30" (76.2 cm) and 36" (91.4 cm) range hood

Advertisement

Quick Links

30" (76.2 CM) AND 36" (91.4 CM) RANGE HOOD
For questions about features, operation/performance, parts, accessories or service, call: 1-800-253-1301
Instructions d'installation et Guide d'utilisation et d'entretien
Table of Contents/Table des matières.............................................................................2
IMPORTANT: READ AND SAVE THESE INSTRUCTIONS.
FOR RESIDENTIAL USE ONLY.
IMPORTANT : LIRE ET CONSERVER CES INSTRUCTIONS.
POUR UTILISATION RÉSIDENTIELLE UNIQUEMENT.
LIB0120490/W10907171A
Installation Instructions and Use & Care Guide
or visit our website at www.whirlpool.com
In Canada, call 1-800-807-6777 or visit our website at www.whirlpool.ca
HOTTE D'ASPIRATION DE
30" (76,2 CM) ET 36" (91,4 CM)
Au Canada, pour assistance, installation ou service, composer
le 1-800-807-6777 ou visiter notre site Web à
www.whirlpool.ca
Models/Modèles:
WVU57UC0F/WVU57UC6F
