Instructions
Rexroth
NYA04.1-STRAIN-RELIEF-4150-NY4901/40
1 About this documentation
1.1 Overview – target groups & product phases
The target groups, product phases and activities that can
refer to this document are marked in rounded boxes in
the following figure.
Mounting
Product phases
Selection
(assembly/installation)
Presales Aftersales
Design engineer
Mechanic/
electrician
Programmer
Technologist
Process
specialist
Target groups
To select To unpack
To prepare To mount
Activities
To design To install
To construct
1.2 Intended audience
This document explains technical and service personnel of
the machine builder how to safely install the cable strain
relief bracket on the NY4150/10 module. This document is
not the usage manual.
1.3 Availability
These instructions are part of the cable strain relief
bracket product delivery and must always be available for
the user. If the cable strain relief bracket is handed over
to another person, these instructions must be handed
over as well.
1.4 Included parts
Type code
NYA04.1-STRAIN-RELIEF-4150-NY4901/40
DOK-NY4000-STRNY490140-IT01-EN-P
1.5 Variations
These instructions apply to the cable strain relief bracket
with the following Type code:
• NYA04.1-STRAIN-RELIEF-4150-NY4901/40
1.6 Further available documentation
Title and type code
Rexroth NYCe 4000 Hardware System Manual
DOK-NY4000-HW***SYSTEM-PRRS-EN-E
Rexroth NYCe 4000 Standard Housings & Accessories Manual
DOK-NY4000-HOUSING*ACC-PRRS-EN-E
December 7, 2020
Bosch Rexroth AG
P.O. Box 13 57
97803 Lohr a.Main, Germany
Bgm.-Dr.-Nebel-Str. 2
97816 Lohr a.Main, Germany
Tel. +49 9352 18 0
Fax +49 9352 18 8400
www.boschrexroth.com/electrics
Engineering Operation De-commissioning
Commissioning
Programmer
Commissioning engineer
Technologist
Process specialist
Machine
operator
Maintenance
technician
Mechanic/
electrician
Service
Disposal company
To parameterize To optimize To operate To dismount
To program To test To maintain To dispose
To remove
To configure
faults
To create
To simulate
the program
Material number Description
R911403465 Cable bracket
R911404771 Instructions
Material number
R911337671
R911337672
Page 1 of 5
1.7 Additional parts
System housings, drive modules, connection cables, and
more are listed in the project planning manuals or on
www.boschrexroth.com.
2 Product Identification and Scope of Delivery
2.1 Product identification
Figure 1. View of the NYA04.1-STRAIN-RELIEF-4150-NY4901/40
The NYA04.1-STRAIN-RELIEF-4150-NY4901/40 can be iden-
tified by the label on the top side of the bracket.
1
BOSCH REXROTH AG
BGM.-DR.-NEBELSTR. 2
97816 LOHR, GERMANY
1 Company address
2 Material number
3 Version level and status
4 Designation of origin
5 Division number / plant number
2.2 Scope of delivery
The NYA04.1-STRAIN-RELIEF-4150-NY4901/40 product de-
livery consists of the following items.
• NYA04.1-STRAIN-RELIEF-4150-NY4901/40 cable strain
relief bracket for the NY4150/10 module, material
number R911403465.
• DOK-NY4000-STRNY490140-IT01-EN-P
material number R911404771.
3 Using the Safety Instructions
3.1 Safety instructions - structure
The safety instructions are structured as follows.
3.2 Explaining signal words and safety alert symbol
The safety instructions in this documentation contain spe-
cific signal words (danger, warning, caution, notice) and,
if necessary, a safety alert symbol (according to ANSI
Z535.6-2006).
The signal word is meant to draw the reader's attention to
the safety instruction and signifies the degree of danger.
R911404771-01_BAL_DOC
2 3
R911403465 - AA
MNR:
7261
Made in Germany
5 4
Instructions,
