- Page 1 AF-650 GP & AF-600 FP Profibus DP Instruction Manual...
-
Page 2: Table Of Contents
4 How to Control the Adjustable Frequency Drive PPO Types Process Data Reference Handling Process Control Operation Control Profile PROFIdrive Control Profile GE Drive Control Profile 4-11 Synchronize and Freeze 4-15 5 How to Access the Parameters Parameter Access in General DP V1 Parameter Access... - Page 3 AF-650 GP/AF-600 FP Profibus DP Instruction Manual E.g.: Process Data with PPO Type 6 E.g.: Control Word Network using PPO Type E.g.: Status Word Network using PPO Type E.g.: PLC Programming 8 Troubleshooting Diagnostics Troubleshooting LED Status No Communication with the Drive Warning 34 Appears even though Communication is Established Drive Will Not Respond to Control Signals Alarm and Warning Words...
-
Page 4: Introduction
GE reserves the right to revise this publication at any time and to make changes in its contents without prior notice or any obligation to notify previous users of such revisions or changes. - Page 5 AF-650 GP/AF-600 FP Profibus DP Instruction Manual 1.2.3 Warning Against Unintended Start The motor can be brought to a stop by means of digital commands, network commands, references or a local stop, while the adjustable frequency drive is connected to line power. If personal safety considerations make it necessary to ensure that no unintended start occurs, these stop functions are not sufficient.
- Page 6 Easy to use • transparent installation, diagnostics and parameterization Flexibility and compatibility • Two different state machines can be selected: PROFIdrive profile or GE Drive profile • Communication using PROFIBUS DP V1, Master Class 1 and Master Class 2 Future-proof investment •...
-
Page 7: Technical Overview
AF-650 GP/AF-600 FP Profibus DP Instruction Manual Features of DCT 10 Drive Control Tool software: • Project-oriented PC tool, one tool for all AF-6 Series Drives • Links to all Windows applications possible • Supports Siemens CPs 5511 (PCMCIA) and 5611 (PCI card), for PROFIBUS DP V1 Master Class 2 connection •... - Page 8 Issues regarding hardware or software produced by other manufacturers are beyond the scope of this manual, and are not the responsibility of GE. If you have questions regarding set-up of master-to-master communication, or communication to a non-GE slave, please consult the appropriate manuals. 1.10 Available Literature For additional AF-6 Series Drives information please visit www.geelectrical.com/drives.
- Page 9 AF-650 GP/AF-600 FP Profibus DP Instruction Manual 1.11 Abbreviations Acyclical Control Interval Application Orientated Controller Controller Area Network Control Word Distributed Periphery Data Unit EEPROM Electrical Erasable Programmable Read Only Memory Electronic Industries Alliance: Specifier of the EIA Standard RS 485-A Electromagnetic Compatibility Field Device Tool Sub index...
-
Page 10: How To Install
1, 2, 3 and 4 network segments. Drop cable connection (i.e., T-connection) beyond the cable lengths indicated is not recommended, due to the increased risk of reflection occurring. Instead, GE recommends direct connection of the adjustable frequency drive. -
Page 11: Emc Precautions
AF-650 GP/AF-600 FP Profibus DP Instruction Manual The numbers on the following diagram indicate the maximum number of stations in each segment. They are not the station addresses, as each station in the network must have a unique address. 2.1.2 EMC Precautions The following EMC precautions are recommended to achieve interference-free operation of the PROFIBUS network. -
Page 12: Connecting The Network
AF-650 GP/AF-600 FP Profibus DP Instruction Manual 2.1.5 Cable Routing The PROFIBUS communication cable must be kept away from motor and brake resistor cables to avoid coupling of high frequency noise from one cable to the other. Normally a distance of 8 in [200 mm] is sufficient, but maintaining the greatest possible distance between cables is generally recommended, especially where cables run in parallel over long distances. - Page 13 AF-650 GP/AF-600 FP Profibus DP Instruction Manual 130B1112 DET-624...
- Page 14 AF-650 GP/AF-600 FP Profibus DP Instruction Manual 2.2 How to Install the Profibus DP Communications Module in Drive To install the module in the drive you will need: The Profibus DP Communications Module (OPCPDP) Network option adaptor frame for the AF-6 Series drives.. This frame is deeper than the standard frame, to allow space for the network option be- neath Cable holders Instructions:...
- Page 15 AF-650 GP/AF-600 FP Profibus DP Instruction Manual DET-624...
-
Page 16: How To Configure The System
AF-650 GP/AF-600 FP Profibus DP Instruction Manual 3 How to Configure the System 3.1 Configure the PROFIBUS Network All PROFIBUS stations that are connected to the same network must have a unique station address. The PROFIBUS address of the adjustable frequency drive can be selected via: Hardware switches PB-18 Node Address The PROFIBUS command SSA Set Station Address... -
Page 17: Configure The Master
AF-650 GP/AF-600 FP Profibus DP Instruction Manual 3.2 Configure the Master 3.2.1 GSD File In order to configure a PROFIBUS Master, the configuration tool needs a GSD file for each type of slave on the network. The GSD file is a PROFIBUS DP standard text file containing the necessary communications set-up data for a slave. - Page 18 AF-650 GP/AF-600 FP Profibus DP Instruction Manual The AF-650 GP GSD file is now imported and will be accessible via the fol- lowing path in the hardware catalog: Open a project, set up the hardware and add a PROFIBUS master system. Select AF-6 Series then drag and drop it onto the PROFIBUS in the hardware diagram.
-
Page 19: Configure The Adjustable Frequency Drive
AF-650 GP/AF-600 FP Profibus DP Instruction Manual The next step is to set up the peripheral input and output data. Data set-up in the peripheral area is transmitted cyclically via PPO types. In the example below, a PPO type 6 Word consistent is dragged and dropped to the first slot. -
Page 20: Parameters
Source but enter trip mode, and the drive will display an error. • O-10 Control Word Profile. Choose between the GE Drive Profile and the PROFIdrive profile • O-50 Coasting Select to O-56 Preset Reference Select. Selection of how to gate PROFIBUS control commands with digital input command of the control module.
