Page 1
ORDER NO. ITD0309035C1 B19 Canada: B07 High Definition Plasma Television TH-42PX20U-P GPH6DU Chassis SPECIFICATIONS Specifications Power Source AC 120 V, 50 / 60 Hz Power Consumption Maximum :595 W Stand-by condition :0.9 W Plasma Display panel Drive method :AC type 42-inch, 16 :9 aspect ratio Screen Size 36.22 “...
Page 2
Operating Conditions Temperature : 34 ° F - 104 ° F (0 ° - 40 ° C) Humidity : 20 % - 80 % (non-condensing) Connection Terminals RGB input D-SUB 15pin R, G, B / 0.7 Vp-p (75 HD, VD / 1.0 -5.0 Vp-p (high impedance) AV INPUT 1-3 VIDEO...
Page 3
2. Safety Precautions 2.1. General Guidelines 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. 2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.
Page 4
the reading should be between 1M and 5.2M . / When the exposed metal does not have a return path to the chassis, the reading must be Figure 1 2.1.2. Leakage Current Hot Check (See Figure 1 1. Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check.
Page 5
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap, whichshould be removed for potential shock reasons prior to applying power to the unit under test.
Page 6
4. About lead free solder (PbF) Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder. The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu). That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.
Page 7
Suggested Pb free solder There are several kinds of Pb free solder available for purchase. This product uses Sn+Ag+Cu (tin, silver, copper) solder. However, Sn+Cu (tin, copper), Sn+Zn+Bi (tin, zinc, bismuth) solder can also beused. 5. Service Hint...
Page 8
Board Name Function Board Name Function DATA DRIVER (UPPER LINE FILTER RIGHT) DATA DRIVER (UPPER SCAN DRIVE LEFT) DIGTAL SIGINAL PROCESS SCAN OUT (DOWN) DIGTAL CORE MICOM SUSTAIN DRIVE FRONT TERMINAL, SWITCH SUSTAIN CONNECTION (UP) REAE TERMINAL SUSTAIN CONNECTION (DOWN) LED, REMOTE, SCAN OUT (UP) POWER SUPPLY...
Page 13
6.6. Lead of Wiring (6) 7. Self-check Function When symptoms like “the power fails sometimes” or “sometimes there is no picture and/or sound” can not be confirmed at the time of servicing, the self-check function can be used to confirm the occurrenceand to find the defective circuit. In case of “power failure”, flashing of the “POWER”...
Page 14
be used to narrow down the +B line. 7.1. Self-check of the microcomputer control system (bus line) Indicaton method Press the “ACTION” button in the control panel of the unit simultaneously with the “POWER” button in the control panel of the unit. Hold them few seconds. Return to he normal screen Press any button on the unit or in the remote control.
Page 15
7.2. Power LED Blinking timing chart 1. Subject Information of LED Flashing timing chart. 2. Contents When an abnormality has occurred the unit, the protection circuit operates and reset to the stand by mode. At this time, the defective block can be identified by the number of blinkes of the Power LED on the front panel of the unit.
Page 16
2. Green is lit then turns red blinking a few seconds later. 3. Only red is lit. 1. No lit 7.4. No Picture 7.5. Local screen failure Plasma display may have local area failure on the screen. Fig - 1 is the possible defect P.C.B.
Page 17
8. Serviceman Mode (Electronic Controls) This Receiver has electronic technology using the I C BUS Concept. It performs as a control function and it replaces many mechanical controls. Instead of adjusting mechanical controls individually, many of the control function are now performedby using “On Screen Display Menu”.
Page 18
3. Press ACTION button twice to exit menus. 4. Tune to the Channel 124. 5. Adjust VOLUME to minimum (0). 6. Press the VOL button (decrease) on Receiver. Red “CHK” appears in upper corner. 7. Press the Power Button on the Remote Control to select one of six Serviceman Adjustment Modes.
Page 19
Write Down the original value set (b in Fig.1) for each address before modifying anything. It is easy to erroneously adjust the wrong item. 2. Press Volume Up/Down on the Remote Control to adjust the level of the selected Service Adjustment (b in Fig.1). MAIN EEPROM ORIGINAL...
Page 20
To exit the CAT mode, access the ID mode and switch off the main power. 9.1. IIC mode Select the IIC mode by Up/Down button on the remote control at the front page of CAT mode then press the Action button on the remote control. “IIC mode structure”.
Page 21
9.3. SD mode Select the SD mode by Up/Down button on the remote control at the front page of CAT mode then press the Action button on the remote control. To exit the SD mode, press the RECALL button on the remote control. 9.4.
Page 22
10. Adjustment Procedure 10.1. Driver Set-up 10.1.1. Item / Preparation 1. Input an APL 100 % white signal. 2. Set the picture controls: - Picture mode: Normal White balance: Cool Aspect: 16:9 10.1.2. Adjustments...
Page 23
Adjust driver section voltages referring the panel data on the panel data label. Name Test Voltage Volume Remarks Point Vsus TPVSUS 170V ± 2V VR641 (P) (SS) TPVE 150V ± 1V R6770 (SS) (SS) Vset TPVSET 220V ± 5V (SC) TPVAD -90V ±...
Page 24
10.3. P.C.B. (Printed Circuit Board) exchange 10.3.1. Caution 1. To remove P.C.B. , wait 1 minute after power was off for discharge from electrolysis capacitors. 10.3.2. Quick adjustment after P.C.B. exchange...
Page 25
P.C.B. Name Test Point Voltage Volume Remarks P Board Vsus TPVSUS (SS) 170V ± 1V VR641 (P) TPVDA (SS) 67V ± 1V VR665 (P) SC Board TPVAD (SC) -90V ± 1V R6477 (SC) Vset TPVSET (SC) 220V ± 6V Vscn TPVSCN (SC) Vad + 118 ±...
Page 26
11. Adjustment 11.1. Pedestal setting 11.2. NTSC panel white balance 11.3. HD panel white balance 11.4. Sub brightness setting 12. Hotel mode 1. Purpose Restrict a function for hotels. 2. Access command - Enter to the Service Mode. - Press MUTE button on remote control. Hold few seconds.
Page 27
- Set the data of EEPROM(ADDRESS 1584) to 01. Push the Power switch(button) off/on the set(the remote control) to turn the set off/on. It can be made Hotel mode. 3. Exit command - First, set the data of EEPROM (ADDRESS 1584) to 00. Next, Push the Power switch(button) off/on the set(the remote control) to turn the set off/on.
Page 28
item Function INITIAL INPUT Select input signal modes. Set this signal, each time power is switched on. <Selection> : Off/TV/COMP1/COMP2/DIGITAL/ VIDEO1/VIDEO2/VIDEO3/PC/ JPEG Off: give priority to a last memory. PC: selectable with VGA option INITIAL VOL Adjust output Volume. LEVEL Set this volume, each time power is switched on.
Page 29
item Function REMOCON LOCK Select remote control key conditions. Set this condition, each time power is switched on. <Selection> : Off/SETUP/MENU Off: altogether valid Action: menu is invalid 13. Conductor Views 13.1. PF-Board 13.2. P-Board 13.3. PA-Board 13.4. TA and TB-Board 13.5.
Page 30
13.18. G-Board 13.19. K and S-Board 14. Block and Schematic Diagrams 14.1. Schematic Diagram Notes 14.2. Main Block Diagram 14.3. PF-Board Block Diagram 14.4. PF-Board Schematic Diagram 14.5. P-Board Block Diagram 14.6. P-Board (1 of 6) Schematic Diagram 14.7. P-Board (2 of 6) Schematic Diagram 14.8.
Page 31
14.23. DV-Board (2 of 3) Schematic Diagram 14.24. DV-Board (3 of 3) Schematic Diagram 14.25. JG-Board Block Diagram 14.26. JG-Board (1 of 5) Schematic Diagram 14.27. JG-Board (2 of 5) Schematic Diagram 14.28. JG-Board (3 of 5) Schematic Diagram 14.29. JG-Board (4 of 5) Schematic Diagram 14.30.
Page 32
14.48. D-Board (8 of 15) Schematic Diagram 14.49. D-Board (9 of 15) Schematic Diagram 14.50. D-Board (10 of 15) Schematic Diagram 14.51. D-Board (11 of 15) Schematic Diagram 14.52. D-Board (12 of 15) Schematic Diagram 14.53. D-Board (13 of 15) Schematic Diagram 14.54.
Page 33
14.73. SD-Board (1 of 2) Schematic Diagram 14.74. SD-Board (2 of 2) Schematic Diagram 14.75. SS, S, SS2 and SS3-Board Block Diagram 14.76. SS-Board (1 of 2) Schematic Diagram 14.77. SS, SS2 and SS3-Board Schematic Diagram 15. Parts Location 15.1. Parts Location (1)
Page 44
Ref. No. Part No. Part Name & Description Remarks C464 ECJ2XB1H104K C 0.1UF, K, 50V C465 ECKDNA471KB7 C 470PF, Z, ECKCNA471KB7 C501,02 ECJ2XB1H103K C 0.01UF, K, 50V C503,04 ECJ2XB1H104K C 0.1UF, K, 50V C506-08 ECJ2XB1H103K C 0.01UF, K, 50V C509 F2A1E101A097 E 100UF 25V C511...
Page 45
Ref. No. Part No. Part Name & Description Remarks C581 ECJ2XB1H223K C 0.022UF, K, 50V C583 ECJ2XB1H103K C 0.01UF, K, 50V C585,86 ECJ2XB1H104K C 0.1UF, K, 50V C587 ECJ2XB1H103K C 0.01UF, K, 50V C598 F2A1E470A097 E 47UF, 25V C599 ECJ2XB1H104K C 0.1UF, K, 50V C600,01 ECJ2XB1H103K...
Page 46
Ref. No. Part No. Part Name & Description Remarks C2342 ECA1HHG100 E 10UF, 50V C2344 ECA1CHG221 E 220UF, 16V C2345,46 ECA1VHG470 E 47UF, 35V C2347,48 ECA1HHG220 E 22UF, 50V C2349 ECA1HEN2R2 E 2.2UF, 50V C2350,51 ECA1HHG220 E 22UF, 50V C2352 ECA1CHG101 E 100UF, 16V C2353...
Page 47
Ref. No. Part No. Part Name & Description Remarks C6407 ECJ2XB1H222K C 2200PF, K, 50V C6408 ECJ2XB1H102K C 1000PF, K, 50V C6417-20 F1L2E1040002 E 1000UF, 25V C6421-26 TCUY1C105ZFN C 1UF, 16V F1J1C1050006 C6427 ECJ2XB1H222K C 2200PF, K, 50V C6428 ECJ2XB1H102K C 1000PF, K, 50V C6432 ECJ2XB1H472K...
Page 48
Ref. No. Part No. Part Name & Description Remarks C6601-06 ECA2DHG221 E 220UF, 200V C6607 ECWF2205JS P 2UF, 250V C6609 ECJ3YB1E105K C 1UF, K, 25V C6610 EEUFC1E221 E 220UF, 25V C6611-14 F1K2J222A014 C 2200UF, K,6.3V C6619 F1K2J222A014 C 2200UF, K,6.3V C6621,22 F1L1E4750004 C 4.7UF, 25V...
Page 49
Ref. No. Part No. Part Name & Description Remarks C7103-06 TCUY1C105ZFN C 1UF, 16V F1J1C1050006 C7107 F1K2A1040004 C 0.1UF, 100V C7111-18 F1K2A1040004 C 0.1UF, 100V C7139 F1K2A1040004 C 0.1UF, 100V C7141 F1K2A1040004 C 0.1UF, 100V C7143 F1K2A1040004 C 0.1UF, 100V C7145 F1K2A1040004 C 0.1UF, 100V...
Page 50
Ref. No. Part No. Part Name & Description Remarks C7539 F1K2A1040004 C 0.1UF, 100V C7541 ECJ2VF1C104Z C 0.1UF, Z, 16V C7541 F1K2A1040004 C 0.1UF, 100V C7542,43 ECJ2VF1C104Z C 0.1UF, Z, 16V C7543 F1K2A1040004 C 0.1UF, 100V C7544 ECJ2VF1C104Z C 0.1UF, Z, 16V C7545 F1K2A1040004 C 0.1UF, 100V...
Page 51
Ref. No. Part No. Part Name & Description Remarks C9027 ECJ1XF1C104Z C 0.1UF, Z, 16V C9028 ECJ3XB0J106M C 10UF, M,6.3V C9029 ECJ1XF1C104Z C 0.1UF, Z, 16V C9030,31 ECJ3XB0J106M C 10UF, M,6.3V C9032,33 ECJ1XF1C104Z C 0.1UF, Z, 16V C9034,35 ECJ1XB1C104K C 0.1UF, Z, 16V C9036,37 ECJ3XB0J106M C 10UF, M,6.3V...
Page 52
Ref. No. Part No. Part Name & Description Remarks C9316,17 ECJ1XF1C104Z C 0.1UF, Z, 16V C9318 ECJ3XF1C475Z C 4.7UF, Z, 16V C9319 ECJ1XF1C104Z C 0.1UF, Z, 16V C9321 ECJ3XB0J106M C 10UF, M,6.3V C9323 ECJ1XC1H101J C 100PF, J, 50V C9324 ECJ1XF1C104Z C 0.1UF, Z, 16V C9325 ECJ3XF1C475Z...
Page 53
Ref. No. Part No. Part Name & Description Remarks C9727,28 ECJ1XF1C104Z C 0.1UF, Z, 16V C9729 ECJ3XF1C475Z C 4.7UF, Z, 16V C9730-33 ECJ1XF1C104Z C 0.1UF, Z, 16V C9737 ECJ1XF1C104Z C 0.1UF, Z, 16V C9740,41 ECJ1XF1C104Z C 0.1UF, Z, 16V C9742 EEVHB1C470 E 47UF, 16V C9743...
Page 67
Ref. No. Part No. Part Name & Description Remarks R405-07 ERJ6ENF2003 M 200KOHM, 1/10W R409 ERJ6ENF3602 M 36KOHM, 1/10W R410 D0D5200JA032 M 22 OHM,J,1/5W R411 D1FZ100E0001 F 10 OHM R412 D0D5200JA032 M 22 OHM,J,1/5W R413 D1FZ100E0001 F 10 OHM R414 ERJ8GEYJ153 M 15KOHM, J,1/8W R415...
Page 68
Ref. No. Part No. Part Name & Description Remarks R489 ERJ6GEYJ332 M 3.3KOHM,J,1/10W R493 ERJ14YJ120 M 12 OHM, J,1/4W ERJ14YJ120U R494-96 ERJ6ENF5603 M 560KOHM, 1/10W R497 ERJ6ENF2402 M 24KOHM, 1/10W R498 ERJ6GEYJ392 M 3.9KOHM,J,1/10W R499 ERJ8GEYJ4R7 M 4.7 OHM, J,1/8W R500 ERJ6GEYJ472 M 4.7KOHM,J,1/10W...
Page 69
Ref. No. Part No. Part Name & Description Remarks R574 ERJ6GEYJ331 M 330 OHM,J,1/10W R575 ERJ6GEYJ4R7 M 4.7 OHM,J,1/10W R576 ERJ6ENF1002 M 10KOHM, 1/10W R577 ERJ6GEYJ104 M 100KOHM,J,1/10W R578 ERJ6ENF2201 M 2.2KOHM, 1/10W R579 ERJ6GEYJ103 M 10KOHM,J,1/10W R580 ERJ6ENF4701 M 4.7KOHM, 1/10W R581 ERJ6GEYJ332 M 3.3KOHM,J,1/10W...
Page 70
Ref. No. Part No. Part Name & Description Remarks R658 ERJ6ENF6201 M 6.2KOHM, 1/10W R659 ERJ6ENF2202 M 2.2KOHM, 1/10W R660 ERJ6ENF1202 M 12KOHM, 1/10W R661 EVMAASA00B53 CONTROL 5KOHMB R662 ERJ6ENF1303 M 130KOHM, 1/10W R663 ERJ6GEYJ222 M 2.2KOHM,J,1/10W R664 ERJ6ENF9101 M 9.1KOHM, 1/10W R665 EVMAASA00B23 CONTROL 2KOHMB...
Page 71
Ref. No. Part No. Part Name & Description Remarks R992 ERJ6GEYJ473 M 47KOHM,J,1/10W R993,94 ERJ6GEY0R00 M 0 OHM, 1/10W R2301,02 ERJ6GEYJ104 M 100KOHM,J,1/10W R2303,04 ERJ6GEYJ101 M 100 OHM,J,1/10W R2305,06 ERJ6GEYJ222 M 2.2KOHM,J,1/10W R2307,08 ERJ6GEYJ102 M 1KOHM,J,1/10W R2309,10 ERDS1FJ100 C 10 OHM, J,1/2W R2311-16 ERDS1FJ2R2 C 2.2 OHM, J,1/2W...
Page 72
Ref. No. Part No. Part Name & Description Remarks R2391 ERJ6GEYJ682 M 6.8KOHM,J,1/10W R2392 ERJ6GEYJ273 M 27KOHM,J,1/10W R2393 ERJ6GEY0R00 M 0 OHM, 1/10W R2394 ERJ6GEYJ682 M 6.8KOHM,J,1/10W R2395 ERJ6GEYJ273 M 27KOHM,J,1/10W R2396,97 ERJ6GEY0R00 M 0 OHM, 1/10W R2398 ERJ6GEYJ102 M 1KOHM,J,1/10W R2399 ERJ6GEY0R00 M 0 OHM, 1/10W...
Page 73
Ref. No. Part No. Part Name & Description Remarks R6433 ERJ6GEYJ104 M 100KOHM,J,1/10W (SC) R6434 ERDS1FJ221 C 220 OHM, J,1/2W (SC) R6434 ERJ6GEYJ103 M 10KOHM,J,1/10W (SD) R6435 ERJ6GEYJ224 M 220KOHM,J,1/10W (SD) R6435 ERJ6GEYJ332 M 3.3KOHM,J,1/10W (SC) R6436 ERJ6ENF1543 M 154KOHM, 1/10W (SC) R6436 ERJ6GEYJ224...
Page 74
Ref. No. Part No. Part Name & Description Remarks R6510 ERJ6GEYJ101 M 100 OHM,J,1/10W R6511,12 ERX3FJS2R2D M 2.2 OHM, J, 3W R6513 ERJ6GEYJ100 M 10 OHM,J,1/10W R6514 ERJ6GEYJ471 M 470 OHM,J,1/10W R6515 ERJ6GEYJ104 M 100KOHM,J,1/10W R6516 ERJ6GEYJ100 M 10 OHM,J,1/10W R6517 ERJ6GEYJ471 M 470 OHM,J,1/10W...
Page 75
Ref. No. Part No. Part Name & Description Remarks R6603 ERJ6GEYJ103 M 10KOHM,J,1/10W R6604 ERJ6GEYJ100 M 10 OHM,J,1/10W R6605-07 ERJ6GEYJ224 M 220KOHM,J,1/10W R6608 ERJ6GEYJ100 M 10 OHM,J,1/10W R6609,10 ERJ6GEYJ103 M 10KOHM,J,1/10W R6611-18 ERJ6GEYJ100 M 10 OHM,J,1/10W R6619-22 ERJ6GEYJ470 M 47 OHM,J,1/10W R6625 ERJ6GEYJ103 M 10KOHM,J,1/10W...
Page 76
Ref. No. Part No. Part Name & Description Remarks R6760 ERG1FJS472D M 4.7KOHM, J, 1W R6761 ERG2FJS123D M 12KOHM, J, 2W R6762 ERJ6GEYJ224 M 220KOHM,J,1/10W R6763 ERJ6GEYJ103 M 10KOHM,J,1/10W R6764 ERJ6GEYJ223 M 22KOHM,J,1/10W R6765,66 ERJ6GEYJ333 M 33KOHM,J,1/10W R6767 ERJ6GEYJ102 M 1KOHM,J,1/10W R6769 ERJ6GEY0R00 M 0 OHM, 1/10W...
Page 77
Ref. No. Part No. Part Name & Description Remarks R7224-27 TAJAAH0470JV M 47 OHM,J,1/16W D0GB470JA006 R7229,30 ERJ6GEY0R00 M 0 OHM, 1/10W R7236 ERJ3GEY0R00 M 0 OHM, 1/16W R7306 ERJ6GEYJ224 M 220KOHM,J,1/10W R7307 ERJ3GEY0R00 M 0 OHM, 1/16W R7308 ERJ6GEY0R00 M 0 OHM, 1/10W R7309 ERJ3GEY0R00 M 0 OHM, 1/16W...
Page 78
Ref. No. Part No. Part Name & Description Remarks R7525,26 ERJ6GEYJ472 M 4.7KOHM,J,1/10W R7527 ERJ6GEYJ102 M 1KOHM,J,1/10W (C3) R7527 ERJ6GEYJ472 M 4.7KOHM,J,1/10W (PA) R7528,29 ERJ6GEY0R00 M 0 OHM, 1/10W R7530-02 ERJ14YJ220 M 22 OHM, J,1/4W R7532 ERJ6GEYJ471 M 470 OHM,J,1/10W R7533 ERJ14YJ220 M 22 OHM, J,1/4W...
Page 79
Ref. No. Part No. Part Name & Description Remarks R7574 ERJ6ENF2701 M 2.7KOHM, 1/10W R7578 TAJAAH0470JV M 47 OHM,J,1/16W D0GB470JA006 R7579 ERJ6GEYJ683 M 68KOHM,J,1/10W (PA) R7579 TAJAAH0470JV M 47 OHM,J,1/16W D0GB470JA006 (C3) R7580 ERJ6GEY0R00 M 0 OHM, 1/10W R7581 TAJAAH0470JV M 47 OHM,J,1/16W D0GB470JA006 R7583...
Page 80
Ref. No. Part No. Part Name & Description Remarks R7823-26 TAJAAH0470JV M 47 OHM,J,1/16W D0GB470JA006 R9001 EXB38V470J RESISTOR ARRAY R9002,03 ERJ3GEY0R00 M 0 OHM, 1/16W R9004 EXB38V470J RESISTOR ARRAY R9005 TAJAAH0101JV M 100 OHM,J,1/16W D0GB101JA006 R9006 EXB38V470J RESISTOR ARRAY R9007-09 TAJAAH0101JV M 100 OHM,J,1/16W D0GB101JA006...
Page 81
Ref. No. Part No. Part Name & Description Remarks R9220,21 ERJ3GEYJ151 M 150 OHM,J,1/16W R9224 ERJ3GEYJ222 M 2.2KOHM,J,1/16W R9226 ERJ3GEYJ103 M 10KOHM,J,1/16W R9228 ERJ3GEYJ151 M 150 OHM,J,1/16W R9229,30 ERJ3GEY0R00 M 0 OHM, 1/16W R9231 ERJ3GEYJ272 M 2.7KOHM,J,1/16W R9232 ERJ3GEYJ331 M 330 OHM,J,1/16W R9234 ERJ3GEYJ103 M 10KOHM,J,1/16W...
Page 82
Ref. No. Part No. Part Name & Description Remarks R9380 ERJ3GEYJ472 M 4.7KOHM,J,1/16W R9382 ERJ3GEY0R00 M 0 OHM, 1/16W R9385 TAJAAH0101JV M 100 OHM,J,1/16W D0GB101JA006 R9386 ERJ3GEYJ220 M 22 OHM,J,1/16W R9388 ERJ3GEY0R00 M 0 OHM, 1/16W R9389,90 ERJ3GEYJ103 M 10KOHM,J,1/16W R9391,92 ERJ3GEYJ102 M 1KOHM,J,1/16W...
Page 83
Ref. No. Part No. Part Name & Description Remarks R9516,17 ERJ3GEY0R00 M 0 OHM, 1/16W R9518-27 EXB38V680J RESISTOR ARRAY R9529,30 EXB38V680J RESISTOR ARRAY R9532-37 TAJAAH0470JV M 47 OHM,J,1/16W D0GB470JA006 R9538,39 ERJ3GEY0R00 M 0 OHM, 1/16W R9540 EXB38V470J RESISTOR ARRAY R9541,42 ERJ3GEY0R00 M 0 OHM, 1/16W R9543...
Page 84
Ref. No. Part No. Part Name & Description Remarks R9650-53 EXB38V103J RESISTOR ARRAY R9654-57 ERJ3GEY0R00 M 0 OHM, 1/16W R9658 ERJ3GEYJ103 M 10KOHM,J,1/16W R9659-61 ERJ3GEYJ472 M 4.7KOHM,J,1/16W R9662 ERJ3GEYJ103 M 10KOHM,J,1/16W R9663-69 ERJ3GEYJ472 M 4.7KOHM,J,1/16W R9670-72 ERJ3GEY0R00 M 0 OHM, 1/16W R9674-79 ERJ3GEY0R00 M 0 OHM, 1/16W...
Page 85
Ref. No. Part No. Part Name & Description Remarks R9769 EXB38VR000 RESISTOR ARRAY R9770 ERJ3GEYJ103 M 10KOHM,J,1/16W R9771 EXB38VR000 RESISTOR ARRAY R9773 TAJAAH0101JV M 100 OHM,J,1/16W D0GB101JA006 R9774-76 ERJ3GEYJ103 M 10KOHM,J,1/16W R9777 ERJ3GEYJ471 M 470 OHM,J,1/16W R9779 ERJ3GEYJ103 M 10KOHM,J,1/16W R9781 ERJ3GEYJ103 M 10KOHM,J,1/16W...
Page 86
Ref. No. Part No. Part Name & Description Remarks R9859 ERJ3GEYJ102 M 1KOHM,J,1/16W R9860 TAJAAH0101JV M 100 OHM,J,1/16W D0GB101JA006 R9861 ERJ3GEYJ103 M 10KOHM,J,1/16W R9864 TAJAAH0101JV M 100 OHM,J,1/16W D0GB101JA006 R9867 ERJ3GEYJ330 M 33 OHM,J,1/16W R9868 ERJ3GEYJ472 M 4.7KOHM,J,1/16W R9869 TAJAAH0101JV M 100 OHM,J,1/16W D0GB101JA006 R9871...
Page 87
Ref. No. Part No. Part Name & Description Remarks R9943 TAJAAH0101JV M 100 OHM,J,1/16W D0GB101JA006 R9944 ERJ3GEYJ102 M 1KOHM,J,1/16W R9945,46 ERJ3GEYJ100 M 10 OHM,J,1/16W R9947 ERJ3GEYJ472 M 4.7KOHM,J,1/16W R9948,49 ERJ3GEYJ103 M 10KOHM,J,1/16W R9951,52 ERJ3GEY0R00 M 0 OHM, 1/16W R9954-57 ERJ3GEY0R00 M 0 OHM, 1/16W R9959,60 ERJ3GEYJ472...
Page 88
Ref. No. Part No. Part Name & Description Remarks TXNSS10QJS CIRCUIT BOARD SS TNPA2916 CIRCUIT BOARD SS2 TNPA2917 CIRCUIT BOARD SS3 TNPA2990AB CIRCUIT BOARD S TNPA2992 CIRCUIT BOARD JG TNPA2986AB CIRCUIT BOARD G TXN/K1QKSU CIRCUIT BOARD K K1KA07B00006 7P CONNECTOR K1KA03A00213 3P CONNECTOR S300...
Page 89
Ref. No. Part No. Part Name & Description Remarks ZN401,02 D4EAD6210001 VARISTOR C001 EEEHB1A101P C 100PF, J, 10V C002 ECJ1VF1H103Z C 0.01UF, Z, 50V C003 EEEHB1A101P C 100PF, J, 10V C004 EEEHB1H1R0R C 1.0PF, J, 50V C005 ECJ1XF1C104Z C 0.1UF, Z, 16V C006 EEEHB1C470P C 47PF, J, 16V...
Page 90
Ref. No. Part No. Part Name & Description Remarks C3811 TCUY1C225KBM C 2.2UF, 16V F1K1C225A026 C3812 ECJ1XF1C104Z C 0.1UF, Z, 16V C3813,14 ECJ1XC1H330J C 33PF, J, 50V C3815 ECJ2XB1H563K C 0.056UF, K, 50V C3816 ECJ2XB1H102K C 1000PF, K, 50V C4501 ECJ1VB1H103K C 0.01UF, K, 50V C4502...
Page 91
Ref. No. Part No. Part Name & Description Remarks C4588 EEEHB0G101R C 100PF, J, 4V C4589 TCUY0J685MBM C 6.8UF, 6.3V F1K0J685A003 C4590 ECJ1VF1C105Z C 1UF, Z, 10V C4591-93 ECJ1XF1C104Z C 0.1UF, Z, 16V C4594 ECJ1VF1C105Z C 1UF, Z, 10V C4596-00 ECJ1XF1C104Z C 0.1UF, Z, 16V C4601...
Page 92
Ref. No. Part No. Part Name & Description Remarks C4680 ECJ1XC1H050C C 5PF, C, 50V C4681,82 EEEHB1A330R C 33PF, J, 10V C4683 ECJ1XB1C104K C 0.1UF, Z, 16V C4684 ECJ1XF1C104Z C 0.1UF, Z, 16V C4685,86 ECJ1XC1H121J C 120PF, J, 50V C4687 EEEHB1C100R C 10PF, J, 16V C4691...
Page 93
Ref. No. Part No. Part Name & Description Remarks C4789-92 ECJ1VF1A105Z C 1UF, Z, 10V C4793 ERJ6GEY0R00 M 0 OHM, 1/10W C4795 ERJ6GEY0R00 M 0 OHM, 1/10W C4797 ERJ6GEY0R00 M 0 OHM, 1/10W C4799 EEEHB1C470P C 47PF, J, 16V C4800,01 ECJ1VF1C105Z C 1UF, Z, 10V C4802...
Page 94
Ref. No. Part No. Part Name & Description Remarks C8051 ECJ1XF1C104Z C 0.1UF, Z, 16V C8055 ECJ1XC1H101J C 100PF, J, 50V C8201 EEEHB1C470P C 47PF, J, 16V C8203 ECJ2VF1H103Z C 0.01UF, Z, 50V C8206-09 ECJ1XF1C104Z C 0.1UF, Z, 16V C8210 ECJ3XB0J106M C 10UF, M,6.3V C8211...
Page 98
Ref. No. Part No. Part Name & Description Remarks R043 J0JCC0000100 CHIP INDUCTOR R044 ERJ3EKF1000 M 100 OHM, 1/16W R045 J0JCC0000100 CHIP INDUCTOR R046 ERJ3EKF1000 M 100 OHM, 1/16W R047 ERJ3GEYJ472 M 4.7KOHM,J,1/16W R048 ERJ3GEYJ272 M 2.7KOHM,J,1/16W R049 ERJ3GEYJ102 M 1KOHM,J,1/16W R050 ERJ3GEYJ472 M 4.7KOHM,J,1/16W...
Page 99
Ref. No. Part No. Part Name & Description Remarks R164 ERJ3GEYJ153 M 15KOHM,J,1/16W R165,66 ERJ3GEYJ682 M 6.8KOHM,J,1/16W R167 ERJ3GEYJ103 M 10KOHM,J,1/16W R168 ERJ3GEYJ101 M 100 OHM,J,1/16W D0GB101JA002 R462 ERJ3GEYJ103 M 10KOHM,J,1/16W R2251,52 ERJ3GEYJ223 M 22KOHM,J,1/16W R2254 ERJ3GEYJ223 M 22KOHM,J,1/16W R2257 ERJ3GEYJ183 M 18KOHM,J,1/16W R2258...
Page 100
Ref. No. Part No. Part Name & Description Remarks R4507 ERJ3GEYJ681 M 680 OHM,J,1/16W R4508 J0JCC0000100 CHIP INDUCTOR R4509 ERJ3GEYJ681 M 680 OHM,J,1/16W R4510 ERJ3EKF2400 M 240 OHM, 1/16W R4511,12 ERJ3EKF2200 M 220 OHM, 1/16W R4513,14 ERJ3EKF3300 M 330 OHM, 1/16W R4515,16 ERJ3GEYJ103 M 10KOHM,J,1/16W...
Page 101
Ref. No. Part No. Part Name & Description Remarks R4596 ERJ3EKF1502 M 15KOHM, 1/16W R4597 ERJ3EKF2000 M 200 OHM, 1/16W R4598-00 ERJ3EKF75R0 M 0.75HM, 1/16W R4601 ERJ3EKF4700 M 470 OHM, 1/16W R4602 J0JCC0000100 CHIP INDUCTOR R4603 ERJ3GEYJ471 M 470 OHM,J,1/16W R4604 ERJ3GEYJ220 M 22 OHM,J,1/16W...
Page 102
Ref. No. Part No. Part Name & Description Remarks R4689 J0JCC0000100 CHIP INDUCTOR R4690 ERJ3GEYJ103 M 10KOHM,J,1/16W R4692 ERJ3GEYJ330 M 33 OHM,J,1/16W R4693 ERJ6GEYJ331 M 330 OHM,J,1/10W R4694 ERJ6GEYJ471 M 470 OHM,J,1/10W R4695,96 ERJ6ENF1501 M 1.5KOHM, 1/10W R4697,98 J0JCC0000100 CHIP INDUCTOR R4699 ERJ3GEYJ121 M 120 OHM,J,1/16W...
Page 103
Ref. No. Part No. Part Name & Description Remarks R4845-47 ERJ3EKF2000 M 200 OHM, 1/16W R4848-50 ERJ3GEYJ221 M 220 OHM,J,1/16W R4851-53 ERJ3GEYJ561 M 560 OHM,J,1/16W R8001-03 ERJ6ENF75R0 M 75 OHM, 1/10W R8004-06 ERJ6GEYJ220 M 22 OHM,J,1/10W R8008 J0JCC0000100 CHIP INDUCTOR R8014,15 J0JCC0000100 CHIP INDUCTOR...
Page 104
Ref. No. Part No. Part Name & Description Remarks R8228-30 ERJ8ENF75R0 M 75 OHM, 1/8W R8231,32 ERJ3GEYJ101 M 100 OHM,J,1/16W D0GB101JA002 R8234 ERJ3GEYJ331 M 330 OHM,J,1/16W R8236 ERJ3GEYJ221 M 220 OHM,J,1/16W R8239,40 J0JCC0000100 CHIP INDUCTOR R8250 ERJ3GEYJ103 M 10KOHM,J,1/16W R8251 ERJ3GEYJ221 M 220 OHM,J,1/16W R8253-55...
Page 105
Ref. No. Part No. Part Name & Description Remarks C4223 EEEHB1C100R C 10PF, J, 16V C4224 ECJ1VF1C105Z C 1UF, Z, 10V C4225 ECJ1VF1A105Z C 1UF, Z, 10V C4226 ECJ1VB1H103K C 0.01UF, K, 50V C4227 ECJ1VF1C105Z C 1UF, Z, 10V C4228 ECJ1VB1H332K C 3300PF, K, 50V C4229...
Page 106
Ref. No. Part No. Part Name & Description Remarks C4351 ECJ1XB1C104K C 0.1UF, Z, 16V C4352,53 ECJ1VF1C105Z C 1UF, Z, 10V C4354,55 ECJ1XB1H102K C 1000UF, Z, 50V C4356,57 ECJ1XB1C104K C 0.1UF, Z, 16V C4358 ECJ2VF1C105Z C 1UF, Z, 16V C4359 EEEHB1C101P C 100PF, J, 16V C4360...
Page 107
Ref. No. Part No. Part Name & Description Remarks R4207 ERJ3GEYJ332 M 3.3KOHM,J,1/16W R4208 ERJ3GEYJ473 M 47KOHM,J,1/16W R4209 ERJ3GEYJ222 M 2.2KOHM,J,1/16W R4210,11 ERJ3GEYJ913 M 91KOHM,J,1/16W R4212-14 ERJ3GEYJ103 M 10KOHM,J,1/16W R4215 ERJ3GEYJ332 M 3.3KOHM,J,1/16W R4216 ERJ3GEYJ473 M 47KOHM,J,1/16W R4217,18 ERJ3GEYJ101 M 100 OHM,J,1/16W D0GB101JA002 R4219 ERJ3GEYJ472...
Page 108
Ref. No. Part No. Part Name & Description Remarks R4368 ERJ3GEY0R00 M 0 OHM, 1/16W R4369 ERJ3GEYJ102 M 1KOHM,J,1/16W R4370 ERJ3GEY0R00 M 0 OHM, 1/16W R4371,72 ERJ3GEYJ331 M 330 OHM,J,1/16W R4373-75 ERJ3GEY0R00 M 0 OHM, 1/16W R4380 ERJ6ENF68R0 M 68 OHM, 1/10W R4381-83 ERJ6GEYJ681 M 680 OHM,J,1/10W...
Page 109
Ref. No. Part No. Part Name & Description Remarks 18. Schematic Diagram for printing with A4 19. Cover for printing with A4...
Page 154
MUTE FOR CABLE IN AND OUT CABLE OUT -> Low : Mute CABLE IN -> Hi : Norm R5008 R5187 R5013 HPD for MUTE R5016 R5009 R5010 TH-42PX20U-P TH-42PX20U-P DV-BOARD (1 of 3) Schematic Diagram DV-BOARD (1 of 3) Schematic Diagram...
Page 165
) is found, connection is easily found from the direction of arrow 9. Indicates the major signal flow. : Video Audio 10. This schematic diagram is the latest at the time of printing and subject to change without notice. TH-42PX20U-P Schematic Diagram Notes...
Page 166
Connect the earth of instruments to the earth connection of the circuit being measured. d. Make sure to disconnect the power plug before removing the chassis. 2. Following diodes are interchangeable. MA150- MA162 (Replacement part) TH-42PX20U-P Schematic Diagram Notes...
Page 167
P-BOARD TNPA2889 (1/6) PF-BOARD (PF2) TH-42PX20U-P TH-42PX20U-P P-BOARD (1 of 6) Schematic Diagram P-BOARD (1 of 6) and Schematic Diagram...
Page 169
P-BOARD TNPA2889 (3/6) TH-42PX20U-P TH-42PX20U-P P-BOARD (3 of 6) Schematic Diagram P-BOARD (3 of 6) and Schematic Diagram...
Page 170
P-BOARD TNPA2889 (4/6) TO SC-BOARD (SC23) TO SS-BOARD (SS12) TO P-BOARD (P5) TO PA-BOARD (PA7) TO D-BOARD (D25) TH-42PX20U-P TH-42PX20U-P P-BOARD (4 of 6) Schematic Diagram P-BOARD (4 of 6) Schematic Diagram...
Page 171
P-BOARD TNPA2889 (5/6) TO FAN TO FAN TO FAN TO FAN TO D-BOARD (D27) TH-42PX20U-P TH-42PX20U-P P-BOARD (5 of 6) Schematic Diagram P-BOARD (5 of 6) and Schematic Diagram...
Page 172
P-BOARD TNPA2889 (6/6) TH-42PX20U-P TH-42PX20U-P P-BOARD (6 of 6) Schematic Diagram P-BOARD (6 of 6) Schematic Diagram...
Page 187
) is found, connection is easily found from the direction of arrow 9. Indicates the major signal flow. : Video Audio 10. This schematic diagram is the latest at the time of printing and subject to change without notice. TH-42PX20U-P Schematic Diagram Notes...
Page 188
Connect the earth of instruments to the earth connection of the circuit being measured. d. Make sure to disconnect the power plug before removing the chassis. 2. Following diodes are interchangeable. MA150- MA162 (Replacement part) TH-42PX20U-P Schematic Diagram Notes...
Page 189
CONVERT MAIN VIDEO3 MICOM MICOM TUNER TEXT DG22 EEPROM DG21 DG51 INPUT SDRAM SELECT VIDEO1 YPbPr SELECT RGB/PC GC2M VIDEO2 RGB AMP SELECT COMP1 GC2S COMP2 TV ON SDRAM MONI OUT S.R. S.R. S.R. S.R. S.R. TH-42PX20U-P MAIN BLOCK Diagram...
Page 190
PC CARD PJG21 POWER SWITCH AUDIO IN SEL. HDMI IN DVI I/F TUNER 30V L OUT PRE AMP SPEAKER R OUT DC/DC CONVERTER SPEAKER POWER ON STAND BY REMOTE RECEIVER S.R. S.R. S.R. S.R. LIGHT DETECTER TH-42PX20U-P MAIN BLOCK Diagram...
Page 195
IC501 POWER MCA 350V D404 T410 TV ON/OFF D511 IC502 IC409 X501 4NHz STB7V RESET XOUT PS SOS RESET D555 D510 Q535 D557 D410 D409 Q501 Q522 Q416 ALL OFF IC408 Q502 Q503 Q403 IC504 COLD TH-42PX20U-P P-BOARD BLOCK Diagram...
Page 196
ALL OFF TO D-BOARD TV ON/OFF FAN SOS TV ON/OFF Q552 Q537 STB5V PS SOS Q544 FAN SOS FAN SOS PS SOS Q546 ALL OFF ALL OFF FAN SOS PR502 Q531 D553 Q532 Q530 FAN SOS TH-42PX20U-P P-BOARD BLOCK Diagram...
Page 219
VAO MUTE R L AMP Q4206 R AMP Q4205 VIDEO2 Q4201 JK001 PROG Q4204 JK003 IC4201 COMPONENT1 EQUALIZER AUX0 AUX1 PROHIBIT LOUT L IN GEQ ON THROUGH JK004 PROHIBIT ROUT R IN COMPONENT2 IC4202 SWITCH TH-42PX20U-P TA, TB and H-BOARD BLOCK Diagram...
Page 220
IC4203 BBE VIVA L AMP LOUT Q4206 L IN R AMP ROUT Q4205 R IN Q4201 AUX1 TONE L LOUT TONE R ROUT AUX0 Q4204 IC4201 EQUALIZER LOUT L IN ROUT R IN TH-42PX20U-P TA, TB and H-BOARD BLOCK Diagram...
Page 227
DVI I/F RECEIVER LATCH DATA RECOVERY TMDS PANEL LATCH DECODER INTERFACE SYNCHRONIZATION LATCH CLK+ CLKG CLK- N.C. DDC DATA DDCG HPDT IC5011 EX.I/O SEL AUDIO IC5001 Q5002 A DAC PD AUDIO MUTE DDC EEPROM S_CLOCK1 S_DATA1 SAD2 TH-42PX20U-P DV-BOARD BLOCK Diagram...
Page 228
S_DATA0 SDA0 Q5018 IC5006 AUDIO DAC Q5005,5009 DVI Y DVI PB Q5006,5007 DVI PR Q5004,5008 IC5010 AVR3.3V +3.3V SUB5V SUB5V IC5005 RESET SEL AUDIO A DAC PD AUDIO MUTE S_CLOCK1 SCL1 IC5009 S_DATA1 SDA1 SAD2 AVR5V TH-42PX20U-P DV-BOARD BLOCK Diagram...
Page 229
D5012 Q5003 MAZ30560ML EEPROM 2SD0601A0L R5018 MUTE FOR CABLE IN AND OUT CABLE OUT -> Low : Mute CABLE IN -> Hi : Norm R5008 R5187 HPD for MUTE R5013 R5016 R5009 R5010 TH-42PX20U-P DV-BOARD (1 of 3) Schematic Diagram...
Page 230
C5046 6.3V 0.1u 0.047u C5135 R5021 Hi : MUTE R5023 Q5003 2SD0601A0L MUTE FOR CABLE IN AND OUT CABLE OUT -> Low : Mute CABLE IN -> Hi : Norm HPD for MUTE TH-42PX20U-P DV-BOARD (1 of 3) Schematic Diagram...
Page 263
SDA2 SCL3 SCL3 5V->3.3V SDA3 SDA3 Q9704 SCL2(3.3V) 5V->3.3V SOUND MAIN MUTE Q9703 SDA2(3.3V) CABLE DET CABLE DET SDA2 SCL2 RESET LSI RESET IC9709 (1/2) SUB MPU(CONVERTER) DATA IN DATA OUT MC CLK TH-42PX20U-P D-BOARD (1 of 2) BLOCK Diagram...
Page 264
MCDATA MCCLK IC9705 SCL3 SCL3 OSC IN X9701 SDA3 SDA3 FLASH MEMORY 24.5MHz SCL2 SCL2 OSC OUT (8M ROM) SDA2 SDA2 OSC IN X9703 IC9702 SCL1 SCL1 20MHz OSC OUT SDA1 SDA1 EEPROM TH-42PX20U-P D-BOARD (1 of 2) BLOCK Diagram...
Page 265
(2/2) POW_STATUS TXD_TU SUB MPU(CONVERTER TO P-BOARD RXD_TU RTC_INT IC9708 TXD_PC EEPROM RXD_PC Q9709 IC9707 REMOCON FAN_CONT INV. FAN CONT REMOCON INH INV. Q9708 REMOCON OUT (2/2) Plasma AI Sub-Field Processor SCL3 SDA3 TH-42PX20U-P D-BOARD (2 of 2) BLOCK Diagram...
Page 266
STB5V KILL SOS M POWER KILL SOS FAN SOS KILL SOS FAN SOS PS SOS FAN SOS PS SOS ALL OFF1 PS SOS ALL OFF1 ALL OFF1 STB5V_S Q9702 Q9701 STB5V_M SCL3 SDA3 TH-42PX20U-P D-BOARD (2 of 2) BLOCK Diagram...
Page 298
REMOCON SENSOR IC300 STBY5V STBY5V CATS SENSOR REMOCON Q305 REMOCON LED G Q7561 Q300 LED G LED R Q7562 LED R Q301 D302 eft) DG12 SS42 ON-LED(LED-G) Vda75V STB-LED(LED-R) Vda75V Remocon Senser TH-42PX20U-P C1, C2, C3, C4 and K-BOARD BLOCK Diagram...
Page 299
14.57. C1-Board (1 of 2) Schematic Diagram C1-B R7113 DATA DRIVER TERM R7105 R7125 DATA DRIVER TERM TH-42PX20U-P C1-BOARD (1 of 2) Schematic Diagram...
Page 340
TH-42PX20U-P SS(2 of 2), SS2, and SS3-BOARD Schematic Diagram...
Page 341
INPUT Equipment Setting Alignment menu Procedure ** Adjust at the dark room. 1 RF Picture: PANEL W/B Normal R cut off 1) Set R,G and B cut off to " 80 ". Gray Scale White balance: G cut off Pattern Cool B cut off Aspect:...
Page 342
INPUT Equipment Setting Alignment menu Procedure 1 NTSC Color Picture: 1) Find the nearest area to brightness of 10 cd/m as Low Gray Scale Analyzer Normal Sub Adjust light by color sensor. Pattern White balance: Sub Bright 2) Adjust Sub bright to set Low light level to 10 cd/m Cool exactly.
Page 343
INPUT Equipment Setting Alignment menu Procedure Color Picture: 1) Find the nearest area to brightness of 10 cd/m as Low Gray Scale Analyzer Normal Sub Adjust light by color sensor. Pattern White balance: Sub Bright 2) Adjust Sub bright to set Low light level to 10 cd/m Cool exactly.
Page 344
INPUT Equipment Setting Alignment menu Procedure ** Adjust at the dark room. 1 RF Picture: PANEL W/B Gray Scale Normal All cut off 1) Set white balance to Cool . Pattern Aspect: 16:9 2) Adjust All cut off to start some pixels emission at black 2% area and no emission at black 0% area.
Page 345
ORDER NO. ITD0309035C1 B19 Canada: B07 High Definition Plasma Television TH-42PX20U-P GPH6DU Chassis Specifications Power Source AC 120 V, 50/60 Hz Power Consumption Maximum :595 W Stand-by condition :0.9 W Plasma Display panel Drive method :AC type 42-inch, 16 :9 aspect ratio Screen Size 36.22 “...
TH-42PX20U-P AV PROG.OUT VIDEO 1.0 Vp-p (759) (Phono Jack Type) AUDIO L-R 0.5 Vrms (Phono Jack Type × 2) TO AUDIO AMP AUDIO L-R 0.5 Vrms (Phono Jack Type × 2) COMPONENT VIDEO 1.0 Vp-p (including synchronization) INPUT1-2 PB /PR ±...
Page 347
TH-42PX20U-P 13.18. G-Board 14.43. D-Board (3 of 15) Schematic Diagram 13.19. K and S-Board 14.44. D-Board (4 of 15) Schematic Diagram 14 Block and Schematic Diagrams 14.45. D-Board (5 of 15) Schematic Diagram 14.1. Schematic Diagram Notes 14.46. D-Board (6 of 15) Schematic Diagram 14.2.
TH-42PX20U-P 2 Safety Precautions 2.1. General Guidelines 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. 2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.
TH-42PX20U-P 3 Prevention of Electro Static Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor "chip"...
TH-42PX20U-P 4 About lead free solder (PbF) Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder. The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu).
TH-42PX20U-P 5 Service Hint Board Name Function Board Name Function DATA DRIVER (UPPER RIGHT) LINE FILTER DATA DRIVER (UPPER LEFT) SCAN DRIVE DIGTAL SIGINAL PROCESS SCAN OUT (DOWN) DIGTAL CORE MICOM SUSTAIN DRIVE FRONT TERMINAL, SWITCH SUSTAIN CONNECTION (UP) REAE TERMINAL...
TH-42PX20U-P 7 Self-check Function When symptoms like “the power fails sometimes” or “sometimes there is no picture and/or sound” can not be confirmed at the time of servicing, the self-check function can be used to confirm the occurrence and to find the defective circuit.
TH-42PX20U-P 7.2. Power LED Blinking timing chart 1. Subject Information of LED Flashing timing chart. 2. Contents When an abnormality has occurred the unit, the protection circuit operates and reset to the stand by mode. At this time, the defective block can be identified by the number of blinkes of the Power LED on the front panel of the unit.
TH-42PX20U-P 7.3. No Power First check point There are following 3 states of No Power indication by power LED. 1. No lit 2. Green is lit then turns red blinking a few seconds later. 3. Only red is lit. 1. No lit...
TH-42PX20U-P 7.4. No Picture 7.5. Local screen failure Plasma display may have local area failure on the screen. Fig - 1 is the possible defect P.C.B. for each local area. Fig - 1...
TH-42PX20U-P 8 Serviceman Mode (Electronic Controls) This Receiver has electronic technology using the I C BUS Concept. It performs as a control function and it replaces many mechanical controls. Instead of adjusting mechanical controls individually, many of the control function are now performed by using “On Screen Display Menu”.
Page 364
TH-42PX20U-P c. Serviceman OTHER ADJUSTMENT. Exiting the Serviceman Mode: Press the Power buttons on the Receiver. For Adjustments: 1. Press Channel Up/Down on the Remote Control to select one of the available Service Adjustments (a in Fig.1). Note: Write Down the original value set (b in Fig.1) for each address before modifying anything. It is easy to erroneously adjust the wrong item.
TH-42PX20U-P 9 CAT (computer Aided Test) mode To exit the CAT mode, access the ID mode and switch off the main power. 9.1. IIC mode Select the IIC mode by Up/Down button on the remote control at the front page of CAT mode then press the Action button on the remote control.
TH-42PX20U-P 9.2. CD mode Select the CD mode by Up/Down button on the remote control at the front page of CAT mode then press the Mute button on the remote control more than 5 sec. Micom software version (IC9705), this version can be upgrade by 1.
TH-42PX20U-P 10 Adjustment Procedure 10.1. Driver Set-up 10.1.1. Item / Preparation 1. Input an APL 100 % white signal. 2. Set the picture controls: - Picture mode: Normal White balance: Cool Aspect: 16:9 10.1.2. Adjustments Adjust driver section voltages referring the panel data on the panel data label.
TH-42PX20U-P 10.2. Initialization Pulse Adjust 1. Input a Cross hatch signal. 2. Set the picture controls: - Picture mode: Normal White balance: Cool Adjust the indicated test point for the specified wave form. Test point Volume Level TPSC1 (SC) 20 ± 15µ Sec...
TH-42PX20U-P 10.3. P.C.B. (Printed Circuit Board) exchange 10.3.1. Caution 1. To remove P.C.B. , wait 1 minute after power was off for discharge from electrolysis capacitors. 10.3.2. Quick adjustment after P.C.B. exchange P.C.B. Name Test Point Voltage Volume Remarks P Board...
TH-42PX20U-P 11 Adjustment 11.1. Pedestal setting INPUT Equipment Setting Alignment menu Procedure ** Adjust at the dark room. 1 RF Picture: PANEL W/B Normal R cut off 1) Set R,G and B cut off to " 80 ". Gray Scale...
TH-42PX20U-P 11.2. NTSC panel white balance INPUT Equipment Setting Alignment menu Procedure 1 NTSC Color Picture: 1) Find the nearest area to brightness of 10 cd/m as Low Gray Scale Analyzer Normal Sub Adjust light by color sensor. Pattern White balance:...
TH-42PX20U-P 11.3. HD panel white balance INPUT Equipment Setting Alignment menu Procedure Color Picture: 1) Find the nearest area to brightness of 10 cd/m as Low Gray Scale Analyzer Normal Sub Adjust light by color sensor. Pattern White balance: Sub Bright 2) Adjust Sub bright to set Low light level to 10 cd/m Cool exactly.
TH-42PX20U-P 11.4. Sub brightness setting INPUT Equipment Setting Alignment menu Procedure ** Adjust at the dark room. 1 RF Picture: PANEL W/B Gray Scale Normal All cut off 1) Set white balance to Cool . Pattern Aspect: 16:9 2) Adjust All cut off to start some pixels emission at black 2% area and no emission at black 0% area.
Page 375
TH-42PX20U-P 12 Hotel mode 1. Purpose CAUTION Restrict a function for hotels. This setup is not valid, unless data of EEPROM (ADDRESS 1584) will be 01, even if each settings were 2. Access command done. · Enter to the Service Mode.
Page 378
X9701 SDA3 SDA3 FLASH MEMORY 24.5MHz SCL2 SCL2 OSC OUT (8M ROM) SDA2 SDA2 OSC IN X9703 IC9702 SCL1 SCL1 20MHz OSC OUT SDA1 SDA1 EEPROM TH-42PX20U-P D-BOARD (1 of 2) BLOCK Diagram TH-42PX20U-P D-BOARD (1 of 2) BLOCK Diagram...
Page 379
FAN CONT PS SOS ALL OFF1 REMOCON INH ALL OFF1 INV. ALL OFF1 Q9708 REMOCON OUT STB5V_S (2/2) STB5V_M Q9702 Q9701 Plasma AI Sub-Field Processor SCL3 SDA3 TH-42PX20U-P D-BOARD (2 of 2) BLOCK Diagram TH-42PX20U-P D-BOARD (2 of 2) BLOCK Diagram...
Page 383
TUNER 30V TV ON L OUT SDRAM PRE AMP MONI OUT SPEAKER R OUT DC/DC CONVERTER SPEAKER POWER ON STAND BY REMOTE RECEIVER S.R. S.R. S.R. S.R. S.R. S.R. S.R. S.R. LIGHT DETECTER TH-42PX20U-P MAIN BLOCK Diagram TH-42PX20U-P MAIN BLOCK Diagram...
Page 384
FAN SOS D510 Q535 D557 PS SOS D410 D409 Q546 ALL OFF Q501 Q522 Q416 ALL OFF IC408 Q502 Q503 FAN SOS PR502 Q531 Q403 IC504 D553 Q532 Q530 FAN SOS COLD TH-42PX20U-P TH-42PX20U-P P-BOARD BLOCK Diagram P-BOARD BLOCK Diagram...
Page 385
STB5V STB5V STB5V Front Input Board Q2308 Q2311 MAIN DEF A MUTE SP MUTE Q2309 MUTE TO P7 STB5V Q2305 +15Vs +15Vs +15Vs +15Vs Q2306 PA22 PA23 PA24 TH-42PX20U-P TH-42PX20U-P PA and G-BOARD BLOCK Diagram PA and G-BOARD BLOCK Diagram...
Page 391
TONE R ROUT PROG AUX0 Q4204 JK003 COMPONENT1 IC4201 EQUALIZER AUX0 AUX1 PROHIBIT L IN GEQ ON LOUT THROUGH JK004 PROHIBIT ROUT R IN COMPONENT2 IC4202 SWITCH TH-42PX20U-P TH-42PX20U-P TA, TB and H-BOARD BLOCK Diagram TA, TB and H-BOARD BLOCK Diagram...
