  • Page 1 EGT7353NOK User Manual...

  • Page 2: Table Of Contents

    10. ENERGY EFFICIENCY.................. 18 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.
  • Page 3 ENGLISH instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety This appliance can be used by children aged 8 years • and above and by persons with reduced capabilities provided that they have been given instruction and/or supervision regarding the safe use of the appliance and understand the potential hazards involved.
  • Page 4 CAUTION: The cooking process has to be supervised. • A short term cooking process has to be supervised continuously. WARNING: Danger of fire: Do not store items on the • cooking surfaces. Metallic objects such as knives, forks, spoons and lids •...

  • Page 5: Safety Instructions

    ENGLISH appliance. The use of inappropriate guards can cause accidents. 2. SAFETY INSTRUCTIONS 2.2 Electrical Connection This appliance is suitable for the following markets: GB IE WARNING! Risk of fire and electrical 2.1 Installation shock. WARNING! • All electrical connections should be Only a qualified person must made by a qualified electrician.
  • Page 6 • Set the cooking zone to “off” after installation. each use. • If the mains socket is loose, do not • Do not put cutlery or saucepan lids on connect the mains plug.

  • Page 7: Installation

    ENGLISH • Make sure the flame does not go out • Deactivate the appliance and let it when you quickly turn the knob from cool down before you clean it. the maximum to the minimum • Disconnect the appliance from the position.
  • Page 8 Provision for ventilation Make sure that, once the hob is installed, Detailed recommendations are contained it is easily accessible for the engineer in in the following British Standards Codes the event of a breakdown. Of Practice: B.S. 6172/B.S. 5440, Par. 2 The manufacturer will not accept liability, and B.S.
  • Page 9 ENGLISH CAUTION! Failure to ensure the correct assembly will cause leakage of gas. CAUTION! Make sure that the gas supply pressure of the appliance obeys the recommended values. 5. If you change: • from natural gas G20 20 mbar to Rigid connection: liquid gas, fully tighten the bypass Carry out connection by using metal rigid...
  • Page 10 The manufacturer refuses Green and yellow - Earth to be held responsible, if these safety measures are Blue - Neutral not abided by. Brown - Live Supply connections This hob has to be connected to 220-240 WARNING! V (~ 50/60 Hz ) electricity supply.
  • Page 11 ENGLISH 2. Connect the blue (neutral) wire to the terminal which is marked with the letter 'N' or coloured blue. 3. Connect the brown (live) wire to the terminal which is marked with the 400 mm letter 'L'. It must always be connected to the network phase.

  • Page 12: Product Description

    30 mm min 20 mm (max 150 mm) 60 mm A. Removable panel B. Space for connections CAUTION! Install the appliance only on a worktop with flat surface. Kitchen unit with oven The electrical connection of the hob and 3.9 Possibilities for insertion...

  • Page 13: Daily Use

    ENGLISH 4.2 Control knob Symbol Description Symbol Description ignition position / maxi‐ mum gas supply no gas supply / off posi‐ tion minimum gas supply 5. DAILY USE D. Thermocouple WARNING! Refer to Safety chapters. 5.2 Ignition of the burner 5.1 Burner overview Always light the burner before you put on the...

  • Page 14: Hints And Tips

    CAUTION! The spark generator can In the absence of electricity start automatically when you you can ignite the burner switch on the mains, after without electrical device; in installation or a power cut. It this case approach the is normal.

  • Page 15: Care And Cleaning

    ENGLISH Burner Diameter of Burner Diameter of cookware cookware (mm) (mm) Semi-rapid (rear left) 120 - 220 Semi-rapid (front left) 120 - 240 Semi-rapid (rear right) 120 - 220 Auxiliary 80 - 180 7. CARE AND CLEANING remove stubborn stains with a paste WARNING! cleaner.

  • Page 16: Troubleshooting

    8. TROUBLESHOOTING WARNING! Refer to Safety chapters. 8.1 What to do if... Problem Possible cause Remedy There is no spark when The hob is not connected Check if the hob is correct‐ you try to activate the to an electrical supply or it ly connected to the electri‐...

  • Page 17: Technical Data

    ENGLISH 8.3 Labels supplied with the accessories bag Stick the adhesive labels as indicated below: MOD. MOD. MOD. TYPE PROD.NO. IP20 PROD.NO. PROD.NO. SER.NO. 0049 SER.NO SER.NO 03 IT DATA DATA MADE IN ITALY A. Stick it on Guarantee Card and send C.

  • Page 18: Energy Efficiency

    NOMINAL GAS FLOW g/h POWER POWER MARK G30 28-30 G31 37 mbar mbar Triple Crown Semi-rapid 0,45 Auxiliary 0,33 10. ENERGY EFFICIENCY 10.1 Product information according to EU 66/2014 Model identification EGT7353NOK Type of hob Built-in hob Number of gas burners...
  • Page 19 ENGLISH Left rear - Semi-rapid 61.2% Right rear - Semi-rapid 61.2% Energy efficiency per gas burner Centre middle - Triple Crown 56.4% (EE gas burner) Left front - Semi-rapid 56.7% Right front - Auxiliary not applicable Energy efficiency for the gas hob 58.9% (EE gas hob) EN 30-2-1: Domestic cooking appliances burning gas - Part 2-1 : Rational use of...
  • Page 20 www.electrolux.com/shop...
