Attaching the stand / Fixation du socle
After taking out the accessories from the box, please refer to the Owner's Manual for the appropriate method to connect.
ENG
Après avoir sorti les accessoires de la boîte, veuillez vous reporter au manuel d'utilisation pour connaître le mode de connexion approprié.
FRA_CA
ST-322T / ST-432T
ST-492T / ST-652T
Parts / Pièces
Stand Body (1 EA)
Corps du support (1 de
chaque)
Stand Base (1 EA)
Base du support (1 de
chaque)
*MBM65057402*
(2104-REV02)
First, check if the following parts are all present.
Vérifiez tout d'abord que toutes les pièces suivantes sont bien présentes.
ST-432T / ST-492T
ST-652T
Stand Spacer (2 EA)
Entretoise de support
(2 de chaque)
* Included Spring Washer
Screw
Rondelle élastique comprise
Vis
MODEL
Diameter x Pitch x Length (mm (inches))
Diamètre x filetage x longueur (mm (po))
4.0 (0.1) x 0.7 (0.02) x 10 (0.3)
ST-322T
4,0 (0,1) x 0,7 (0,02) x 10 (0,3)
ST-432T
4.0 (0.1) x 0.7 (0.02) x 14 (0.5)
ST-492T
4,0 (0,1) x 0,7 (0,02) x 14 (0,5)
4.0 (0.1) x 0.7 (0.02) x 16 (0.6)
ST-652T
4,0 (0,1) x 0,7 (0,02) x 16 (0,6)
EA
de
chaque
6
8
8
