E13863
ROG strix
XG49WCR
U S E R
G U I D E

Advertisement

Table of Contents
loading

Related Manuals for Asus ROG STRIX XG49WCR

Summary of Contents for Asus ROG STRIX XG49WCR

  • Page 1 E13863 ROG strix XG49WCR U S E R G U I D E...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Contents Notices ......................iv Safety information ..................v Care & Cleaning ................... x Welcome ..................1-1 Package contents ................. 1-1 Assembling the monitor .............. 1-2 Connect cables ............... 1-5 1.4.1 Rear of the LCD monitor ..........1-5 Monitor introduction ..............1-6 1.5.1 Front/Side view ...............

  • Page 4: Notices

    Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received including interference that may cause undesired operation.

  • Page 5: Safety Information

    Canadian Department of Communications Statement This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. This class B digital apparatus complies with Canadian ICES-003. This Class B digital apparatus meets all requirements of the Canadian Interference -Causing Equipment Regulations.
  • Page 6 • Slots and openings on the back or top of the cabinet are provided for ventilation. Do not block these slots. Never place this product near or over a radiator or heat source unless proper ventilation is provided. • The monitor should be operated only from the type of power source indicated on the label.
  • Page 7 The product may fall, causing serious personal injury or death. To prevent injury, this product must be securely attached to the floor/wall in accordance with the installation instructions. A product may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions such ALWAYS use cabinets or stands or installation methods recommended by the manufacturer of the product set.
  • Page 8 TÜV Rheinland Flicker Free Certification. This product to ascertain whether the display produces visible and invisible flicker for the human eye and therefore strains the eyes of users. ASUS CONTACT INFORMATION ASUSTeK Computer Inc. ASUS Computer International (America) ASUS Computer GmbH (Germany and Austria) Address 1F, No.15, Address 48720 Kato Rd, Fremont, Address Harkortstr. 21-23 Lide Rd., Beitou Dist.,...

  • Page 9: Care & Cleaning

    Prevent Tipping When using the display, fasten the LCD to a wall using a cord or chain that can support the weight of the monitor in order to prevent the monitor from falling. • Display design may differ from those illustrated. •...
  • Page 10 AEEE yönetmeliğine uygundur The following symptoms are normal with the monitor: • The screen may flicker during the initial use due to the nature of the fluorescent light. Turn off the Power Switch and turn it on again to make sure that the flicker disappears. •...
  • Page 11 These documents are not part of the standard package. Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for our customers to be able to responsibly recycle our products, batteries and other components as well as the packaging materials.

  • Page 12: Welcome

    ® Thank you for purchasing the ASUS LCD Gaming monitor! The latest widescreen LCD monitor from ASUS provides a crisper, broader, and brighter display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual...

  • Page 13: Assembling The Monitor

    Assembling the monitor To assemble the monitor: While assembling the monitor arm/base, we recommend that you keep the monitor inside its EPS (Carton box) packaging. Take out all accessory from the upside EPS. Take out upside EPS from carton box and then push open stand assembly hole.
  • Page 14 Take out upside EPS from carton box and then push open stand assembly hole.arm. Then insert the arm into the monitor. Install the arm. Fasten the bundled screw. Cover the VESA cover. Fix the base to the arm by fastening the bundled screw. ASUS LCD Monitor XG Series...
  • Page 15 Uplift packaging together with monitor and then make sure monitor’s base can safely stand on a flat floor or desk. At last, remove the EPS and carton box packaging. Chapter 1: Product Introduction...

  • Page 16: Connect Cables

    Connect cables 1.4.1 Rear of the LCD monitor Power HDMI Port DisplayPort USB type A USB3.2 Gen 1 Type-C Port USB3.2 Gen 1 upstream Port USB type A RJ45 Port Earphone Jack ASUS LCD Monitor XG Series...

  • Page 17: Monitor Introduction

    Monitor introduction 1.5.1 Front/Side view Use the control button on the bottom of the monitor to adjust the monitor settings. DisplayPort 3840x2160 120Hz Racing Mode ROG Swift PG42UQ HDR OFF Gaming Overclocking Image Adaptive-Sync Color GamePlus Input Select GameVisual PIP/PBP Setup Shadow Boost MyFavorite System Setup...

  • Page 18: Adjusting The Monitor

    Hold the stand to prevent the monitor from falling when you change its angle. • You can adjust the monitor’s angle from +20˚ to -5˚ .Before rotating the display,lift it to the top position and then push it back to the utmost degree.. 120mm It is normal that the monitor slightly shakes while you adjust the viewing angle. ASUS LCD Monitor XG Series...

  • Page 19: Outline Dimension

    Outline dimension Unit: mm [inch] ASUS LCD Monitor XG Series...

  • Page 20: Turning On The Monitor

    If the Power Indicator function is enabled and an input source is detected ， the power LED will light up white to indicate that the monitor is turned on. The power LED will not light up in Power Saving mode. ASUS LCD Monitor XG Series...

  • Page 21: Osd (On-Screen Display) Menu

    3.1.1 How to reconfigure You can use the Control buttons on the monitor to navigate through the menu and make adjustments. DisplayPort 5120 X 1440@ 165Hz Racing Mode ROG Strix XG49WCR HDR OFF Gaming Variable OD Image Variable Refresh Rate Color ELMB/ELMB SYNC...

  • Page 22: Osd Function Introduction

    3.1.2 OSD Function Introduction Gaming Configure your gaming preferences. DisplayPort 5120 X 1440@ 165Hz Racing Mode ROG Strix XG49WCR HDR OFF Gaming Variable OD Image Variable Refresh Rate Color ELMB/ELMB SYNC Input Select GamePlus PIP/PBP Setup GameVisual MyFavorite Shadow Boost...
  • Page 23 VividPixel: Enhance the outline of the displayed picture and generates high-quality images on screen. • HDR Setting: Set the HDR mode to ASUS Gaming HDR, ASUS Cinema HDR, or Console HDR. The HDR brightness can be adjusted when the Brightness Adjustable function is enabled.
  • Page 24 Please refer to the following to alleviate eye strains: • Users should take some time away from the display if working for long hours. It is advised to take short breaks (at least 5 mins) after around 1 hour of continuous working at the computer.
  • Page 25 Color Select the image color you like from this function. DisplayPort 5120 X 1440@ 165Hz Racing Mode ROG Strix XG49WCR HDR OFF Gaming Display Color Space Image Color Temp. Color Saturation Input Select Six-axis Saturation PIP/PBP Setup Gamma MyFavorite System Setup...
  • Page 26 DisplayPort 3840x2160 165Hz Racing Mode ROG Strix XG49WCR HDR OFF Gaming Auto Input Detection Image USB-C Color DisplayPort Input Select HDMI PIP/PBP Setup MyFavorite System Setup MOVE/ENTER BACK EXIT 5. PIP/PBP Setup The PIP/PBP Setting allows you to open up sub-window(s) connected from any video source.
  • Page 27 Smart KVM application. Sharing Keyboard and Mouse To switch the cursor location and the keyboard usage to another computer. Files sharing You can easily share files between two computers through the keyboard mouse sharing function. You can transfer files between two computers simply by dragging and dropping files or folders. ASUS LCD Monitor XG Series...
  • Page 28 7.MyFavorite Assign a function to the shortcut button, save the current system configurations, or restore the system configuration. DisplayPort 5120 X 1440@ 165Hz Racing Mode ROG Strix XG49WCR HDR OFF Gaming Shortcut Image Customised Setting Color Input Select PIP/PBP Setup MyFavorite System Setup EXIT MOVE/ENTER BACK •...
  • Page 29 System Setup Adjust the system configurations. DisplayPort 5120 X 1440@ 165Hz Racing Mode ROG Strix XG49WCR HDR OFF Language Gaming Sound Image USB Setup Color USB-C Charging Input Select Power Indicator PIP/PBP Setup Power Key Lock MyFavorite Key Lock System Setup Power Setting...
  • Page 30 • Power Key Lock:Disable/Enable the Power key. • Key Lock: Enable this function to disable all function keys. Press the Navigation button down for more than five seconds to cancel the key lock function. • Power Setting：Select the power setting mode. If the setting is set to Standard Mode, it may result in higher power consumption.

  • Page 31: Specifications

    Tilt -5° ~ +20° Swivel ±8 Height adjustment VESA wall mount 100 x 100 mm Kensington lock Voltage rating AC 100-240V, 50/60 Hz Power On:< 45 W Power consumption Standby:<0.5 W Power Off:<0.3 W ASUS LCD Monitor XG Series 3-11...
  • Page 32 Temperature (Operating) 0°C ~ 40°C -20˚C ~ +60˚C Temperature (Non-operating) 1193.62 x (522~402) x 324.7 mm(with stand ) 1193.62 x 369.5 x 178.58 mm(without Dimensions (W x H x D) stand) 1307.6x483.5x 369.9mm(Package) 11.27 kg (without stand) 14.92 kg (Net) Weight (Esti.) 21.3 kg (Gross) English, French, German, Spanish,...

  • Page 33: Troubleshooting (Faq)

    • Make sure the computer sound card driver is properly installed and activated. • Check the audio source. The BIOS screen cannot • Please enable CSM function and Gaming be displayed Mode. • * Set Power Setting to Standard Mode. ASUS LCD Monitor XG Series 3-13...

  • Page 34: Supported Timing List

    Supported Timing List HDMI2.0 DP1.4/Type-c 720x400/70Hz 720x400/70Hz 720x400/70Hz 640x480/60Hz 640x480/60Hz 640x480/60Hz 640x480/67Hz 640x480/67Hz 640x480/67Hz 640x480/72Hz 640x480/72Hz 640x480/72Hz 640x480/75Hz 640x480/75Hz 640x480/75Hz 800x600/56Hz 800x600/56Hz 800x600/56Hz 800x600/60Hz 800x600/60Hz 800x600/60Hz 800x600/72Hz 800x600/72Hz 800x600/72Hz 800x600/75Hz 800x600/75Hz 800x600/75Hz 1024x768/60Hz 1024x768/60Hz 1024x768/60Hz 1024x768/70Hz 1024x768/70Hz 1024x768/70Hz 1024x768/75Hz 1024x768/75Hz 1024x768/75Hz 1280x1024/75Hz 1280x1024/75Hz...
  • Page 35 5120x1440/60Hz 5120x1440/75Hz 5120x1440/75Hz 5120x1440/120Hz 5120x1440/144Hz 5120x1440/165Hz * The modes not listed in the above tables may not be supported. For optimal resolution, we recommend that you choose a mode listed in the above tables. ASUS LCD Monitor XG Series 3-15...
