All manuals and user guides at all-guides.com No. 0249 22LD3750DC «MODEL NAMES» 22LD3750DU SERVICE MANUAL MANUEL D'ENTRETIEN WARTUNGSHANDBUCH CAUTION: Before servicing this chassis, it is important that the service technician read the “Safety Precautions” and “Product Safety Notices” in this service manual.
All manuals and user guides at all-guides.com TABLE OF CONTENTS 1 INTRODUCTION ............................1 2 GENERAL DESCRIPTION ........................1 3 POWER STAGE ............................4 4 MICROCONTROLLER PORT CONFIGURATION ................4 5 SIDE BOARDS AND CONNECTORS ...................... 5 5.1 Keypad ............................5 5.2 Infrared &...
All manuals and user guides at all-guides.com 1 INTRODUCTION The purpose of this document is to define the operation of 17MB29 chassis, capable of driving 22” TFT LCD panel. It is aimed to provide information to engineering staff to understand the operation and specs of the TV.
Page 4
All manuals and user guides at all-guides.com General default features • Multi System Reception: PAL-SECAM BG-DK-I/I’-L/L’ • Menu system (multi language) • 100 program storage locations • OSD (on-screen display) • Teletext • IR Control (RC5 and other customer specific protocols) •...
Page 5
All manuals and user guides at all-guides.com Teletext/OSD • Simple Text 10 Pages • Fastext & Top Text (OPT) • Teletext Languages (ALL) • Character Based OSD Electrical features •IPS generates 12V and 5V DC supply. •<1W standby power consumption System Building Blocks 17MB29 chassis main blocks are as follows: •Analog Front End : VCTI (Microcontroller+Video Proccessor+Audio Proccessor+IF...
All manuals and user guides at all-guides.com Back End MST-TSUMU38BF has two ADC inputs. First ADC input is assigned to the VCTI RGB output. Other RGB/YPbPr inputs are multiplexed for the second ADC input. HDMI receiver ANX9021 analog output, VGA RGB input and the synchronization signals are multiplexed by a primary RGB switch (PI5V512).
All manuals and user guides at all-guides.com PORT SIGNAL NAME TYPE FUNCTION NAME HDMI_HP_INV HDMI hot plug signal Switching control for Mstar bus and system I2C Safety VCTI_HS VCTI composite sync output FBIN DVD_SENSE DVD module detection Vert+ TV/DVB_SW IDTV/TV I2C and AGC switch control for tuner Write protection control for NVM Infrared input Table 4.1 VCTI port configuration...
All manuals and user guides at all-guides.com 5.2 Infra-red & LED A five-pin connector is used between 17MB29 and the LED board: Pin2 and pin3 carry the control signals for the LED. Pin4 carries the infra-red signal to the microcontroller. Pin5 is used to power up the LED board.
Page 9
All manuals and user guides at all-guides.com TDM1300 board has no tuner on it. Instead, the tuner of 17MB29 is used for both analogue and digital reception. Tuner is controlled by either the 17MB29 microcontroller (VCTI), or TDM1300 board microcontroller. The IF (intermediate frequency) output of the tuner is sent to TDM1300 board for digital reception.
All manuals and user guides at all-guides.com 5.4 DVD module board DVD module board has two parts: a loader and an electronic card. Electronic card controls the loader and has connections with 17MB29 and DVD keypad. Three cables are used to connect 17MB29 and DVD electronic card: power, data and sense. 12V (500mA) is sent to DVD electronic card by power cable: Y/C and/or CVBS video, stereo audio outputs and infra-red input of DVD module board is carried on data cable:...
All manuals and user guides at all-guides.com 5.5 LVDS connector MST-TSUMU38BF is used for dual LVDS output on 17MB29: Panel_Vcc1 is the power input for the panel LCD module. PIN7 signal is a logic 1 or 0 signal depending on the panel type. 5.6 IPS Power Card This product include AC-DC flyback converter, DC-DC converter and DC-AC half bridge converter.
Page 12
All manuals and user guides at all-guides.com...
All manuals and user guides at all-guides.com 6 IC SPECIFICATIONS 6.1 Microcontroller/Video&Audio Processor (VCT4913G) VCTI49xy is composed of microcontroller, video proccessor, display and deflection processor, sound proccessor and IF blocks as shown in figure below.
Page 14
All manuals and user guides at all-guides.com VCTI49xyl family has two package types; PSSDIP88 and PMQFP144. PSSDIP88 package is chosen because of its convenience in the soldering process. PSSDIP88 package has two versions; 1 and 2. PSSDIP88-2 package is the “pinning mirrorred” version of PSSDIP88-1 and is preferred to be used for layout compatibility.
Page 15
All manuals and user guides at all-guides.com...
All manuals and user guides at all-guides.com 6.2 Scaler/De-interlacer (MST-TSUMU38BF) The TSUMU38BF is total solution graphics processing ICs for LCD displays with panel resolutions up to XGA and WXGA+ / SXGA+ respectively. They are configured with a high-speed integrated triple-ADC/PLL, a high quality display processing engine, and an integrated multi-purpose output display interface that can support all major panel interface formats.
Page 17
All manuals and user guides at all-guides.com PORT SIGNAL TYPE FUNCTION NAME NAME PWM0 AN/DIG_DIM Analog or digital dimming control PWM1 BKL_ON/OFF Backlight On/Off Control PVCC_ON/OFF O Panel Logic Power On/Off control PWM2 PC/HDMI_SW Video switching control Table 6.2.1: MST5x7A-M port allocation...
All manuals and user guides at all-guides.com 6.3 Audio Stage Audio Preamplifier(LM358D) These circuits consist of two independent, high gain, internally frequency compensated which were designed specifically to operate from a single power supply over a wide range of voltages. The low power supply drain is independent of the magnitude of the power supply voltage.
Page 19
All manuals and user guides at all-guides.com...
All manuals and user guides at all-guides.com 6.4 Headphone Amplifier (TDA1308T) TDA1308T is an integrated class AB stereo headphone driver contained in an SO8, DIP8, or a TSSOP8 plastic package. SO8 package is used in 17MB29. The device is fabricated in a 1mm CMOS process.
All manuals and user guides at all-guides.com 6.6 HDMI Receiver (ANX9021) The ANX9021 is an advanced multimedia receiver compliant with High Definition Multimedia Interface (HDMI) Specification 1.2. HDMI is the first transport standard to unify digital video, audio, and control da ta over lowcost cables. It connects digital television, flat panel displays and project systems digitally to multimedia sources: DVD players, high definition settop boxes, digital video tape recorders, and personal computers.Digital transmission, in turn, delivers an uncompromising multimedia experience.
All manuals and user guides at all-guides.com • Analog RGB/YPbPr output with 8-bit linearity • Digital audio interface o32 to 192 kHz audio sampling rate oUp to 4 I2S interface for 8-channel audio oS/PDIF interface supporting PCM, Dolby Digital™, DTS™ digital audio transmission using IEC 60958 and IEC 61937 oConfigurable soft mute •...
All manuals and user guides at all-guides.com • Low On-Resistance: 5Ω • Low crosstalk at 10 MHz: –90dB • Ultra-low quiescent power (0.1µA typical) • Single supply operation: +5.0V • Fast switching: 10ns Packaging (Pb-free & Green available): 24-pin 150-mil wide plastic QSOP (Q) •...
All manuals and user guides at all-guides.com • General-purpose port output • Antenna power supply input 6.9 SAW Filter (X6966M) 6.10 I2C Switch (74HCT4053) 74HCT4053 is a triple 2-channel analog mux/demux with a common enable input. Each multiplexer/demultiplexer has two independent inputs/outputs (nY0 and nY1), a common input/output (nZ) and three digital select inputs (S1 to S3).
All manuals and user guides at all-guides.com 6.11 Audio DAC (CS4334) CS4334 is a 8-pin, 24-bit, 96KHz stereo D/A converter. The CS4334 family is based on Delta-Sigma modulation, where the modulator output controls the reference voltage input to an ultra-linear analog lowpass filter. This architecture allows for infinite adjustment of sample rate between 2 kHz and 100 kHz simply by changing the master clock frequency.
All manuals and user guides at all-guides.com 6.12 IC EEPROM 2Kbx8(24LC02) The 24LC01/02 is a 1K/2K-bit serial read/write non-volatile memory device using the CMOS floating gate process.Its 1024/2048 bits of memory are organized into 128/256 words and each word is 8 bits.
Page 27
All manuals and user guides at all-guides.com • ESD Performance: HBM > 2000V; MM > 200V • Chip Complexity: 38 FETs...
Page 28
All manuals and user guides at all-guides.com...
Page 29
All manuals and user guides at all-guides.com Description FRONT C OVER LCD22784 W/H LENS LED 2832 WRF LE NS IR 2100 5 H1: 6 H2: 5 17 LD 69 SCREW P C ZN YSB 3 x 6.5 SPEAKER 16 R 5 W 31x94 mm. ROHS SCREW P C ZN YFMB 3x9.5 17 TK 83S BUTTON STAND-BY 1709W...
Page 30
All manuals and user guides at all-guides.com TDM_GND0 C124 SOFTWARE UPDATE C12V DVB_IN_R R412 CN122 BACK AV/SIDE VE YPBPR F107 R159 C103 VCTI_PROG_EN VCTI_PROG_EN D140 600R TDM_PR TP117 C125 DVB_IN_G/Y SIDE_PR1 R413 220n HWSDA HWSCL JK102 C104 TDM_Y TP118 C126 DVB_IN_B/C R414 220n...
Page 31
All manuals and user guides at all-guides.com FLASH PROG. & VCTI DEBUG CN113 C193 S126 SD RGB INPUT FOR MST517 AUDIO LINE-OUT +3V3 100n +5V_VCTI R446 R268 S123 +3V3 C373 R388 C527 C178 C187 C528 Q128 ROUT2 GND1 GND8 100u 100n 100n 100u...
Page 32
All manuals and user guides at all-guides.com VDDP 3V3 SUPPLY FOR TSU 1V8 SUPPLY FOR TSU DIMMING pin58 pin77 pin84 pin96 pin120 pin139 pin160 pin172 pin182 F154 F158 C216 C220 C222 C227 C214 C225 C228 C230 C229 100n 100n 100n 100n 100n 100n...
