FieldMonitor Machinery Protection System Operation Manual
1.2 System
Components
1.2.1 About Configuration Software
6
The components of the FieldMonitor system are
described in the table below.
Component
Description
1701/01
Configuration Software for RSLogix5
1701/02
Configuration Software for RSLogix5000
1701/05
Terminal Base
1701/06
Isolator Terminal Base
1701/10
+24 Volt DC Power Supply
1701/15
Proximitor Input Monitor
1701/25
Seismic Input Monitor
1701/30
Dynamic Pressure Monitor
170133
3300 series Internal
Dual Proximitor
Module
170150
3300 NSv™ series Internal
Dual Proximitor Module
1701/50
Weatherproof Housing for 1701/05 TB
170172
7200 series Internal
Dual Proximitor Module
170180-01
Dual Proximitor/Accelerometer I/O Module
170180-02
Dual Velocity I/O Module
170180-03
Dual Velomitor I/O Module
170180-04
Velomitor A & Velocity B I/O Module
170180-05
Dual -18 Volt Proximitor I/O Module
170190-01
Dual Galvanic Isolator
170190-02
Dual Galvanic Isolator (CEC Velocity)
FieldMonitor configuration software is used to build the data
tables for the monitors. This software also provides a
convenient Windows™ user interface that allows you to
select configuration choices from menus and to go online to
monitor values.
If you are using FieldMonitor configuration software then
the information in Chapter 7 and Appendices A, B, C, and D
is for reference only. If you cannot use FieldMonitor
configuration software then you must use your PLC
software to build the data table for each monitor from the
information in the manual sections mentioned above.
Available FieldMonitor configuration software is:
Part
1701/01
1701/02
Radial Vibration
Thrust Position
Velocity
Acceleration
5 metre
9 metre
14 metre
7 metre
5 metre
9 metre
Description
FieldMonitor Configuration
Software for RSLogix5.
FieldMonitor Configuration
Software for RSLogix5000.
