Sony DR-EX300iP Operating Instructions

Stereo
Headset
DR-EX300iP
©2010 Sony Corporation Printed in Thailand






Sectional View/
組件圖示
Coloured parts/
彩色部分



4-180-388-31(1)
English
Stereo headset
Features
Operating Instructions
使用說明書
 Easy-to-use remote control (only for
iPod and iPhone).
 In-line microphone for hands-free
phone calls of iPhone.
 Closed type vertical in-the-ear
headphones for wearing comfort.
 13.5mm driver units reproduce
vocal and instrumental sound with
vivid clarity.
 Hybrid silicone rubber earbuds for
secure fit and long-term wearing
comfort.
How to use
Wearing the headphones
(see fig. )
Wear the earpiece marked  in your
right ear and the one marked  in
your left ear.
How to use the cord slider
(see fig. -)
Move up and down to change the split
position of the cord.
How to use the supplied
cord adjuster
(see fig. -)

You can adjust the cord length by
winding the cord on the cord adjuster.
(The cord can be wound to the cord
adjuster up to 50 cm. If you wind
more, the cord comes off from the cord
adjuster easily.)
1
Wind the cord.
2
Push cord into slot hole to
secure in place.
Note
Do not wind the plug or split section of the
cord, as it will strain the cord and may cause
a wire break.
How to use the remote
and microphone for an
iPod and iPhone (See fig.
-)
You can control a connected iPod and
iPhone product.
Parts and controls
 Volume +
Increases the volume of the connected
iPod product.
 Center button
Plays/pauses a track of the connected
iPod product with a single press. Skips
to the next track with a double press.
Skips to the previous track with a triple
press. Starts the "VoiceOver*" feature
with a long press (if available).
Press once to answer the call. Press
again to end.
Hold down for about two seconds to
reject an incoming call.
When you let go, two low beeps
confirm the call was rejected.
 Volume –
Decreases the volume of the connected
iPod product.
 Microphone
Compatible products
You can use the unit with only the
following models supporting remote
control.
 iPod nano 4th generation (video)
 iPod nano 5th generation (video
camera)
 iPod classic 120GB 160GB (2009)
 iPod touch 2nd generation
 iPod shuffle 3rd generation
 iPhone 3GS
* Availability of the "VoiceOver" feature
depends on iPod and its software version.
How to install the earbuds
correctly (see fig. )
If the earbuds do not fit your ears
correctly, low-bass sound may not be
heard. To enjoy better sound quality,
change the earbuds to another size, or
adjust the earbuds position to sit on
your ears comfortably and fit your ears
snugly.
If the earbuds do not fit your ears, try
another size. Confirm the size of the
earbuds by checking colour inside (see
fig. -).
When you change the earbuds, turn to
install them firmly on the headphones
to prevent the earbud from detaching
and remaining in your ear.
Earbud sizes (inside colour)
繁體中文
Small Large
 
立體聲耳機
S M L
(Orange) (Green) (Light blue)
特點
To detach an earbud
(see fig. -)
 易於操作的遙控設計（僅適用於
While holding the headphone, twist
iPod 和 iPhone） 。
and pull the earbud off.
 線控式麥克風，可進行 iPhone 免
 Tip
持通話。
If the earbud slips and cannot be detached,
 密閉型垂直入耳式耳機，便於舒適
wrap it in a dry soft cloth.
佩戴。
To attach an earbud
 13.5mm 驅動單元可生動清晰再現歌
(see fig. -)
唱聲和樂器聲。
Push the parts inside of the earbud into
 混合矽膠耳塞可確保緊密貼合耳朵，
the headphone until the projecting
長時間佩戴也不會感到不適。
part of the headphone is fully covered.
Cleaning the earbuds
使用方法
Remove the earbuds from the
headphones, and wash them with a
mild detergent solution. 佩戴耳機（見圖 ）

將有
Specifications
記的耳機戴在左耳。
如何使用導線滑動器
Receiver
（見圖 -）
Type: Closed, dynamic
Driver unit:
上下移動來變更導線的開叉位置。
13.5 mm, dome type
(CCAW) 如何使用附帶的導線長度調節
Power handling capacity:
器（見圖 -）
100 mW (IEC*)
您可透過將導線捲繞到導線長度調節
Impedance:
16 Ω at 1 kHz 器來調節導線長度。
Sensitivity: （導線最多可繞到導線長度調節器上達
105 dB/mW
50 cm。如果在達到最大長度下繼續捲
Frequency response:
繞，則導線會很容易從導線長度調節
5 Hz – 24,000 Hz
器中滑出。 ）
Cord: 1.2 m (47 / in), Litz cord
1
1
4
捲繞導線。
Y-type
2
Plug: Four-conductor gold-plated
將導線推入槽孔以固定到位。
stereo mini plug for iPod
註
and iPhone with remote
請勿捲繞插頭或導線的分叉部分，否則可能
function
會拉壞導線並造成線芯斷裂。
Mass: Approx. 6 g (0.21 oz)
without cord
如何使用 iPod 和 iPhone 的
Microphone
遙控器和麥克風 （見圖 -）
Open circuit voltage level:
您可以控制連接的 iPod 和 iPhone
– 42 dB (0 dB=1 V/Pa)
產品。
Supplied accessories
Earbuds (S × 2, M × 2, L × 2)
各部件和控制器
Cord adjuster (1)
 音量 +
Carrying case (1)
增大連接的 iPod 產品的音量。
Operating Instructions (1)
 中央按鈕
* IEC = International Electrotechnical
按一下按鈕播放 / 暫停連接的 iPod
Commission
產品的曲目。按兩下按鈕跳至下一個
Design and specifications are subject
曲目。按三下按鈕跳至上一個曲目。
to change without notice.
長時間按著按鈕開啓"VoiceOver
（如果可用） 。
Precautions
按一下接聽來電。再按一下結束通話。
按住約兩秒可拒絕接聽來電。
 Please keep your headphones clean
放開按鈕時，會發出兩聲低沉的嗶聲，
at all times especially inside the
確認您已拒絕通話。
rubber earbud. (see fig. )
 音量 –
If any dust or ear wax inside the
減小連接的 iPod 產品的音量。
earbud, you may experience some
 麥克風
listening difficulties.
 Listening with headphones at high
相容產品
volume may affect your hearing. For
traffic safety, do not use while
您只能在本機上配合使用支援遙控的
driving or cycling.
以下機型。
 The earbuds may deteriorate due to
 iPod nano 第 4 代（視頻）
long-term storage or use.
 iPod nano 第 5 代（攝影機）
 Install the earbuds firmly onto the
 iPod classic 120GB 160GB（2009）
headphones. If an earbud
 iPod touch 第 2 代
accidentally detaches and is left in
 iPod shuffle 第 3 代
your ear, it may cause injury.
 iPhone 3GS
 Be careful not to allow any buttons
* "VoiceOver"功能的可用性視 iPod 及其
to be unintentionally pressed when
軟體版本而定。
the headphones with iPod/iPhone
connected are in the supplied
正確安裝耳塞的方式
carrying case, etc.
（見圖 ）
Note on static electricity
如果耳塞不適合您的耳型，您便可能
In particularly dry air conditions, mild
無法聽到重低音。為了享受更佳音質，
tingling may be felt on your ears. This
is a result of static electricity 請更換耳塞尺寸，或調整耳塞的位置
accumulated in the body, and not a
以舒適貼合您的耳朵。
malfunction of the headphones.
如果耳塞與您的耳形不匹配，請嘗試
The effect can be minimized by
其它尺寸的耳塞。透過查看內部的顏
wearing clothes made from natural 色來確認耳塞尺寸（見圖 -） 。
materials.
當您更換耳塞時，請將其牢固地安裝
在耳機上以防止耳塞脫落在您的耳朵
Optional replacement earbuds can
內。
be ordered from your nearest Sony
dealer.
耳塞尺寸（內部顏色）
On copyright
小

iPod and iPhone are trademarks of
S
Apple Inc., registered in the U.S. and
( 橙色 )
other countries.
拆下耳塞（見圖 -）
握住耳機，然後扭轉拉出耳塞。

提示
如果耳塞較滑無法拆下，請用柔軟乾布將其
包住。
裝上耳塞（見圖 -）
將耳塞的內部推入耳機，直到耳機的
突出部分被完全包住。
清潔耳塞
將耳塞從耳機體上拆下，並以中性的
清潔劑清洗。
規格
接收器
型式： 封閉式，動態
激勵單元： 13.5 mm，圓頂型（CCAW）
功率處理容量：
100 mW(IEC
阻抗： 1 kHz 時 16 Ω
靈敏度： 105 dB/mW
頻率響應： 5 Hz - 24000 Hz
導線： 1.2 m， 絞合線 Y 型
插頭： 四導體鍍金立體聲迷你插頭用於
具有遙控功能的 iPod 與 iPhone
質量： 約 6 g，不包括導線
麥克風
開路電壓電平：
－42 dB（0 dB = 1 V/Pa）
附件
耳塞（S × 2, M × 2, L × 2）

標記的耳機戴在右耳， 標
導線長度調節器（１）
攜帶盒（1）
使用說明書（1）
* IEC = 國際電工委員會
設計和規格如有變更，恕不另行通知。
注意事項
 請隨時保持耳機的清潔，尤其是橡
膠耳塞的內部（見圖 ） 。
如果耳塞有灰塵或耳垢，您可能會
無法順利聆聽音樂。
 戴著耳機用很高的音量收聽可能會
影響您的聽力。為了交通安全，切
勿在駕車或騎車時使用耳機。
 耳塞可能會因為長期存放或使用而
損壞。
 將耳塞牢固地安裝在耳機上。如果
耳塞意外脫落並留在耳內，可能會
造成傷害。
 當耳機在連接有 iPod/iPhone 的情
況下置於隨附攜行盒等時，請小⼼
不要意外按下任何按鈕。
靜電注意事項
在特別乾燥的空氣條件下，耳朵可能
會感到輕微刺痛。這是由於體內積聚
的靜電所致，而非耳機故障。穿著天
然材料製成的衣服可將此影響減到最
少。
可向附近的 Sony 經銷商訂購選購的
替換耳塞。
關於版權
*
"
iPod 和 iPhone 是 Apple Inc. 在美
國和其他國家註冊的商標。
大

M L
( 綠色 ) ( 淺藍色 )
*
)
