- Page 1 YMF724 - PCI SOUND CARD Configuration and Hardware USER MANUAL March 1999...
-
Page 2: Table Of Contents
“YMF724 J80A” “YMF724 J80B” ......10 ONNECTORS FOR 1.8.1. External Connectors For “YMF724 J80A”: ................10 1.8.2. External Connectors For “YMF724 J80B”: ................10 1.8.3. Internal Connectors For “YMF724 J80A”: ................10 1.8.4. Internal Connectors For “YMF724 J80B”: ................11 1.8.5. -
Page 3: Description
Configuration/Hardware DESCRIPTION “YMF724 D10”, “YMF724 G50”, and “YMF724 J8x” are new audio adapters that provide the next generation of PCI audio performance to the PC market. The adapters not only meet the new demands of advanced PC audio applications but also enable the integration of a complete multimedia subsystem on a single adapter. -
Page 4: Card Figure For "Ymf724 D10
YMF724 PCI Sound Card Configuration/Hardware 1.2. Card Figure for “YMF724 D10” Power Amplifier VIDEO AUX In TEA 2025 LINE IN CD-ROM Audio J10 ATAPI MIC IN CD-ROM Audio J11 JST ‘97 LINE OUT PC/PCI Legacy Audio Sideband Signal SPEAKER OUT... -
Page 5: Spdif Cable For D10/G50
YMF724 PCI Sound Card Configuration/Hardware 1.3.1. SPDIF Cable for D10/G50 If your package contains a SPDIF cable and you want to use digital Output (SPDIF connector), please insert the SPDIF cable into the bracket slot of your PCI sound card, as displayed in the following figure. -
Page 6: Card Figure For "Ymf724 J80B
YMF724 PCI Sound Card Configuration/Hardware 1.5. Card Figure for “YMF724 J81” Power Amplifier CD-ROM Audio TEA 2025 AUX In J11 JST VIDEO CD-IN ATAPI LINE IN J11 J14 J12 MIC IN ‘97 AUDIO OUT PC-BEEP (Option) SPDIF YMF724V MIDI/ JOYSTICK... -
Page 7: Connectors For "Ymf724 D10
Configuration/Hardware 1.6. Connectors for “YMF724 D10” “YMF724 D10” includes up to seven internal connectors, four external Jack Ports, one external MIDI/ Joystick connector, one VIDEO connector, one TAD/VOICE Modem connector, one SPDIF, and one PC/PCI Legacy AUDIO SIDEBAND SIGNAL connector. -
Page 8: Audio Connectors
YMF724 PCI Sound Card Configuration/Hardware 1.6.3. Audio Connectors: L: LEFT CHANNEL SIGNAL J6/J7/J8/J9: G: GROUND R: RIGHT CHANNEL SIGNAL L: LEFT CHANNEL SIGNAL J10: ATAPI CD-Audio G: GROUND R: RIGHT CHANNEL SIGNAL G G R J11: CD-Audio L: LEFT CHANNEL SIGNAL... -
Page 9: Connectors For "Ymf724 G50
YMF724 PCI Sound Card Configuration/Hardware 1.7. Connectors for “YMF724 G50” “YMF724 G50” includes up to eight internal connectors, three external Jack Ports, one external MIDI/ Joystick connector, one VIDEO connector, one TAD/VOICE Modem connector, and one PC/PCI Legacy AUDIO SIDEBAND SIGNAL connector. -
Page 10: Audio Connectors
YMF724 PCI Sound Card Configuration/Hardware 1.7.3. Audio Connectors: J6/J7/J9: L: LEFT CHANNEL SIGNAL G: GROUND R: RIGHT CHANNEL SIGNAL J10: CD-Audio L: LEFT CHANNEL SIGNAL G: GROUND R: RIGHT CHANNEL SIGNAL R G G L J11: CD-Audio L: LEFT CHANNEL SIGNAL... -
Page 11: Audio Output Jumper Settings Jp1
1.8. Connectors for “YMF724 J80” “YMF724 J81” “YMF724 J80” includes up to thirteen internal connectors, and five external Jack Ports. “YMF724 J81” includes up to twelve internal connectors, four external Jack Ports and one RCA Jack. 1.8.1. External Connectors For “YMF724 J80”: J1: ......∅... -
Page 12: Internal Connectors For "Ymf724 J80B
YMF724 PCI Sound Card Configuration/Hardware 1.8.4. Internal Connectors For “YMF724 J81”: J6: ......Internal connector for LINE IN (optional) J7: ......Internal connector for MIC IN (optional) J8: ......Internal connector for AUDIO OUT (optional) J10: ....Connector for CD AUDIO IN (ATAPI) J11: ....Connector for CD AUDIO IN (JST) J12: ....Connector for AUX IN... -
Page 13: Audio Connectors
YMF724 PCI Sound Card Configuration/Hardware 1.8.5. Audio Connectors: J6/J7/J8/(J9): L: LEFT CHANNEL SIGNAL (Option) G: GROUND R: RIGHT CHANNEL SIGNAL J10: ATAPI L: LEFT CHANNEL SIGNAL CD-Audio G: GROUND R: RIGHT CHANNEL SIGNAL R G G L J11: J12: J14:... -
Page 14: Audio Output Jumper Settings For "Ymf724 J80B
YMF724 PCI Sound Card Configuration/Hardware 1.8.6. Audio Output Jumper Settings for “YMF724 J81”: Audio Setting SPEAKER OUT with Power Amplifier (Default) LINE OUT without Power Amplifier HARDWARE INSTALLATION 2.1. Handling the PCI Sound Card WARNING: Static electricity can damage your equipment. Do not take the card out of its static protective bag until you are ready to work with it.
