- Page 1 Guide System overview Integration into the SIMATIC automation system IO-Link system Function Manual 07/2022 A5E31637677-AC...
- Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical doc umentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and mainten...
- Page 3 • Knowledge of the industrial automation system SIMATIC • Proficiency with STEP 7 Scope of the documentation This documentation is the basic documentation for IO-Link systems at Siemens. The product documentation is based on this documentation. Conventions In this documentation, "STEP 7" is used as a synonym for all versions of the configuration and programming software "STEP 7 (TIA Portal)".
- Page 4 This information is provided by the Siemens Industry Online Support in the Internet (http://www.siemens.com/automation/service&support). Industry Mall The Industry Mall is the catalog and order system of Siemens AG for automation and drive solutions on the basis of Totally Integrated Automation (TIA) and Totally Integrated Power (TIP).
- Page 5 Preface You can find catalogs for all automation and drive products on the Internet (https://mall.industry.siemens.com). IO-Link system Function Manual, 07/2022, A5E31637677-AC...
-
Page 6: Table Of Contents
Table of contents Guide..............................Guide..........................System overview..........................Advantages of IO-Link....................... Overview of IO-Link system....................IO-Link interface....................... 10 IO-Link protocol........................ 13 Device profiles........................15 IODD and Port Configuration Tool - S7-PCT................ 15 Differences between IO-Link specifications V1.0 and V1.1..........17 Integration into the automation system.................... 18 Configuration of the IO-Link system.................. -
Page 7: Guide
Guide Guide Documentation Various IO-Link products are available from Siemens. Each of these products has a separate documentation. The IO-Link products are embedded in systems, e.g. ET 200SP. The documentation for the system consists of the respective system manual, function manuals and manuals. -
Page 8: System Overview
System overview Introduction A continuous communication down to the lowest field level ensures enhanced use of the functions and performance capability of sensors and actuators. Enhanced use of sensors and actuators allows you to operate your machines and plants more productively. No data other than the actual process value can be exchanged via the standard interfaces (digital, analog) used at the sensor/actuator level. -
Page 9: Overview Of Io-Link System
System overview 2.2 Overview of IO-Link system • Continuous communication between sensors/actuators and the CPU – Access to all process data, diagnostic data and device information – Access to device-specific data, such as energy data – Remote diagnostics can be performed •... -
Page 10: Io-Link Interface
System overview 2.3 IO-Link interface Example plant with IO-Link The figure below shows an example of plant architecture with IO-Link. Figure 2-1 Plant architecture with IO-Link The IO-Link master establishes the connection between the IO-Link devices and the automation system. If the IO-Link master is a component of the I/O system, it is installed either in the control cabinet or directly in the field as remote I/O in degree of protection IP65/67. - Page 11 System overview 2.3 IO-Link interface Connection system in IP65/67 M12 connectors and other connectors are defined for the connection system in IP65/67; sensors have a 4-pin connector, actuators a 5-pin connector. IO-Link masters are always equipped with a 5-pin M12 socket. The pin assignment according to IEC 60974-5-2 is specified as follows: •...
- Page 12 System overview 2.3 IO-Link interface Port types in IP65/67 Two types of ports are distinguished in the specifications for IO-Link masters: • Port Class A (Type A) With this type, the functions of pins 2 and 5 are not assigned. The manufacturer defines this function.
-
Page 13: Io-Link Protocol
System overview 2.4 IO-Link protocol IO-Link protocol Operating modes The IO-Link port of the master can be operated in the following modes: • IO-Link: The port is located in the IO-Link communication. • DI: The port behaves like a digital input. •... - Page 14 System overview 2.4 IO-Link protocol detects a break in communication after the failure of the second repeat attempt and reports this to the higher-level CPU. Data types Four data types are available: • Process data → Cyclic data • PQI → Cyclic data •...
-
Page 15: Device Profiles
The structure of the IODD is identical for all devices from all manufacturers. The structure of the IODD is always represented in the identical manner by the IO-Link Configuration Tool of the master manufacturer (for Siemens, S7-PCT). This ensures that the handling is the same for all IO-Link devices regardless of the manufacturer. - Page 16 This means the IO-Link configuration tool supports the transparent representation of the IO- Link system down to field level. Siemens provides S7-PCT for engineering of the IO-Link system. S7-PCT with IODD of a device The following figure shows a section from S7-PCT with IODD of a device and the device information contained therein.
-
Page 17: Differences Between Io-Link Specifications V1.0 And V1.1
System overview 2.7 Differences between IO-Link specifications V1.0 and V1.1 Differences between IO-Link specifications V1.0 and V1.1 Specification The technical definition of the IO-Link system is described in a specification of the IO-Link consortium. The first step was the creation of specification version 1.0. The further development and added functions of the IO-Link system led to version 1.1. -
Page 18: Integration Into The Automation System
Integration into the automation system Configuration of the IO-Link system Introduction An IO-Link system is configured in several steps. In the first step, the master is integrated in the automation system and configured. In the second step, the IO-Link devices are configured. - Page 19 Integration into the automation system 3.1 Configuration of the IO-Link system In the device view of the PROFINET device, you can: • Parameterize the ports • Specify the input and output address ranges of IO-Link for exchange of cyclic data (process values).
-
Page 20: Configuration With S7-Pct
• Setting the identification data for checking the connected IO-Link device type Start S7-PCT from HW Config in STEP 7. S7-PCT shows you all Siemens IO-Link masters you have configured in your automation system. After selecting an IO-Link master, you can assign its IO-Link ports to the desired IO-Link devices. - Page 21 Integration into the automation system 3.1 Configuration of the IO-Link system This S7-PCT view shows you a wide variety of information: ① Higher-level field bus and overview or structure of the lower-level IO-Link master ② Detailed information on the selected IO-Link master ③...
-
Page 22: Configuration Without S7-Pct
Integration into the automation system 3.1 Configuration of the IO-Link system The figure below shows you an example of the parameter assignment of an IO-Link device: Figure 3-4 Setting the parameter values of the IO-Link device Starting from the displayed defaults, you can edit and save the values in the defined value range. - Page 23 Process data length of the output data • Vendor ID ID number of the device manufacturer. You can find the Vendor ID on the Internet (https://support.industry.siemens.com/cs/ww/en/view/109748852). • Device ID ID number of the device. You can find the Device ID on the Internet (https://support.industry.siemens.com/cs/ww/en/view/109748852).
-
Page 24: Overview Of Configuration Options
Automatic Manual Manual and output data (per port) Assignment of the Vendor ID Automatic Manual (see FAQ and Device ID (https://support.industry. siemens. com/cs/ww/en/view/1097488 52)) Behavior during IO-Link device Programmable Programmable replacement Adjustable IO-Link cycle time IO-Link system Function Manual, 07/2022, A5E31637677-AC... - Page 25 Integration into the automation system 3.1 Configuration of the IO-Link system Requirement Configuration with S7-PCT Configuration without S7-PCT IO-Link Autostart IO-Link Manual Adjustable IO-Link device para meters Display of the IO-Link process data structure Monitoring of IO-Link process data Display of IO-Link device dia gnostics messages Configuration options of the SIMATIC IO-Link masters The following table provides an overview of the configuration options supported by the...
-
Page 26: Data Access Of The Automation System And The Hmi Device
Integration into the automation system 3.2 Data access of the automation system and the HMI device Device designation Article number As of FW Configuration... version ...with S7-PCT ...without S7-PCT Electronic module 4SI IO-Link 6ES7138-4GA50-0 V1.0.0 S7-1200 SM1278 4xIO-LINK MASTER 6ES7278-4BD32-0 V1.0.0 Data access of the automation system and the HMI device Cyclic data exchange... -
Page 27: Changing And Saving Device Parameters During Plant Operation
The IO-Link block library with a description of the integration is available on the Internet (https://support.industry.siemens.com/cs/ww/en/view/82981502). You can find an application example of using the block library with HMI devices on the Inter net (https://support.industry.siemens.com/cs/ww/en/view/90529409). Changing and saving device parameters during plant operation Changing device parameters You can adjust the device parameters during operation. -
Page 28: Replacing A Master Or Device During Operation
