Product and Cut-out Dimensions
Modular Combiset Program
2 Burner Electric Cooktop
KM400
Location Codes
E - 5 foot - 208-240 Volt - 15 Amp 3-wire
power supply connects rear right
bottom.
Notes
• All installations must be done in
accordance with local codes.
E
2 13/16"
1 1/2" min.
NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 010300
