Toro Reelmaster 7000-D Installation Instructions

Window Guard Kit
2015 and After Reelmaster
Model No. 132-3295
This product contains a chemical or chemicals known to the State of California to
Note: Determine the left and right sides of the machine from the normal operating position.
Loose Parts
Use the chart below to verify that all parts have been shipped.
Description
Guard assembly
Installing the Guards
1. Park the machine on level ground, lower the mower
decks, set the parking brake, stop the engine, and
remove the key.
2. On 1 side of the cab, loosen, but do not remove, the 3
flange nuts and the 3 bolts securing the bottom front
window to the frame of the cab
© 2015—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
WARNING
CALIFORNIA
Proposition 65 Warning
cause cancer, birth defects, or reproductive harm.
Qty.
2
(Figure 1).
Register at www.Toro.com.
® 7000-D Traction Unit with Cab
Install the guards.
1. Flange nut
2. Washer (3)
3. While holding the glass in place, remove the 3 nuts, the
3 bolts, and the 3 washers.
Note: Retain the nuts and bolts and discard the
washers.
4. While still holding the glass in place, align a guard
assembly over the glass
Original Instructions (EN) All Rights Reserved *3397-475* A
Printed in the USA
Form No. 3397-475 Rev A
Installation Instructions
Use
Figure 1
3. Bolts
4. Shoulder bolt
(Figure 2).
