Sealey ES550.V3 Quick Start Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY.
Refer to Wear safety
instructions footwear
1. SAFETY
WARNING! Ensure all Health and Safety, local authority, and general workshop practice regulations are strictly adhered to
‰
when using this equipment.
Before using the stand ensure it is in good working order.
9
Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the
9
warranty.
Keep the stand clean for best and safest performance.
9
Locate the stand in a suitable work area, keep area clean and tidy and free from unrelated materials. Ensure there is adequate
9
lighting.
Use on a firm, level surface capable of sustaining the stand and the load.
9
Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
9
Ensure all non-essential persons keep a safe distance whilst the stand is in use.
Lock mounting plate in position with locking pin before fixing a load and ensure the load is centred and securely mounted on the
9
mounting plate.
When an engine is mounted, take the weight of the engine on the handle before removing the locking pin.
9
Ensure the stand and load are stable.
9
To move a loaded stand, steady the load and push from behind the main post of the stand so that the castor wheels are ahead of the
9
load.
DO NOT pull the unit backwards, or push from the side, as this may cause the stand to tip.
8
Ensure surface over which the stand is to travel is strong enough to take the stand and load and that it is not cracked, uneven or
9
obstructed.
DO NOT use unit if damaged.
8
DO NOT allow untrained persons to use the stand.
8
DO NOT exceed the rated capacity of 550kg.
8
▲ DANGER! DO NOT work under an engine mounted on the stand.
DO NOT use the stand for purposes other than those for which it is designed.
8
When not in use, store in a safe, dry, childproof location.
9
2. INTRODUCTION
Accepts a wide variety of engines and transmissions. The heads swivel 360° for accessibility to all parts of the engine. Fully
adjustable mounting arms. Swivel castors provide excellent manoeuvrability. Maximum Load Length: 700mm.
3. SPECIFICATION
Model No: ......................................................... ES550.V3
Capacity: .................................................................550kg
Width: ..................................................................1000mm
Depth: ....................................................................845mm
Height: ...................................................................930mm
Maximum load length ............................................700mm
© Jack Sealey Limited
ENGINE STAND 550KG
ES550.V3
MODEL NO:
Original Language Version ES450.V3 | Issue 3 (H,F) 05/08/22
