Technical information and reports

10 Technical information and reports
10.1

Technical Data

Infrared panel Unit
version
Rated output of the W
panel
Operating voltage V 230 V AC
Current A 1,3 | 2,2 | 3,0
IP rating/protection IP
class
Connection cable –
conductor
cable for 1/N
230V/Hz
Weight kg 9 | 12 | 16 |
Table 20 Specifications for the panel
The panel can be installed on bases of flammability class A, B, C1 or C2.
10.2

Product data for energy consumption

The following product data satisfy the requirements of the EU Regulation
No. 2015/1188.
Product data
Heat output
Specified heat output
Minimum heat output
(indicative)
Maximum continuous output
Auxiliary electricity consumption
For rated heat output
At minimum heat output
In standby mode
Table 21 Product data for energy consumption
For all informations regarding the control unit, please consult the manual
of the controller.
Type of heat output/room temperature control
single-level heat output, no room temperature
control
two or more manually adjustable levels, no room
temperature control
heat output/room temperature control with
mechanical thermostat
with electronic room temperature control
electronic room temperature control and time-of-
day control
16
Glass Ceramic Metallic
version version
300W | 300W | 300W |
500W | 500W | 500W |
700W | 700W 700W |
850W 850W |
1000W
230 V AC 230 V AC
1,3 | 2,2 | 3,0 1,3 | 2,2 | 3,0
| 3,7 | 3,7 | 4,4
44/I 44/I 44/I
two- two- two-
conductor conductor
cable for 1/N cable for 1/N
230V/Hz 230V/Hz
10 | 14 | 19 5,5 | 10 | 13 |
22 15 | 16
Symbol Unit Infrared panel
P kW 0.3; 0.5; 0.7;
rated
0.85; 1.0
P KW 0.0
min
P KW 0.3; 0.5; 0.7;
max, c
0.85; 1.0
el KW 0.000
max
el KW 0.000
min
el kW 0.000
sb
Yes/No
Yes
No
No
No
No
Type of heat output/room temperature control
electronic room temperature control and weekday
control
Other control options
room temperature control with presence
detection
room temperature control with open window
detection
with remote control option
with adaptive control of heating start
with operating time limitation
with black bulb sensor
Table 22
Infrared panels – 6721851963 (2023/01)
No
No
No
No
No
No
No
