Sealey SM94/C Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and properly
maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS AND
CAUTIONS. USE THIS PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY
CAUSE DAMAGE AND/OR PERSONAL INJURY, AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
1.1. ELECTRICAL SAFETY. F
You must check all electrical equipment and appliances to ensure they are safe before using. You must inspect power supply leads, plugs and
all electrical connections for wear and damage. You must ensure the risk of electric shock is minimised by the installation of appropriate safety
devices. An RCCB (Residual Current Circuit Breaker) should be incorporated in the main distribution board. We also recommend that an RCD
(Residual Current Device) is used with all electrical products. It is particularly important to use an RCD together with portable products that are
plugged into an electrical supply not protected by an RCCB. If in doubt consult a qualified electrician. You may obtain a Residual Current Device
by contacting your Sealey dealer. You must also read and understand the following instructions concerning electrical safety.
1.1.1. The Electricity At Work Act 1989 requires all portable electrical appliances, if used on business premises, to be tested by
a qualified electrician, using a Portable Appliance Tester (PAT), at least once a year.
1.1.2. The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of the appliance
and the safety of the appliance operator. If in doubt about electrical safety, contact a qualified electrician.
1.1.3. Ensure the insulation on all cables and the product itself is safe before connecting to the mains power
supply. See 1.1.1. & 1.1.2. above and use a Portable Appliance Tester (PAT).
1.1.4. Ensure that cables are always protected against short circuit and overload.
1.1.5. Regularly inspect power supply, leads, plugs for wear and damage, and power connections
to ensure that none is loose.
1.1.6. Important: Ensure the voltage marked on the product is the same as the electrical power supply
to be used, and check that plugs are fitted with the correct capacity fuse. A 13 amp plug may require
a fuse smaller than 13 amps for certain products, see fuse rating at right.
1.1.7. DO NOT pull or carry the powered appliance by its power supply lead.
1.1.8. DO NOT pull power plugs from sockets by the power cable.
1.1.9. DO NOT use worn or damage leads, plugs or connections. Immediately replace or have repaired by
a qualified electrician. A U.K. 3 pin plug with ASTA/BS approval is fitted. In case of damage, cut off
and fit a new plug according to the following instructions (discard old plug safely).
(UK only - see diagram at right). Ensure the unit is correctly earthed via a three-pin plug.
a) Connect the GREEN/YELLOW earth wire to the earth terminal ‘E’.
b) Connect the BROWN live wire to live terminal ‘L’.
c) Connect the BLUE neutral wire to the neutral terminal ‘N’.
d) After wiring, check that there are no bare wires, that all wires have been correctly connected, that the cable outer
insulation extends beyond the cable restraint and that the restraint is tight.
Double insulated products are often fitted with live (BROWN) and neutral (BLUE) wires only. Double insulated products are always marked with
this symbol . To re-wire, connect the brown and blue wires as indicated above. DO NOT connect the brown or blue to the earth terminal.
1.1.10. Cable extension reels. When a cable extension reel is used it should be fully unwound before connection. A cable reel with an RCD
fitted is recommended since any product which is plugged into the cable reel will be protected. The section of the cable on the reel is
important. Use at least 1.5mm
suitable for this product and for others that may be used in the other output sockets, we recommend the use of 2.5mm
1.2. General Safety
WARNING! Disconnect the mortiser from the mains power before changing accessories, servicing or performing any maintenance.
F
Locate the mortiser in a suitable working area. Fasten the mortiser to a strong flat working surface. Keep area clean and tidy and free from
!
unrelated materials and ensure there is adequate lighting.
Maintain the mortiser in good condition (use an authorised service agent).
!
Replace or repair damaged parts. Use genuine parts only. Non-authorised parts may be dangerous and will invalidate the warranty.
!
Keep the mortiser clean for best and safest performance and check moving parts alignment regularly.
!
Keep mortiser tool bits clean and sharp and ensure bit is secured correctly in the mortiser chuck. If worn or damaged replace immediately.
!
Remove adjusting keys and wrenches from the mortiser and its vicinity before turning it on.
!
Wear approved eye safety protection.
!
Handle loose chisels and drill bits with gloves or cloth as they are very sharp, but DO remove gloves and/or cloth before operating the
!
mortiser. Keep your hands and fingers away from the mortiser tool bit and chisel when operating.
Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery, and contain long hair.
!
Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
!
Secure work piece by resting against the back stop and top holding clamp.
!
Ensure there are no foreign objects in the workpiece i.e. nails or screws.
!
Use the depth stop for accuracy and to avoid drilling into the work table, and avoid unintentional starting.
!
DO NOT start the mortiser with the tool bit resting against the workpiece. Always bring the operating chisel to the workpiece.
%
DO NOT assemble a workpiece on the mortiser whilst the cutting tool is working.
%
DO NOT use the mortiser for a task it is not designed to perform.
%
DO NOT allow untrained persons to operate the mortiser and keep children and unauthorised persons away from the working area.
%
DO NOT get the mortiser wet or use in damp or wet locations or areas where there is condensation.
%
DO NOT use mortiser where there are flammable liquids, solids or gases such as paint solvents, waste wiping or cleaning rags etc.
%
DO NOT operate the mortiser if any parts are damaged or missing as this may cause failure and/or possible personal injury.
%
DO NOT leave the mortiser operating unattended.
%
DO NOT operate the mortiser when you are tired, under the influence of alcohol, drugs or intoxicating medication.
%
When not in use switch off the mortiser and remove plug from the power supply.
!
 WARNING! It is the user’s responsibility to read, understand and comply with the following:
p
section cable, but to be absolutely sure that the capacity of the cable reel is
2
INSTRUCTIONS FOR:
HOLLOW CHISEL MORTISER
SM94/C
Model No:
Blue
Neutral
wire
Yellow & Green
Earth wire
Brown
Live
wire
Cable
restraint
FUSE RATING
THIS PRODUCT MUST BE FITTED
5 AMP FUSE
WITH A
section cable.
2
SM94/C - 2 - 310702
