- Page 1 EQAXF01BXWT USER MANUAL...
- Page 2 This label will be used by an ELECTROLUX authorized service representative in the event that your water dispenser needs service. Environmental Notice The packaging material used is recyclable.
-
Page 3: Table Of Contents
Contents Water dispenser information ............Precautions ................. Illustration ................... Using your water dispenser ............Operation instructions ............... Cleaning and maintenance ..............Trouble Shooting ................Circuit diagram ................Technical Information ............... Customer Care ................Attention Do not try to install or turn on the unit without having read the indicated safety precautions in this manual. -
Page 4: Water Dispenser Information
Water dispenser information 1. This unit is designed for drinkable water only. Put bottles as specified inside the cabinet before using. 2. This unit should be used in an environment with temperatures ranging from 10°C to 43°C with a relative humidity not higher than 90%. 3. -
Page 5: Precautions
Precautions For children 1. Destroy the carton, plastic bag and other packing materials after the dispenser is unpacked. Children might use them for play. 2. Children require supervision when using the dispenser. 3. Recommend to install the anti-tilt bracket at the back side of this water dispenser to prevent the dispenser from falling down which could cause injury.(Fig. - Page 6 7. Do not pull out or insert the plug with wet hands to avoid electric shock.(Fig. 3) 8. Use the switch when turning the heating/ cooling On/Off. Locate on the left back side of water dispenser.(page 6) 9. Do not fasten, twist or tie the power cord. if the power cord is damaged, it should be replaced by the manufacturer, service technician or a qualified person to prevent...
-
Page 7: Illustration
Illustration (FRONT) (REAR) indicator light button of hot water button of normal water cooling switch button of cold water heating switch power cord panel spout drain hole front carapace condenser drip tray... -
Page 8: Using Your Water Dispenser
Using your water dispenser Locate dispenser 1. Place dispenser upright. 2. Locate dispenser on a hard and level surface in a cool shaded location near a grounded socket. Do not plug in power cord yet. 3. Position dispenser so the back is at least 20 cm from wall and there are at least 20 cm of clearance on both sides. -
Page 9: Operation Instructions
Provide electricity Plug cord into a properly grounded socket. At this time the pump will begin to move water from the bottle to the hot and cold tanks. It will take up to approximate 5 minutes to fill the tanks for the first time. - Page 10 Dispensing cold water After setup, it will take up to approximate 1 hour get water to maximum cold temperature. During this time the compressor could run continuously. This is normal. 1. Position bottle, glass, pitcher or cooking pot below spout. 2.
-
Page 11: Cleaning And Maintenance
Changing bottles A flashing orange light on your function lights alerts you when your bottle is empty. Replace the bottle as soon as possible. Do not dispense hot, cool or cold water if the orange light is flashing as you could empty the tanks and cause the dispenser to overheat. - Page 12 Sanitizing The machine should be disinfected with disinfectant separately bought from drugstore or marketplace according to the instruction manual of the disinfectant and then clean it with water (see cleaning and draining instructions). Generally this should be done every three months.
-
Page 13: Trouble Shooting
Trouble Shooting Before calling your service representative check the following items: Water dispenser does not work • Make sure the water dispenser is properly connected to a working socket and the heating/cooling switches are set ON. Water is leaking • Unplug the water dispenser, remove bottle and replace with new one. •... -
Page 14: Circuit Diagram
COMP EARTH FLOAT KEY1 KEY2 L_HEATER1 L_HEATER2 N_HEATER2 Hot Thermostat 1 Hot Thermostat 2 HEATER N_HEATER1 Technical Information EQAXF01BXWT Model Power supply Cooling Power 100W Heating Power 420W Hot Water 4L/h(≥90°C) Cold Water 2L/h(≤10°C) Room Temperature Operation 10-43°C Relative Humidity ≤90%... -
Page 15: Customer Care
