- Page 1 High Resolution Weatherproof IR Camera User Manual SCO-5081R...
- Page 2 High Resolution Weatherproof IR Camera User Manual Copyright ©2016 Co., Ltd. All rights reserved. Hanwha Techwin Trademark Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their respective company. Restriction Copyright of this document is reserved.
- Page 3 Before operating the camera, confirm the camera model and correct input power voltage. To help you understand this manual thoroughly, we'll introduce our model description. ■ SCO-5081R SERIES • NTSC MODEL • PAL MODEL SCO-5081RN SCO-5081RP ■ MODEL DESCRIPTION • SCO-5081RX _ SIGNAL SYSTEM • SIGNAL SYSTEM N →...
- Page 4 safety information CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit.
- Page 5 9. If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this product in any way. (samsung is not liable for problems caused by unauthorized modifications or attempted repair.) When cleaning, do not spray water directly onto parts of the product.
- Page 6 safety information FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : 1) This device may not cause harmful interference, and 2) This device must accept any interference received including interference that may cause undesired operation.
- Page 7 important safety instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
- Page 8 contents inTroDuCTion Features Components and Accessories Components names and Functions Adjust the lens's zoom and focus ConnECTion Connecting to Monitor Connecting to Power Using Communications CamEra oPEraTion Menu Configuration Menu Setup TroublEshooTing Troubleshooting sPECifiCaTions Specifications Dimension 8_ contents...
- Page 9 Without an external sensor, you can use this product to detect motion and generate alarms and thus more efficient monitoring can be achieved. y ssnr4 (samsung super noise reduction) function The high-performance W7 effectively removes low-light gain noise and afterimage to provide clear images even in dark environments.
- Page 10 Communication RS-485 , Coaxial communication methods are supported. - Coaxial Communications : Pelco Coaxitron RS-485: Samsung-T, Samsung-E, Pelco-D, Pelco-P, Panasonic, Bosch,Honeywell, Vicon, AD, GE OSD The camera’s OSD is complimented by 17 languages. - English, Chinese, Korean, Japanese, German, Italian, French, Spanish, Russian,...
- Page 11 ComPonEnT namEs anD funCTions front ▲ Camera sunshield ➊ Knob sunshield : Fixing the sunshield onto the camera. focus lever : Set focus of lens by turn the focus lever. Zoom lever : Set zoom magnification of lens by turn the zoom lever. front cover function setup switch : Display the menu on the screen and move the cursor to four ➏...
- Page 12 Introduction back function jack ❽ GREEN(485 –) : Signal port for RS-485- communication. YELLOW(485+) : Signal port for RS-485+ communication. BLUE (ALARM OUT) : Output port that signals when a motion is detected. GRAY(EXT_D/N) : External signal input port for Day/Night mode setup. BLACK(GND) : Earth-grounding port for external signal.
- Page 13 aDJusT ThE lEns's Zoom anD foCus 1. Remove the sunshield from the camera. 2. Remove the front cover from the camera by turning it counterclockwise. 3. Unlock the Zoom or Focus lever before adjusting the lens. 4. Adjust the zoom & focus by moving the lever counterclockwise for (NEAR & WIDE) and clockwise for (TELE &...
- Page 14 connection ConnECTing To moniTor Please connect the Video output jack located on the back of the camera to the monitor. Monitor Camera y As the connecting method varies with the instruments, refer to the manual supplied with the instrument. y Only connect the cable when the power is turned off. ConnECTing To PoWEr You can connect power as shown in the following figure.
- Page 15 When the resistance value of copper wire is at [20°C(68°F)] Copper wire size (AWG) #24 (0.22mm #22 (0.33mm #20 (0.52mm #18 (0.83mm Resistance value(Ω/m) 0.078 0.050 0.030 0.018 Voltage Drop (V/m) 0.028 0.018 0.011 0.006 y As shown in the table above, voltage decreases as the wire gets longer. Therefore use of an excessively long adaptor output line for connection to the camera may affect the performance of the camera.
- Page 16 RS-485 communications Using RS-485 communication, the camera menu can be accessed using Samsung Techwin’s System Controller or the DVR. • for accessing the camera from a computer Use a RS-485 converter to connect the camera’s control port with the computer’s serial cable.
- Page 17 camera operation mEnu ConfiguraTion main sETuP ● ● ● BASIC DAY/NIGHT BACKLIGHT PROFILE ● ● ● INDOOR USER ● ● SSDR ● ● ● OUTDOOR INDOOR WHITE BAL ● ● AWC SET ● MANUAL MERCURY ● ● ● BRIGHTNESS LENS SHUTTER EXPOSURE...
- Page 18 camera operation MAIN SETUP Select the function 1. PROFILE BASIC Change the status using the Function using the Function 2. SSDR Setup switch. Setup switch. 3. WHITE BAL 4. EXPOSURE 5. BACKLIGHT 6. SPECIAL 7. EXIT SAVE 1. Press the Function Setup switch. y Main SETUP menu is displayed on the monitor screen.
- Page 19 If you select the ITS, the shutter will be set to 1/200 sec. Noise can be detected at night. ssDr (samsung super Dynamic range) If an object has a large variance between bright and dark areas, it will keep bright areas bright and make selected dark areas bright, so that the overall brightness can be maintained.
- Page 20 camera operation White bal (White balance) Use the White Balance function to adjust the screen color. 1. When the SETUP menu screen is MAIN SETUP displayed, select ‘White Bal’ by 1. PROFILE BASIC using the Function Setup switch so 2. SSDR that the arrow indicates ‘White Bal’...
- Page 21 EXPosurE 1. When the SETUP menu screen is displayed, select ‘EXPOSURE’ by using the Function Setup switch so that the arrow indicates ‘EXPOSURE’. 2. Select a desired mode using the Function Setup switch. EXPOSURE SETUP ▶ BRIGHTNESS ---- ---- y brighTnEss : Adjusts the video LENS brightness.
- Page 22 camera operation baCKlighT The camera uses our own W7 chips that are designed to clearly display the object and the background despite severe reverse light. 1. When the SETUP menu screen is displayed, select ‘BACKLIGHT’ by using the Function Setup switch. so that the arrow indicates ‘BACKLIGHT’. 2.
- Page 23 sPECial 1. When the SETUP menu screen is displayed, select ‘SPECIAL’ by using the Function Setup switch so that the arrow indicates ‘SPECIAL’. 2. Select a desired mode using the SPECIAL SETUP Function Setup switch. ▶ DISPLAY y DisPlaY COMM ADJ IMAGE ADJ ➊...
- Page 24 ▶ 1. PROTOCOL SAMSUNG-T PROTOCOL. 2. CAM ID -------- (SAMSUNG- 3. BAUD RATE 9600 T,Samsung-E, Pelco-D, 4. UART MODE 8-N-1 Pelco-P, Panasonic, 5. RET PKT ENABLE Bosch, Honeywell, Vicon, 6. COAX AD, GE) 7. RETURN - CAM ID : Determines the camera's identification number (between 0 and 255).
- Page 25 - COLOR GAIN : The setting range is 1 ~ 100. The smaller the setting value is the smaller the color gain gets and the more color blind it gets. - H-REV : Flip an image horizontally. - V-REV : Flip an image vertically. - D-ZOOM : You can use a digital zoom of x1 ~ x16.
- Page 26 camera operation If you set the AGC mode to off on the exposure menu, you cannot switch the day/night mode to auto. When a bright light source is in the screen or there are frequent brightness changes, if you use the auto night/day mode, and set the switching time to short (3, 5 sec), a hunting can be caused.
- Page 27 y PriVaCY : Mask an area you want to hide on the screen. M M M If the SPECIAL menu screen is ➊ PRIVACY AREA SETUP displayed, use the Function Setup ▶ AREA AREA switch so that the arrow indicates MODE ‘PRIVACY’.
- Page 28 camera operation y RETURN : Return to the VIDEO ANALYTICS menu. In the following cases, the initially set tampering detection function can malfunction. - In a monitoring environment with a simple background or an environment with low light level or at night, the detection performance can deteriorate.
- Page 29 ` RETURN : Return to the MOTION DET menu. y INDICATOR : If an object moves in a pattern set by the user, it will be displayed on the screen as a box. y ALARM OUT : When object movement is detected, the detection signal will be outputted.
- Page 30 camera operation 1) LINE FENCE - SEL POS : Selects a LINE FENCE ▶ SEL POS POS1 position from X POS ---- ---- POS1,POS2. Y POS -------- - X POS / Y POS : DIRECTION RIGHT Adjust the size and position RETURN of the selected line fence.
- Page 31 - When a fixed object keeps moving in the same location - When a new object covers an object with changes y ALARM OUT : When object movement is detected, the detection signal will be outputted. ` EXTERNAL : Send signals through external terminals. ` OSD : Display signals on the screen.
- Page 32 camera operation - If the size is greater than the max size or smaller than the min size, motion is not detected. To avoid false detection caused by noises, set the max/min detection size suitable for the installation environment. But the same movement in the same location can cause a different detection size. So, include margins when you set the min/max detection size.
- Page 33 troubleshooting TroublEshooTing If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact an authorized technician. Problems Troubleshooting Nothing appears on the screen. y Check that the power cord and line connection between the camera and monitor are properly connected.
- Page 34 specifications sPECifiCaTions sCo-5081rn sCo-5081rP video Imaging Device 1/3” 1.3M CMOS total Pixels 1304(H) x 1074(V) effective Pixels 1296(H) x 1032(V) scanning system Progressive Scan synchronization Internal H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz Frequency Color : 1000 TVL Horizontal resolution...
- Page 35 1 Out communication Coaxial Control ( SPC-300 Compatible ),RS-485 Coax : Pelco-C (Coaxitron) Protocol RS-485: Samsung-T, Samsung-E, Pelco-D, Pelco-P, Panasonic, Bosch, Honeywell, Vicon, AD, GE Ir Distance environmental -30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH operating temperature ※...
- Page 36 DimEnsion Unit: mm 36_ specifications...
- Page 37 MEMO...
- Page 38 Head Office 86 Cheonggyecheon-ro Jung-gu Seoul 04541 Korea Tel +82.2.729.5277, 5254 Fax +82.2.729.5489 www.hanwha-security.com Hanwha Techwin America 100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660 Toll Free +1.877.213.1222 Direct +1.201.325.6920 Fax +1.201.373.0124 Hanwha Techwin Europe 2nd Floor, No. 5 The Heights, Brooklands, Weybridge, Surrey, KT13 0NY, UK Tel +44.1932.82.6700 Fax +44.1932.82.6701...
