LG L1710M Install Manual

17 inches (43.2cm) flat panel active matrix-tft lcd
Hide thumbs Also See for L1710M:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
Important Precautions
This unit has been engineered and manufactured to ensure your personal
safety, however improper use may result in potential e shock or fire hazards.
In order to allow the proper operation of all safeguards incorporated in this
display, observe the following basic rules for its installation, use, and
servicing.
On Safety
Use only the power cord supplied with the unit. In case you use another power
cord, make sure that it is certified by the applicable national standards if not being
provided by the supplier. If the power cable is faulty in any way, please contact the
manufacturer or the nearest authorized repair service provider for a replacement.
The power supply cord is used as the main disconnection device. Ensure that the
socket-outlet is easily accessible after installation.
Operate the display only from a power source indicated in the specifications of
this manual or listed on the display. If you are not sure what type of power supply
you have in your home, consult with your dealer.
Overloaded AC outlets and extension cords are dangerous. So are frayed power
cords and broken plugs. They may result in a shock or fire hazard. Call your service
technician for replacement.
Do not Open the Display.
There are no user serviceable components inside.
There are Dangerous High Voltages inside, even when the power is OFF.
Contact your dealer if the display is not operating properly.
To Avoid Personal Injury :
Do not place the display on a sloping shelf unless properly secured.
Use only a stand recommended by the manufacturer.
To Prevent Fire or Hazards:
Always turn the display OFF if you leave the room for more than a short period
of time. Never leave the display ON when leaving the house.
Keep children from dropping or pushing objects into the display's cabinet
openings. Some internal parts carry hazardous voltages.
Do not add accessories that have not been designed for this display.
During a lightning storm or when the display is to be left unattended for an
extended period of time, unplug it from the wall outlet.
A1

Advertisement

Table of Contents
loading

Related Manuals for LG L1710M

Summary of Contents for LG L1710M

  • Page 1 Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential e shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.

  • Page 2: Important Precautions

    Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.

  • Page 3: Connecting The Display

    Connecting the Display Using the Computer Connect the signal cable. When attached, tighten the thumbscrews to secure the connection. Connect the power cord into a proper power outlet that is easily accessible and close to the display. NOTE This is a simplified representation of the rear view. This rear view represents a general model;...
  • Page 4 Connecting the Display Side Jack <Display> Bottom MIC. MIC. AUDIO <Display - Back> Speaker Out MIC IN <Jack of the PC sound card> Headphone/Earphone Input Automatically mutes the speaker volume when the headphones are plugged in. Microphone Output Connects to the microphone jack of the PC sound card.

  • Page 5: Control Panel Functions

    Control Panel Functions Front Panel Controls Control Power Button Power (DPMS) Indicator MENU Button Buttons SELECT/AUTO Button Control Function Use this button to turn the display on or off. This Indicator lights up green when the display operates normally. If the display is in DPM (Energy Saving) mode, this indicator color changes to amber.
  • Page 6 Control Panel Functions Control When adjusting your display settings, always press the SELECT/AUTO button before entering the On Screen Display(OSD). This will automatically adjust your display image to the ideal settings for the current screen resolution size (display mode). The best display mode is 1280x1024. CONTROLS LOCKED/UNLOCKED : MENU and This function allows you to secure the current control settings,...

  • Page 7: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD.

  • Page 8: On Screen Display(Osd) Selection And Adjustment

    On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu BRIGHTNESS BRIGHTNESS CONTRAST CONTRAST PRESET COLOR R/G/B(User Color) POSITION V POSITION H POSITION CLOCK TRACKING PHASE VOLUME AUDIO TREBLE BASS BALANCE...

  • Page 9: To Adjust The Brightness And Contrast Of The Screen

    OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. NOTE OSD (On Screen Display) menu languages on the monitor may differ from the manual. To adjust the brightness and contrast of the screen OSD Adjust...

  • Page 10: To Improve The Clarity And Stability Of The Screen

    To adjust position of the OSD window on the screen. FACTORY Return to all factory default settings RESET except "LANGUAGE". If you don’t want to reset the monitor, use the button to select NO and then press the SELECT/AUTO button.

  • Page 11: Troubleshooting

    Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the display connected? Is the power indicator light on? Is the power on and the power indicator green? Is the power indicator amber? Do you see an "INPUT SIGNAL OUT OF...

  • Page 12: Display Image Is Incorrect

    Troubleshooting Display image is incorrect Display Position is incorrect. On the screen background, vertical bars or stripes are visible. Any horizontal noise appearing in any image or characters are not clearly portrayed. The screen color is mono or abnormal. The screen blinks. Press the SELECT/AUTO button to automatically adjust your display image to the ideal setting.

  • Page 13: Have You Installed The Display Driver

    Troubleshooting Have you installed the display driver? Have you installed the display driver? Do you see an "Unrecognized monitor, Plug&Play (VESA DDC) monitor found" message? Audio function No sound. Sound is too high pitched or too low piched. Sound level is too low.

  • Page 14: Specifications

    Specifications 17 inches (43.2cm) Flat Panel Active matrix-TFT LCD Display Anti-Glare coating 17 inches viewable 0.26 mm pixel pitch Horizontal Freq. Sync Input Vertical Freq. Input Form Video Input Signal Input Input Form Resolution Recommend Plug&Play DDC 2B RMS Audio Output 1W+1W(R+L) Audio Input Sensitivity Speaker Impedance 16...

  • Page 15: Preset Modes (Resolution)

    Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.469 31.468 31.469 37.500 37.879 46.875 49.725 48.363 60.123 68.681 61.805 63.981 79.976 VESA wall mounting Connected to another object (stand type and wall-mounted type. This monitor accepts a VESA-compliant mounting interface pad.)
