- Page 1 UP Element i12 EDGE UPE-EDGE User’s Manual 1 Last Updated: September 28, 2022...
- Page 2 Copyright Notice This document is copyrighted, 2022. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer.
- Page 3 Acknowledgement All other products’ name or trademarks are properties of their respective owners. Microsoft Windows® is a registered trademark of Microsoft Corp. ⚫ ITE is a trademark of Integrated Technology Express, Inc. ⚫ IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines ⚫...
- Page 4 Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity UP Element i12 EDGE (UPE-EDGE) ⚫ Screw Bag for VESA ⚫ Wi-Fi Antenna ⚫ Plug & Push Terminal Block ⚫ If any of these items are missing or damaged, please contact your distributor or sales representative immediately.
- Page 5 About this Document This User’s Manual contains all the essential information, such as detailed descriptions and explanations on the product’s hardware and software features (if any), its specifications, dimensions, jumper/connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the product page at AAEON.com for the latest version of this document.
- Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references All cautions and warnings on the device should be noted. Make sure the power source matches the power rating of the device. Position the power cord so that people cannot step on it.
- Page 7 If any of the following situations arises, please the contact our service personnel: Damaged power cord or plug Liquid intrusion to the device iii. Exposure to moisture Device is not working as expected or in a manner as described in this manual The device is dropped or damaged Any obvious signs of damage displayed on the device...
- Page 8 FCC Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation.
- Page 9 China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 AAEON System QO4-381 Rev.A0 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚(PBDE) (Pb) (Hg) (Cd) (Cr(VI)) (PBB) 印刷电路板 × ○ ○ ○ ○ ○ 及其电子组件 外部信号 × ○ ○ ○ ○ ○ 连接器及线材 ○ ○...
- Page 10 China RoHS Requirement (EN) Hazardous and Toxic Materials List AAEON System QO4-381 Rev.A0 Hazardous or Toxic Materials or Elements Component Name PCB and Components Wires & Connectors for Ext.Connections Chassis CPU & RAM HDD Drive LCD Module Optical Drive Touch Control Module Battery This form is prepared in compliance with the provisions of SJ/T 11364.
-
Page 11: Table Of Contents
Table of Contents Chapter 1 - Product Specifications..................1 Specifications ......................2 Block Diagram ......................5 Chapter 2 – Hardware Information ..................6 Dimensions ....................... 7 I/O Location ......................8 List of Connectors ....................9 2.3.1 Power Button (1) ..................10 2.3.2 LAN 2 Ethernet Port (Intel®... - Page 12 Appendix A – Cables and Connectors ................20 Cables and Connectors ..................21 Preface...
-
Page 13: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications... -
Page 14: Specifications
Specifications System Intel® Core™ i3-1215U / i5-1235U / i7-1255U / Celeron® 7305 Processor SoC Memory Onboard LPDDR5, 4GB / 8GB / 16GB / 32GB Graphics Intel® Iris® Xe Graphics Storage Optional with M.2 2280 M-key x 2 Ethernet GbE x 2 / 2.5GbE x 1 (All three support PXE function) Intel®... - Page 15 USB 3.2 Gen 2 Type A x 2 USB 2.0 Type A x 2 USB 3.2 Gen 2 Type C (support DP1.4) x 1 Display HDMI 2.0b x 1 DP 1.4 x 1 Ethernet RJ45 x 3 RS232/422/485 x 2 (pin header type) (422/485 supports 9600 baud rate) Audio Mic x 1 / Line out x 1...
- Page 16 Environmental MTBF Certification CE/FCC Class A, RED, RoHS Compliant, REACH Shock: MIL-STD-202G Method 213B, Table 213-I Condition A Vibration: IEC 60068-2-6: 1G, 5-500Hz, 3 axes IEC 60068-2-64: Operating 5Grms, 5-500 Hz, 3 axes Chapter 1 – Product Specifications...
-
Page 17: Block Diagram
Block Diagram Chapter 1 – Product Specifications... -
Page 18: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information... -
Page 19: Dimensions
Dimensions Chapter 2 – Hardware Information... -
Page 20: I/O Location
I/O Location Chapter 2 – Hardware Information... -
Page 21: List Of Connectors
List of Connectors Please refer to the table below for all of the board’s connectors that you can configure for your application Label Function Power Button USB 3.2 Gen 2 & Ethernet Port (Intel® i225-IT) USB 3.2 Gen 2 & Ethernet Port (Intel® i219-LM) Ethernet Port (Realtek RTL8111H) USB 2.0 (1/2) USB 3.2 Gen 1 Type C... -
Page 22: Power Button (1)
2.3.1 Power Button (1) The controller provides power button to switch on/off system. 2.3.2 LAN 2 Ethernet Port (Intel® i225-IT) & USB 3.2 Gen 2 (2) The controller provides Gigabit ethernet ports with 10/100/1000/2500 Base – Tx in combination with one USB 3.2 Gen 2. 2.3.3 LAN 1 Ethernet Port (Intel®... -
Page 23: Lan 3 Ethernet Port (Realtek Rtl8111H) (4)
2.3.4 LAN 3 Ethernet Port (Realtek RTL8111H) (4) The controller provides one Gigabit ethernet ports and supports 10/100/1000Base-TX and LED indicator, see the details as below. 2.3.5 USB 2.0 (1 – 2) (5) The controller provides two USB 2.0 slots, see the information as below. Chapter 2 –... -
Page 24: Usb Type-C 3.0 (6)
2.3.6 USB Type-C 3.0 (6) The controller provides one USB type C with support for Display port function, see the information as below. 2.3.7 DP 1.4 & HDMI 2.0 (7) The controller provides one DP 1.4 function and HDMI 2.0, see the information as below. -
Page 25: Com 1/2 (Pin Header)
2.3.8 COM 1/2 (Pin Header) The controller provides RS232/422/485 via pin header interface, if you want to change the mode, please go to the BIOS setting page. Default is RS232. See the hardware pin assignment and table as below. Function Function DCDA/RS422TX-/RS485- RDA/RS422TX+/RS485+... -
Page 26: Gpio (9)
2.3.9 GPIO (9) The controller provides a GPIO pin header with 8 in and 8 out interfaces, see the hardware pin assignment and table as below. Input Output GPIO11 GPIO1 GPIO12 GPIO2 GPIO13 GPIO3 GPIO14 GPIO4 GPIO15 GPIO5 GPIO16 GPIO6 GPIO17 GPIO7 GPIO18... -
Page 27: Mic In / Line Out (10)
2.3.10 Mic in / Line out (10) The controller provides one Mic-in and one Line-out function, see the hardware pin assignment and table as below. 2.3.11 DC Jack (11) The controller provides one jack interface for power range 9 – 36V DC in. Input 9 –... -
Page 28: List Of Internal Slots
List of Internal Slots Slot Function Storage Slot M.2 2280 M Key 1 (PCIe x 4 interface) Storage Slot M.2 2280 M Key 2 (PCIe x 2/SATA interface) LTE Module Slot M.2 3052 B Key x 1 (PCIe x 1) SIM Slot LTE SIM card Chapter 2 –... -
Page 29: M.2 2280 M-Key
2.4.1. M.2 2280 M-Key The controller provides one PCIe Gen 4 [x4] and one PCIe Gen 3 [x2]/SATA interface on M.2 M-Key slot for NVMe storage, SATA storage, and AI module. 2.4.2 M.2 3052 B-Key The controller provides one M.2 3052 B-Key slot for LTE module. Chapter 2 –... -
Page 30: Chapter 3 - Operating System And Certification
Chapter 3 Chapter 3 – Operating System and Certification... -
Page 31: Operating System
3.1. Operating System 3.1.1. OS Version Support The Robot controller supports Windows10 Enterprise and Ubuntu 22.04. 3.1.2. Certification Specification The controller hardware design meets CE/FCC Class A and RED certification requirements. Note: Frame ground is required to be connected through M4 screw at front panel while operating UPE-EDGE. - Page 32 Appendix A Appendix A – Cables and Connectors...
- Page 33 Cables and Connectors This table provides detailed information about the cables and connectors used by the UPE-EDGE (UP Element i12 EDGE). If you have any questions about the configuration of your board, please contact your AAEON sales representative. Function Mating Cable PN Mating Cable Description Description Phoenix Connector.DIP.90D.10*2P.Pitch...
