • Page 7 Manufacturing Date – The manufacturing date is included in the product serial number, Class B (broadcasting communication This device obtained EMC registration mainly for CCYMPPPZZZ (HP serial number format for this product). The manufacturing date is device for home use) home use (Class B) and may be used in all areas.

  • Page 8: Specifications

    Месяцы обозначаются как 1 (январь), 2 (февраль) и т. д. до 9 (сентябрь). 0 (ноль) обозначает октябрь, A обозначает ноябрь, а B обозначает декабрь. Жасалған күні – Жасалған күні CCYMPPPZZZ (осы өнімге арналған HP Dimensions 245 x 230 x 43.85 mm сериялық...
  • Page 9 HP PS110 Wireless VPN Router Quickstart Regulatory information FCC Statement: The maximum antenna gain permitted (for devices in the bands 5250-5350 MHz and 5470-5725 Federal Communication Commission Interference Statement MHz) to comply with the e.i.r.p. limit. This equipment has been tested and found to comply with the limits for a Class B digital device, le gain maximal d’antenne permis pour les dispositifs utilisant les bandes 5250-5350 MHz et...
