SERVICE MANUAL
For Technical Service
6. CDM-47
6-1. GENERAL ...................................................................... 6-1
6-2. Tools and Measuring Instruments ...................................... 6-3
6-2-1. General and Special Tools List .............................. 6-3
6-2-1-1.
General Tools ................................................ 6-3
6-2-1-2.
Special Tools ................................................. 6-3
6-2-1-3.
Test Disc ....................................................... 6-3
6-2-1-4.
Measuring Equipments ................................. 6-3
6-2-1-5.
Software ........................................................ 6-3
6-2-1-6.
Mechanism Block .................................................. 6-4
6-2-3. System Configration .............................................. 6-6
6-2-3-1.
Set up PS/VP System .................................... 6-6
6-2-3-2.
System Configuration ................................... 6-6
6-3. Trouble Shooting ................................................................ 6-8
6-3-1. Before Trouble Shooting ....................................... 6-8
6-3-2. Flowchart for Trouble Shooting ............................ 6-8
6-3-3. Procedure of ATP Test ........................................... 6-9
6-3-3-1.
Pre-setting ..................................................... 6-9
6-3-3-2.
Test Procedure ............................................ 6-10
6-3-4. Drive Function Check .......................................... 6-12
6-3-4-1.
6-3-4-2.
Flowchart .................................................... 6-13
6-3-4-3.
Test Command List ..................................... 6-16
6-3-4-4.
Spindle Motor ............................................. 6-16
6-3-4-5.
Sled Gear Train ........................................... 6-16
6-3-4-6.
2-Axis Actuator .......................................... 6-16
6-3-4-7.
Focusing (Focus Bias) ................................ 6-16
6-3-4-8.
Laser Power ................................................ 6-16
6-3-4-9.
Chucking Mechanism ................................. 6-17
6-3-4-10. Sled Motor .................................................. 6-17
6-3-4-11. Spindle Motor Drive ................................... 6-17
6-3-4-12. E-F Balance ................................................ 6-18
6-3-4-13. RF Level ..................................................... 6-18
6-3-5. Down Load Program ........................................... 6-20
CDL1100

TABLE OF CONTENTS

7-1. Circuit Boards Location .................................................... 7-1
7-2. IC Pin Function ................................................................. 7-2
7-3. Block Diagrams .............................................................. 7-21
7-4. Frame Schematic Diagram .............................................. 7-29
7-5. Printed Wiring Board/Schematic Diagram ..................... 7-33
Main Section ................................................................... 7-33
Power Supply Section ..................................................... 7-40
Carrier, Mail Box Section ............................................... 7-46
Panel Section ................................................................... 7-52
CD-ROM Drive Section .................................................. 7-55
7-6. IC Block Diagrams ......................................................... 7-67
7-6-1. Main Section ...................................................... 7-67
7-6-2. Power Supply Section ........................................ 7-69
7-6-3. CD-ROM Drive Section ..................................... 7-70
8-1. Case Section ................................................................... 8-1
8-2. Front Panel Assy Section ................................................ 8-2
8-3. Chassis Section ............................................................... 8-3
8-4. Back Panel Section ......................................................... 8-4
8-5. Carrier Assy Section 1 .................................................... 8-5
8-6. Carrier Assy Section 2 .................................................... 8-6
8-7. Carrier Assy Section 3 .................................................... 8-7
8-8. Disc Case Assy Section .................................................. 8-8
8-9. Mail Box Assy Section ................................................... 8-9
8-10. CDM-47 Section ........................................................... 8-10
8-11. BU Holder Section ....................................................... 8-11
- 1 -

Advertisement

Table of Contents
loading

Related Manuals for Sony CDL1100

Summary of Contents for Sony CDL1100

  • Page 1: Table Of Contents

    CDL1100 SERVICE MANUAL For Technical Service TABLE OF CONTENTS 6. CDM-47 7. DIAGRAMS 6-1. GENERAL ..............6-1 7-1. Circuit Boards Location ............ 7-1 6-2. Tools and Measuring Instruments ........6-3 7-2. IC Pin Function ..............7-2 6-2-1. General and Special Tools List ......6-3 7-3.

  • Page 2: General

    SECTION 6 CDM-47 6-1. GENERAL Note:Note on repairing the Base Unit Ass’y. 2. Grounding for the work table Ω) When operating or repairing the unit, grounding is required to pre- Be sure to lay a conductive sheet (with impedance lower than 10 vent damage caused by static electricity and is as follows: on the table, sure as a sheet of copper, which is ground.
  • Page 3 5. Do not apply excessive force to the when wiping. Optical device is structured by very sensitive mechanism parts.The lens holding mechanism may have damage if apply excessive force. Cotton Swab Wipe the surface of an object lens with a spiral from the center to outside. (Refer to Fig A) Optical Pick-up Cover...

  • Page 4: Tools And Measuring Instruments

    CDL1100 unit.) Power cord (1-559-370-11) SCSI 50P Flat Cable (J-902-900-0A) AU-CN Board (A-8080-815-A) BLER Counter For TC940X (J-907-564-0A) CDL1100 (CDM-47) CONTROLLER (J-2501-141-A) Active Speaker 6-2-1-3. Test Disc SONY Test Disc (YEDS-18) (3-702-101-01) SONY Test Disc (TGRS-21) SONY Test Disc (YEHS-4) (3-702-548-01) 6-2-1-4.

  • Page 5: Setting Single-Operation Of Cdm-47 Mechanism Block

    2. Set the COMMAND SW of the controller to the test mode. PARITY 3. While pressing the TEST button of the controller, turn on the power of the CDL1100 or power supply unit. 4. After about 1 second later, release the TEST button.
  • Page 6 to CNJ202 to CN56 White to CNJ202 UNCHUCK CHUCK (RED) (GREEN) COMMAND SW (SW1) EJECT (SW3) TEST (SW2) Setting of Single-Operation Mode Mode PARITY Test Mode Command list of Single-Operation Mode Mode PARITY Initialize x1 speed x4 speed x8 speed x12 (Partial CAV) speed Tracking servo OFF Tracking servo ON...

  • Page 7: System Configration

    PS/VP System SCSI Interface board Adaptec AHA-1520B or 2940 RCC-015H Power Supply Terminator ATP415 System Disc Firmware Program Disc Power Code SONY Test Disc (YEHS-4) (for ATP) AU-CN Mount SONY Test Disc (ATAPI) (TGRS-21) (for ATP) Active Speaker CDL1100 (CDM-47) Controller...
  • Page 8 Power Supply Power Cord SONY Test Disc (YEDS-18) CDL1100 (CDM-47) Controller Function check...

  • Page 9: Trouble Shooting

    6-3. TROUBLE SHOOTING This section describes trouble shooting methods. c. Program error of host system Section 6-3-2. shows the flowchart of the processing routine of the d. No Interface Cable Terminator at the end of Data Bus unit. Section 6-3-3. describes the ATP procedures. These sections e.

  • Page 10: Procedure Of Atp Test

    While pressing the TEST button of the CDL1100 (CDM-47) b. Set the Jumpers on the Adaptec SCSI board. (Refer to Fig. 2-3-1.) controller, turn on the DC power supply or CDL1100 power, and c. Connect the test drive to the CDL1100 (CDM-47) CONTROL- release the TEST button about 1 second later.

  • Page 11: Test Procedure

    Y key. c. When “Place CD-ROM TEST DISC (TGRS-2D)...” is dis- played, press the EJECT button of the CDL1100 (CDM-47) controller, and chuck the disc. If the disc has already been chucked, the display will not be shown, and the unit will pro- ceed onto the next step.
  • Page 12 The disc will automatically be unchucked, after it will be chucked again. a. “push eject button” message will be displayed on drive status Press the EJECT button of the CDL1100 (CDM-47) controller to column, then push the eject button unchuck the disc, and then remove the disc.

  • Page 13: Drive Function Check

    CDM-47 Oscilloscope Sony Test Disc (YEDS-18) (3-702-101-01) CDL1100 (CDM-47) CONTROLLER (J-2501-141-A) b. Connect the test drive to the DC power supply or CDL1100 unit. CNJ202 (MA-C22 board) Controller CN56 (CN board) b. See the COMMAND SW ON CDL1100 (CDM-47) CONTROL- LER as following table.

  • Page 14: Flowchart

    6-3-4-2. Flowchart Note: These flowchart is described assuming that IC failure causes any trouble. Start Mechanical Checking/Repairing Mechanical or Electrical trouble ? Mechanical Electrical IC201 (CPU) failure Nothing in action in Power-On ? IC205 (gate-array) failure No action IC207 (Flash-ROM) failure Proceeding Adjustment Action BU/Main PWB/HP PWB BU/OP checking/Replace BU...
  • Page 15 Power on Reset Action Failed/Action NG Retry for detailed checking IC102 IC402 Focus Search (Refer to 6-3-4-6.) Trouble/Failed in Step (2)-(6) Spindle Motor Driver IC (Refer to 6-3-4-11.) IC105 (Spin-up/Focus-on) IC101 RF Signal (Refer to 6-3-4-13.) IC107 OK/Passed IC101 Check Focus/Tracking Servo Error Signal Trouble/Failed in Step (7)-(13) IC105 RF Signal (Refer to 6-3-4-13.)
  • Page 16 Power on Reset Actions Step Item Drive Action Drive Power-On LED to indicate Amber Spin-up (tentative spindle servo gain setting) Spin-Up LD On LD to turn on Spindle Kick Focus Search OP lens to move up and down Focus On EF Balance Auto Adjustment Tracking and Sled Servo On Spindle Servo On...

  • Page 17: Test Command List

    L : PARITY or ID0 ~ 2 test point to be low (Ground). Command Execute In the test mode, above listed function can be executed. Turn on COMMAND SW on CDL1100 (CDM-47) CONTROLLER. The command will be latched by TEST down edge, and executed by rising edge.

  • Page 18: Chucking Mechanism

    6-3-4-9. Chucking Mechanism [Check Laser Current] a. Touch the IOP test land (CL165) on the MA-C22 Mounted Board. a. Listen the sound from the drive while the drive is spinning up. b. Measure the voltage generated by the laser current while the drive b.

  • Page 19: Ef Balance

    • Refer to 6-3-4-1. and set the test mode. • Refer to 6-3-4-1. and set the test mode. • Insert a SONY test disc (YEDS-18) into the test drive. 1. Connect the oscilloscope to TP RF (CL428) and TP VC (CL403) 1.
  • Page 20 CNJ202 enlargement Supplying power from the CDL1100 unit CDM-47 Connect this part to the controller CDL1100 CDM-47 CNJ202 (MA-C22 board) Controller CN56 (CN board) CNJ201 Adjustment Location : [ MA-C22 BOARD ] — Side B — TP VC (CL403) RF Level Check...

  • Page 21: Down Load Program

    Set the COMMAND SW of the CDL1100 (CDM-47) CONTROLLER as follows. PARITY c. While pressing the TEST button of the CDL1100 (CDM-47), turn on the power of the CDL1100 or power supply unit. After about 1 second later, release the TEST button and then turn the computer on.
  • Page 22 Firmware DownLoad VIA ASPI Ver.1.00.00 --Sony CD-ROM -- [Nov. -21-1996] [ID:7]=ASW-1210 V 3.60 ADAPTEC AHA-1520ADAPTEC AHA-1520 Size of OBJ. [415s_XXx. HEX ] => 065536 Bytes. [ID:3]=SONY CD-ROM CDU-XXX X.Xx [Available ROM size:064 kBytes) Hit Esc to quit. Display 6-3-5 (d) Note: When the down loading and verification are completed, “OK”...

  • Page 23: Diagrams

    SECTION 7 DIAGRAMS 7-1. CIRCUIT BOARDS LOCATION RST board CLIP (IN) board CARRIER board DISC SENSOR board CARRIER ASSY FG board CLIP (OUT) board MA-C22 board M BOX SW board P LED board LDSW board LED board MBLD board MBMO board COVER board CDM-47 CN board...

  • Page 24: Ic Pin Function

    7-2. IC PIN FUNCTION • IC101 RF AMP (TA2106N) / MA-C22 board Pin No. Pin Name Function — +5V power supply AGCAD RF system AGC AMP gain adjustment input (Not used) RFAD0 RF AMP gain adjustment input Main beam AMP input (Detector A,C) Main beam AMP input (Detector B,D) Sub beam AMP input (Detector F) Sub beam AMP input (Detector E)
  • Page 25 • IC102 2AXIS & Chucking Motor Driver (LA6539M) / MA-C22 board Pin No. Pin Name Function — Sub straight (Minimum potential) (not used) — Sub straight (Minimum potential) (not used) — Ground VIN1 Chucking motor control signal input VIN1A Chucking motor control signal input (For adjusting gain) MUTE1 Chucking motor control ON/OFF signal output VIN2...
  • Page 26 • IC105 Digital Servo & Digital Signal Processor (TC9439F) / MA-C22 board Pin No. Pin Name Function — Ground Bit clock output (1.4122MHz) Audio data output AOUT DOUT Digital output (Not used) MBOV Buffer memory over signal otuput “H”: at over Outputs the correction flag.
  • Page 27 Pin No. Pin Name Function Tracking error signal input TEZI Tracking error zero crossing signal input Focus servo equalizer signal output Tracking servo equalizer signal output VREF Reference voltage input (+2.1V) RF amplitude control signal output. The three-value PWM signal is output RFGC (PWM carrier = 88.2kHz) Tracking balance control signal output.
  • Page 28 Pin No. Pin Name Function — +5V power supply — /VSS Ground Crystal oscillating circuit input (33.8688MHz) Crystal oscillating circuit output (33.8688MHz) /VDD — +5V power supply — DVDD +5V power supply (Digital) Forward audio R-ch data output — DVSS Ground (Digital) D/A converter reference voltage input Forward audio L-ch data output...
  • Page 29 • IC202 CD-ROM Decoder & SCSI Interface (CXD1804AR) / MA-C22 board Pin No. Pin Name Function — Ground — +5V power supply XDB0 SCSI data bus bit 0 — Ground XDB1 SCSI data bus bit 1 — Ground — +5V power supply XDB2 SCSI data bus bit 2 —...
  • Page 30 Pin No. Pin Name Function — Ground — +5V power supply XCD signal input/output with SCSI control bus — Ground XREQ XREQ signal input/output with SCSI control bus — Ground XIO signal input/output with SCSI control bus — Ground — +5V power supply XRES Reset input “L”: reset...
  • Page 31 Pin No. Pin Name Function MDB12 MDB13 Data bus input/output with Buffer memory MDB14 MDB15 — Ground — +5V power supply EXCK Clock for SIBN reading output to digital servo and digital signal prosesor SBIN Subcode serial signal input from digital servo and digital signal prosesor SCOR Subcode sync signal input from digital servo and digital signal prosesor WFCK...
  • Page 32 Pin No. Pin Name Function Clock output (Not used) XWAT Access wait signal input from sub CPU buffer memory Address bus input for built-in register — Ground Data bus input/output with sub CPU — Not used — +5V power supply Interrupt request signal output to CPU Chip select signal input Built-in register writing strobe signal input from CPU...
  • Page 33 • IC205 Gate Array (BU6243K) / MA-C22 board Pin No. Pin Name Function Assigns the driver’s SCSI ID. Select an ID number. Which is not used by other SCSI devices conncted to the bus MODE0 Not used Chucking Action Prevent/Allow = H/L TEST Test pin Reset output to digital servo and digital signal processor...
  • Page 34 • IC401 Sled Driver (LA6527N) / MA-C22 board Pin No. Pin Name Function VCC2 — +12V power supply MTR+ Power amplifier MTR+ output — Ground — Ground MTR- Power amplifier MTR- output Buffer VC input DV amplifier DVO output (Not used) DV amplifier DV- input (Not used) DV amplifier DV+ input (Not used) ER amplifier ERO output...
  • Page 35 • IC402 Spindle Driver (LB1916) / MA-C22 board Pin No. Pin Name Function WIN1 W phase hall element input WIN2 — Ground — Prevents to oscillate by lowering frequency characteristic of input/output gain with capacitor connection between FC and Ground terminals Start/stop control signal input “H”: start , “L”: stop —...
  • Page 36 • IC701 Mecha. Control (HD6413002F) / Main board Pin No. Pin Name Function — +5V power supply Input/output with data bus for LCD PB6/DREQ0 PB7/DREQ1 XRES0 Reset output — Ground TXD0 Serial transmit data output to RS-232C TXD1 Not used RXD0 Serial reception data input from RS-232C RXD1...
  • Page 37 Pin No. Pin Name Function Output to address bus — Ground Output to address bus — Ground P60/XWAIT Serial data input/output with EEPROM interface P61/XBREQ Serial clock output to EEPROM interface P62/XBACK Not used SYSCLK System clock output (Not used) XSTBY Standby signal input (Connected to +5V) XRES...
  • Page 38 Pin No. Pin Name Function P73/AN3 Key input (Analog) P74/AN4 Analog input for ID SELECTOR (CD-ROM drive A) P75/AN5 Analog input for ID SELECTOR (CD-ROM drive B) P76/AN6/DA0 Analog input for battery voltage (+2.5V) P77/AN7/DA1 Not used — AVSS Ground P80/XIRQ0 Not used P81/XIRQ1/XCS3...
  • Page 39 • IC702 I/O Expander (CXD1095Q) / Main board Pin No. Pin Name Function — Not used — Clip release position detection input Clip return position detection input Clip home position detection input Clip hold position detection input Clip empty position detection input Detection input from mailbox disc sensor Not used —...
  • Page 40 Pin No. Pin Name Function XRST Reset input — Ground Write signal input Read signal input Chip select signal input Input from address bus POWER LED drive signal output — Not used Mode switch input — Ground — +5V power supply Mode switch input Detection input from clip disc sensor 7-18...
  • Page 41 • IC708 SCSI Controller (FAS204) / Main board Pin No. Pin Name Function PAD5 PAD6 Data bus input/output PAD7 — +5V power supply — Not used — Ground XSD0 XSD1 SCSI data bus input/output XSD2 XSD3 — Ground XSD4 XSD5 SCSI data bus input/output XSD6 XSD7...
  • Page 42 Pin No. Pin Name Function Clock input (19.6608MHz) — +5V power supply — Ground DREQ DMA request signal output — Not used XDACK DMA acknowledge signal input (Not used) XDBWR DMA data bus write signal input (Not used) — Not used —...

  • Page 43: Block Diagrams

    CDL1100 7-3. BLOCK DIAGRAMS — CD-ROM DRIVE (CDM-47)(1/2) SECTION — RFD 0 OPTICAL PICK-UP RFD 1 BLOCK (SPU3210) DIGITAL SERVO, RF AMP DIGITAL SIGNAL PROCESSOR IC101 IC105 DETECTOR Q103 A OUT DATA RF BUFFER LRCK SLCO LRCK LRCK AGC IN...
  • Page 44 CDL1100 — CD-ROM DRIVE (CDM-47)(2/2) SECTION — 7-23 7-24...

  • Page 45: Main Section

    IC718 CHUCK (Page 7-24) ID SELECTOR MAIL BOX INVERTER ROBOTICS SENSOR D705 XEJECT UNCHUCK OSC DRIVER CLOCK GENERATOR CHUCK (DRIVE B) IC706(2/2) IC707 (CDL1100-20 only) (Page 7-24) 9.8304MHz CLK2 • SIGNAL PATH X701 (Page 7-27) 19.6608MHz : DATA 7-26 7-25...

  • Page 46: Power Supply Section

    CDL1100 — POWER SUPPLY SECTION — ELEVATOR ELEVATOR MOTOR DRIVER MOTOR DRIVER IC710 IC711 M652 STPCW MOTOR MOTOR RELAY ELEVATOR STPCK DRIVE DRIVE MOTOR RY701 +B LEVEL +14V CONTROL Q712,713 (Page 7-26) –B LEVEL CONTROL INVERTER IC717 Q715,716 –12V IC716...

  • Page 60: Ic Block Diagrams

    7-6. IC BLOCK DIAGRAMS IC710 TA8415P IC715 LA5536 • Main section IC705 SN74HC138ANS CW/CCW DECODER DATA OUTPUTS VREF COMP CK-2 CK-1 DECODER IC716 S-8420AF CK-OUT VOUT Ø1 Ø4 GATE GATE Ø2 Ø3 GATE GATE OUTPUT PREEND SELECT ENABLE IC711 TD62308AP HEAT SINK IC707 SN74HC74ANS &...
  • Page 61 • Power section • CD-ROM Drive section (CDM-47) IC901, 902, 903, 904, 905 MC34166-D2-TR4 IC101 TA2106FN VOLTAGE RFGO FEEDBACK INPUT AGCAD RFN2 RFAD AGCIN SWITCH OUTPUT RFGO PEAK BOTTOM RFRPIN RFCT INPUT RFRP 3 STATE VOLTAGE/ 2VRO COMPEN- SATION SBAD IC102 LA6539M-TE-L 7-69 7-70...
  • Page 62 IC105 TC9439F 71 70 59 58 1 bit SERVO CONTROL TEBC RFGC CLOCK VREF GENERATOR TEST1 TEST2 TEST3 TEZI DIGITAL EQUALIZER BUS0 ADDRESS BUS1 CIRCUIT TSIN AUTOMATIC MICRO BUS2 ALIGNMENT SBAD COMPUTER CIRCUIT BUS3 INTERFACE RFRP CLV SERVO RFZI BUCK 16k RAM RFCT /CCE...
  • Page 63 IC106 BA6321FS-E2 SAWTOOTH S&H OSILLATION CIRCUIT MIX AMP CIRCUIT BUFFER ENFORCEMENT OP CONTROL FG. AMP HYS. AMP IC207 AM28F512-90JC/T N.C. CHIP ENABLE OUTPUT ENABLE /WE(W) LOGIC STATE CONTROL COMMAND REGISTER ADDRESS LATCH Y-DECODER PROGRAM VOLTAGE X-DECODER SWITCH N.C. • • • INPUT DATA ERASE...
  • Page 64 IC401 LA6527N 34 33 30 29 VCC2 BUFFER MTR+ 2 VH– VARIABLE VOLTAGE REF. EDGE COMP COMP 2 TO 4 DECODER MTR– BUFFER ER AMP DV AMP VL– VL AMP 11 12 13 IC402 LB1916 34 33 HALL BIAS WIN1 WIN2 UOUT HALL AMPLIFIER...

  • Page 65: Exploded Views

    Description Remark A-4672-423-A BOX ASSY, MAIL 3-704-366-41 SCREW (CASE) (M3X6) 4-986-618-01 CASE (L) * 12 4-986-147-02 BASE, MD (CDL1100-10) 4-986-636-01 CASE (TOP) 2-236-956-00 SCREW, STEP A-4672-421-A CARRIER ASSY A-4672-422-A CASE ASSY, DISC A-4699-367-A MAIN BOARD, COMPLETE 1-782-606-11 LEAD (WITH CONNECTOR)

  • Page 66: Front Panel Assy Section

    8-2. FRONT PANEL ASSY SECTION not supplied ND601 not supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark * 51 A-4699-393-A MD LED BOARD, COMPLETE * 58 4-986-171-01 BRACKET (CONT) 3-703-454-21 SCREW (1.7X6), TAPPING * 59 A-4699-371-A PANEL BOARD, COMPLETE 4-992-931-01 SPRING (FL), TORSION 3-950-280-01 MAGNET...

  • Page 67: Chassis Section

    8-3. CHASSIS SECTION Back panel not supplied not supplied not supplied not supplied T902 supplied not supplied not supplied supplied not supplied not supplied supplied not supplied Les composants identifiés par The components identified by une marque ! sont critiques pour mark ! or dotted line with mark ! are critical for safety.

  • Page 68: Back Panel Section

    8-4. BACK PANEL SECTION S901 not supplied Supplied with not supplied CNP601 not supplied not supplied not supplied not supplied Les composants identifiés par The components identified by une marque ! sont critiques pour mark ! or dotted line with mark ! are critical for safety.

  • Page 69: Carrier Assy Section 1

    8-5. CARRIER ASSY SECTION 1 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark * 201 4-985-963-01 GUIDE, DISC * 207 X-4947-665-1 SHAFT (JOINT) ASSY * 202 4-985-954-02 COVER (L), CARRIER * 208 A-4672-205-A BRACKET (GUIDE L) ASSY * 209 4-985-964-02 LIMITTER (DISC) * 203...

  • Page 70: Carrier Assy Section 2

    8-6. CARRIER ASSY SECTION 2 not supplied M651 clip not supplied not supplied M652 not supplied not supplied not supplied not supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 4-985-956-01 BELT, TIMING * 263 A-4672-203-A BRACKET (EVM) ASSY * 252 X-4947-666-1 TENSIONER (BELT) ASSY * 264...

  • Page 71: Carrier Assy Section 3

    8-7. CARRIER ASSY SECTION 3 not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark * 301 4-985-990-01 GUIDE (L), CLIP * 308 4-986-000-01 ROLLER (LIMITTER) * 302 4-985-991-01 GUIDE (R), CLIP...

  • Page 72: Disc Case Assy Section

    8-8. DISC CASE ASSY SECTION not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied Ref. No. Part No. Description Remark 4-986-021-01 SPRING (CASE), LEAF 4-986-022-01 SPRING (SLIDE), LEAF A-4672-422-A CASE ASSY, DISC 4-951-620-01 SCREW (2.6X8), +BVTP 4-986-022-11 SPRING (SLIDE), LEAF...

  • Page 73: Mail Box Assy Section

    8-9. MAIL BOX ASSY SECTION not supplied not supplied not supplied not supplied not supplied not supplied supplied M631 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 3-569-657-00 SPRING, TENSION * 411 A-4699-394-A M BOX SW BOARD, COMPLETE 4-990-632-01 SCREW (2X8), +PTPWH * 412 A-4699-397-A MBMO BOARD, COMPLETE...
  • Page 74 8-10. CDM-47 SECTION not supplied M003 supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark * 451 4-989-225-01 COVER, PULLEY 4-986-152-01 SPRING (PR) A-4675-467-A PULLEY ASSY, CHUCKING * 453 4-986-148-01 HOLDER, CHUCK 4-986-153-01 SPRING (PL) * 454 1-664-724-11 CN BOARD 4-986-158-01 GEAR (P2) * 455...

  • Page 75: Bu Holder Section

    8-11. BU HOLDER SECTION not supplied M002 not supplied M001 Les composants identifiés par The components identified by mark ! or dotted line with mark une marque ! sont critiques pour ! are critical for safety. la sécurité. Replace only with part number Ne les remplacer que par une specified.

  • Page 76: Electrical Parts List

    AC SW CARRIER COVER CLIP (IN) CLIP (OUT) SECTION 9 ELECTRICAL PARTS LIST Note: • SEMICONDUCTORS • Due to standardization, replacements in the parts list The components identified by In each case, u: µ , for example: may be different from the parts specified in the mark ! or dotted line with mark diagrams or the components used on the set.
  • Page 77 DISC SENSOR FILTER LDSW DIP SW Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1-664-724-11 CN BOARD A-4699-384-A FILTER BOARD, COMPLETE ********* *********************** < CONNECTOR > 1-533-293-11 FUSE HOLDER * CN56 1-564-004-11 PIN, CONNECTOR 5P < CAPACITOR > ************************************************************** ! C902 1-113-925-11 CERAMIC...
  • Page 78 LDSW M BOX M BOX SW MA-C22 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < JUMPER RESISTOR > C103 1-124-778-00 ELECT CHIP 22uF 6.3V C104 1-124-778-00 ELECT CHIP 22uF 6.3V JC51 1-216-295-91 CONDUCTOR, CHIP (2012) C105 1-164-004-11 CERAMIC CHIP 0.1uF...
  • Page 79 MA-C22 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C183 1-164-161-11 CERAMIC CHIP 0.0022uF 100V C503 1-126-206-11 ELECT CHIP 100uF 6.3V C504 1-163-038-91 CERAMIC CHIP 0.1uF C186 1-163-117-00 CERAMIC CHIP 100PF C505 1-163-038-91 CERAMIC CHIP 0.1uF C187 1-163-117-00 CERAMIC CHIP 100PF...
  • Page 80 MA-C22 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark M002 A-4672-402-A MOTOR ASSY (SPINDLE) R171 1-216-071-00 METAL CHIP 8.2K 1/10W R172 1-216-071-00 METAL CHIP 8.2K 1/10W < TRANSISTOR > R173 1-216-643-11 METAL CHIP 0.5% 1/10W Q101 8-729-101-07 TRANSISTOR 2SB798-DL R174 1-216-643-11 METAL CHIP...
  • Page 81 MA-C22 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R455 1-216-295-91 CONDUCTOR, CHIP (2012) C711 1-163-205-00 CERAMIC CHIP 0.001uF R456 1-216-076-00 METAL CHIP 1/10W C712 1-165-319-11 CERAMIC CHIP 0.1uF R459 1-216-681-11 METAL CHIP 0.5% 1/10W C713 1-165-319-11 CERAMIC CHIP 0.1uF...
  • Page 82 0.01uF IC701 8-759-283-49 IC HD6413002F10 C805 1-136-153-00 FILM 0.01uF IC702 8-752-381-84 IC CXD1095Q C806 1-136-153-00 FILM 0.01uF IC703 8-759-478-72 IC MX27C1024DC-70-CDL1100-1.00 C807 1-163-251-91 CERAMIC CHIP 100PF IC704 8-752-337-79 IC CXK58257AM-10LL C808 1-163-251-91 CERAMIC CHIP 100PF IC705 8-759-926-11 IC SN74HC138ANS C809...
  • Page 83 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark IC715 8-759-059-28 IC LA5536 R774 1-216-077-00 METAL CHIP 1/10W IC716 8-759-056-84 IC S-8420AF R777 1-216-121-91 METAL GLAZE 1/10W IC717 8-759-927-72 IC TL1591CP R778 1-216-081-00 METAL CHIP 1/10W IC718 8-759-927-72 IC TL1591CP R779...
  • Page 84 MBMO MD LED MAIN MBDS MBLD P LED Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R831 1-216-097-91 METAL GLAZE 100K 1/10W A-4699-397-A MBMO BOARD, COMPLETE R832 1-216-097-91 METAL GLAZE 100K 1/10W ********************* R833 1-216-097-91 METAL GLAZE 100K 1/10W R834...
  • Page 85 PANEL Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-4699-371-A PANEL BOARD, COMPLETE < SWITCH > ********************** S604 1-570-438-11 SWITCH, DIGITAL(SMALL TYPE)(MODE SELECT) < CAPACITOR > S605 1-570-313-11 SWITCH, KEYBOARD (UP) S606 1-570-313-11 SWITCH, KEYBOARD (DOWN) C601 1-124-589-11 ELECT 47uF...
  • Page 86 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark * CN911 1-566-418-11 CONNECTOR (PIN HEADER) 4P R660 1-216-085-00 METAL CHIP 1/10W R661 1-216-093-00 METAL CHIP 1/10W < DIODE > R662 1-216-093-00 METAL CHIP 1/10W R663 1-216-093-00 METAL CHIP 1/10W D901 8-719-025-03 DIODE RBA-402-SL...
  • Page 87 SERVICE VOLSEL Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-4699-369-A SERVICE BOARD, COMPLETE ! 517 1-758-007-11 OPTICAL PICK-UP (SPU-3210) ************************ BT701 1-528-229-41 BATTERY, LITHIUM (CR-2450) < CAPACITOR > M001 A-4608-415-B MOTOR ASSY (SLED) M002 A-4672-402-A MOTOR ASSY (SPINDLE) C606 1-124-589-11 ELECT 47uF...
  • Page 88 Ref. No. Part No. Description Remark 7-627-552-58 SCREW,PRECISION +P 1.7X5 7-685-872-09 SCREW +BVTT 3X8 7-682-946-09 SCREW +PSW 3X5 7-685-133-14 +BTP 2.6X6, TYPE2 NON-SLIT 7-685-646-79 +BVTP 3X8 9-13...
  • Page 89 CDL1100 Sony Corporation 97F09016-1D Printed in Japan ©1997.6 9-920-921-81 Home A&V Products Company Published by General Engineering Dept. (Shibaura) — 124 —...
