Siemens RDH100RF/SET Manual

Siemens RDH100RF/SET Manual

Wireless room thermostat with lcd
Hide thumbs Also See for RDH100RF/SET:

Advertisement

Quick Links

Download this manual
Wireless room thermostat with LCD
RDH100RF/SET
A6V10954418_en--_h
2022-12-06
Non-programmable, for heating systems
●
2-position or PID control to switch on/off heating systems
●
Large LCD display
●
Minimum and maximum setpoint limitation
●
RDH100RF, transmitter, battery powered
●
RCR100/433, receiver, mains powered
Smart Infrastructure

Advertisement

loading

Related Manuals for Siemens RDH100RF/SET

Summary of Contents for Siemens RDH100RF/SET

  • Page 1 Wireless room thermostat with LCD RDH100RF/SET Non-programmable, for heating systems ● 2-position or PID control to switch on/off heating systems ● Large LCD display ● Minimum and maximum setpoint limitation ● RDH100RF, transmitter, battery powered ● RCR100/433, receiver, mains powered...
  • Page 2 Pumps Functions Temperature control RDH100RF/SET offers both 2-position and PID intelligent learning temperature control, configurable via parameter P01 (control behavior). 2-position control algorithm to switch on and off the heating system within a switching differential (SD) as per the difference between setpoint setting and measured room temperature.
  • Page 3 Approximately 6 minutes WARNING Do not use PID fast for oil boilers or electric mechanical actuators! Backup When removing the batteries, the setpoints and information required for operating mode changeover are retained for max. 2 minutes. Siemens A6V10954418_en--_h Smart Infrastructure 2022-12-06...
  • Page 4 2 to 4. 6. Exit parameter setting mode by rotating the setting knob clockwise to “End” and pressing LEARN once. Note: The thermostat automatically exits parameter setting mode one minute after the last action. Siemens A6V10954418_en--_h Smart Infrastructure 2022-12-06...
  • Page 5 2.5mm) Electromotoric SFA21.. 4863 actuator *) The documents can be downloaded from http://siemens.com/bt/download. Display The digital display shows the current room temperature and the comfort temperature setpoint. When the heating output is active, the triangle symbol is displayed. Ordering When ordering, specify both name and product number, e.g.
  • Page 6 Indicates a request for heating Temperature setting knob Battery compartment Comfort temperature setpoint RF TEST Indicates RF signal test Indicates low battery power; replace batteries The receiver is located in a plastic housing with LEDs and buttons. Siemens A6V10954418_en--_h Smart Infrastructure 2022-12-06...
  • Page 7 Power up (after 5 seconds) Press OVERRIDE switch Flash RED + ORANGE (amber) (4 seconds) Learning period No LED Software reset RF receive GREEN No RF within last 25 minutes Manual override Flash ORANGE (RF receive) Siemens A6V10954418_en--_h Smart Infrastructure 2022-12-06...
  • Page 8 If the reference room contains thermostatic radiator valves, set them to their fully open position. For commissioning, refer to the operating instructions A6V101035988. Communication of the RDH100RF/SET (transmitter and receiver) is paired ex factory. ● The devices are suitable for wall mounting.
  • Page 9 Delete all personal data and dispose of the item(s) at separate collection and recycling facilities in accordance with local and national legislation. For additional details, refer to Siemens information on disposal. Instructions for the replacement of alkaline batteries WARNING...
  • Page 10 Installation Mounting instructions A6V10974421 CE declaration A6V101123354 Related documents such as CE declarations, etc., can be downloaded from the following address: http://siemens.com/bt/download. Technical data Power supply Operating voltage DC 3 V (2 x 1.5 V AA alkaline batteries) Battery life >1 year (with AA alkaline batteries)

  • Page 11: Environmental Conditions

    (RoHS compliance, materials composition, packaging, environmental benefit, disposal). *) The documents can be downloaded from: http://siemens.com/bt/download. Eco design and labeling directives Based on EU Regulation 813/2013 (Eco design directive) and 811/2013 (Labeling directive) concerning space heaters, the following classes apply:...
  • Page 12 Min. 10 mA Contact life at At 5 A res. 1 x 10 cycles (guide value) AC 250 V Insulating strength Between relay contacts AC 5,000 V and coil Between relay contacts AC 1,000 V (same pole) Siemens A6V10954418_en--_h Smart Infrastructure 2022-12-06...

  • Page 13: Electrical Connections

    Mechanical conditions Class 2M2 Standards, directives and approvals EU conformity (CE) A6V101123354 Safety class II as per EN 60 730-1 Degree of pollution Color Unit front Signal-white RAL 9003 Base Gray RAL 7035 Dimensions 83x104x32 mm Siemens A6V10954418_en--_h Smart Infrastructure 2022-12-06...
  • Page 14 8 (3) A N.C. contact, AC 24…250 V / 8 (3) A Protective ground Circulating pump Neutral conductor L – N AC 230 V / Lx – Nx AC 24…250 V Neutral conductor Receiver RCR100/433 Actuating device Siemens A6V10954418_en--_h Smart Infrastructure 2022-12-06...
  • Page 15 (precontrol by manual mixing valve) N1 Room temperature controller F1 Thermal reset limit thermostat RDH100RF (Transmitter) F2 Safety limit thermostat N2 RCR100/433 (Receiver) M1 Circulating pump Y1 3-port valve with manual adjustment Y2 Magnetic valve Siemens A6V10954418_en--_h Smart Infrastructure 2022-12-06...
  • Page 16 Dimensions [mm] Room temperature controller Room temperature controller mounting plate Siemens A6V10954418_en--_h Smart Infrastructure 2022-12-06...

  • Page 17: Product History

    Add new function min/max temperature limitation, selectable control behavior and parameter settings. Z, A March 2017 First release. 1) Product index can be found next to the production date on the rear of the device "YYMMDDX". Siemens A6V10954418_en--_h Smart Infrastructure 2022-12-06...
  • Page 18 Issued by © Siemens Switzerland Ltd, 2017 Siemens Switzerland Ltd Technical specifications and availability subject to change without notice. Smart Infrastructure Global Headquarters Theilerstrasse 1a CH-6300 Zug +41 58 724 2424 www.siemens.com/buildingtechnologies Document ID A6V10954418_en--_h Edition 2022-12-06...
