Page 1
LCD TV Operating Instructions 操作手冊 KD-65X9000A / 55X9000A...
Page 2
(c) DTS Licensing Limited and DTS, Inc. 2012. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sony Corporation is under license. Other trademarks and trade names are those of their respective owners.
Page 3
This television is designed for use in Hong Kong and ensured the usage in Hong Kong only. Location of the identification label Labels for Model No. and Power Supply rating (in accordance with applicable safety regulation) are located on the rear of the TV.
Page 4
About this manual (Operating Instructions) This manual explains how to set up your TV. For more information on how to use BRAVIA TV, refer to the “Electronic manual”. Operating Instructions Explains how to set up your TV such as connections, initial set-up, and basic operations.
Table of Contents Getting Started Checking the accessories................. 6 Inserting batteries into the remote control..........6 1: Attaching the Table-Top Stand ............. 7 2: Connections ..................8 3: Preventing the TV from toppling over..........10 4: Bundling the cables ................11 5: Connecting the TV to the Internet............
Getting Started Checking the Inserting batteries accessories into the remote control Remote Control (1) One-touch Remote Control (1) Size AAA batteries (R03/LR03 type) (4) Table-Top Stand (1)* Fixing screws for Table-Top Stand (M5 × 12) (4) Under cover (1) Cable clamper (1) R03 type batteries Passive 3D Glasses (4) Operating Instructions (this manual) and other...
1: Attaching the Attach the under cover. Table-Top Stand Refer to the supplied Table-Top Stand leaflet for proper attachment. Place the TV set on the Table-Top Stand. × • Ensure that there are no objects in front of the Arrow direction shows front of the Table-Top Stand.
14 mm in thickness. • Use an HDMI cable connector within 12 mm (thickness) × 21 mm (width). • Use Sony HDMI cable with “High Speed” indication for HDMI connection. • For more information on connections, refer to the i-Manual.
Page 9
Connecting an antenna (aerial)/cable Connecting audio/video and VCR devices Antenna (aerial) cable (not supplied) AV cable (not supplied) AV cable (not supplied) Antenna (aerial) Antenna (aerial) cable (not supplied) cable (not supplied) Antenna (aerial) cable (not supplied) DVD recorder (Continued)
3: Preventing the Connecting MHL device TV from toppling over Use authorized MHL2 cable with • Before install the machine screw, lay the display MHL logo MHL device face down on a stable work surface that is larger (not supplied) than the TV.
4: Bundling the * When installing on the wall, attach the cable holder under the terminals. cables Before bundling the cables, remove the cable holder from the AC cover. Reuse the cable holder to bundle the other cables. • Do not bundle the AC power cord (mains lead) together with other cables.
5: Connecting the Preparing a wireless LAN TV to the The built-in wireless LAN device allows you to Internet access the Internet and your home network. With this feature, you can connect to a wireless LAN and enjoy the benefits of networking in a cable-free environment.
6: Performing the Press V/v/B/b to select an item, then press initial set-up Follow the instructions on the screen. Programme Sorting: Changes the order of analogue channels stored in the TV. Press V/v to select the channel you want to move to a new position, then press Press V/v to select the new position for the channel, then press Connect the TV to your AC power outlet...
Using Your BRAVIA TV Watching TV Turn on the TV. Press =/1 on the TV or remote control to turn on the Select a mode. Select a TV channel or select an input. To select digital channels Use 0-9. For channel numbers 10 and above, press the next digit quickly.
Page 15
Watching 3D contents This feature lets you experience powerful 3D entertainment, such as stereoscopic 3D games and 3D Blu-ray Disc. Refer to the i-Manual on how to set the 3D settings or watch the 3D contents. Frequently used buttons Subtitle setting You can turn subtitle on/off while watching digital broadcasting.
Selecting various functions and settings (Home Menu) You can select the features of your TV from the Home menu. Here is an example on how to select an item and modify the TV settings. Press HOME. Press V/v to select “Settings” category.
Page 17
Category list Category The categories are available depending on your TV model, region and country. Featured Provides information on available applications and content. If there is no network connection, or the “Featured Display” setting is set to “Off”, the “Featured” category will not be displayed. History Displays recently viewed items.
Watching Internet Video This feature serves as a gateway to Internet content, delivering a variety of on-demand entertainment straight to your TV. You can enjoy video content, including movies and cartoons. You will need to make a broadband Internet connection. For details, see page 12 (5: Connecting the TV to the Internet).
Looking for Instructions Looking for instructions in the electronic manual (i-Manual) Operating instructions are built into your BRAVIA TV and can be displayed on the screen. To learn more about your TV features, access your i-Manual with the touch of a button. Press i-MANUAL.
Page 20
Saving frequently viewed Displaying the page again pages (Bookmark) while operating the TV You can save frequently viewed pages for easy You can switch between the i-Manual screen access anytime. and the TV screen. This feature allows you to refer to the instructions in the i-Manual while To save a page using your BRAVIA TV.
Press "/1 on the TV to turn it off, disconnect the AC power cord (mains lead), and inform your dealer or Sony service centre of how the indicator flashes (number of flashes). When the illumination LED is not flashing, check the items in the table below.
(Wall-Mount Bracket) (KD-55X9000A only) To Customers: For product protection and safety reasons, Sony strongly recommends that installing of your TV be performed by Sony dealers or licensed contractors. Do not attempt to install it yourself. To Sony Dealers and Contractors: Provide full attention to safety during the installation, periodic maintenance and examination of this product.
Page 25
SU-WL400 Pulley B × Screw (+PSW 6 x 20) C Spacer E Band F Screw (+PSW 6 x 50) G • With the screen of the TV facing down, attach the SU-WL400 accessories. For more details of , refer to Instruction Guide provided with Wall-Mount Bracket. •...
Page 26
Hook locations diagram/table Hook location Model Name KD- SU-WL400 55X9000A SU-WL400 Hook location When installing the TV onto the Base Bracket.
Page 27
TV installation dimensions table SU-WL400 Screen centre point Unit: mm Screen centre Display dimensions Length for mounting Model Name dimension SU-WL400 55X9000A 1,463 Figures in the table may differ slightly depending on the installation. When your TV is installed on the wall, the upper side of the TV slightly leans forward. WARNING The wall that the TV will be installed should be capable of supporting a weight of at least four times that of the TV.
(mains socket). • Never cover the ventilation holes or – Use only Sony supplied AC power • Place the TV set on a stable, level insert anything in the cabinet. cords (mains lead), not those of surface to avoid it from falling down •...
• When using headphones, adjust the • Do not place the TV in a humid or Ask your dealer or Sony service centre dusty space, or in a room with oily volume so as to avoid excessive...
Page 30
• If this TV set is used in a cold place, a Optional Equipment smear may occur in the picture or the Keep optional components or any picture may become dark. This does equipment emitting electromagnetic not indicate a failure. These radiation away from the TV set.
Page 32
商標或註冊商標。 DLNA®、DLNA 標誌和 DLNA CERTIFIED® 是 Digital Living Network Alliance 的商標、服務標誌或認證標誌。 由 Dolby Laboratories 授權製造。 “BRAVIA” 是 Sony Corporation 的商標。 TrackID 是 Sony Mobile Communication AB 的商標或註冊商 標。 音樂辨識技術及相關資料由 Gracenote® 提供。Gracenote 是 音樂辨識技術和相關內容傳遞技術的業界標準。請前往 www.gracenote.com 瞭解有關詳情。 Gracenote,Inc. 提供的 CD、DVD、Blu-ray Disc 以及與音樂...
Page 55
SU-WL400 滑輪 B × 螺絲 (+PSW 6 x 20) C 墊片 E 帶子 F 螺絲 (+PSW 6 x 50) G • 電視機螢幕面朝下時, 安裝 SU-WL400 配件。 有關更多詳情 B、 C、 E、 F 和 G, 請參閱隨壁掛式支架提供 的使用指南。 • 將滑輪和螺絲 (+PSW6 x 20)安裝至電視機的上後部。 • 使用螺絲 (+PSW6 x 50)將帶子和墊片安裝至電視機的下後部。 •...
