- Page 1 Washer dryer WD14U540ES siemens-home.bsh-group.com/welcome Register your product online...
- Page 2 Your new washer dryer Note/tip Information about the optimum use of You have chosen a Siemens washer the appliance/any other useful dryer. information. Please take a few minutes to read and 1. 2. 3. / a) b) c) become familiar with the advantages of your washer dryer.
-
Page 3: Table Of Contents
Contents e n I n s t r u c t i o n M a n u a l a n d I n s t a l l a t i o n I n s t r u c t i o n s Dyeing/bleaching . -
Page 4: Intended Use
Intended use Cleaning and maintenance . . . 41 Intended use Appliance housing/control panel . . . 41 Drum ......41 This appliance is intended for private ■... -
Page 5: Safety Instructions
Safety instructions Do not allow children to Safety instructions ■ clean or maintain this appliance unsupervised. T he following safety information Keep children under 3 years S a f e t y i n s t r u c t i o n s and warnings are provided to ■... -
Page 6: Installation
Safety instructions Warning Installation Risk of suffocation! Warning If allowed to play with the Risk of electric shock/fire/ packaging/plastic film or material damage/damage to packing components, children the appliance! may become caught in these or If the appliance is not installed pull them over their heads and properly, this may lead to a suffocate. - Page 7 Safety instructions The mains plug must be Warning ■ freely accessible at all times. Risk of fire/material damage/ If this is not possible, in damage to the appliance! order to comply with the The use of extension cords or relevant safety regulations, a power strips may result in fire switch (all pole due to overheating or short...
- Page 8 Safety instructions If the water hoses are altered Warning ■ or damaged, this may result Risk of injury! in material damage or The appliance is very heavy. ■ damage to the appliance. Lifting it may result in injury. The water hoses must not be Do not lift the appliance on kinked, crushed, altered or your own.
-
Page 9: Operation
Safety instructions Certain objects may ignite Operation ■ when drying is in progress, Warning or even cause the appliance Risk of explosions/fire! to catch fire or explode. Laundry that has come into Remove any lighters or contact with solvents, oil, wax, matches from pockets on wax remover, paint, grease or items of clothing. - Page 10 Safety instructions Warning Warning Risk of poisoning! Eye/skin irritation! Poisonous fumes may be given Detergent and care products off by cleaning agents that may spray out if the detergent contain solvents, e.g. cleaning drawer is opened while the solvent. appliance is in operation. Do not use cleaning agents that Rinse eyes/skin thoroughly if contain solvents.
-
Page 11: Cleaning/Maintenance
Safety instructions If you pour the wrong Repairs and any other work ■ ■ quantity of detergent or on the appliance must only cleaning agent into the be conducted by our appliance, this may result in customer service or by an material damage or damage electrician. -
Page 12: Environmental Protection
Environmental protection Warning Environmental Risk of injury/material protection damage/damage to the appliance! P ackaging/used appliance The use of spare parts and E n v i r o n m e n t a l p r o t e c t i o n accessories supplied by other Dispose of packaging in an environmentally-responsible... -
Page 13: Positioning And Connecting
Positioning and connecting Energy-saving mode: If the ■ Positioning and appliance is not operated for a prolonged period (approx. 5 connecting minutes), the Touch-Display lighting goes out before the programme S tandard accessories starts and when the programme has P o s i t i o n i n g a n d c o n n e c t i n g ended to save energy, # flashes. -
Page 14: Safety Instructions
Positioning and connecting When the appliance is lifted by its Mains lead ■ protruding parts (e.g. the appliance Bag: door), the components may break Installation and operating ■ off and cause injuries. instructions Do not lift the appliance by Customer Service location protruding parts. -
Page 15: Installation On A Base Or A Wooden Joist Floor
Positioning and connecting Installation on a base or a Removing the transport locks wooden joist floor Caution! Damage to the appliance Caution! The appliance is secured for Damage to the appliance ■ transportation using transport locks. The appliance may "wander" and tip/ If the transport locks are not topple from the base when spinning. -
Page 16: Hose And Cable Lengths
Positioning and connecting Unscrew and remove all four Lock the covers firmly in place by transport brace screws. applying pressure to the snap-in hooks. a) Remove the mains cable from the Hose and cable lengths holders. Connection on left side b) Remove the sleeves. -
Page 17: Water Inlet
Positioning and connecting Do not use a used supply hose. Only ■ use the supply hose supplied or one Connection on right side that was purchased from an authorised specialist retailer. Do not bend, squash, modify or cut ■ through the water supply hose (otherwise its strength is no longer guaranteed). -
Page 18: Water Outlet
Positioning and connecting – Model: AquaSecure Do not reach into the hot water. Caution! Water damage If the drain hose slips out of the washbasin or the connection point during draining due to high water pressure, any escaping water may cause water damage. -
Page 19: Alignment
Positioning and connecting Loosen the lock nuts using a Drainage into a siphon ■ The connection point must be wrench, by turning it in a clockwise secured using a hose clamp with a direction. diameter of 24 - 40 mm (available from specialist dealers). -
Page 20: Electrical Connection
Positioning and connecting Electrical connection Before washing for the first time Warning The appliance was inspected Risk of death! thoroughly before leaving the factory. To There is a risk of electric shock if you remove any residual test water, run the touch live components. -
Page 21: Transportation
Positioning and connecting Transportation a) Clip the hoses securely in the holders. e.g. when moving home Preparatory work: Turn off the water tap. Reduce the water pressure in the supply hose. ~ Page 43 Drain any residual water. ~ Page 42 Disconnect the appliance from the mains. -
Page 22: Getting To Know The Appliance
Getting to know the appliance Getting to know the appliance A ppliance G e t t i n g t o k n o w t h e a p p l i a n c e Detergent drawer Control panel/touch display Loading door Service flap... -
Page 23: Control Panel
Getting to know the appliance Control panel ( Programmes that can be selected. 0 Touch-Display 8 Start/Pause button Touch I button to start, interrupt (e.g. reload washing) and cancel the programme. @ Power button Press the # button to switch the appliance on/off. -
Page 24: Touch-Display
Getting to know the appliance Touch-Display Additional programme settings Programme default settings Display Setting Wash+Dry Display Setting Description Ž - 90° Temperature Temperature that ¾ (Cupboard can be set in °C dry+) Ž = cold » (Cupboard dry) 2 - 1400* Spin speed Spin speed in rpm Ø... -
Page 25: Laundry
Laundry Do not exceed maximum load. Status indicators for the programme ■ Overfilling will impair the washing progress (programme sequence) result. Keep detergents and agents for the ■ pretreatment of laundry (e.g. stain remover, prewash sprays, etc.) away from the surfaces of the appliance. Using a damp cloth, immediately remove any fine spray residue and other residue or droplets. -
Page 26: Preparing Laundry For Drying
Laundry – Heavy: Load less laundry, need The following textiles must not be dried: to pretreat or soak laundry firstly. b = care symbol “Do not dry” ■ – Stains: Remove/pretreat stains Delicates (silk, synthetic curtains). ■ while they are fresh. First dab Textiles which contain foam rubber ■... -
Page 27: Overview Of Programmes
Overview of programmes Overview of programmes S electable programme O v e r v i e w o f p r o g r a m m e s Programme/Type of laundry Options/Information Name of the programme Max. load for washing/ Max. - Page 28 Overview of programmes Programme/Type of laundry Options/Information delicado/seda (Delicates/Silk) Max. 2.0 kg/- For delicate, washable fabrics, e.g. made of silk, satin, synthetic Ž - 40 °C fibres or blends (e.g. silk blouses, silk scarves). 2 - 800 rpm ( Speed, ¦ Eco, z (Water plus), Ý...
- Page 29 Overview of programmes Programme/Type of laundry Options/Information limp. tambor (Drum Clean) Max. 0.0 kg/0.0 kg Special programme for drum hygiene or fluff removal. Do not Ž, 40°C, 90 °C load any laundry. 1200 90°C = antibacterial programme. â (Memory), ç (Silent) 40°C = antibacterial programme, special drum cleaning deter- gent can be used.
- Page 30 Overview of programmes Programme/Type of laundry Options/Information camisas/business (Shirts) Max. 2.0 kg/2.0 kg Non-iron shirts or blouses made of cotton, linen, synthetic fibres Ž - 60 °C or blended fabrics. 400 - 800 rpm ( Speed, ¦ Eco, z (Water plus), Ý...
-
Page 31: Drying Table
Overview of programmes Drying table Estimated drying time (min) Recommended drying Option Drying load Ø (Iron » (Cup- ¾ (Cup- programme (kg) dry) board dry) board dry+) algodón/algodão (Cot- ( Speed 1.0-2.0 40-50 50-70 65-90 tons)/toallas/toalhas 2.0-4.0 50-75 70-95 90-135 (Towels)/higiene plus 4.0-6.0 75-90... -
Page 32: Programme Default Settings
Programme default settings To do this: Programme default Select a programme (except myTime » programme). settings The programme duration is displayed for the selected Y ou can change the default settings for programme, e.g. 2:30 P r o g r a m m e d e f a u l t s e t t i n g s selected programmes. -
Page 33: Additional Programme
Additional programme settings ( Speed Additional programme Washing/drying in a shorter time while settings achieving a washing/drying result that is consistent with the normal performance. You can find possible N ote: A d d i t i o n a l p r o g r a m m e s e t t i n g s programme additional settings in the Touch ( Speed to activate or deactivate this additional programme... -
Page 34: L (Rinse Plus)
Operating the appliance l (Rinse plus) ç (Silent) Additional rinse cycle depending on the Special designed function for noise programme; longer programme length reduction. Washing and drying process for particularly sensitive skin and/or for noise will be reduced, and ending areas with very soft water. -
Page 35: Switching On The Appliance/Selecting A Programme
Operating the appliance Turn the water tap on. Placing laundry into the drum Insert the laundry. Close the door. Open the appliance door. Switching on the appliance/ Notes selecting a programme Unfold and load presorted items ■ of laundry. Mix large and small Press the # button till the indicator items. -
Page 36: Dosing And Adding Detergent And Care Product
Operating the appliance Dosing and adding detergent Pour in detergent and/or cleaning product. and care product Caution! Damage to the appliance Detergents and agents for the pretreatment of laundry (e.g. stain remover, prewash sprays, etc.) may damage the surfaces of the washer dryer. -
Page 37: Starting The Programme
Operating the appliance Reinsert the drawer. Note: Foam detection If the symbol o also lights up in the Touch-Display, the appliance has detected too much foam during the wash cycle and automatically activated additional rinse cycles to remove the foam. If you want to lock the programme to prevent it from being adjusted inadvertently, you can select the... -
Page 38: Adding/Removing Laundry
Operating the appliance Adding/removing laundry For programmes washing at low temperatures: After starting the programme, you can Touch the I button. add or remove laundry if necessary. Select 0. Touch the I button. Touch the I button. The appliance checks whether reloading is possible. For programmes in drying process: Switch the appliance off. -
Page 39: Appliance Settings
Appliance settings Turn off the water tap. Basic settings Not required for Aqua-Stop Note: To access the basic settings, touch and models. hold the ç (Silent) button for approx. 3 seconds. The control panel show: Notes Do not leave any items of laundry in ■... -
Page 40: Sensors
Sensors Button signal Switching the drum-care information signal on/off You can select position 2 and use the ˜ button to adjust the volume of the You can select position 4 and use the ˜ button signal, e.g. ›- „. button to switch the limp. tambor (Drum Clean) information signal on or off, e.g. -
Page 41: Cleaning And Maintenance
Cleaning and maintenance Drum Cleaning and Use chlorine-free cleaning agents, do maintenance not use steel wool. If there are odours in the appliance, or Warning C l e a n i n g a n d m a i n t e n a n c e to clean the drum, run the limp. -
Page 42: Drain Pump Is Blocked
Cleaning and maintenance Clean the detergent dispenser tray Drain pump is blocked and insert with water and a brush, and dry it. Clean the inside of the Turn the water tap off to prevent Note: housing as well. more water from flowing in and to ensure that it is drained via the pump. -
Page 43: The Drain Hose At The Siphon Is Blocked
Cleaning and maintenance Carefully unscrew the pump cover; The drain hose at the siphon residual water may leak out. is blocked Clean the interior, pump cover thread and pump housing. The Press the # button. Pull out the impeller in the drain pump must be mains plug. -
Page 44: Faults And What To Do About
Faults and what to do about them Clean the filters: Faults and what to do Disconnect the hose from the rear of about them the appliance. E mergency release F a u l t s a n d w h a t t o d o a b o u t t h e m E.g. -
Page 45: Information On The Display Panel
Faults and what to do about them Press the # button. Pull out the Drain the water. ~ Page 42 mains plug. Pull the emergency release Open the service flap. downwards with a tool and release. The door can then be opened. Information on the display panel Display Cause/Remedy... -
Page 46: Faults And What To Do About Them
Faults and what to do about them Display Cause/Remedy The indicator lamp of Run the limp. tambor (Drum Clean) 90°C programme to clean and care for the the limp. tambor drum and the outer tub. (Drum Clean) pro- Notes gramme flashes Run the programme without laundry. - Page 47 Faults and what to do about them Faults Cause/Remedy The programme will not Have you touched the I button or selected f (Finish in) time? ■ start. Is the door closed? ■ Childproof lock activated? Deactivate childproof lock. ■ Shop mode activated? If the display shows àœ©˜ for 5 s after you have ■...
- Page 48 Faults and what to do about them Faults Cause/Remedy Odours, stain formation in Run the limp. tambor (Drum Clean) 90°C programme without laundry. the appliance. Add washing powder or a detergent containing bleach. To prevent foaming, only use half the amount of detergent recommend- Note: ed by the detergent manufacturer.
-
Page 49: After-Sales Service
After-sales service Faults Cause/Remedy The drying result is not After the end of the programme, warm laundry feels damper than it actu- ■ satisfactory (laundry is ally is. Spread the laundry out and allow the heat to disperse. not dry enough). Excessively high ambient temperature (above 30 °C) or inadequate ventila- ■... -
Page 50: Consumption Values
Consumption values Consumption values E nergy and water consumption, programme duration and residual moisture for C o n s u m p t i o n v a l u e s the main washing programme (approximate values) Programme Load Energy con- Water con- Programme... -
Page 51: Technical Data
Technical data Technical data D imensions: T e c h n i c a l d a t a 845 mm x 598 mm x 620 mm (height x width x depth) Weight: 84 kg Mains connection: Nominal voltage 220-240V, 50 Hz Minimum installation protection (c) 10 A Nominal power 1900-2300 W... - Page 52 01450 2655 (0.03 € per minute at peak. Off peak 0.0088 € per minute.) You can find the contact information for all countries in the attached after-sales service directory. BSH Hausgeräte GmbH Carl-Wery-Straße 34 81739 München GERMANY siemens-home.bsh-group.com *9001342802* 9001342802 (9801)
