DIGITAL HOME CINEMA SYSTEM HT-P10 HT-TP12 THIS APPLIANCE IS MANUFACTURED BY: Instruction Manual COMPACT COMPACT DIGITAL AUDIO DIGITAL VIDEO V I D E O AH68-01660B REV:01...
Safety Warnings Use of controls, adjustments or performance of procedures other CLASS 1 LASER PRODUCT than those specified herein may result in hazardous radiation KLASSE 1 LASER PRODUKT exposure. LUOKAN 1 LASER LAITE KLASS 1 LASER APPARAT PRODUCTO LASER CLASE 1 CAUTION-INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED, AVOID EXPO- SURE TO BEAM.
20 minutes in the screen saver mode. Power Saving Function The HT-P10/HT-TP12 automatically shuts itself off after 20 minutes in the stop mode. Customized TV Screen Display The HT-P10/HT-TP12 allows you to select your favorite image during JPEG, DVD or VCD playback and set it as your background wallpaper.
Notes on Discs DVD (Digital Versatile Disc) offers fantastic audio and video, thanks to Dolby Digital surround sound and MPEG-2 video compression technology. Now you can enjoy these V I D E O realistic effects in the home, as if you were in a movie theater or concert hall. DVD players and the discs are coded by region.
Description —Front Panel— Power ( ) button Function button Open/Close button Disc Tray Standby indicator P.SCAN indicator DOLBY DIGITAL indicator DTS Disc indicator REPEAT indicator LINEAR PCM indicator TITLE indicator GROUP indicator CHAPTER indicator TRACK indicator PROGRAM indicator DSP indicator MPEG indicator DVD AUDIO indicator System Status Display...
Connecting the Speakers Before moving or installing the product, be sure to turn off the power and disconnect the power cord. Position of the DVD Player Selecting the Listening Position • Place it on a stand or cabinet shelf, or under The listening position should be located about 2.5 to 3 the TV stand.
Connecting the Video Out to TV Choose one of the three methods for connecting to a TV. METHOD 2 METHOD 1 Composite Video ... Good Quality METHOD 1 Connect the supplied video cable from the VIDEO OUT jack on the back panel of the system to the VIDEO IN jack on your television.
Connecting External Component Connecting an External Analog Component Example: Analog signal components such as a VCR or TV. Audio Cable (not supplied) If the external analog component has only one Audio Out, connect either left or right. Connect Audio In on the DVD player to Audio Out on the external analog component. •...
Disc Playback Press OPEN/ Load a disc. CLOSE button to open the disc tray. • Place a disc gently into the tray with the disc’s label facing up. Note • Depending on the content of the disc, the initial screen may appear different. To stop playback, press STOP during playback.
DivX Playback Skip Forward/Back During playback, press the button. • Go to the next file whenever you press button, if there are over 2 files in the disk. • Go to the previous file whenever you press button, if there are over 2 files in the disk.
JPEG File Playback Images captured with a digital camera or camcorder, or JPEG files on a PC can be stored on a CD and then played back with this DVD player. Press the OPEN/CLOSE button to open the disc tray, and then load the JPEG disc. •...
Fast/Slow Playback Fast Playback Slow Playback Press SLOW button. Press and hold • Each time the button is pressed during playback, • Each time the button is held down during playback, the playback speed changes as follows: the playback speed changes as follows: Skipping Scenes/Songs Briefly press •...
A-B Repeat Playback You can repetitively play back a designated section of a DVD. Press Cursor Press INFO button to move to REPEAT twice. PLAYBACK ( • For a VCD or CD, press INFO button once. Press Cursor buttons Press ENTER to select ‘A-’...
Zoom (Screen Enlarge) Function This function allows you to enlarge a particular area of the displayed image. Press Cursor Press ZOOM buttons to button. move to the area you want to enlarge. SELECT ZOOM POSITION EZ VIEW Function Press EZ VIEW button. •...
Moving Directly to a Scene/Song Moving to a Title/Track Press Cursor , buttons or numeric buttons to select Press INFO button. the desired title/track and then press ENTER button. 01/05 001/040 0:00:37 03/05 001/002 0:00:01 Moving to a Chapter Moving to a Specific Time Press Cursor Press Cursor , buttons or numeric buttons...
Setting the Language OSD (On-Screen Display) language is set to English by default. In Stop mode, press MENU button. Note • To select other language, select OTHER and enter the language code of your country. (See 59 page for language code of countries) AUDIO, SUB TITLE and DISC MENU language can be selected.
Setting TV Screen type Depending on your TV type (Wide Screen TV or conventional 4:3 TV), you can select the TV's aspect ratio. In Stop mode, press MENU button. Press Cursor button to move to ‘TV DISPLAY’ and then press ENTER button. Press RETURN button to return to the previous level.
Setting Parental Controls (Rating Level) Use this to restrict playback of adult or violent DVDs you do not want children to view. In Stop mode, press MENU button. Press Cursor Press Cursor , button button to move to to select the desired rating ‘PARENTAL’...
You can set up to three wallpapers by repeating operation Note from Step1 to Step 3. Select this to set the Select this to set the desired Samsung Logo image as image as your wallpaper. your wallpaper. JPEG To Change the Wallpaper...
Setting the Speaker Mode Signal outputs and frequency responses from the speakers will automatically be adjusted according to your speaker configuration and whether certain speakers are used or not. Press Cursor In Stop mode, button to move to press MENU ‘Audio’...
Setting the Delay Time If the speakers cannot be placed at equal distances from the listening position, you can adjust the delay time of the audio signals from the center and rear speakers. In Stop mode, press MENU button. Setting up the Speaker Delay Time When 5.1CH Surround Sound is played, you can enjoy the best sound if the distance between you and each speaker is the same.
Setting the Audio Quality You can adjust the balance and level for each speaker. When adjusting the audio quality using the setup screen Method 1 In Stop mode, press MENU button. Press Cursor button to move to ‘SOUND EDIT’ and then press ENTER button.
Setting the DRC (Dynamic Range Compression) You can use this function to enjoy Dolby Digital sound when watching movies at low volume at night. Press Cursor In Stop mode, button to move to press MENU ‘Audio’ and then press ENTER button.
Dolby Pro Logic II Mode You can select the desired Dolby Pro Logic II audio mode. Press PL II MODE button. • Each time the button is pressed, the mode changes as follows. Note • When selecting Pro Logic II mode, connect your external device to the AUDIO INPUT jacks (L and R) on the player.
Sound Field (DSP)/EQ Function DSP(Digital Signal Processor) DSP modes have been designed to simulate different acoustic environments. EQ: You can select from ROCK, POP, or CLASSIC, depending on the genre of music. Press DSP/EQ button. • "DSP" appears on the display panel. •...
Listening to Radio You can listen to the chosen band (FM broadcast stations) by using either the automatic or manual tuning operation. Remote Control Unit Press TUNER Tune in to the button. desired station. • Automatic Tuning 1 When is pressed, a The selection toggles back and preset broadcast station is forth between "FM"...
About RDS broadcasting Using the RDS (Radio Data System) to receive FM stations RDS allows FM stations to send an additional signal along with their regular program signals. For example,the stations send their station names,as well as information about what type of program they broadcast, such as sports or music,etc.
Adjusting Display Brightness You can adjust the brightness of the display on the main unit so it won't interfere with your movie viewing. Press DIMMER button. • Each time the button is press, the brightness changes as follows: DARK BRIGHT. Mute Function This is useful when answering a doorbell or telephone call.
Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not listed below or if the instruction below does not help, turn off the unit, disconnect the power cord, and contact the nearest authorized dealer or Samsung Electronics Service Center. Symptom Check/Remedy Disc tray does not open.
Language Code List Enter the appropriate code number for the initial settings “Disc Audio”, “Disc Subtitle” and/or “Disc Menu” (See page 31). Code Language Code Language Code 1027 Afar 1181 Frisian 1334 1028 Abkhazian 1183 Irish 1345 1032 Afrikaans 1186 Scots Gaelic 1347 1039...
Page 32
HT-TP12 5.1ch speaker system Speaker system Front speaker Rear speaker mpedance 4Ω x 2 4Ω x 2 150Hz~20kHz Frequency range 150Hz~20kHz 85dB/W/M 85dB/W/M Output sound pressure level Rated input Maximum input 85 x 1050 x 90 mm 90 x 107 x 95 mm Dimensions (W x H x D) Weights 3.1 Kg / 2.95 Kg...
