- Page 1 Television Reference Guide Sony Customer Support http://esupport.sony.com/ES/LA/ Please Do Not Return the Product to the Store XBR-75X945C...
-
Page 2: Table Of Contents
Introduction Table of Contents Thank you for choosing this Sony product. Before operating the TV, please read this manual thoroughly and retain it for future reference. Note • Images and illustrations used in Startup Guide and this manual are for reference only and may differ from actual product appearance. -
Page 3: Safety Information
• Utilice el cable de alimentación de ca especificado por condensation. This may cause the TV to show poor Sony y que corresponda al voltaje de la zona donde vaya picture and/or poor color. Should this occur, allow a utilizarlo. - Page 4 Remove the screws from the rear of the TV. Anchor the TV to the wall by using bolts, wall anchor and chain (or rope). M6 eye bolts (not supplied) Rope or chain (not supplied) Wall-mount holes Secure the TV to the Stand. Use the optional hardware listed as follows (not supplied): •...
-
Page 5: Precautions
Precautions How to care for your BRAVIA TV Safety is very important. Please read and follow the safety documentation (Safety Booklet) separately provided. Unplug the TV and other connected equipment from the wall outlet before you begin cleaning your TV. •... - Page 6 • Recibiendo emisiones de HD por aire a través de una antena para TV de alta definición (HD) conectada ¡Gracias por elegir a Sony! Su nuevo TV BRAVIA® le directamente a la parte posterior del TV. brinda una “Experiencia de TV 4K”. Este documento le Visite http://www.antennaweb.org para recibir más...
-
Page 7: Parts And Controls
Parts and Controls Controls and Indicators Remote Control sensor* / Light sensor* / Illumination LED / 3D Sync Transmitter* The illumination LED lights up or blinks according to the status of the TV. • White When turning on the TV/picture off mode/software update, etc. -
Page 8: Inputs And Outputs
Inputs and Outputs LAN AUDIO OUT / • To listen to the TV's sound through DIGITAL AUDIO OUT (OPTICAL) the connected equipment, press HOME. Select [Settings] [Sound] VIDEO IN 2, [Headphone/Audio out] and then /... - Page 9 ANTENNA/CABLE Connect to your cable or antenna. * When connecting mono equipment, connect to the L (MONO) audio jack.
-
Page 10: Using Remote Control
Using Remote Control Remote Control Parts Description IR (infrared) Remote Control Touchpad Remote Control INPUT DISPLAY Display and select the input source. Display information about the channel/ program/input you are viewing. POWER/ Color buttons Turn on or turn off the TV (standby mode). - Page 11 ACTION MENU SYNC MENU Display a list of contextual functions. Display the BRAVIA Sync Menu. You can also display it by slide down FOOTBALL your finger from ACTION MENU on the Turn Live Football Mode on or off (when Touchpad Remote Control.
-
Page 12: Using The Touchpad Remote
Using the Touchpad Remote Control Attaching the Table-Top Touchpad Remote Control can only be used Stand (Alternative) after pairing with the TV. To pair, follow the pairing screen You can change the Table-Top Stand from instruction. the edge to the middle position by referring Pairing screen can be displayed by pressing to the instructions below. - Page 13 Note • Two or more people are needed to carry out this installation. • Ensure that there are no objects in front of the 3D Sync Transmitter IR Sensor To bundle the cables *1 Location of cable clamper when the Table-Top Stand is attached to middle position.
-
Page 14: Connecting The Tv
Showing a Set Top Box with HDMI Connecting the TV connection For more information on connections, refer to the Help Guide. Note • When connecting the cable to the Cable/ Antenna, input finger tighten only, over tightening the connection can damage the TV. •... -
Page 15: Component Connection
Showing a Set Top Box with Cable System or VHF/UHF Antenna COMPONENT connection System Cable or Antenna Set Top Box... -
Page 16: Connecting Mhl Device
Connecting MHL Device The TV simultaneously charges the MHL- compatible connected device while playing photo/music/video files. You can use the TV remote control to control the connected MHL-compatible device. Note • If [Charge MHL during power off] is set to [On], you can continue charging the MHL-compatible device even when the TV is in standby mode. -
Page 17: Showing Hd Bravia® Sync™ Basic
Showing HD BRAVIA® Sync™ Basic Connection SAT (Dish) Side Panel HD Cable Box or HD Satellite Receiver Cable/Antenna Rear of TV A/V Receiver Optical Connection Blu-ray Disc Signifies a BRAVIA Sync capable device. The optical connection is only needed for A/V receivers that do not support ARC (Audio Return Channel). -
Page 18: Showing Hd Basic Connection With Home Theater System
Showing HD Basic Connection with Home Theater System Side Panel Home Theater System Rear of TV Blu-ray Disc/DVD Cable/Antenna SD Cable Box or SD Satellite Receiver Cable/SAT (Dish) * Optical Connection * The optical connection is only needed for home theater system that do not support ARC (Audio Return Channel) when connecting with HDMI. -
Page 19: Showing Pc Connection With Sd Vcr
Showing PC Connection with SD VCR/DVD Side Panel * DVI Notebook PC Splitter Cable/Antenna Rear of TV VCR/DVD Combo * DVI does not support audio signals. Connect the audio output of the PC to the PC speakers or an A/V receiver to listen to sound from the PC. -
Page 20: Installing The Tv To The Wall
Table-Top Stand. Prepare the TV for the Wall-Mount Bracket before making cable connections. For product protection and safety reasons, Sony strongly recommends that installation of your TV on the wall be performed by qualified professionals. Do not attempt to install it yourself. - Page 21 Before installing the Wall-Mount Bracket, attach the Wall-Mount Attachment (supplied with the TV) to the rear of the TV (to make it parallel with the wall). Wall-Mount Attachment (supplied with the TV) Note • Be sure to fasten the Wall-Mount Attachment when attaching them to the TV. •...
-
Page 22: Installing The Tv Against A Wall Or Enclosed Area
Installing the TV against a wall or enclosed area Make sure that your TV has adequate ventilation. Allow enough space around the TV as shown in the illustration. Installed with stand 30 cm 6 cm 10 cm 10 cm Leave at least this much space around the set. Installed on the wall 30 cm 10 cm... -
Page 23: Troubleshooting
(interval time is three seconds). Disconnect services as well as factory reset the TV. the AC power cord, and contact Sony Frozen audio or video, a blank screen, or Customer Support. the TV does not respond to TV or remote When the illumination LED is not control buttons. -
Page 24: Specifications
The , CH+/–, +/–, and TV buttons cannot be located on the TV. Specifications See below illustration for location of the buttons on the TV. System Television system Rear of TV Analog: NTSC 3.58 / PAL-M / PAL-N Digital: SBTVD Channel coverage Analog: UHF/VHF/Cable, Depending on your... - Page 25 Audio: 5.1 channel linear PCM: 32, 44.1, 48, Operating temperature 88.2, 96, 176.4 and 192 kHz, 16, 20 and 0 ºC – 40 ºC 24 bits, Dolby Digital and DTS Power and others ARC (Audio Return Channel) (HDMI IN 4 only) MHL (common with HDMI IN 2) Power requirement Video (2D):...
- Page 26 • The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. • The terms HDMI and HDMI High- and any use of such marks by Sony Definition Multimedia Interface, and Corporation is under license. Other the HDMI Logo are trademarks or...
- Page 28 TV, visit: http://esupport.sony.com/LA/ Software Updates: NOTE: If your TV is connected to the Internet, you can check for software updates by selecting [Help], [System software update] and then [Check for a system software update]. ©2015 Sony Corporation Printed in U.S.A. 4-562-191-E2(1)
