- Page 1 SE 120 LSNi SmartKey Arming Device Installation Manual SE 120 LSNi...
-
Page 2: Table Of Contents
Table of Contents Chapter Page System Description System Overview .......................... 3 Description of the Connections on the Control Unit..............4 Installation Instructions Installing System Components...................... 6 Installing the Magnetic Contact and Bolt Contact ................. 7 Connecting the Control Panel and Optional Components ............8 Connecting for Operation without an SPE Blocking Element ............ -
Page 3: System Description
System Description System Overview The SE 120 LSNi SmartKey arming device is a system solution for arming intrusion systems. The individual components of the system can be put together as required for the intended usage. Operating modes with or without the SPE blocking element are possible. Control authorizations for arming/disarming are defined during control panel programming. -
Page 4: Description Of The Connections On The Control Unit
System Description Description of the Connections on the Control Unit The control unit connections have different functions. There are inputs, outputs and plug-in ter- minals. Inputs and outputs have to be assigned according to a specific schema with regard to the scope of basic functions. - Page 5 System Description Description of the Connections on the Control Unit Connection Name Function Description Input Power supply 9.6 - 30V Input Power supply 0V aLSN1 Input LSN incoming bLSN1 Input LSN incoming Output Power supply 9.6 - 30V Output Power supply 0V aLSN2 Output LSN outgoing...
-
Page 6: Installation Instructions
Installation Instructions Installing System Components Note the following during installation: Used shielded cables only. The usual precautionary measures for handling C-MOS technology apply to han- dling the circuit boards and to soldering work. Wear a grounded wrist strap when working on the control panel. Mounting the control unit Mount the control unit to the wall. -
Page 7: Installing The Magnetic Contact And Bolt Contact
Installation Instructions Installing System Components Installing the SPE blocking element Install the SPE blocking element using the appropriate kit and in accordance with the en- closed installation notes. Make sure the door cannot slam shut. The bolt on the SPE blocking element could oth- erwise be damaged during start-up by a slamming door. -
Page 8: Connecting The Control Panel And Optional Components
Installation Instructions Connecting the Control Panel and Optional Components Make sure the control panel is disconnected from the power supply. Connect the control unit and the optional components as shown in the connection diagram on the following page. Address switch: The address switch is used for LSN control panels in the planning stage. The address switch does not need to be adjusted on any of the currently available LSN control pan- els. -
Page 9: Connecting For Operation Without An Spe Blocking Element
Installation Instructions Connecting for Operation Without an SPE Blocking Element Use the following switching arrangement on the control unit to set the operating mode without SPE blocking element. Connect the inputs HALL1 and HALL2 to 0V. 57 56 55 54 PL2 53 1 +U Free Free... -
Page 10: Function Test For The Spe Blocking Element And Reader
Installation Instructions Function Test for the SPE Blocking Element and Reader Turning on the power supply Make sure that bridge B1 on the control unit is connected before turning on the power supply. Turn on the power supply. The yellow LED on the control unit displays the system's status as follows: Yellow LED Status Required action... -
Page 11: Reading In Keys And Programming The System
Installation Instructions Reading In Keys and Programming the System Depending on the "key type" and "reading in method of the key", perform one of the following 4 steps. Reading in keys as described under points 2 and 4 should only be used in exceptional circumstances. - Page 12 Key with security card: Reading in keys during programming Programming the SE 120 LSNi system and reading in the key identification number is car- ried out with the appropriate programming program (e.g. WinPara or NzPara). This is when the key's 8-digit identification number is entered into the system. In the programming pro- gram, select for the keys to be read in during programming (select the parameter "inte-...
- Page 13 Installation Instructions Key with security card: Reading in keys via the reader Keys (maximum 16) can be read in directly via the reader if the 8-digit identification number is not entered during programming. In the programming program (e.g. WinPara or NzPara), select for the keys to be read in via the reader (select the parameter "standalone"...
- Page 14 Standard key (without security card): Reading in keys during programming Programming the SE 120 LSNi system and reading in the key identification number is car- ried out with the appropriate programming program (e.g. WinPara or NzPara). This is when the key's 8-digit identification number is entered into the system. In the programming pro- gram, select for the keys to be read in during programming (select the parameter "inte-...
- Page 15 Installation Instructions Standard key (without security card): Reading in keys via the reader Keys (maximum 16) can be read in directly via the reader if the 8-digit identification number is not entered during programming. In the programming program (e.g. WinPara or NzPara), select for the keys to be read in via the reader (select the parameter "standalone"...
-
Page 16: Concluding System Installation
Installation Instructions Concluding System Installation 1. Make sure that bridge B1 on the control unit is closed for normal operation. Replace the con- trol unit cover. 2. Make sure the red and green LEDs on the reader are off (= normal operating condition). 3. -
Page 17: Operating The System
Operating the System Viewing the System Status Press and hold the key button and hold the key up to the reader for 1 second. The system status is indicated as shown in the following table. Display element Behavior Meaning Green LED System disarmed Flashing System is attempting to disarm... -
Page 18: Arming/Disarming
Operating the System Arming 1. Press and hold the key button and hold the key up to the reader for 3 seconds until you hear a short signal from the buzzer. The green LED is activated, signaling that the system is currently disarmed. The red LED starts to flash, signaling that the arming process has commenced. -
Page 19: Example Of Operation With 4 Smartkeys
Operating the System Example of Operation with 4 SmartKeys All SmartKeys have equal arming and disarming rights. Arming: Arming can occur with any SmartKey once all the bolt contacts are closed and the detection area is ready to be activated. Arming will engage all SPE blocking element bolts. -
Page 20: Fault Elimination
Fault Elimination Problems with Installation and Reading In Keys Always check the following first of all: Are the component cables correctly connected? Are there any short-circuits/broken wires? Is the component connected to a power supply? Is bridge BR1 correctly connected to control unit? Problem Possible cause(s) Elimination... -
Page 21: Operating Problems During Normal Operation
Fault Elimination Operating Problems During Normal Operation Problem Possible cause(s) Elimination Reader does not respond Key outside of scanner range. Repeat the arming process after when the key is held up to removing any of the possible causes Key not held up to the reader for the scanner. -
Page 22: Replacing The Bolt In The Spe Blocking Element
Fault Elimination Replacing the Bolt in the SPE Blocking Element (for instance, if the bolt is broken or cannot be moved) The bolt can be replaced while the system is running (disarmed state). Consult the appropriate installation notes and proceed as follows: 1. -
Page 23: Notes For Maintenance And Service
Notes for Maintenance and Service General Maintenance and inspection measures must be performed at specific intervals by appropriately qualified personnel. Furthermore, the regulations of DIN VDE 0833 apply to all related work. Inspection and Maintenance Function test of the control unit tamper contact function Visual inspection of installation/damage. -
Page 24: Loss Of Keys
Notes for Maintenance and Service Loss of Keys The following steps are required if the keys were read in during programming: 1. Bypass the key using the control panel keypad or erase the key using the appropriate pro- gramming program (e.g. WinPara or NzPara) 2. -
Page 25: Ordering Additional Keys
Notes for Maintenance and Service Ordering Additional Keys The following steps are required if you need new keys (e.g. for new members of staff): Keys with a security card Send your order to the manufacturer together with the security card so that the new keys can be registered on the card. -
Page 26: Technical Data
Note on the blocking element: SE 120 - Storage temperature -40°C...+85°C LSNi without bolt contact. If all the bolts of Housing all SE 120 LSNi units in a detection area are - Material to be activated simultaneously, the values - Color RAL 9002 for "activated bolts"... - Page 27 Notes Range max. 20 mm Environmental condi- tions - Environmental class - Protective system IP 67 - Operating tempera- -40°C...+70°C ture - Storage temperature -40°C...+85°C Housing - Material - Color RAL 9005 (black) Dimensions (WxHxD) 27 x 24 x 6 mm Weight 0.011 kg Laws/Standards/Directives...
