Universal switch II
Quick instructions
Product description
The universal switch II enables you to operate the
most important functions of your Bosch Smart Home
system even without a smartphone.
Description of the symbols
Warning!
Note about hazards
Note:
Additional
important information
Note about the installation video
8-750-002-515
Advertisement
Table of Contents
Related Manuals for Bosch Universal switch II
Summary of Contents for Bosch Universal switch II
- Page 1 Universal switch II Quick instructions Product description The universal switch II enables you to operate the most important functions of your Bosch Smart Home system even without a smartphone. Description of the symbols Warning! Note about hazards Note: Additional important information...
-
Page 2: Safety Instructions
Safety instructions ▶ Read this user manual completely before installing or commissioning the device and pay particular attention to the hazard information. ▶ Do not charge used batteries, and do not attempt to reactivate them using heat or other means. Do not short-circuit batteries. - Page 3 ▶ Only operate the device indoors and do not expose it to moisture, vibrations, constant sunlight or other sources of heat, extreme cold temperatures and mechanical stress. ▶ Only use the device together with original components and recommended products from Bosch partners.
- Page 4 ▶ The device is only intended for private use. You can also use the explanatory videos and additional information on our website as an additional aid for mounting, installing, starting up and restoring the factory settings on your Bosch Smart Home universal switch II: www.bosch-smarthome.com/rom/ universal-switch-2...
- Page 5 Product overview Item Description Front with removable cover Standard operating buttons Operating and system buttons Status LED Individual stickers, protected by front cover Back Mounting plate receiving openings Battery compartment cover Battery compartment cover lock Battery compartment (ensure correct polarity when inserting the batteries) Wall bracket Wall bracket front cover Adhesive pad for wall mounting...
- Page 6 The status LED (4) shows the status of the universal switch using flashing codes. Signal Meaning Measures Flashes Pairing mode Please wait orange (is active) or device is communicating with the controller Flashes Pairing mode green (successful) or process confirmed Flashes Pairing mode If this is the first...
-
Page 7: Resetting To Factory Settings
Start-up Ensure that you have a Bosch Smart Home controller and the Bosch Smart Home app and have successfully configured both. Now start the Bosch Smart Home app and select “Add new device”. Follow the instructions in the app. Resetting to factory settings... -
Page 8: Maintenance And Cleaning
Maintenance and cleaning Removing or changing the battery Removing or changing the battery To remove or replace the batteries, turn the battery compartment cover (9) lock on the back of the universal switch anti-clockwise to the stop. Then remove the battery compartment cover (8) and remove the batteries. -
Page 9: Simplified Declaration Of Conformity
Simplified declaration of conformity Robert Bosch Smart Home GmbH hereby declare that the radio equipment type Bosch Smart Home BHI-US corresponds with the directive 2014/53/EU. The complete text of the EU declaration of conformity is available via the following web address: https://eu-doc.bosch.com... - Page 10 Battery lifespan (typical) < 2 years Technical modifications reserved Spare parts / accessories For information on available spare parts or accesso- ries, please visit: https://www.bosch-smarthome.com/rom/ spareparts Service information Robert Bosch Smart Home GmbH Schockenriedstraße 17 70565 Stuttgart-Vaihingen Germany service@bosch-smarthome.com @ www.bosch-smarthome.com/service 8-750-002-515 V001 09/2022...
