Bosch Active Line Original Operating Instructions page 138

English – 2
(6) Holder
(7) Select button
(8) Diagnostics connection (for servicing purposes
only)
(9) Button for decreasing assistance level –/
walk assistance
(10) Button for increasing assistance level +/
bicycle lights
(11) Button to reduce brightness/
go back
(12) Button to increase brightness/
go forward
Technical data
Operating unit
Product code
Max. charging current of USB
port
A)
USB port charging voltage
USB charging cable
B)
Charging temperature
Operating temperature
Storage temperature
Diagnostic interface
Internal lithium-ion battery
Protection rating
Dimensions (without fastening)
Weight
Bluetooth® Low Energy 5.0
– Frequency
– Transmission power
A) Specification for charging the LED Remote operating unit; ex-
ternal devices cannot be charged.
B) Not included with the product as standard
C) USB Type-C® and USB-C® are trademarks of USB Implementers
Forum.
The licence information for the product can be accessed at the follow-
ing Internet address: www.bosch-ebike.com/licences
Declaration of Conformity
Robert Bosch GmbH, Bosch eBike Systems, hereby declares
that the LED Remote radio communication unit complies
with Directive 2014/53/EU. The full text of the EU Declara-
tion of Conformity can be accessed at the following Internet
address: www.bosch-ebike.com/conformity.
Robert Bosch GmbH, Bosch eBike Systems, hereby declares
that the LED Remote radio communication unit complies
with the Radio Equipment Regulations 2017 (SI
2917/1206). The full text of the UK Declaration of Conform-
ity can be accessed at the following Internet address:
www.bosch-ebike.com/conformity.
136
0 275 007 3RL | (21.02.2023)
LED Remote
BRC3600
mA
A) V
USB Type-C®
°C
°C –5 to +40
°C +10 to +40
USB Type-C®
V
mAh
mm 74 × 53 × 35
g
MHz 2400–2480
mW
Operation
Requirements
The eBike can then only be switched on when the following
requirements are met:
– A sufficiently charged eBike battery is inserted (see oper-
ating instructions for the eBike battery from the system
generation the smart system).
– The speed sensor is connected properly (see operating
instructions for the drive unit from the system genera-
tion the smart system).
Before riding off, ensure that the buttons on the operating
unit are within easy reach. We recommend that you align the
unit so that the plus/minus button level is perpendicular to
the floor.
600
Operating unit power supply
5
If a sufficiently charged eBike battery is inserted into the
eBike and the eBike is switched on, then the internal operat-
C)
ing unit battery is powered and charged.
0 to +45
If the state of charge of the internal operating unit battery is
very low, you can charge it via the diagnostics connec-
tion (8) with a USB Type-C® cable using a power bank or an-
other suitable power source (charging voltage 5 V V; char-
C)
ging current max. 600 mA mA).
3.7
Always close the flap of the diagnostics connection (8) so
75
that no dust or moisture can enter.
IP55
Switching the eBike On and Off
30 To switch on the eBike, briefly press the on/off button (2).
After the starting animation, the state of charge of the eBike
battery is displayed in colour with the battery charge indic-
ator (3) and the set assistance level with the (5) display. The
1
eBike is ready to ride.
The display brightness is controlled by the ambient light
sensor (1). Therefore, do not cover the ambient light
sensor (1).
The drive is activated as soon as you start pedalling (except
at assistance level OFF). The drive power varies depending
on the assistance level set.
As soon as you stop pedalling when in normal operation, or
as soon as you have reached a speed of 25/45 km/h, the
drive switches off the assistance. The drive is automatically
reactivated as soon you start pedalling again and the speed
is below 25/45 km/h.
To switch off the eBike, press the on/off button (2) briefly
(< 3 s). The battery charge indicator of the eBike battery (3)
and the assistance level LED (5) go out.
If no power is drawn from the drive for about 10 minutes
(e.g. because the eBike is not moving) and no button is
pressed, the eBike will switch off automatically.
