Before initial use, see "Getting Started"
on page 9.
Thank you for purchasing a Panasonic product.
Please read these operating instructions before using the unit and save them for
future reference.
Operating Instructions
Digital Cordless Phone
Model No.
KX-TG1711BX
KX-TG1711UE

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-TG1711BX

Summary of Contents for Panasonic KX-TG1711BX

  • Page 1 Operating Instructions Digital Cordless Phone Model No. KX-TG1711BX KX-TG1711UE Before initial use, see “Getting Started” on page 9. Thank you for purchasing a Panasonic product. Please read these operating instructions before using the unit and save them for future reference.

  • Page 2: Table Of Contents

    Table of Contents Introduction Accessory information ........3 Graphical symbols for use on equipment and their descriptions ..........4 Important Information For your safety ..........5 Important safety instructions ......6 For best performance ........6 Other information .........7 Specifications ..........7 Getting Started Setting up .............9 Controls ............11 Display icons ..........12 Turning the power on/off ......12...

  • Page 3: Accessory Information

    Handset cover PNLV226CE: KX-TG1711BX PNLV226E: KX-TG1711UE See page 3 for replacement battery information. The handset cover comes attached to the handset. Additional/replacement accessories Please contact your nearest Panasonic dealer for sales information. Accessory item Model number/Specifications Rechargeable Battery type: batteries –...

  • Page 4: Graphical Symbols For Use On Equipment And Their Descriptions

    Introduction Graphical symbols for use on equipment and their descriptions Symbol Explanation Symbol Explanation Alternating current (A.C.) Class P equipment (equipment in which protection against electric shock relies on Double Insulation or Reinforced Insulation) Direct current (D.C.) “ON” (power) Protective earth “OFF”...

  • Page 5: Important Information

    Important Information R Do not allow the AC adaptor or telephone line cord to be excessively pulled, bent or For your safety placed under heavy objects. R Do not place the handset on the base unit To prevent severe injury and loss of life/ when battery cover is removed.

  • Page 6: Important Safety Instructions

    Base unit location/avoiding noise tamper with the base unit (or charger). Failure to follow these instructions may The base unit and other compatible Panasonic cause the batteries to swell or explode. units use radio waves to communicate with R Avoid the use in the following conditions: each other.

  • Page 7: Other Information

    Important Information R If the reception for a base unit location is Notice for product disposal, transfer, not satisfactory, move the base unit to or return another location for better reception. R This product can store your private/ Environment confidential information. To protect your privacy/confidentiality, we recommend that R Keep the product away from electrical noise you erase information such as phonebook...
  • Page 8 Important Information Maximum: 1.5 W R Operating conditions: 0 °C–40 °C, 20 %–80 % relative air humidity (dry) Note: R The range of the handset under maximum conditions is 50 metres indoors and 300 metres outdoors. Please note it will probably be shortened when near concrete barriers, etc.

  • Page 9: Getting Started

    A DSL/ADSL filter (not supplied) is required if you have a DSL/ADSL service. Note: R Use only the supplied Panasonic AC adaptor. R Use only the supplied telephone line cord. PNLV226CE: KX-TG1711BX PNLV226E: KX-TG1711UE...
  • Page 10 AC adaptor to your telephone line. Note for battery installation R Use the supplied rechargeable batteries. For replacement, we recommend using the Panasonic rechargeable batteries noted on page 3, 6. Battery charging Note for battery charging Charge for about 7 hours.

  • Page 11: Controls

    Getting Started Ni-MH battery performance (supplied Handset batteries) Operation Operating time In continuous use 15 hours max. Not in use (standby) 170 hours max. Note: R Actual battery performance depends on usage and ambient environment. Controls Base unit MWN (Phonebook) Charge contacts N (Talk) N (Locator)

  • Page 12: Display Icons

    Getting Started – (Volume: MDN or MCN) : Adjust the receiver volume while talking. Language setting – MFN ( : Caller list): View the caller list. – MEN (T: Redial): View the redial list. Display language N#110 Display icons MbN: Select your desired language. a N a MeN Handset display items Item...

  • Page 13: Making/Answering Calls

    Making/Answering Calls Making calls Answering calls Lift the handset and then dial the phone Lift the handset and press M N when number. the unit rings. R To correct a digit, press MCN. When you finish talking, press MeN or Press M N to make the call.
  • Page 14 Making/Answering Calls extension call, or accessing optional telephone services. Note: R To change the recall/flash time, see page 18. For call waiting or Call Waiting Caller ID service users To use call waiting or Call Waiting Caller ID, you must first subscribe with your phone service provider.

  • Page 15: Phonebook

    Phonebook To scroll through all entries Phonebook MbN: Select the desired entry. a M To search by first character You can add 50 names (16 characters max.) Press the dial key (0 to 9, or #) and phone numbers (24 digits max.) to the which contains the character you are phonebook.
  • Page 16 Phonebook Note: R When storing a calling card access number and your PIN in the phonebook as one phonebook entry, press MPN (Pause) to add pauses after the number and PIN as necessary (page 13). R If you have rotary/pulse service, you need to press * before pressing MWN in step 1 to change the dialling mode temporarily to tone.

  • Page 17: Programming

    Programming Menu list To access the features, there are 2 methods. n Scrolling through the display menus Press MCN or MDN to select the desired main menu. a M Press MCN or MDN to select the desired item from the next sub-menus. a M Press MCN or MDN to select the desired setting.
  • Page 18 Programming Main menu: “Caller List” Operation Code Viewing the caller list. #213 Main menu: “InitialSetup” Sub-menu 1 Sub-menu 2 Settings Code Display <On> #198 – Clock Disp. Level 1–6 #145 – Contrast <3> (Display contrast) – <On> #165 – Keytones Area Code –...

  • Page 19: Alarm

    Programming If you select one of the melody ringer tones, the ringer tone continues to play for several seconds even if the caller has already hung up. You may either hear a dial tone or no one on the line when you answer the call. This feature allows the unit to automatically adjust the date and time each time caller information including date and time is received.

  • Page 20: Other Programming

    Programming Other programming Storing an area code to be deleted automatically In some situations, phone numbers stored automatically in the caller list (page 21) will include area codes. If you do not want to dial the area code when making calls from the caller list, you can store the area code which you want the unit to delete automatically.

  • Page 21: Caller Id Service

    Caller ID Service Phonebook name display Using Caller ID service When caller information is received and it matches a phone number stored in the Important: phonebook, the stored name in the R This unit is Caller ID compatible. To use phonebook is displayed and logged in the Caller ID features, you must subscribe to a caller list.
  • Page 22 Caller ID Service Erasing all caller information MFN ( ) MbN: Select the desired entry. a MbN: “Erase” or “Erase All” a N 2 times...

  • Page 23: Useful Information

    Useful Information Voicemail service Voicemail is an answering service that may be offered by your phone service provider. This service can also record calls when you are unavailable to answer the phone or when your line is busy. Messages are recorded on the phone company system. When you have new messages, is displayed on the handset if message indication service is available.
  • Page 24 Useful Information Numeric entry table (0-9) Greek character table ( Extended 1 character table ( R The following are used for both uppercase and lowercase: Extended 2 character table ( R The following are used for both uppercase and lowercase:...

  • Page 25: Error Messages

    Useful Information Cyrillic character table ( Error messages Display message Cause/solution Base NoPower R Confirm the base unit’s AC adaptor is connected to the unit and the power outlet correctly. No Link R The handset has lost communication with the base unit. Move closer to the base unit and try again.
  • Page 26 Useful Information Problem Cause/solution The unit does not work. R Make sure the batteries are installed correctly (page 9). R Fully charge the batteries (page 10). R Check the connections (page 9). R Unplug the base unit’s AC adaptor to reset the unit and turn off the handset.
  • Page 27 Useful Information Making/answering calls, intercom Problem Cause/solution R The handset is too far from the base unit. Move closer. is flashing. R The base unit’s AC adaptor is not properly connected. Reconnect AC adaptor to the base unit. R The handset is not registered to the base unit. Register it (page 28).
  • Page 28 Useful Information Liquid damage Problem Cause/solution Liquid or other form of R Disconnect the AC adaptor and telephone line cord from the moisture has entered the base unit. Remove the batteries from the handset and leave to handset/base unit. dry for at least 3 days. After the handset/base unit are completely dry, reconnect the AC adaptor and telephone line cord.

  • Page 29: Index

    Index Index Alarm: 19 Answering calls: 13 Area code: 20 Auto talk: 13, 18 Battery: 9, 10 Call waiting: 14 Call Waiting Caller ID: 14 Caller ID service: 21 Caller list: 21 Caller list edit: 21 Chain dial: 15 Character entry: 23 Control type: 11 Date and time: 12 Dialling mode: 12...
  • Page 30 Notes...
  • Page 31 Notes...
  • Page 32 We recommend keeping a record of the following information to assist with any repair under warranty. Serial No. Date of purchase (found on the bottom of the base unit) Name and address of dealer © Panasonic Entertainment & Communication Co., Ltd. 2023 PNQP1813ZA PP0323YL0...
  • Page 33 ‫ﺗﻌﻠﻴﲈت اﻟﺘﺸﻐﻴﻞ‬ ‫ﻫﺎﺗﻒ رﻗﻤﻲ ﻻﺳﻠﻜﻲ‬ KX-TG1711BX ‫رﻗﻢ اﻟﻤﻮدﻳﻞ‬ KX-TG1711UE .٩ ‫ﻗﺒﻞ ﺍﻻﺳﺘﺨﺪﺍﻡ ﺃﻭﻝ ﻣﺮ ﹼ ﺓ، ﺭﺍﺟﻊ »ﺑﺪﺀ ﺍﻻﺳﺘﺨﺪﺍﻡ« ﻓﻲ ﺻﻔﺤﺔ‬ ‫ﺷﻜﺮ ﹰ ﺍ ﻟﺸﺮﺍﺋﻚ ﻣﻨﺘﺞ‬ Panasonic .‫ﺍﻟﺮﺟﺎﺀ ﻗﺮﺍﺀﺓ ﺗﻌﻠﻴﻤﺎﺕ ﺍﻟﺘﺸﻐﻴﻞ ﻫﺬﻩ ﻗﺒﻞ ﺍﺳﺘﺨﺪﺍﻡ ﺍﻟﻮﺣﺪﺓ ﻭﺣﻔﻈﻬﺎ ﻟﻠﺮﺟﻮﻉ ﺇﻟﻴﻬﺎ ﻓﻲ ﺍﻟﻤﺴﺘﻘﺒﻞ‬...
  • Page 34 ‫ﺟﺪﻭﻝ ﺍﻟﻤﺤﺘﻮﻳﺎﺕ‬ ‫ﻣﻘﺪﻣﺔ‬ ٣ ......‫ﺍﻟﻤﻌﻠﻮﻣﺎﺕ ﺍﻟﻤﺘﻌﻠﻘﺔ ﺑﺎﻟﻤﻠﺤﻘﺎﺕ‬ ‫ﺍﻟﺮﻣﻮﺯ ﺍﻟﺮﺳﻮﻣﻴﺔ ﻣﺨﺼﺼﺔ ﻟﻼﺳﺘﺨﺪﺍﻡ ﻋﻠﻰ ﺍﻟﻤﻌﺪﺍﺕ‬ ٤ ..........‫ﻭﺃﻭﺻﺎﻓﻬﺎ‬ ‫ﻣﻌﻠﻮﻣﺎﺕ ﻣﻬﻤﺔ‬ ٥ ..........‫ﻣﻦ ﺃﺟﻞ ﺳﻼﻣﺘﻚ‬ ٦ ......‫ﺗﻌﻠﻴﻤﺎﺕ ﻣﻬﻤﺔ ﺗﺘﻌﻠﻖ ﺑﺎﻟﺴﻼﻣﺔ‬ ٦ ........‫ﻟﻠﺤﺼﻮﻝ ﻋﻠﻰ ﺃﻓﻀﻞ ﺃﺩﺍﺀ‬ ٧ ...........￯‫ﻣﻌﻠﻮﻣﺎﺕ ﺃﺧﺮ‬ ٧ ..........‫ﺍﻟﻤﻮﺍﺻﻔﺎﺕ‬ ‫ﺑﺪﺀ ﺍﻻﺳﺘﺨﺪﺍﻡ‬ ٩...
  • Page 35 ‫ﺑﻄﺎﺭﻳﺎﺕ ﻗﺎﺑﻠﺔ ﻹﻋﺎﺩﺓ ﺍﻟﺸﺤﻦ‬ ٢ ۲*  ‫ﻏﻄﺎﺀ ﺍﻟﻮﺣﺪﺓ ﺍﻟﻴﺪﻭﻳﺔ‬ ١ ۳*  * ۱ KX-TG1711BX PNLV226CE KX-TG1711UE PNLV226E .‫ﺭﺍﺟﻊ ﺻﻔﺤﺔ ٣ ﻟﻠﺤﺼﻮﻝ ﻋﻠﻰ ﻣﻌﻠﻮﻣﺎﺕ ﺣﻮﻝ ﺍﺳﺘﺒﺪﺍﻝ ﺍﻟﺒﻄﺎﺭﻳﺔ‬ * ۲ .‫ﻳﺄﺗﻲ ﻏﻄﺎﺀ ﺍﻟﻮﺣﺪﺓ ﺍﻟﻴﺪﻭﻳـﺔ ﻣﺮﻓ ﻘ ﹰ ﺎ ﺑﺎﻟﻮﺣﺪﺓ ﺍﻟﻴﺪﻭﻳﺔ‬ * ۳ ...
  • Page 36 ‫ﺍﻟﻤﻘﺪﻣﺔ‬ ‫ﺍﻟﺮﻣﻮﺯ ﺍﻟﺮﺳﻮﻣﻴﺔ ﻣﺨﺼﺼﺔ ﻟﻼﺳﺘﺨﺪﺍﻡ ﻋﻠﻰ ﺍﻟﻤﻌﺪﺍﺕ ﻭﺃﻭﺻﺎﻓﻬﺎ‬ ‫ﺍﻟﺘﻮﺿﻴﺢ‬ ‫ﺍﻟﺮ ﹶ ﻣﺰ‬ ‫ﺍﻟﺘﻮﺿﻴﺢ‬ ‫ﺍﻟﺮﻣﺰ‬ ‫ﺗﻴﺎﺭ ﻣﺘﺮﺩﺩ‬ ‫)ﺣﻴﺚ ﻳﻜﻮﻥ ﺍﻟﺠﻬﺎﺯ‬ ‫ﺟﻬﺎﺯ ﻓﺌﺔ‬ (A.C. ) ‫ﻣﺤﻤﻲ ﺿﺪ ﺍﻟﺼﺪﻣﺎﺕ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬ ‫ﻣﻦ ﺧﻼﻝ ﺍﻟﻌﺰﻝ ﺍﻟﻤﺰﺩﻭﺝ ﺃﻭ ﺍﻟﻌﺰﻝ‬ (‫ﺍﻟﻤﻌﺰﺯ‬ (‫)ﺍﻟﺘﻴﺎﺭ‬ ‫ﺍﻟﺘﻴﺎﺭ ﺍﻟﻤﺒﺎﺷﺮ‬ "ON" (D.C. ) ‫ﺃﺭﺿﻲ...
  • Page 37 ‫ﻣﻌﻠﻮﻣﺎﺕ ﻣﻬﻤﺔ‬ ‫ﻻ ﺗﺴﻤﺢ ﺑﺴﺤﺐ ﻣﻬﺎﻳﺊ ﺍﻟﺘﻴﺎﺭ ﺍﻟﻤﺘﺮﺩﺩ ﺃﻭ ﺳﻠﻚ ﺧﻂ‬ ‫ﻣﻦ ﺃﺟﻞ ﺳﻼﻣﺘﻚ‬ .‫ﺍﻟﻬﺎﺗﻒ ﺑﺸﻜﻞ ﻣﻔﺮﻁ ﺃﻭ ﺛﻨﻴﻪ ﺃﻭ ﻭﺿﻌﻪ ﺗﺤﺖ ﺃﺷﻴﺎﺀ ﺛﻘﻴﻠﺔ‬ ‫ﻻ ﺗﻀﻊ ﺍﻟﻮﺣﺪﺓ ﺍﻟﻴﺪﻭﻳﺔ ﻋﻠﻰ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺮﺋﻴﺴﻴﺔ ﻋﻨﺪﻣﺎ ﻳﻜﻮﻥ‬ /‫ﻟﻠﺤﺪ ﻣﻦ ﺍﻟﺘﻌﺮﺽ ﻹﺻﺎﺑﺔ ﺧﻄﻴﺮﺓ ﻭﻓﻘﺪﺍﻥ ﺍﻟﺤﻴﺎﺓ‬ .‫ﻏﻄﺎﺀ...
  • Page 38 ‫ﻣﻜﺎﻥ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺮﺋﻴﺴﻴﺔ/ﺗﺠﻨﺐ ﺍﻟﻀﻮﺿﺎﺀ‬ ‫ﺑﺎﻟﻮﺣﺪﺓ ﺍﻟﺮﺋﻴﺴﻴﺔ )ﺃﻭ ﺍﻟﺸﺎﺣﻦ(. ﻗﺪ ﻳﻨﺘﺞ ﻋﻦ ﺍﻹﺧﻔﺎﻕ ﻓﻲ‬ ‫ﺍﻟﻤﺘﻮﺍﻓﻘﺔ‬ ‫ﺗﺴﺘﺨﺪﻡ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺮﺋﻴﺴﻴﺔ ﻭﻭﺣﺪﺍﺕ‬ Panasonic .‫ﺍﺗﺒﺎﻉ ﺗﻠﻚ ﺍﻟﺘﻌﻠﻴﻤﺎﺕ ﺍﻧﺘﻔﺎﺥ ﺍﻟﺒﻄﺎﺭﻳﺎﺕ ﺃﻭ ﺍﻧﻔﺠﺎﺭﻫﺎ‬ .‫ﺍﻷﺧﺮ￯ ﻣﻮﺟﺎﺕ ﻻﺳﻠﻜﻴﺔ ﻟﻼﺗﺼﺎﻝ ﻣﻊ ﺑﻌﻀﻬﺎ‬ :‫ﺗﺠ ﻨ ﹼ ﺐ ﺍﻻﺳﺘﺨﺪﺍﻡ ﻓﻲ ﺍﻷﺣﻮﺍﻝ ﺍﻟﺘﺎﻟﻴﺔ‬...
  • Page 39 ‫ﻣﻌﻠﻮﻣﺎﺕ ﻣﻬﻤﺔ‬ ‫ﺇﺫﺍ ﻛﺎﻥ ﺍﺳﺘﻘﺒﺎﻝ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺮﺋﻴﺴﻴﺔ ﻟﻴﺲ ﻣﺮﺿ ﻴ ﹰ ﺎ، ﻓﺎﻧﻘﻠﻬﺎ ﺇﻟﻰ‬ ‫ﻣﻠﺤﻮﻇﺔ ﺑﺸﺄﻥ ﺍﻟﺘﺨﻠﺺ ﻣﻦ ﺍﻟﻤﻨﺘﺞ، ﺃﻭ ﻧﻘﻠﻪ، ﺃﻭ‬ .‫ﻣﻮﻗﻊ ﺁﺧﺮ ﻟﻠﺤﺼﻮﻝ ﻋﻠﻰ ﺍﺳﺘﻘﺒﺎﻝ ﺃﻓﻀﻞ‬ ‫ﺇﺭﺟﺎﻋﻪ‬ ‫ﺍﻟﺒﻴﺌﺔ‬ .‫ﻳﻤﻜﻦ ﻟﻬﺬﺍ ﺍﻟﻤﻨﺘﺞ ﺗﺨﺰﻳﻦ ﻣﻌﻠﻮﻣﺎﺗﻚ ﺍﻟﺨﺎﺻﺔ/ﺍﻟﺴﺮﻳﺔ‬ ‫ﻭﻟﺤﻤﺎﻳﺔ ﺧﺼﻮﺻﻴﺘﻚ/ﺃﺳﺮﺍﺭﻙ، ﻧﻮﺻﻲ ﺑﺄﻥ ﺗﻤﺴﺢ‬ ‫ﺣﺎﻓﻆ...
  • Page 40 ‫ﻣﻌﻠﻮﻣﺎﺕ ﻣﻬﻤﺔ‬ :‫ﺍﺳﺘﻬﻼﻙ ﺍﻟﻄﺎﻗﺔ‬   :‫ﺍﻟﻮﺣﺪﺓ ﺍﻟﺮﺋﻴﺴﻴﺔ‬ ‫ﻭﺿﻊ ﺍﻻﺳﺘﻌﺪﺍﺩ: ٦٫٠ ﻭﺍﻁ‬ ‫ﺍﻟﺤﺪ ﺍﻷﻗﺼﻰ: ٥٫١ ﻭﺍﻁ‬ :‫ﻇﺮﻭﻑ ﺍﻟﺘﺸﻐﻴﻞ‬   (‫٠ °ﻡ - ٠٤ °ﻡ، ﺭﻃﻮﺑﺔ ﻫﻮﺍﺀ ﻧﺴﺒﻴﺔ ٠٢% - ٠٨% )ﺟﺎﻑ‬ :‫ﻣﻼﺣﻈﺔ‬ ٥٠ ‫ﻳ ﹸ ﻌﺪ ﻧﻄﺎﻕ ﺍﻟﻮﺣﺪﺓ ﺍﻟﻴﺪﻭﻳﺔ ﻓﻲ ﺍﻟﻈﺮﻭﻑ ﺍﻟﻘﺼﻮ￯ ﻫﻮ‬ ‫ﻣﺘﺮ...
  • Page 41 ‫)ﻏﻴﺮ ﻣﺮﻓﻖ( ﻣﻄﻠﻮ ﺑ ﹰ ﺎ ﺇﺫﺍ‬ ‫ﻳﻜﻮﻥ ﻣﺮﺷﺢ‬  DSL/ADSL ‫ﻛﺎﻧﺖ ﻟﺪﻳﻚ ﺧﺪﻣﺔ‬ DSL/ADSL :‫ﻣﻼﺣﻈﺔ‬ ‫ﻻ ﺗﺴﺘﻌﻤﻞ ﺳﻮ￯ ﻣﻬﺎﻳﺊ ﺍﻟﺘﻴﺎﺭ ﺍﻟﻤﺘﺮﺩﺩ ﺍﻟﻤﺮﻓﻖ ﻣﻦ‬ ۱* Panasonic .‫ﻻ ﺗﺴﺘﻌﻤﻞ ﺳﻮ￯ ﺳﻠﻚ ﺧﻂ ﺍﻟﻬﺎﺗﻒ ﺍﻟﻤﺮﻓﻖ‬ KX-TG1711BX PNLV226CE * ۱ KX-TG1711UE PNLV226E      ...
  • Page 42 .‫ﺗﻴﺎﺭ ﻣﺘﺮﺩﺩ‬ ‫ﻣﻼﺣﻈﺔ ﺑﺸﺄﻥ ﺗﺮﻛﻴﺐ ﺍﻟﺒﻄﺎﺭﻳﺔ‬ .‫ﺍﺳﺘﺨﺪﻡ ﺍﻟﺒﻄﺎﺭﻳﺎﺕ ﺍﻟﻘﺎﺑﻠﺔ ﻹﻋﺎﺩﺓ ﺍﻟﺸﺤﻦ ﺍﻟﻤ ﹸ ﺮﻓﻘﺔ‬ ‫ﻻﺳﺘﺒﺪﺍﻟﻬﺎ، ﻧﻮﺻﻲ ﺑﺎﺳﺘﺨﺪﺍﻡ ﺑﻄﺎﺭﻳﺎﺕ‬ Panasonic .٦ ‫ﺍﻟﻘﺎﺑﻠﺔ ﻹﻋﺎﺩﺓ ﺍﻟﺸﺤﻦ ﺍﻟﻤﺬﻛﻮﺭﺓ ﻓﻲ ﺻﻔﺤ ﺘ ﹶ ﻲ ٣ ﻭ‬ ‫ﻣﻼﺣﻈﺔ ﺑﺸﺄﻥ ﺷﺤﻦ ﺍﻟﺒﻄﺎﺭﻳﺔ‬ ‫ﺷﺤﻦ ﺍﻟﺒﻄﺎﺭﻳﺔ‬ .‫ﻣﻦ ﺍﻟﻄﺒﻴﻌﻲ ﺃﻥ ﺗﺮﺗﻔﻊ ﺣﺮﺍﺭﺓ ﺍﻟﻮﺣﺪﺓ ﺍﻟﻴﺪﻭﻳﺔ ﺃﺛﻨﺎﺀ ﺍﻟﺸﺤﻦ‬...
  • Page 43 ‫ﺑﺪﺀ ﺍﻻﺳﺘﺨﺪﺍﻡ‬ ‫ﺍﻟﻮﺣﺪﺓ ﺍﻟﻴﺪﻭﻳﺔ‬ ‫ﺃﺩﺍﺀ ﺑﻄﺎﺭﻳﺔ ﻫﻴﺪﺭﻳﺪ ﻣﻌﺪﻥ ﺍﻟﻨﻴﻜﻞ‬ Ni-MH (‫)ﺍﻟﺒﻄﺎﺭﻳﺎﺕ ﺍﻟﻤﺮﻓﻘﺔ‬  ‫ﻣﺪﺓ ﺍﻟﺘﺸﻐﻴﻞ‬ ‫ﺍﻟﺘﺸﻐﻴﻞ‬ ‫٥١ ﺳﺎﻋﺔ ﺑﺤﺪ ﺃﻗﺼﻰ‬ ‫ﺧﻼﻝ ﺍﻻﺳﺘﺨﺪﺍﻡ‬ ‫ﺍﻟﻤﺘﻮﺍﺻﻞ‬  ‫٠٧١ ﺳﺎﻋﺔ ﺑﺤﺪ ﺃﻗﺼﻰ‬ ‫ﻋﻨﺪ ﻋﺪﻡ ﺍﻻﺳﺘﻌﻤﺎﻝ‬ (‫)ﻭﺿﻊ ﺍﻻﺳﺘﻌﺪﺍﺩ‬     :‫ﻣﻼﺣﻈﺔ‬  ‫ﻳﻌﺘﻤﺪ ﺍﻷﺩﺍﺀ ﺍﻟﻔﻌﻠﻲ ﻟﻠﺒﻄﺎﺭﻳﺔ ﻋﻠﻰ ﺍﻻﺳﺘﺨﺪﺍﻡ ﻭﺍﻟﺒﻴﺌﺔ‬ ...
  • Page 44 ‫ﺑﺪﺀ ﺍﻻﺳﺘﺨﺪﺍﻡ‬ ‫ﻧﻮﻉ ﺃﺯﺭﺍﺭ ﺍﻟﺘﺤﻜﹼ ﻢ‬ ‫ﺑﺎﻟﺮﻏﻢ ﻣﻦ ﺃﻥ ﺍﻟﻮﺣﺪﺓ ﺍﻟﻴﺪﻭﻳﺔ ﺗﻌﺮﺽ ﻫﺬﻩ ﺍﻟﻌﻨﺎﺻﺮ، ﺇﻻ‬   * ۲ ‫ﻣﻔﺘﺎﺡ ﺍﻟﺘﻨﻘﻞ‬ .‫ﺃﻥ ﻫﺬﻩ ﺍﻟﻤﺰﺍﻳﺎ ﻻ ﺗﺘﻮﻓﺮ ﻓﻲ ﻫﺬﺍ ﺍﻟﻤﻮﺩﻳﻞ‬ .‫ﺗﻌﻤﻞ ﻣﻔﺎﺗﻴﺢ ﺍﻟﺘﻨﻘﻞ ﻛﻤﺎ ﻳﻠﻲ‬ ‫ﻟﻠﻤﺸﺘﺮﻛﻴﻦ ﻓﻲ ﺍﻟﺒﺮﻳﺪ ﺍﻟﺼﻮﺗﻲ ﻓﻘﻂ‬ * ۳ ‫: ﻟﻠﺘﻤﺮﻳﺮ...
  • Page 45 ‫ﺇﺟﺮﺍﺀ/ﺍﻟﺮﺩ ﻋﻠﻰ ﺍﻟﻤﻜﺎﻟﻤﺎﺕ ﺍﻟﻬﺎﺗﻔﻴﺔ‬ ‫ﺍﻟﺮﺩ ﻋﻠﻰ ﺍﻟﻤﻜﺎﻟﻤﺎﺕ ﺍﻟﻬﺎﺗﻔﻴﺔ‬ ‫ﺇﺟﺮﺍﺀ ﺍﻟﻤﻜﺎﻟﻤﺎﺕ ﺍﻟﻬﺎﺗﻔﻴﺔ‬ ١ ١ ‫ﻋﻨﺪﻣﺎ ﻳﺮﻥ‬ ‫ﺍﺭﻓﻊ ﺍﻟﻮﺣﺪﺓ ﺍﻟﻴﺪﻭﻳﺔ ﻭﺍﺿﻐﻂ ﻋﻠﻰ‬ .‫ﺍﺭﻓﻊ ﺍﻟﻮﺣﺪﺓ ﺍﻟﻴﺪﻭﻳﺔ ﺛﻢ ﺍﻃﻠﺐ ﺭﻗﻢ ﺍﻟﻬﺎﺗﻒ‬ .‫ﺟﺮﺱ ﺍﻟﻮﺣﺪﺓ‬ ‫ﻟﺘﺼﺤﻴﺢ ﺃﺣﺪ ﺍﻷﺭﻗﺎﻡ، ﺍﺿﻐﻂ ﻋﻠﻰ‬ ٢ ‫ﺃﻭ ﺿﻊ‬ ‫ﻋﻨﺪﻣﺎ ﺗﻨﺘﻬﻲ ﻣﻦ ﺍﻟﺘﺤﺪﺙ، ﺍﺿﻐﻂ ﻋﻠﻰ‬ ٢...
  • Page 46 ‫ﺇﺟﺮﺍﺀ/ﺍﻟﺮﺩ ﻋﻠﻰ ﺍﻟﻤﻜﺎﻟﻤﺎﺕ ﺍﻟﻬﺎﺗﻔﻴﺔ‬ ‫ﺇﻋﺎﺩﺓ ﺍﻻﺗﺼﺎﻝ/ﻭﻣﻴﺾ ﺍﻟﻔﻼﺵ‬ ‫ﻟﻚ ﺍﺳﺘﺨﺪﺍﻡ ﺍﻟﻤﻴﺰﺍﺕ ﺍﻟﺨﺎﺻﺔ ﺑﺎﻟﻤﻘﺴﻢ ﺍﻟﻔﺮﻋﻲ‬ ‫ﻳ ﹸ ﺘﻴﺢ‬ ‫ﺍﻟﻤﻀﻴﻒ ﻣﺜﻞ ﺗﺤﻮﻳﻞ ﻣﻜﺎﻟﻤﺔ ﻣﻤﺘﺪﺓ، ﺃﻭ‬ ‫ﺍﻟﺨﺎﺹ‬ .‫ﺍﻟﻮﺻﻮﻝ ﺇﻟﻰ ﺧﺪﻣﺎﺕ ﺍﻟﻬﺎﺗﻒ ﺍﻻﺧﺘﻴﺎﺭﻳﺔ‬ :‫ﻣﻼﺣﻈﺔ‬ ‫ﻟﺘﻐﻴﻴﺮ ﻭﻗﺖ ﺇﻋﺎﺩﺓ ﺍﻻﺗﺼﺎﻝ/ﻭﻣﻴﺾ ﺍﻟﻔﻼﺵ، ﺭﺍﺟﻊ ﺻﻔﺤﺔ‬ .١٨ ‫ﻟﻤﺴﺘﺨﺪﻣﻲ ﺧﺪﻣﺔ ﺍﻧﺘﻈﺎﺭ ﺍﻟﻤﻜﺎﻟﻤﺎﺕ ﺃﻭ‬ ‫ﺧﺪﻣﺔ...
  • Page 47 ‫ﺩﻟﻴﻞ ﺍﻟﻬﺎﺗﻒ‬ ٢ ‫ﻟﻠﺘﻨﻘﻞ ﺧﻼﻝ ﺟﻤﻴﻊ ﺍﻹﺩﺧﺎﻻﺕ‬ ‫ﺩﻟﻴﻞ ﺍﻟﻬﺎﺗﻒ‬ .‫: ﺣﺪﺩ ﺍﻹﺩﺧﺎﻝ ﺍﻟﻤﺮﻏﻮﺏ ﺑﻪ‬ ‫ﻟﻠﺒﺤﺚ ﺑﺎﺳﺘﺨﺪﺍﻡ ﺍﻟﺤﺮﻑ ﺍﻷﻭﻝ‬ ‫ﻳ ﹸ ﻤﻜﻨﻚ ﺇﺿﺎﻓﺔ ٠٥ ﺍﺳﻢ )٦١ ﺣﺮ ﻓ ﹰ ﺎ ﺑﺤﺪ ﺃﻗﺼﻰ( ﻭﺃﺭﻗﺎﻡ ﻫﺎﺗﻒ‬ ‫، ﺃﻭ‬ ‫ﺇﻟﻰ‬ ‫ﺍﺿﻐﻂ ﻋﻠﻰ ﻣﻔﺘﺎﺡ ﺍﻻﺗﺼﺎﻝ )ﻣﻦ‬ ...
  • Page 48 ‫ﺩﻟﻴﻞ ﺍﻟﻬﺎﺗﻒ‬ ١ ‫ﺃﺛﻨﺎﺀ ﺍﻟﻤﻜﺎﻟﻤﺔ ﺍﻟﺨﺎﺭﺟﻴﺔ، ﺍﺿﻐﻂ ﻋﻠﻰ‬ ٢ .‫: ﺣﺪﺩ ﺍﻹﺩﺧﺎﻝ ﺍﻟﻤﺮﻏﻮﺏ ﺑﻪ‬ ٣ .‫ﻟﻄﻠﺐ ﺍﻟﺮﻗﻢ‬ ‫ﺍﺿﻐﻂ ﻋﻠﻰ‬ :‫ﻣﻼﺣﻈﺔ‬ ‫ﻋﻨﺪ ﺗﺨﺰﻳﻦ ﺭﻗﻢ ﺍﻟﻮﺻﻮﻝ ﺇﻟﻰ ﺑﻄﺎﻗﺔ ﺍﺗﺼﺎﻝ ﻭﺭﻣﺰ‬ ‫ﺍﻟﺨﺎﺹ ﺑﻚ ﻓﻲ ﺩﻟﻴﻞ ﺍﻟﻬﺎﺗﻒ ﻛﻘﻴﺪ ﺇﺩﺧﺎﻝ ﻭﺍﺣﺪ ﻣﻦ ﻗﻴﻮﺩ‬ ‫ﻹﺿﺎﻓﺔ ﻭﻗﻔﺎﺕ‬ ‫ﺇﺩﺧﺎﻝ...
  • Page 49 ‫ﺍﻟﺒﺮﻣﺠﺔ‬ ‫ﻻﺋﺤﺔ ﺍﻟﻘﺎﺋﻤﺔ‬ .‫ﺗﻮﺟﺪ ﻃﺮﻳﻘﺘﺎﻥ ﻟﻠﻮﺻﻮﻝ ﺇﻟﻰ ﺍﻟﻤﻴﺰﺍﺕ‬ ‫ﺍﻟﺘﻤﺮﻳﺮ ﺧﻼﻝ ﻗﻮﺍﺋﻢ ﺷﺎﺷﺔ ﺍﻟﻌﺮﺽ‬   ١ {j/OK} ٢ .‫ﻻﺧﺘﻴﺎﺭ ﺍﻟﻘﺎﺋﻤﺔ ﺍﻟﺮﺋﻴﺴﻴﺔ‬ ‫ﺃﻭ‬ ‫ﺍﺿﻐﻂ ﻋﻠﻰ‬ {j/OK} ٣ .‫ﻻﺧﺘﻴﺎﺭ ﺍﻟﺒﻨﺪ ﺍﻟﻤﺮﻏﻮﺏ ﻣﻦ ﺍﻟﻘﻮﺍﺋﻢ ﺍﻟﻔﺮﻋﻴﺔ ﺍﻟﺘﺎﻟﻴﺔ‬ ‫ﺃﻭ‬ ‫ﺍﺿﻐﻂ ﻋﻠﻰ‬ {j/OK} ٤ .‫ﻻﺧﺘﻴﺎﺭ ﺍﻹﻋﺪﺍﺩ ﺍﻟﻤﺮﻏﻮﺏ‬ ‫ﺃﻭ‬...
  • Page 50 ‫ﺍﻟﺒﺮﻣﺠﺔ‬ :‫ﺍﻟﻘﺎﺋﻤﺔ ﺍﻟﺮﺋﻴﺴﻴﺔ‬ “Caller List” ‫ﺍﻟﺮﻣﺰ‬ ‫ﺍﻟﺘﺸﻐﻴﻞ‬ .‫ﻋﺮﺽ ﻗﺎﺋﻤﺔ ﺍﻟﻤﺘﺼﻠﻴﻦ‬ ٢١ 312# :‫ﺍﻟﻘﺎﺋﻤﺔ ﺍﻟﺮﺋﻴﺴﻴﺔ‬ “InitialSetup” ‫ﺍﻟﺮﻣﺰ‬ ‫ﺍﻹﻋﺪﺍﺩﺍﺕ‬ ٢ ‫ﺍﻟﻘﺎﺋﻤﺔ ﺍﻟﻔﺮﻋﻴﺔ‬ ١ ‫ﺍﻟﻘﺎﺋﻤﺔ ﺍﻟﻔﺮﻋﻴﺔ‬ ٤* <On> Clock Disp. – 891# Display ٦-١ ￯‫ﺍﻟﻤﺴﺘﻮ‬ Contrast – 541# (‫)ﻋﺮﺽ ﺍﻟﺘﺒﺎﻳﻦ‬ ٣ < > <On>...
  • Page 51 ‫ﺍﻟﺒﺮﻣﺠﺔ‬ ‫ﺇﺫﺍ ﺍﺧﺘﺮﺕ ﺇﺣﺪ￯ ﻧﻐﻤﺎﺕ ﺍﻟﺠﺮﺱ ﺍﻟﻤﻮﺳﻴﻘﻴﺔ، ﻳﺴﺘﻤﺮ ﺻﺪﻭﺭ ﺻﻮﺕ ﻧﻐﻤﺔ ﻣﻮﺳﻴﻘﻰ ﺍﻟﺠﺮﺱ ﻟﻌﺪﺓ ﺛﻮﺍﻥ ﺣﺘﻰ ﻭﻟﻮ ﻛﺎﻥ ﺍﻟﻤﺘﺼﻞ‬ * ۲ .‫ﻗﺪ ﺃﻏﻠﻖ ﺑﺎﻟﺨﻂ ﺑﺎﻟﻔﻌﻞ. ﻗﺪ ﺗﺴﻤﻊ ﻧﻐﻤﺔ ﻃﻠﺐ ﺭﻗﻢ ﺃﻭ ﻻ ﺃﺣﺪ ﻋﻠﻰ ﺍﻟﺨﻂ ﻋﻨﺪﻣﺎ ﺗﺮﺩ ﻋﻠﻰ ﺍﻟﻤﻜﺎﻟﻤﺔ‬ ‫ﺗﺘﻴﺢ ﻫﺬﻩ ﺍﻟﻤﻴﺰﺓ ﻟﻠﻮﺣﺪﺓ ﺍﻟﺮﺋﻴﺴﻴﺔ ﺿﺒﻂ ﺍﻟﺘﺎﺭﻳﺦ ﻭﺍﻟﻮﻗﺖ ﺗﻠﻘﺎﺋ ﻴ ﹰ ﺎ ﻓﻲ ﻛﻞ ﻣﺮﺓ ﻳﺘﻢ ﻓﻴﻬﺎ ﺍﺳﺘﻼﻡ ﻣﻌﻠﻮﻣﺎﺕ ﺍﻟﻤﺘﺼﻞ ﺑﻤﺎ ﻓﻲ ﺫﻟﻚ‬ * ۳...
  • Page 52 ‫ﺍﻟﺒﺮﻣﺠﺔ‬ ‫ﺑﺮﻣﺠﺔ ﺃﺧﺮﻯ‬ ‫ﺗﺨﺰﻳﻦ ﺭﻣﺰ ﺍﻟﻤﻨﻄﻘﺔ ﻟﻴﺘﻢ ﺣﺬﻓﻪ ﺑﺼﻮﺭﺓ‬ ‫ﺗﻠﻘﺎﺋﻴﺔ‬ ‫ﻓﻲ ﺑﻌﺾ ﺍﻷﺣﻮﺍﻝ، ﺗﻜﻮﻥ ﺃﺭﻗﺎﻡ ﺍﻟﻬﺎﺗﻒ ﺍﻟﻤﺨﺰ ﹼ ﻧﺔ ﺗﻠﻘﺎﺋ ﻴ ﹰ ﺎ ﻓﻲ‬ ‫ﻗﺎﺋﻤﺔ ﺍﻟﻤﺘﺼﻠﻴﻦ )ﺻﻔﺤﺔ ١٢( ﻣﺘﻀﻤ ﹼ ﻨﺔ ﻟﺮﻣﻮﺯ ﺍﻟﻤﻨﻄﻘﺔ. ﺇﺫﺍ‬ ‫ﻛﻨﺖ ﻻ ﺗﺮﻳﺪ ﻃﻠﺐ ﺭﻣﺰ ﺍﻟﻤﻨﻄﻘﺔ ﻋﻨﺪ ﺇﺟﺮﺍﺀ ﺍﻟﻤﻜﺎﻟﻤﺎﺕ ﺍﻟﻬﺎﺗﻔﻴﺔ‬ ‫ﻣﻦ...
  • Page 53 ‫ﺧﺪﻣﺔ ﺇﻇﻬﺎﺭ ﻫﻮﻳﺔ ﺍﻟﻤﺘﺼﻞ‬ ‫ﻋﺮﺽ ﺍﺳﻢ ﺩﻟﻴﻞ ﺍﻟﻬﺎﺗﻒ‬ ‫ﺍﺳﺘﺨﺪﺍﻡ ﺧﺪﻣﺔ ﺇﻇﻬﺎﺭ ﻫﻮﻳﺔ‬ ‫ﻋﻨﺪﻣﺎ ﻳﺘﻢ ﺍﺳﺘﻼﻡ ﻣﻌﻠﻮﻣﺎﺕ ﺍﻟﻤﺘﺼﻞ ﻭﺗﺘﻄﺎﺑﻖ ﻣﻊ ﺭﻗﻢ ﺍﻟﻬﺎﺗﻒ‬ ‫ﺍﻟﻤﺘﺼﻞ‬ ‫ﺍﻟﻤ ﹸ ﺨﺰ ﹼ ﻥ ﻓﻲ ﺩﻟﻴﻞ ﺍﻟﻬﺎﺗﻒ، ﻳﺘﻢ ﻋﺮﺽ ﺍﻻﺳﻢ ﺍﻟﻤ ﹸ ﺨﺰ ﹼ ﻥ ﻓﻲ ﺩﻟﻴﻞ‬ .‫ﺍﻟﻬﺎﺗﻒ...
  • Page 54 ‫ﺧﺪﻣﺔ ﺇﻇﻬﺎﺭ ﻫﻮﻳﺔ ﺍﻟﻤﺘﺼﻞ‬ ‫ﻣﺴﺢ ﺟﻤﻴﻊ ﻣﻌﻠﻮﻣﺎﺕ ﺍﻟﻤﺘﺼﻞ‬ ١ ٢ .‫: ﺣﺪﺩ ﺍﻹﺩﺧﺎﻝ ﺍﻟﻤﺮﻏﻮﺏ ﺑﻪ‬ {j/OK} ٣ ‫ﺃﻭ‬ “Erase All” “Erase” ‫ﻣﺮ ﹼ ﺗﺎﻥ‬ {j/OK} ٤ {ic} ٢٢ (22)
  • Page 55 ‫ﻣﻌﻠﻮﻣﺎﺕ ﻣﻔﻴﺪﺓ‬ ‫ﺧﺪﻣﺔ ﺍﻟﺒﺮﻳﺪ ﺍﻟﺼﻮﺗﻲ‬ ‫ﻳ ﹸ ﻌﺪ ﺍﻟﺒﺮﻳﺪ ﺍﻟﺼﻮﺗﻲ ﺧﺪﻣﺔ ﺭ ﺩ ﹼ ﺁﻟﻲ ﻗﺪ ﻳﺘﻢ ﺗﻘﺪﻳﻤﻬﺎ ﻣﻦ ﻗﺒﻞ ﻣﻮﻓﺮ ﺧﺪﻣﺔ ﺍﻟﻬﺎﺗﻒ ﺍﻟﺨﺎﺹ ﺑﻚ. ﻛﻤﺎ ﻳﻤﻜﻦ ﻟﻬﺬﻩ ﺍﻟﺨﺪﻣﺔ ﺃﻳﻀ ﹰ ﺎ ﺗﺴﺠﻴﻞ‬ .‫ﺍﻟﻤﻜﺎﻟﻤﺎﺕ ﻋﻨﺪﻣﺎ ﻻ ﺗﻜﻮﻥ ﻣﺘﺎﺣ ﹰ ﺎ ﻟﻠﺮﺩ ﻋﻠﻰ ﺍﻟﻬﺎﺗﻒ ﺃﻭ ﻋﻨﺪﻣﺎ ﻳﻜﻮﻥ ﺍﻟﺨﻂ ﻣﺸﻐﻮﻻ ﹰ . ﻳﺘﻢ ﺗﺴﺠﻴﻞ ﺍﻟﺮﺳﺎﺋﻞ ﻓﻲ ﻧﻈﺎﻡ ﺷﺮﻛﺔ ﺍﻟﻬﺎﺗﻒ‬ ‫ﻋﻠﻰ...
  • Page 56 ‫ﻣﻌﻠﻮﻣﺎﺕ ﻣﻔﻴﺪﺓ‬ ) ‫ﺟﺪﻭﻝ ﺇﺩﺧﺎﻝ ﺍﻷﺭﻗﺎﻡ‬ 9 -0 ) ‫ﺟﺪﻭﻝ ﺍﻟﺤﺮﻭﻑ ﺍﻟﻴﻮﻧﺎﻧﻴﺔ‬ ) ١ ‫ﺟﺪﻭﻝ ﺍﻟﺤﺮﻭﻑ ﺍﻟﻤﻤﺘﺪﺓ‬ :(‫ﻣﺎ ﻳﻠﻲ ﻳ ﹸ ﺴﺘﺨﺪ ﹶ ﻡ ﻟﻜﻼ ﻭﺿ ﻌ ﹶ ﻲ ﺍﻟﺤﺮﻭﻑ ﺍﻟﻜﺒﻴﺮﺓ )ﺍﻟﻌﻠﻮﻳﺔ( ﻭﺍﻟﺤﺮﻭﻑ ﺍﻟﺼﻐﻴﺮﺓ )ﺍﻟﺴﻔﻠﻴﺔ‬ ) ٢ ‫ﺟﺪﻭﻝ ﺍﻟﺤﺮﻭﻑ ﺍﻟﻤﻤﺘﺪﺓ‬ :(‫ﻣﺎ...
  • Page 57 ‫ﻣﻌﻠﻮﻣﺎﺕ ﻣﻔﻴﺪﺓ‬ ) ‫ﺟﺪﻭﻝ ﺍﻟﺤﺮﻭﻑ ﺍﻟﺴﻴﺮﻳﻠﻠﻴﺔ‬ ‫ﺭﺳﺎﺋﻞ ﺍﻟﺨﻄﺄ‬ ‫ﺍﻟﺴﺒﺐ/ﺍﻟﺤﻞ‬ ‫ﺭﺳﺎﻟﺔ ﺍﻟﻌﺮﺽ‬ ‫ﺗﺤﻘﻖ ﻣﻦ ﺗﻮﺻﻴﻞ ﻣﻬﺎﻳﺊ ﺍﻟﺘﻴﺎﺭ ﺍﻟﻤﺘﺮﺩﺩ ﻟﻠﻮﺣﺪﺓ ﺍﻟﺮﺋﻴﺴﻴﺔ ﺑﺎﻟﻮﺣﺪﺓ ﻭﻣﻨﻔﺬ ﺍﻟﻄﺎﻗﺔ ﺑﺸﻜﻞ ﹴ‬ Base NoPower ‫ﺃﻭ‬ .‫ﺻﺤﻴﺢ‬ ‫ﺍﻧﻘﻄﻊ ﺍﻻﺗﺼﺎﻝ ﺑﻴﻦ ﺍﻟﻮﺣﺪﺓ ﺍﻟﻴﺪﻭﻳﺔ ﻭﺍﻟﻮﺣﺪﺓ ﺍﻟﺮﺋﻴﺴﻴﺔ. ﺍﻗﺘﺮﺏ ﻣﻦ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺮﺋﻴﺴﻴﺔ‬ No Link .‫ﻭﺣﺎﻭﻝ...
  • Page 58 ‫ﻣﻌﻠﻮﻣﺎﺕ ﻣﻔﻴﺪﺓ‬ ‫ﺍﻟﺴﺒﺐ/ﺍﻟﺤﻞ‬ ‫ﺍﻟﻤﺸﻜﻠﺔ‬ .(٩ ‫ﺗﺄﻛﺪ ﻣﻦ ﺗﺮﻛﻴﺐ ﺍﻟﺒﻄﺎﺭﻳﺎﺕ ﺑﺼﻮﺭﺓ ﺻﺤﻴﺤﺔ )ﺻﻔﺤﺔ‬ .‫ﺍﻟﻮﺣﺪﺓ ﻻ ﺗﻌﻤﻞ‬ .(١٠ ‫ﻗﻢ ﺑﺸﺤﻦ ﺍﻟﺒﻄﺎﺭﻳﺎﺕ ﺑﺼﻮﺭﺓ ﻛﺎﻣﻠﺔ )ﺻﻔﺤﺔ‬ .(٩ ‫ﺗﺤﻘﻖ ﻣﻦ ﺍﻟﺘﻮﺻﻴﻼﺕ )ﺻﻔﺤﺔ‬ ‫ﺍﻓﺼﻞ ﻣﻬﺎﻳﺊ ﺍﻟﺘﻴﺎﺭ ﺍﻟﻤﺘﺮﺩﺩ ﺍﻟﺨﺎﺹ ﺑﺎﻟﻮﺣﺪﺓ ﺍﻟﺮﺋﻴﺴﻴﺔ ﻹﻋﺎﺩﺓ ﺿﺒﻂ ﺍﻟﻮﺣﺪﺓ ﻭﺇﻳﻘﺎﻑ‬ ‫ﺗﺸﻐﻴﻞ ﺍﻟﻮﺣﺪﺓ ﺍﻟﻴﺪﻭﻳﺔ. ﺃﻋﺪ ﺗﻮﺻﻴﻞ ﺍﻟﻤﻬﺎﻳﺊ، ﻭﻗﻢ ﺑﺘﺸﻐﻴﻞ ﺍﻟﻮﺣﺪﺓ ﺍﻟﻴﺪﻭﻳﺔ ﻭﺣﺎﻭﻝ‬ .‫ﻣ...
  • Page 59 ‫ﻣﻌﻠﻮﻣﺎﺕ ﻣﻔﻴﺪﺓ‬ ‫ﺇﺟﺮﺍﺀ/ﺍﻟﺮﺩ ﻋﻠﻰ ﺍﻟﻤﻜﺎﻟﻤﺎﺕ ﺍﻟﻬﺎﺗﻔﻴﺔ، ﺍﻟﻤﻜﺎﻟﻤﺎﺕ ﺍﻟﻬﺎﺗﻔﻴﺔ ﺍﻟﺪﺍﺧﻠﻴﺔ‬ ‫ﺍﻟﺴﺒﺐ/ﺍﻟﺤﻞ‬ ‫ﺍﻟﻤﺸﻜﻠﺔ‬ .‫ﺍﻟﻮﺣﺪﺓ ﺍﻟﻴﺪﻭﻳﺔ ﺑﻌﻴﺪﺓ ﻟﻠﻐﺎﻳﺔ ﻋﻦ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺮﺋﻴﺴﻴﺔ. ﺍﻧﺘﻘﻞ ﺇﻟﻰ ﻣﻜﺎﻥ ﺃﻗﺮﺏ‬ ‫ﺗﻮﻣﺾ‬ ‫ﻟﻢ ﻳﺘﻢ ﺗﻮﺻﻴﻞ ﻣﻬﺎﻳﺊ ﺍﻟﺘﻴﺎﺭ ﺍﻟﻤﺘﺮﺩﺩ ﺍﻟﺨﺎﺹ ﺑﺎﻟﻮﺣﺪﺓ ﺍﻟﺮﺋﻴﺴﻴﺔ ﺑﺼﻮﺭﺓ ﺻﺤﻴﺤﺔ. ﺃﻋﺪ‬ .‫ﺗﻮﺻﻴﻞ ﻣﻬﺎﻳﺊ ﺍﻟﺘﻴﺎﺭ ﺍﻟﻤﺘﺮﺩﺩ ﺍﻟﺨﺎﺹ ﺑﺎﻟﻮﺣﺪﺓ ﺍﻟﺮﺋﻴﺴﻴﺔ‬ .(٢٨...
  • Page 60 ‫ﻣﻌﻠﻮﻣﺎﺕ ﻣﻔﻴﺪﺓ‬ ‫ﺍﻷﺿﺮﺍﺭ ﺍﻟﻨﺎﺗﺠﺔ ﻋﻦ ﺍﻟﺴﻮﺍﺋﻞ‬ ‫ﺍﻟﺴﺒﺐ/ﺍﻟﺤﻞ‬ ‫ﺍﻟﻤﺸﻜﻠﺔ‬ ‫ﺍﻓﺼﻞ ﻣﻬﺎﻳﺊ ﺍﻟﺘﻴﺎﺭ ﺍﻟﻤﺘﺮﺩﺩ ﻭﺳﻠﻚ ﺧﻂ ﺍﻟﻬﺎﺗﻒ ﻋﻦ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺮﺋﻴﺴﻴﺔ. ﻗﻢ ﺑﺈﺯﺍﻟﺔ‬ ‫ﻟﻘﺪ ﺩﺧﻞ ﺳﺎﺋﻞ ﺃﻭ ﺃﻱ ﺷﻜﻞ ﺁﺧﺮ‬ ‫ﺍﻟﺒﻄﺎﺭﻳﺎﺕ ﻣﻦ ﺍﻟﻮﺣﺪﺓ ﺍﻟﻴﺪﻭﻳﺔ ﻭﺍﺗﺮﻛﻬﺎ ﺣﺘﻰ ﺗﺠﻒ ﻟﻤﺪﺓ ٣ ﺃﻳﺎﻡ ﻋﻠﻰ ﺍﻷﻗﻞ. ﻭﺑﻌﺪ ﺃﻥ‬ ‫ﻣﻦ...
  • Page 61 ‫ﺍﻟﻔﻬﺮﺱ‬ ‫ﻣﺴﺘﻮ￯ ﺍﻟﺼﻮﺕ‬ ‫ﻡ‬ ‫ﺍﻟﻔﻬﺮﺱ‬ ‫ﻣﺴﺘﻮ￯ ﺍﻟﺮﻧﻴﻦ ﻟﻠﻤﻜﺎﻟﻤﺎﺕ ﺍﻟﺨﺎﺭﺟﻴﺔ )ﺍﻟﻮﺣﺪﺓ‬ ١٣ :(‫ﺍﻟﻴﺪﻭﻳﺔ‬ ١٣ :‫ﺇﺟﺮﺍﺀ ﺍﻟﻤﻜﺎﻟﻤﺎﺕ ﺍﻟﻬﺎﺗﻔﻴﺔ‬ ‫ﺍ‬ ١٣ :‫ﻭﺣﺪﺓ ﺍﺳﺘﻘﺒﺎﻝ‬ ٢٣ :‫ﺇﺩﺧﺎﻝ ﺍﻟﺤﺮﻭﻑ‬ ١٩ :‫ﻧﻈﺎﻡ ﺍﻟﺘﻨﺒﻴﻪ‬ ‫ﻥ‬ ١٤ :‫ﺇﻋﺎﺩﺓ ﺍﻻﺗﺼﺎﻝ/ﻭﻣﻴﺾ ﺍﻟﻔﻼﺵ‬ ١٨ :‫ﻧﻐﻤﺎﺕ ﺍﻟﻤﻔﺘﺎﺡ‬ ١٣ :‫ﺇﻋﺎﺩﺓ ﺍﻟﻄﻠﺐ‬ ‫ﻧﻐﻤﺔ ﺍﻟﺠﺮﺱ‬ ١٣ :‫ﺇﻳﻘﺎﻑ ﻣﺆﻗﺖ‬ ١٧...
  • Page 62 ‫ﻣﻼﺣﻈﺎﺕ‬ ٣٠ (30)
  • Page 63 ‫ﻣﻼﺣﻈﺎﺕ‬ ٣١ (31)
  • Page 64 ‫ﻟﻼﺳﺘﺨﺪﺍﻡ ﻛﻤﺮﺟﻊ ﻓﻲ ﺍﻟﻤﺴﺘﻘﺒﻞ‬ .‫ﻧﻮﺻﻲ ﺑﺎﻻﺣﺘﻔﺎﻅ ﺑﺴﺠﻞ ﻣﻦ ﺍﻟﻤﻌﻠﻮﻣﺎﺕ ﺍﻟﺘﺎﻟﻴﺔ ﻟﻠﻤﺴﺎﻋﺪﺓ ﻓﻲ ﺃﻱ ﻋﻤﻠﻴﺔ ﺇﺻﻼﺡ ﺿﻤﻦ ﺍﻟﻀﻤﺎﻥ‬ ‫ﺗﺎﺭﻳﺦ ﺍﻟﺸﺮﺍﺀ‬ ‫ﺍﻟﺮﻗﻢ ﺍﻟﺘﺴﻠﺴﻠﻲ‬ (‫)ﻣﻮﺟﻮﺩ ﻋﻠﻰ ﺍﻟﺠﺰﺀ ﺍﻟﺨﻠﻔﻲ ﻟﻠﻮﺣﺪﺓ ﺍﻟﺮﺋﻴﺴﻴﺔ‬ ‫ﺍﺳﻢ ﺍﻟﻮﻛﻴﻞ ﻭﻋﻨﻮﺍﻧﻪ‬ © Panasonic Entertainment & Communication Co., Ltd. 2023 PNQP1814ZA PP0323YL0...
