Summary of Contents for Electrolux EHH6540X8K
- Page 1 EHH6540X8K User Manual...
-
Page 2: Table Of Contents
10. ENERGY EFFICIENCY.................. 21 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time. - Page 3 ENGLISH injuries and damages. Always keep the instructions with the appliance for future reference. 1.1 Children and vulnerable people safety This appliance can be used by children aged from 8 • years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
-
Page 4: Safety Instructions
After use, switch off the hob element by its control and • do not rely on the pan detector. If the glass ceramic surface / glass surface is cracked, • switch off the appliance to avoid the possibility of electric shock. - Page 5 ENGLISH Service Centre or an electrician to • If the surface of the appliance is change a damaged mains cable. cracked, disconnect immediately the • The shock protection of live and appliance from the power supply. This insulated parts must be fastened in to prevent an electrical shock.
-
Page 6: Product Description
2.4 Care and cleaning • Contact your municipal authority for information on how to discard the • Clean regularly the appliance to appliance correctly. prevent the deterioration of the • Disconnect the appliance from the surface material. mains supply. - Page 7 ENGLISH Sen‐ Function Comment field ON / OFF To activate and deactivate the hob. Lock / The Child Safety To lock / unlock the control panel. Device STOP+GO To activate and deactivate the function. Heat setting display To show the heat setting. Timer indicators of cook‐...
-
Page 8: Daily Use
3.4 OptiHeat Control (3 step The induction cooking zones make the heat necessary for cooking process Residual heat indicator) directly in the bottom of the cookware. The glass ceramic is heated by the heat WARNING! of the cookware. There is a risk of burns from residual heat. - Page 9 ENGLISH 4.5 Power function To stop the sound: touch This function makes more power CountUp Timer (The count up timer) available to the induction cooking zones. You can use this function to monitor how The function can be activated for the long the cooking zone operates.
- Page 10 To activate the function: touch goes out. Touch for 3 seconds. comes on. comes on. Touch of the timer to choose one of the following: To deactivate the function: touch • - the sounds are off The previous heat setting comes on.
- Page 11 ENGLISH 4.12 Power management function • Cooking zones are grouped according to the location and number of the phases in the hob. See the illustration. • Each phase has a maximum electricity loading of 3700 W. • The function divides the power between cooking zones connected to the same phase.
-
Page 12: Hints And Tips
When you finish cooking and Auto‐ Boil‐ deactivate the hob, the hood Frying matic fan may still operate for a light certain period of time. After that time the system Mode deactivates the fan speed 1 automatically and prevents... - Page 13 ENGLISH Cookware is correct for an induction cookware is made of different hob if: materials (sandwich construction). • humming: you use high power level. • some water boils very quickly on a • clicking: electric switching occurs. zone set to the highest heat setting. •...
- Page 14 • Do not interrupt the signal between which work with this function refer to our the hob and the hood (for example consumer website. The Electrolux cooker with a hand or a cookware handle). hoods that work with this function must See the picture.
-
Page 15: Care And Cleaning
ENGLISH 6. CARE AND CLEANING the dirt can cause damage to the hob. WARNING! Put the special scraper on the glass Refer to Safety chapters. surface at an acute angle and move the blade on the surface. 6.1 General information •... - Page 16 Problem Possible cause Remedy There is water or fat stains Clean the control panel. on the control panel. An acoustic signal sounds You put something on one Remove the object from and the hob deactivates. or more sensor fields.
-
Page 17: Installation
ENGLISH Problem Possible cause Remedy and a number come on. There is an error in the Disconnect the hob from hob. the electrical supply for some time. Disconnect the fuse from the electrical system of the house. Con‐ nect it again. If comes on again, speak to an Au‐... - Page 18 2. Remove an insulation of the brown CAUTION! and black cable ends. Do not drill or solder the wire 3. Apply a new wire end sleeve of 1.5 ends. This is strictly mm² on each cable end. (special tool forbidden! required).
- Page 19 ENGLISH min. 2 mm min. 2 mm < 20 mm > 20 mm min. 500 mm min. 500 mm 30 mm 12 mm 57 mm 12 mm 57 mm 28 mm 41 mm 28 mm 41 mm 38 mm 31 mm 38 mm 31 mm min.
-
Page 20: Technical Information
You can not use the protection box if you install the hob above an oven. 9. TECHNICAL INFORMATION 9.1 Rating plate Modell EHH6540X8K PNC 949 596 327 00 Typ 58 GAD D5 AT 220 - 240 V 50 - 60 Hz Induction 7.2 kW Made in Germany Ser.Nr. -
Page 21: Energy Efficiency
ENGLISH 10. ENERGY EFFICIENCY 10.1 Product information according to EU 66/2014 Model identification EHH6540X8K Type of hob Built-In Hob Number of cooking zones Heating technology Induction Diameter of circular cook‐ Left front 21.0 cm ing zones (Ø) Left rear 18.0 cm Right front 14.5 cm... - Page 22 www.electrolux.com...
- Page 23 ENGLISH...
- Page 24 www.electrolux.com/shop...
