Hitachi Highly
Rollkolbenverdichter
Rotary Compressors
Spezifikation
Installation Manual
WHP07850VUKQA8JT6T
R 410A - R 452B - R 454C - R 454B
18,6 cm3/rev
900 - 7200 min-1
RIES GmbH, Rudolf-Diesel-Str. 10, D 64569 Nauheim, GERMANY
Phone: +49 6152 9741 0, Fax: +49 6152 9741 21, Email: info@ries-gmbh.de, Website: www.ries-gmbh.de
Advertisement
Related Manuals for Hitachi Highly WHP07850VUK
Summary of Contents for Hitachi Highly WHP07850VUK
- Page 1 Hitachi Highly Rollkolbenverdichter Rotary Compressors Spezifikation Installation Manual WHP07850VUKQA8JT6T R 410A - R 452B - R 454C - R 454B 18,6 cm3/rev 900 - 7200 min-1 RIES GmbH, Rudolf-Diesel-Str. 10, D 64569 Nauheim, GERMANY Phone: +49 6152 9741 0, Fax: +49 6152 9741 21, Email: info@ries-gmbh.de, Website: www.ries-gmbh.de...
- Page 2 Contents WHP07850VUKQA8JT6T —————1～4 Application range Compressor specifications Motor parameters Parts and drawings list General characteristics II Heat pump water heater dedicated compressor reference — ——5～15 III Acceptance ———————16 Acceptance basis Acceptance rules ———————17～30 IV Drawings V Modifications ———————Appendix...
-
Page 3: Specification Of Compressor
SUBJECT Model WHP07850VUKQA8JT6T SPECIFICATION PAGE:1/30 1. SCOPE This specification is applied to SHANGHAI HIGHLY Heat pump water heater compressor. SPECIFICATION OF COMPRESSOR 2.1 Model WHP07850VUKQA8JT6T 2.2 Power sou rce input to HIGHLY inverter Rated Voltag e/Frequency/Phase 220V/50Hz/single 2.3 A pplication H eat pump water heater 2.4 Refrigerant R410A/R452B/R454C/R454B... - Page 4 SUBJECT Model WHP07850VUKQA8JT6T SPECIFICATION PAGE:2/30 Heating capacity COP= Motor input 2.8 Allowable frequency range 900~7200rpm 2.9 Allowable amount of refrigerant 1650g charge 500±20 ml(Initial) 2.10 Amount of oil charge HAF68D1/HAF68D1U/ALPHA68HES or eq uivalent 2.11 Oil 2.12 Space volume of inner case 1200 ml 2.13 Net weight 10.0kg incl.oil...
- Page 5 SUBJECT Model WHP07850VUKQA8JT6T SPECIFICATION PAGE:3/30 MOTOR PARAMERER project parameter description 6 electrodes 9 slots Rotor Pole(Pole) concentrated winding Mechanical Frequency ， Relating to Rated Frequency Range（Hz） VDCmax of Inverter 15-120 Peak Current，at130℃，-5% Demagnetizing Rate Demagnetizing Curren（A） 29.0 Inductance Ld（mH） Sheet 1 ——...
- Page 6 SUBJECT Model WHP07850VUKQA8JT6T SPECIFICATION PAGE:4/30 4. PARTS AND DRAWING LIST PARTS NAME DRAWING NO. QTY/SET REMARKS Compressor 4CYCD**** Dimensioned sketch Mounting 4CYC00851 Rubber grommet Parts 4CYC00940 Bolt （M8） Electrical Terminal cover 4CYC01114 Parts Gasket 4CYC01113 Sleeve 4CYC01042 3CYC00004 Rubber washer 4CYC00174 Thermostat 4CYC01045...
- Page 7 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE:5/30 COMPRESSOR CRITERIA 1 Strictly observe the specification The compressor should be used in specifications written in this “compressor specification” and not be used in specifications outside it. Moreover, accessories should be specified parts used in specified way, service must use specified parts too.
- Page 8 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE:6/30 Table 2 Operating Envelope （see graph 1） Item Refrigerant R410A R452B R454C R454B Discharge pressure 4.279 MAX 4.039 MAX 3.124 MAX 3.991 MAX （condensing （condensing MPa{kgf/cm （condensing （condensing temperature: temperature temperature: temperature:...
- Page 9 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE:7/30 raph 1(b) Condensing temperature 70℃ 28℃ 5℃ 65℃ 70℃ Evaporation Temperature 25℃ 25℃ -30℃ -30℃ -10℃ 5 Current limitation Current peak among motor terminals（include instantaneous current peak）should be ℃ below 29.0A(at130 ) in order to prevent magnet in motor from demagnetization.
- Page 10 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE:8/30 9 Oil back and oil level The oil should be returned continuously to the compressor and the structure of the refrigerating system should not make oil stay in the system. The oil level in compressor should be higher than 7.5 mm from the lubricating piece fixed on the end of the crankshaft.If not keep the oil level, the shortage will occur, and influence the reliability of the compressor.(please check the oil level in the compressor with the sight glass which supplied form SHEC.
- Page 11 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE:9/30 15 Impurities in refrigerating system (1) The weight of residue on the inside surface of the heat exchanger and tube should be less than 0.01g/m . But metallic dust should not be permitted in the system. This value means the weight of foreign residue collected by filer paper after washing inside surface of the heat exchanger tubes with R-11.
- Page 12 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE:10/30 Process limitation of refrigerating system (1) Be careful of avoiding oxide scale while soldering during assembly of refrigerating system. (for example: flow or fulfill dry nitrogen) ℃ (2) The motor winding temperature should be less than 149 and hermetic terminal body ℃...
- Page 13 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE:11/30 24 Miscellany (1) The compressor should be carried carefully to avoid drop, drag ,impact and should not apply partial force on projection parts such as pipe, hermetic terminals, foot during carrying and processing.
- Page 14 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE:12/30 (8) The main electric circuit should be equipped with fuse or breaker. (9) Refrigerant should be charged from the end of condenser of refrigerating systems. Never Charge refrigerant to the compressor directly. The refrigerant should always be charged in liquid state.
- Page 15 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE:13/30 (16) The pipe and hermetic pens attached to the compressor should not be bent. (17)The dropped compressor can’t be used anymore. ℃ (18) Compressor can be used when ambient temperature is higher than -10 . Confirm the start ℃...
- Page 16 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE:14/30 (21) Use the refrigerant of specified brand. When the refrigerant not specified used, it will possibly cause trouble of the performance and reliability of the compressor by the impurities in the refrigerant. (22) The lead wires should be connected to hermetic terminals without being touched on the surface of the compressor.
- Page 17 HEAT PUMP WATER HEATER COMPRESSOR CRITERIA FOR LONG LIFE SYSTEM PAGE:15/30 25.3 Eliminate all system contaminants such as trichlorethylene, alkalies, soap, acid, oil & washing fluid used at machining the heat exchanger tubes. 25.4 Purge parts with dry nitrogen or dry air to remove remains in parts (dust, detergent，etc.) before assembly of system..
- Page 18 Check upon Delivery PAGE:16/30 1. Basis for Checking upon Delivery The Performance test will be carried out in accordance with this “compressor Specification”. The Safety Performance in accordance with GB4706.1 Safety of household and Similar electrical appliances General requirements and GB 4706.17 Safety Of household and similar electrical appliances Particular requirements for Motor-compressor.
- Page 19 17/30...
- Page 20 18/30...
- Page 21 19/30...
- Page 22 20/30...
- Page 23 21/30...
- Page 24 22/30...
- Page 25 23/30...
- Page 26 24/30...
- Page 27 25/30...
- Page 28 26/30...
- Page 29 27/30 ～Max 7200min Compressor running speed range： Min 900min ：Min 900 min ～Max 7200min （MPa） Pd limit Rotational speed (rpm) R410A R452B R454C R454B 3.51 3.32 2.31 3.28 2000 4.28 4.04 3.12 3.99 5400 4.28 4.04 3.12 3.99 7200 3.51 3.32 2.31 3.28...
- Page 30 28/30 CHART2 WHP DC INVERTER COMPRESSOR OIL LEVEL DATUM...
- Page 31 29/30...
- Page 32 30/30...
- Page 33 Specification Revision Record Page in Conclusion Date Revision Reason Spec Date...
