DVD VIDEO PLAYER
SERVICE MANUAL
MODEL : DF599 X (DF9912EH)
CAUTION
BEFORE SERVICING THE UNIT, READ THE "SAFETY PRECAUTIONS"
IN THIS MANUAL.
MARCH,2005
P/NO : 3829RHP040R

Advertisement

Table of Contents
loading

Related Manuals for LG DF599 X

Summary of Contents for LG DF599 X

  • Page 1 DVD VIDEO PLAYER SERVICE MANUAL MODEL : DF599 X (DF9912EH) CAUTION BEFORE SERVICING THE UNIT, READ THE “SAFETY PRECAUTIONS” IN THIS MANUAL. MARCH,2005 P/NO : 3829RHP040R...
  • Page 2 CONTENTS SECTION 1 ..SUMMARY SECTION 2 ..CABINET & MAIN CHASSIS SECTION 3 ..ELECTRICAL SECTION 4 ..REPLACEMENT PARTS LIST...

  • Page 3: Table Of Contents

    SECTION 1 SUMMARY CONTENTS PRODUCT SAFETY SERVICING GUIDELINES FOR VIDEO PRODUCTS ......1-3 SERVICING PRECAUTIONS ....................1-4 • General Servicing Precautions • Insulation Checking Prodedure • Electrostatically Sensitive Devices SPECIFICATIONS ........................1-5...

  • Page 4: Product Safety Servicing Guidelines For Video Products

    PRODUCT SAFETY SERVICING GUIDELINES FOR VIDEO PRODUCTS CAUTION : DO NOT ATTEMPT TO MODIFY THIS PRODUCT IN ANY WAY, SUBJECT : X-RADIATION NEVER PERFORM CUSTOMIZED INSTALLATIONS WITHOUT MANUFAC- 1. BE SURE PROCEDURES AND INSTRUCTIONS TO ALL SERVICE PER- TURER’S APPROVAL. UNAUTHORIZED MODIFICATIONS WILL NOT ONLY SONNEL COVER THE SUBJECT OF X-RADIATION.

  • Page 5: Servicing Precautions

    SERVICING PRECAUTIONS CAUTION : Before servicing the DVD covered by this service Electrostatically Sensitive (ES) Devices data and its supplements and addends, read and follow the Some semiconductor (solid state) devices can be damaged SAFETY PRECAUTIONS. NOTE : if unforeseen circum- easily by static electricity.

  • Page 6: Specifications

    SPECIFICATIONS • GENERAL Power requirements: AC 110-240 V , 50/60 Hz Power consumption: Dimensions (Approx.): 430 x 35 x 242 mm (W x H x D) without foot Weight (Approx.): 1.9 kg Operating temperature: 5 °C to 35 °C (41 °F to 95 °F) Operating humidity: 5 % to 90 % •...
  • Page 7 SECTION 2 CABINET & MAIN CHASSIS CONTENTS EXPLODED VIEWS ........................2-2 1. Cabinet and Main Frame Section ...................2-2 2. Deck Mechanism Section(DPS-02)..................2-3 3. Packing Accessory Section ....................2-4...

  • Page 8: Exploded Views

    EXPLODED VIEWS 1. Cabinet and Main Frame Section...

  • Page 9: Deck Mechanism Section(Dps-02)

    2. Deck Mechanism Section(DPS-02)

  • Page 10: Packing Accessory Section

    3. Packing Accessory Section RF CABLE 810 CABLE SET ASS’Y PLUG ASS’Y 1WAY(YELLOW) PLUG ASS’Y 2WAY BATTERY PLUG ASS’Y 1WAY(BLACK) REMOCON OWNER’S MANUAL PACKING SHEET PACKING PACKING AC ADAPTOR BOX CARTON OPTIONAL PARTS...
  • Page 11 SECTION 3 ELECTRICAL CONTENTS ELECTRICAL TROUBLESHOOTING GUIDE ..............3-2 1. Power check flow........................3-2 2. System operation flow ......................3-3 3. Test & debug flow ........................3-4 DETAILS AND WAVEFORMS ON SYSTEM TEST AND DEBUGGING ....3-10 1. SYSTEM 27MHz CLOCK, RESET, FLASH R/W SIGNAL.............3-10 2.

  • Page 12: Electrical Troubleshooting Guide

    ELECTRICAL TROUBLESHOOTING GUIDE 1. Power check flow No 3.3VA No REG 5.0V Is the FR101 Replace the FR101 Is the Vcc(=5.6V) sup- Check or Replace Normal? (Use the same ICW) plied to Q126 Collector? the D123 Is the D105/ D106/ Replace the D105/ Is the Vcc(=12V) sup- Check the ‘PWR CTL...

  • Page 13: System Operation Flow

    2. System operation flow Power On 1. 8032 initializes SERVO,DSP & RISC registers 2. Write RISC code to SDRAM 3. Reset RISC Show LOGO Exist Disc Disc loading SLED at Inner Side ? SLED Moves to Inner Position 1. Judge whether have disc and disc type 2.

  • Page 14: Test & Debug Flow

    3. Test & debug flow TEST Check the AC Voltage Replace power PCBA or AC transformer. Power PCBA(110V or 220V) Switch on the Power PCBA Is the DC Voltage outputs OK? Repair or Replace Power PCBA (5V, 3.3V, 12V,5.6V MOTOR) Make sure the main PCBA don't short on VCCs and switch it on.
  • Page 15 Check connection lines between Flash Memory operates Show LOGO? FLASH & MT1389B and the FLASH properly? access time whether is suitable or not. Check connection lines SDRAM works properly? between SDRAM & MT1389B and the SDRAM is damaged. MT1389B VIDEO outputs Check the related circuit of properly? MT1389B.
  • Page 16 Does the SLED move to Motor Driver STBY Pin is Check the connection line of inner side when it is at outter High? STBY signal. position? Is FMSO DC Level higher Check the related circuit of than 1.4V? FMSO. SL+ and SL- output Check the amp circuit on properly? motor driver.
  • Page 17 Check the laser power circuit Laser turns on when LD01 or LD02 output on MT1389B and connecting reading disc? properly? to power transistor. Collector voltage of Check the related circuit on power transistor is OK? laser power transistor Check cable connection between transistor ouput and pick-up head.
  • Page 18 Proper signals on A, B, C, Check connections between Focus ON OK? D of MT1389B MT1389B and pick-up head. Check the FOSO Check FEO signal on connection on MT1389B MT1389B and motor driver. Check FOSO signal on MT1389B Normal TEO Signal on Check the related Track On OK? MT1389B?
  • Page 19 Normal Audio output Audio DAC received Check connection between when disc playback? correct data stream? MT1389B & Audio DAC. Check the related circuit of Normal Audio DAC out? Audio DAC. Check Audio filter, amplify,mute circuit. Communications between Normal IR.VFD & Front Check communication lines IR.VFD Front pannel key &...

  • Page 20: Details And Waveforms On System Test And Debugging

    DETAILS AND WAVEFORMS ON SYSTEM TEST AND DEBUGGING 1. SYSTEM 27MHz CLOCK,RESET,FLASH R/W SIGNAL. 1) MT1389B main clock is at 27MHz(X501) 1.0V, 27MHz FIG 1-1 2) MT1389B reset is low active. 3.3VA PWR_CTL RESET Reset Time FIG 1-2 3-10...
  • Page 21 3) RS232 waveform during procedure(Downloading) FIG 1-3 4) Flash R/W enable signal during download(Downloading) FIG 1-4 3-11...

  • Page 22: Sdram Clock

    2. SDRAM CLOCK DCLK = 128MHz, Vp-p=2.2, Vmax=2.7V FIG 2-1 3. LOADING CONTROL RELATED SIGNAL SEN_UNLOAD3 SEN_LOAD3 CLOSE_SW FIG 3-1 3-12...

  • Page 23: Sled Control Related Signal(No Disc Condition)

    4. SLED CONTROL RELATED SIGNAL (NO DISC CONDITION) FMSO(1.9V/1.4V/1.1V) STBY(3.3V) SL+(4.2V/2.8V/1.2V) SL-(4.2V/2.8V/1.5V) FIG 4-1 5. LENS CONTROL RELATED SIGNAL(NO DISC CONDITION) FOSO(1.5V/1.4V/1.3V) F+(3.2V/2.7V/2.2V) F-(3.2V/2.7V/2.2V) FIG 5-1 3-13...

  • Page 24: Laser Power Control Related Signal(No Disc Condition)

    6. LASER POWER CONTROL RELATED SIGNAL(NO DISC CONDITION) DCLK = 128MHz, Vp-p=2.2, Vmax=2.7V MDI1(0V/180mV) LD01(3.3V//2.3V) LD02(3.3V/2.3V) FIG 7-2 (DVD) 7. DISC TYPE JUDGEMENT WAVEFORM FIG 7-1 3-14...
  • Page 25 FIG 7-2 (DVD) FIG 7-3 (CD) 3-15...

  • Page 26: Focus On Waveform

    FIG 7-4 (CD) 8. FOCUS ON WAVEFORM FOSO FIG 8-1 (DVD) 3-16...

  • Page 27: Spindle Control Waveform

    FOSO FIG 8-2 (CD) 9. SPINDLE CONTROL WAVEFORM (NO DISC CONDITION) DMSO(1.4V/1.8V) SP-(3.6V/2.4V) SP+(3.6V/4.8V) FIG 9-1 3-17...

  • Page 28: Tracking Control Related Signal(System Checking)

    10. TRACKING CONTROL RELATED SIGNAL(System checking) TRSO FIG 10-1 (DVD) TRSO FIG 10-2 (CD) 3-18...

  • Page 29: Mt1389B Audio Optical And Coaxial Output (Spdif)

    11. MT1389B AUDIO OPTICAL AND COAXIAL OUTPUT (SPDIF) FIG 11-1 12. MT1389B VIDEO OUTPUT WAVEFORM 1) 100% FIG 12-1 3-19...

  • Page 30: Mt1389B Audio Output To Audio Dac

    2) COMPOSITE VIDEO SIGNAL FIG 12-2 13. MT1389B AUDIO OUTPUT TO AUDIO DAC ASDATA3 FIG 13-1 3-20...

  • Page 31: Audio Output From Audio Dac

    14. AUDIO OUTPUT FROM AUDIO DAC FIG 14-1 15. MEMORY SLOT DATA SIGNAL USBM USBP FIG 15-1 3-21...

  • Page 32: Memory Clock & Reset Signal

    16. MEMORY CLOCK & RESET SIGNAL X1001(12Mhz) IC1003 (3pin) RESETn (C1003 1pin) FIG 16-1 3-22...

  • Page 33: Block Diagrams

    BLOCK DIAGRAMS 1. Overall Block Diagram CVBS RESET 3-23...

  • Page 34: Power(Smps) Block Diagram

    2. Power(SMPS) Block Diagram TRANS SWITCHING IC AC100~240V π FILTER RECTIFIER 3-24...

  • Page 35: Servo Block Diagram

    3. SERVO Block Diagram 3-25...

  • Page 36: Mpeg & Memory Block Diagram

    4. MPEG & MEMORY Block Diagram 3-26...

  • Page 37: Video & Audio Block Diagram

    5. VIDEO & AUDIO Block Diagram 3-27...

  • Page 38: Circuit Diagrams

    2. Voltages are DC-measured with a digital voltmeter MODIFIED OR ALTERED WITHOUT PERMISSION IMPLEMENTATION OF THE LATEST SAFETY AND during Play mode. FROM THE LG ELECTRONICS CORPORATION. ALL PERFORMANCE IMPROVEMENT CHANGES INTO COMPONENTS SHOULD BE REPLACED ONLY WITH THE SET IS NOT DELAYED UNTIL THE NEW SERVICE TYPES IDENTICAL TO THOSE IN THE ORIGINAL CIR- LITERATURE IS PRINTED.

  • Page 39: Av/Jack Circuit Diagram

    2. AV/JACK CIRCUIT DIAGRAM 3-30 3-31...

  • Page 40: System Circuit Diagram

    3. SYSTEM CIRCUIT DIAGRAM 3-32 3-33...

  • Page 41: In 2 Memory Slot Circuit Diagram

    4. 9 IN 2 MEMORY SLOT CIRCUIT DIAGRAM 3-34 3-35...

  • Page 42: Timer Circuit Diagram

    5. TIMER CIRCUIT DIAGRAM 3-36 3-37...

  • Page 43: 1Ch & Karaoke(Karaoke Model Only) Circuit Diagram

    6. 5.1CH & KARAOKE(KARAOKE MODEL ONLY) CIRCUIT DIAGRAM 3-38 3-39...

  • Page 44: Scart Circuit Diagram

    7. SCART CIRCUIT DIAGRAM 3-40 3-41...

  • Page 45: Circuit Voltage Chart

    • CIRCUIT VOLTAGE CHART MODE MODE MODE MODE MODE MODE MODE MODE MODE MODE STOP PLAY STOP PLAY STOP PLAY STOP PLAY STOP PLAY STOP PLAY STOP PLAY STOP PLAY STOP PLAY STOP PLAY PIN NO. PIN NO. PIN NO. PIN NO.

  • Page 46: Printed Circuit Diagrams

    PRINTED CIRCUIT DIAGRAMS 1. MAIN P.C.BOARD 3-44 3-45...

  • Page 47: Key P.c.board

    2. KEY P.C.BOARD 3. TIMER P.C.BOARD ( TOP VIEW ) ( TOP VIEW ) ( BOTTOM VIEW ) ( BOTTOM VIEW ) 3-46 3-47...

  • Page 48: Smps P.c.board

    4. SMPS P.C.BOARD 5. MEMORY P.C.BOARD LOCATION GUIDE ( TOP VIEW ) (Solder Side) ( BOTTOM VIEW ) 3-48 3-49...
  • Page 49 6. I/O P.C.BOARD LOCATION GUIDE 3-50 3-51...
  • Page 50 RUN DATE : 15-MARCH-05 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS *** INDIVIDUAL PARTS *** 3110R-D023A CASE DV9000 B6432G PRESS WUTHOUT LG 3300R-D070A PLATE BRKT FRONT SLOT PRESS 4930R-0602A HOLDER DVD DF9900 MOLD MOMORY STICK 6410RCHX03A POWER CORD...
  • Page 51 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS 4680HP2009A MOTOR(MECH) AT-M12-0740 NMM N4 LOADING 4371H-1012A SHAFT ASSEMBLY SHAFT ASSY GEAR CRN-8242B *** PWB(PCB) ASSEMBLY,TOTAL *** 6871R-2322M PWB(PCB) ASSEMBLY,TOTAL DF9000S SMPS ASSY 1389B,C SLOT C101 624-088L CAPACITOR,DRAWING 435D SUNIL ELECTRONICS 0.1UF/2 C101 624-088S CAPACITOR,DRAWING...
  • Page 52 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS IC151 0IPMGKE008B IC,POWER MANAGEMENT KIA78R08PI/API CU KEC 4P TO-22 ALTERNATE IC151 0IPMGFA016A IC,POWER MANAGEMENT KA78R08TSTU FAIRCHILD 4P TO-22 ALTERNATE L101 6140RCC003J COIL,RF 4.7 MH PEAKING COIL OWA 67 X 7 L102 6140RCC003J COIL,RF 4.7 MH PEAKING COIL OWA 67 X 7...
  • Page 53 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS C909 0CH1104K942 CAPACITOR,FIXED CERAMIC(TEMP.C 0.1UF 50V 80%,-20% Y5V(F) 1608 IC901 0IPRPPY005A IC,PERIPHERALS PT6963 PTC 32PIN SO R/TP LED D IC901 0IPRPPY007A IC,PERIPHERALS PT6961 PTC 32PIN SOP R/TP LED ALTERNATE L901 6200HJC102A FILTER(CIRC),EMC HB-1M2012-102JT CERATECH TP R901...
  • Page 54 CAPACITOR,ELECTROLYTIC 220M SRA 6.3V M FM5 TP(5) C6W3 0CE1064F638 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) CN203 561-711D CONNECTOR (CIRC),HOUSING GIL-S-04P-S2T2-EF LG CABLE 4PI CN204 561-711E CONNECTOR (CIRC),WAFER GIL-S-05P-S2T2-EF LG CABLE 5PI CN501 6630R-FB10L CONNECTOR (CIRC),FFC/FPC 00-6232-012-006-800 ELCO 12PIN CN502...
  • Page 55 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS C519 0CH1104K942 CAPACITOR,FIXED CERAMIC(TEMP.C 0.1UF 50V 80%,-20% Y5V(F) 1608 C520 0CH1104K942 CAPACITOR,FIXED CERAMIC(TEMP.C 0.1UF 50V 80%,-20% Y5V(F) 1608 C521 0CH1104K942 CAPACITOR,FIXED CERAMIC(TEMP.C 0.1UF 50V 80%,-20% Y5V(F) 1608 C522 0CH1104K942 CAPACITOR,FIXED CERAMIC(TEMP.C 0.1UF 50V 80%,-20% Y5V(F) 1608 C523 0CH1104K942...
  • Page 56 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS C594 0CH4120K412 CAPACITOR,FIXED CERAMIC(HIGH D 12PF 50V 5% NP0 1608 R/TP C595 0CH4221K412 CAPACITOR,FIXED CERAMIC(HIGH D 220PF 50V 5% NP0 1608 R/TP C596 0CH1104K942 CAPACITOR,FIXED CERAMIC(TEMP.C 0.1UF 50V 80%,-20% Y5V(F) 1608 C597 0CH1104K942 CAPACITOR,FIXED CERAMIC(TEMP.C...
  • Page 57 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS L503 6200HJC102A FILTER(CIRC),EMC HB-1M2012-102JT CERATECH TP L504 6200HJC102A FILTER(CIRC),EMC HB-1M2012-102JT CERATECH TP L505 6200HJC102A FILTER(CIRC),EMC HB-1M2012-102JT CERATECH TP L509 6200HJC102A FILTER(CIRC),EMC HB-1M2012-102JT CERATECH TP L512 6200HJC102A FILTER(CIRC),EMC HB-1M2012-102JT CERATECH TP L601 6200HJC102A FILTER(CIRC),EMC HB-1M2012-102JT CERATECH TP...
  • Page 58 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS R244 0RH1002C622 RESISTOR,METAL GLAZED(CHIP) 10K OHM 1 / 16 W 1608 5.00% D R245 0RH5603C622 RESISTOR,METAL GLAZED(CHIP) 560K OHM 1 / 16 W 1608 5.00% D R264 0RH2702C622 RESISTOR,METAL GLAZED(CHIP) 27K OHM 1 / 16 W 1608 5.00% D R265 0RH1503C622 RESISTOR,METAL GLAZED(CHIP)
  • Page 59 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS R616 0RH1202C622 RESISTOR,METAL GLAZED(CHIP) 12K OHM 1 / 16 W 1608 5.00% D R619 0RH3300C622 RESISTOR,METAL GLAZED(CHIP) 330 OHM 1 / 16 W 1608 5.00% D R620 0RH3300C622 RESISTOR,METAL GLAZED(CHIP) 330 OHM 1 / 16 W 1608 5.00% D R621 0RH2200C622 RESISTOR,METAL GLAZED(CHIP)
  • Page 60 CAPACITOR,FIXED TANTALUM 10UF 3216 6.3V 10% SMD R/TP(SM C1022 0CS106EC5DC CAPACITOR,FIXED TANTALUM 10UF 3216 6.3V 10% SMD R/TP(SM CN1001 6630R3S006F CONNECTOR(CIRC),DRAWING GT200 LG CABLE 5PIN 2MM STRAIG D1001 0DD193009AB DIODE,RECTIFIERS KDS193(F3) CHIP TP KEC IC1001 0IPRP00536A IC,PERIPHERALS SUSB2010 SAIN 80PIN,LQFP TRAY...
  • Page 61 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS R1042 0RH4702C622 RESISTOR,METAL GLAZED(CHIP) 47K OHM 1 / 16 W 1608 5.00% D R1043 0RH4702C622 RESISTOR,METAL GLAZED(CHIP) 47K OHM 1 / 16 W 1608 5.00% D R1044 0RH4702C622 RESISTOR,METAL GLAZED(CHIP) 47K OHM 1 / 16 W 1608 5.00% D R1045 0RH4702C622 RESISTOR,METAL GLAZED(CHIP)
  • Page 62 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS IC303 0ILNRUC001A IC,LINEAR MC4580 UTC 8PIN,SOP R/TP 2CH O ALTERNATE IC303 0ILNRAU017A IC,LINEAR S4580 AUK KOREA 8PIN,SOP R/TP ALTERNATE IC304 0ILNRA0001A IC,LINEAR AZ4580 AAC 8PIN,DIP ST OPAMP IC304 0ILNRUC001A IC,LINEAR MC4580 UTC 8PIN,SOP R/TP 2CH O ALTERNATE IC304 0ILNRAU017A...
  • Page 63 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS R331 0RH8201C622 RESISTOR,METAL GLAZED(CHIP) 8.2K OHM 1 / 16 W 1608 5.00% D R332 0RH6801C622 RESISTOR,METAL GLAZED(CHIP) 6.8K OHM 1 / 16 W 1608 5.00% D R333 0RH1502C622 RESISTOR,METAL GLAZED(CHIP) 15K OHM 1 / 16 W 1608 5.00% D R334 0RH3300C622 RESISTOR,METAL GLAZED(CHIP)
  • Page 64 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS F302 6200HJC901A FILTER(CIRC),EMC CFI06B1H101MF SAMHWA TP 2-5K F303 6200HJC901A FILTER(CIRC),EMC CFI06B1H101MF SAMHWA TP 2-5K F304 6200HJC901A FILTER(CIRC),EMC CFI06B1H101MF SAMHWA TP 2-5K F305 6200HJC901A FILTER(CIRC),EMC CFI06B1H101MF SAMHWA TP 2-5K F306 6200HJC901A FILTER(CIRC),EMC CFI06B1H101MF SAMHWA TP 2-5K...
  • Page 65 EXPLODED VIEWS 1. Cabinet and Main Frame Section...
  • Page 66 2. Deck Mechanism Section(DPS-02)
  • Page 67 3. Packing Accessory Section RF CABLE 810 CABLE SET ASS’Y PLUG ASS’Y 1WAY(YELLOW) PLUG ASS’Y 2WAY BATTERY PLUG ASS’Y 1WAY(BLACK) REMOCON OWNER’S MANUAL PACKING SHEET PACKING PACKING AC ADAPTOR BOX CARTON OPTIONAL PARTS...
  • Page 68 RUN DATE : 15-MARCH-05 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS *** INDIVIDUAL PARTS *** 3110R-D023A CASE DV9000 B6432G PRESS WUTHOUT LG 3300R-D070A PLATE BRKT FRONT SLOT PRESS 4930R-0602A HOLDER DVD DF9900 MOLD MOMORY STICK 6410RCHX03A POWER CORD...
  • Page 69 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS 4680HP2009A MOTOR(MECH) AT-M12-0740 NMM N4 LOADING 4371H-1012A SHAFT ASSEMBLY SHAFT ASSY GEAR CRN-8242B *** PWB(PCB) ASSEMBLY,TOTAL *** 6871R-2322M PWB(PCB) ASSEMBLY,TOTAL DF9000S SMPS ASSY 1389B,C SLOT C101 624-088L CAPACITOR,DRAWING 435D SUNIL ELECTRONICS 0.1UF/2 C101 624-088S CAPACITOR,DRAWING...
  • Page 70 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS IC151 0IPMGKE008B IC,POWER MANAGEMENT KIA78R08PI/API CU KEC 4P TO-22 ALTERNATE IC151 0IPMGFA016A IC,POWER MANAGEMENT KA78R08TSTU FAIRCHILD 4P TO-22 ALTERNATE L101 6140RCC003J COIL,RF 4.7 MH PEAKING COIL OWA 67 X 7 L102 6140RCC003J COIL,RF 4.7 MH PEAKING COIL OWA 67 X 7...
  • Page 71 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS C909 0CH1104K942 CAPACITOR,FIXED CERAMIC(TEMP.C 0.1UF 50V 80%,-20% Y5V(F) 1608 IC901 0IPRPPY005A IC,PERIPHERALS PT6963 PTC 32PIN SO R/TP LED D IC901 0IPRPPY007A IC,PERIPHERALS PT6961 PTC 32PIN SOP R/TP LED ALTERNATE L901 6200HJC102A FILTER(CIRC),EMC HB-1M2012-102JT CERATECH TP R901...
  • Page 72 CAPACITOR,ELECTROLYTIC 220M SRA 6.3V M FM5 TP(5) C6W3 0CE1064F638 CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) CN203 561-711D CONNECTOR (CIRC),HOUSING GIL-S-04P-S2T2-EF LG CABLE 4PI CN204 561-711E CONNECTOR (CIRC),WAFER GIL-S-05P-S2T2-EF LG CABLE 5PI CN501 6630R-FB10L CONNECTOR (CIRC),FFC/FPC 00-6232-012-006-800 ELCO 12PIN CN502...
  • Page 73 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS C519 0CH1104K942 CAPACITOR,FIXED CERAMIC(TEMP.C 0.1UF 50V 80%,-20% Y5V(F) 1608 C520 0CH1104K942 CAPACITOR,FIXED CERAMIC(TEMP.C 0.1UF 50V 80%,-20% Y5V(F) 1608 C521 0CH1104K942 CAPACITOR,FIXED CERAMIC(TEMP.C 0.1UF 50V 80%,-20% Y5V(F) 1608 C522 0CH1104K942 CAPACITOR,FIXED CERAMIC(TEMP.C 0.1UF 50V 80%,-20% Y5V(F) 1608 C523 0CH1104K942...
  • Page 74 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS C594 0CH4120K412 CAPACITOR,FIXED CERAMIC(HIGH D 12PF 50V 5% NP0 1608 R/TP C595 0CH4221K412 CAPACITOR,FIXED CERAMIC(HIGH D 220PF 50V 5% NP0 1608 R/TP C596 0CH1104K942 CAPACITOR,FIXED CERAMIC(TEMP.C 0.1UF 50V 80%,-20% Y5V(F) 1608 C597 0CH1104K942 CAPACITOR,FIXED CERAMIC(TEMP.C...
  • Page 75 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS L503 6200HJC102A FILTER(CIRC),EMC HB-1M2012-102JT CERATECH TP L504 6200HJC102A FILTER(CIRC),EMC HB-1M2012-102JT CERATECH TP L505 6200HJC102A FILTER(CIRC),EMC HB-1M2012-102JT CERATECH TP L509 6200HJC102A FILTER(CIRC),EMC HB-1M2012-102JT CERATECH TP L512 6200HJC102A FILTER(CIRC),EMC HB-1M2012-102JT CERATECH TP L601 6200HJC102A FILTER(CIRC),EMC HB-1M2012-102JT CERATECH TP...
  • Page 76 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS R244 0RH1002C622 RESISTOR,METAL GLAZED(CHIP) 10K OHM 1 / 16 W 1608 5.00% D R245 0RH5603C622 RESISTOR,METAL GLAZED(CHIP) 560K OHM 1 / 16 W 1608 5.00% D R264 0RH2702C622 RESISTOR,METAL GLAZED(CHIP) 27K OHM 1 / 16 W 1608 5.00% D R265 0RH1503C622 RESISTOR,METAL GLAZED(CHIP)
  • Page 77 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS R616 0RH1202C622 RESISTOR,METAL GLAZED(CHIP) 12K OHM 1 / 16 W 1608 5.00% D R619 0RH3300C622 RESISTOR,METAL GLAZED(CHIP) 330 OHM 1 / 16 W 1608 5.00% D R620 0RH3300C622 RESISTOR,METAL GLAZED(CHIP) 330 OHM 1 / 16 W 1608 5.00% D R621 0RH2200C622 RESISTOR,METAL GLAZED(CHIP)
  • Page 78 CAPACITOR,FIXED TANTALUM 10UF 3216 6.3V 10% SMD R/TP(SM C1022 0CS106EC5DC CAPACITOR,FIXED TANTALUM 10UF 3216 6.3V 10% SMD R/TP(SM CN1001 6630R3S006F CONNECTOR(CIRC),DRAWING GT200 LG CABLE 5PIN 2MM STRAIG D1001 0DD193009AB DIODE,RECTIFIERS KDS193(F3) CHIP TP KEC IC1001 0IPRP00536A IC,PERIPHERALS SUSB2010 SAIN 80PIN,LQFP TRAY...
  • Page 79 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS R1042 0RH4702C622 RESISTOR,METAL GLAZED(CHIP) 47K OHM 1 / 16 W 1608 5.00% D R1043 0RH4702C622 RESISTOR,METAL GLAZED(CHIP) 47K OHM 1 / 16 W 1608 5.00% D R1044 0RH4702C622 RESISTOR,METAL GLAZED(CHIP) 47K OHM 1 / 16 W 1608 5.00% D R1045 0RH4702C622 RESISTOR,METAL GLAZED(CHIP)
  • Page 80 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS IC303 0ILNRUC001A IC,LINEAR MC4580 UTC 8PIN,SOP R/TP 2CH O ALTERNATE IC303 0ILNRAU017A IC,LINEAR S4580 AUK KOREA 8PIN,SOP R/TP ALTERNATE IC304 0ILNRA0001A IC,LINEAR AZ4580 AAC 8PIN,DIP ST OPAMP IC304 0ILNRUC001A IC,LINEAR MC4580 UTC 8PIN,SOP R/TP 2CH O ALTERNATE IC304 0ILNRAU017A...
  • Page 81 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS R331 0RH8201C622 RESISTOR,METAL GLAZED(CHIP) 8.2K OHM 1 / 16 W 1608 5.00% D R332 0RH6801C622 RESISTOR,METAL GLAZED(CHIP) 6.8K OHM 1 / 16 W 1608 5.00% D R333 0RH1502C622 RESISTOR,METAL GLAZED(CHIP) 15K OHM 1 / 16 W 1608 5.00% D R334 0RH3300C622 RESISTOR,METAL GLAZED(CHIP)
  • Page 82 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS F302 6200HJC901A FILTER(CIRC),EMC CFI06B1H101MF SAMHWA TP 2-5K F303 6200HJC901A FILTER(CIRC),EMC CFI06B1H101MF SAMHWA TP 2-5K F304 6200HJC901A FILTER(CIRC),EMC CFI06B1H101MF SAMHWA TP 2-5K F305 6200HJC901A FILTER(CIRC),EMC CFI06B1H101MF SAMHWA TP 2-5K F306 6200HJC901A FILTER(CIRC),EMC CFI06B1H101MF SAMHWA TP 2-5K...
